FLAT WIDE DISPLAY MONITOR
FWD-50PX3
PROTOCOL MANUAL (For Customer)

FWD-50PX3
Table of Contents
1. Communication Parameters ......................................................... 1
2. Pin Assignment..................................................................................... 1
3. Communication Data Format ....................................................... 1
4. General Function ................................................................................. 3
5. Analog Signal Detect Function ................................................... 9
6. Priority Signal Select Function ................................................. 10
7. Picture/Sound ...................................................................................... 14
8. Size/Shift ................................................................................................. 17
9. Status Enquiry..................................................................................... 20
10. User Reset.............................................................................................. 24

1
FWD-50PX3
1. Communication Parameters
Communication method RS-232C
Synchronous method Asynchronous
Baud rate 9600bps
Character length 8bit
Parity None
Start bit length 1bit
Stop bit length 1bit
Flow control None
2. Pin Assignment
12345
Monitor side (D-sub 9-pin)
_External view _
6789
12345
6789
Host side (D-sub 9-pin)
_External view _
Pin No. Function
1NC
2 TXD
3 RXD
4NC
5 GND
6NC
7NC
8NC
9NC
Pin No. Function
1NC
2 RXD
3 TXD
4NC
5GND
6NC
7NC
8NC
9NC
3. Communication Data Format
(a) Control message
No. Item Value
1 Header 0x8C: Control
2 Category 0xXX
3 Function 0xXX
4 Data1 (Length) 0xXX
5 Data2 (Data1) 0xXX
: : 0xXX
: : 0xXX
X DataX 0xXX
X+1 Check Sum 0xXX
*Check Sum: Sum total of 1 to X. Lower one-byte data is validated when a
value exceeds 255 (1byte).
*Set the command interval to 500 ms or more when transmitting the
Control command continuously.
*Set the command interval to 500 ms or more when transmitting the same
command (Enquiry) after the Control command.
(b) Enquiry message
No. Item Value
1 Header 0x83: Enquiry
2 Category 0xXX
3 Function 0xXX
4 Data1 0xFF
5 Data2 0xFF
6 Check Sum 0xXX
*Check Sum: Sum total of 1 to X. Lower one-byte data is validated when a
value exceeds 255 (1byte).

2FWD-50PX3
4Error answer
No. Item Value
1 Header 0xE0: Answer
2 Answer*0x00: No Function Error
0x01: Check Sum Error
0x02: Data Length Error
3 Check Sum 0xXX
*0x00: No Function Error Packet header,category or function code are
not included in this protocol.
0x01: Check Sum Error Check sum value or received packet is not
correct.
0x02: Data Length Error Packet is correctly received,but the data size
is over the upper limit.
(c) Answer message
1Control answer
No. Item Value
1 Header 0x70: Answer
2 Answer*0x00: Completed
0x01: Limit Over
0x02: Limit Under
0x03: Command Canceled
3 Check Sum 0xXX
*0x00: Completed Packet is correctly received and process
is also correctly completed.
0x01: Limit Over Packet is correctly received, but the data
value is over the upper limit.
0x02: Limit Under Packet is correctly received, but the data
value under the lower limit.
0x03: Command Canceled Packet is correctly received, but the data
value is not correct or the request cannot
be accepted in the current host state.
*Check Sum: Sum total of 1 to X. Lower one-byte data
is validated when a value exceeds 255
(1byte).
2Enquiry answer (Complete)
No. Item Value
1 Header 0x70: Answer
2 Answer 0x00: Completed
3 Return Data Size 0xXX
4 Return Data1 0xXX
: : 0xXX
: : 0xXX
X Return DataX 0xXX
X+1 Check Sum 0xXX
*0x00: Completed Packet is correctly received and process is also
correctly completed.
*Return Data: Returns the read value.
*Check Sum: Sum total of 1 to X. Lower one-byte data is validated
when a value exceeds 255 (1byte).
3Enquiry answer (Command cancel)
No. Item Value
1 Header 0x70: Answer
2 Answer 0x03: Command Canceled
3 Check Sum 0x73
0x03: Command Canceled Packet is correctly received, but the data
value is not correct or the request cannot
be accepted in the current host state.

3
FWD-50PX3
4. General Function
(a) Mode Control
Syntax Header Category Function Data1 Data2 Check Sum
Control 0x8C 0x00 Code Table (1-a) [a] 0x02 Code Table (1-a) [b] 0xXX
Enquiry 0x83 0xFF 0xFF 0xXX
Answer Header Answer Check Sum
Control 0x70 0x00 0x70 Completed
0x70 0x01 0x71 Limit Over
0x70 0x02 0x72 Limit Under
0x70 0x03 0x73 Command Canceled
Answer Header Answer Return to Data Size Return Data1 Check Sum
Enquiry 0x70 0x00 0x02 Code Table (1-a) [b] 0xXX Completed
Code Table (1-a)
[a]Function [b]Range/Switch Code Command
Control Enquiry Standby Power On
0x00 Power 0x00 OFF Yes Yes Enable Enable
0x01 ON
0x01 Input Select*40x08 INPUT1 RGB (Analog) Yes Yes Disable Enable
0x09 INPUT1 YUV (Analog)
0x0C OPTION1 VIDEO
0x0D OPTION1 S-VIDEO
0x0E OPTION1 RGB
0x0F OPTION1 COMPONENT
0x10 OPTION2 VIDEO
0x11 OPTION2 S-VIDEO
0x12 OPTION2 RGB
0x13 OPTION2 COMPONENT
0x20 Input1 DVI
0x84 Option1 Digital1
0x85 Option1 Digital2
0x02 Force Status Display 0x00 ON Yes Yes Disable Enable
0x01 OFF
0x03 Audio Mute 0x00 OFF Yes Yes Disable Enable
0x01 ON
0x04 Auto Status Display 0x00 ON Yes Yes Enable Enable
0x01 OFF (Continued)

4FWD-50PX3
Code Table (1-a)
[a]Function [b]Range/Switch Code Command
Control Enquiry Standby Power On
0x06 Color System 0x00 Auto Yes Yes Disable Enable
0x01 NTSC
0x02 NTSC4.43
0x03 PAL
0x05 PAL-M
0x06 PAL-N
0x07 PAL60
0x0B Picture Inversion 0x00 OFF Yes Yes Disable Enable
0x01 Auto
0x02 On
0x0C Picture Orbit 0x00 OFF Yes Yes Disable Enable
0x01 ON
0x0D Orbit Range 0x00 Small Yes Yes Disable Enable
0x01 Middle
0x02 Large
0x0E Orbit Cycle 0x00 Speed1 (10 sec ) Yes Yes Disable Enable
0x01 Speed2 (30 sec)
0x02 Speed3 (1 min )
0x03 Speed4 (5 min )
0x0F Language 0x00 Japanese Yes Yes Disable Enable
0x01 English
0x02 Deutsch
0x03 Français
0x04 Español
0x05 Italiano
0x10 Index Number 0x01-0xFF Yes Yes Disable Enable
0x12 Standby Power 0x00 Standard Yes Yes Disable Enable
0x01 Low
0x13 ECO Mode 0x00 Off Yes Yes Disable Enable
(Power Saving) 0x01 ECO High
0x02 ECO Low
0x14 Speaker Out 0x00 ON Yes Yes Disable Enable
0x01 OFF
0x18 Sync Mode 0x00 H/Comp Yes Yes Disable Enable
0x01 Video
0x1B Clock Display 0x00 OFF Yes Yes Disable Enable
0x01 ON (Continued)

5
FWD-50PX3
Code Table (1-a)
[a]Function [b]Range/Switch Code Command
Control Enquiry Standby Power On
0x24 Input Detect 0x00 FW12 (HD15) No Yes Disable Enable
(Option1) 0x01 FW10 (VIDEO, S-VIDEO) BNC
0x02 FW11 (BNC)
0x03 Reserved
0x04 FW31/32
0x05 FW50 (RGB)
0x06 FW20 (UART +CTRL-S)
0x07 FW13 (COMPONENT) RCA
0x08 FW15 (HDMI x2)
0x09 FW16 (Digital x1)
0x0A Reserved
0x0B Reserved
0x0C Reserved
0x0D Reserved
0x0E Reserved
0x0F Not Connect
0x25 Input Detect 0x00 FW12 (HD15) No Yes Disable Enable
(Option2) 0x01 FW10 (VIDEO, S-VIDEO) BNC
0x02 FW11 (BNC)
0x03 Reserved
0x04 FW31/32
0x05 FW50 (RGB)
0x06 FW20 (UART +CTRL-S)
0x07 FW13 (COMPONENT) RCA
0x08 FW15 (HDMI x 2)
0x09 FW16 (Digital x 1)
0x0A Reserved
0x0B Reserved
0x0C Reserved
0x0D Reserved
0x0E Reserved
0x0F Not Connect
0x26 Auto Shut OFF 0x00 OFF Yes Yes Disable Enable
0x01 ON
0x27 Auto Screen Adjust 0x00 OFF Yes Yes Disable Enable
0x01 ON
0x30 PAP 0x00 OFF Yes Yes Disable Enable
0x01 P&P
0x02 PinP (Continued)

6FWD-50PX3
Code Table (1-a)
[a]Function [b]Range/Switch Code Command
Control Enquiry Standby Power On
0x31 Active Picture 0x00 Left (P&P)/Main (PinP) Yes Yes Disable Enable
0x01 Right (P&P)/Sub (PinP)
0x02 Swap
0x32 Picture Size (P&P) 0x00-0x0E Yes Yes Disable Enable
0x33 Sub Picture Size 0x00 Large Yes Yes Disable Enable
(PinP) 0x01 Small
0x34 Picture Position 0x00 Position1 Yes Yes Disable Enable
(PinP) 0x01 Position2
0x02 Position3
0x03 Position4
0x35 PAP Input Detect 0x08 INPUT1 RGB (Analog) No Yes Disable Enable
(Left/Main) 0x09 INPUT1 YUV (Analog)
0x0C OPTION1 VIDEO
0x0D OPTION1 S-VIDEO
0x0E OPTION1 RGB
0x0F OPTION1 COMPONENT
0x10 OPTION2 VIDEO
0x11 OPTION2 S-VIDEO
0x12 OPTION2 RGB
0x13 OPTION2 COMPONENT
0x20 INPUT1 DVI
0x84 Option1 Digital1
0x85 Option1 Digital2
0x36 PAP Input Detect 0x08 INPUT1 RGB (Analog) No Yes Disable Enable
(Right/Sub) 0x09 INPUT1 YUV (Analog)
0x0C OPTION1 VIDEO
0x0D OPTION1 S-VIDEO
0x0E OPTION1 RGB
0x0F OPTION1 COMPONENT
0x10 OPTION2 VIDEO
0x11 OPTION2 S-VIDEO
0x12 OPTION2 RGB
0x13 OPTION2 COMPONENT
0x20 INPUT1 DVI
0x84 Option1 Digital1
0x85 Option1 Digital2
0x40 All White 0x00 OFF Yes Yes Disable Enable
0x01 ON
0x41 BackGround 0x00 Gray Yes Yes Disable Enable
0x01 Dark Gray
0x02 Black (Continued)

7
FWD-50PX3
Code Table (1-a)
[a]Function [b]Range/Switch Code Command
Control Enquiry Standby Power On
0x44 Logo Illumination & 0x00 Logo Off Yes Yes Enable Enable
Status LED 0x01 Logo On (Low)
0x02 Logo On (High)
0x04 LED Off
0x05 LED On
0x45 Control Mode 0x00 Main +Remocon Yes Yes Disable Enable
0x01 Main
0x02 Remocon
0x03 All Off
0x04 Limited*5
0x46 On Off Timer Mode 0x00 Every Day (Repeat) Yes Yes Enable Enable
0x01 Day Of Week
0x47 On Timer Enable bit0 Sunday 1: Enable, 0: Disable Yes Yes Enable Enable
bit1 Monday 1: Enable, 0: Disable
bit2 Tuesday 1: Enable, 0: Disable
bit3 Wednesday 1: Enable, 0: Disable
bit4 Thursday 1: Enable, 0: Disable
bit5 Friday 1: Enable, 0: Disable
bit6 Saturday 1: Enable, 0: Disable
bit7 Every day 1: Enable, 0: Disable
0x48 Off Timer Enable bit0 Sunday 1: Enable, 0: Disable Yes Yes Enable Enable
bit1 Monday 1: Enable, 0: Disable
bit2 Tuesday 1: Enable, 0: Disable
bit3 Wednesday 1: Enable, 0: Disable
bit4 Thursday 1: Enable, 0: Disable
bit5 Friday 1: Enable, 0: Disable
bit6 Saturday 1: Enable, 0: Disable
bit7 Every day 1: Enable, 0: Disable
0x49 Auto Dimmer 0x00 OFF Yes Yes Disable Enable
0x01 ON
0x65 IP Setting Mode 0x00 DHCP Yes Yes Enable Enable
0x01 Manual
0x02 Speed
0x66 IP Setting Execute 0x00 No No Yes Enable Enable
0x01 Yes
0X02 NVR Reset (Continued)

8FWD-50PX3
Code Table (1-a)
[a]Function [b]Range/Switch Code Command
Control Enquiry Standby Power On
0x67 IP Setting Result 0x00 Done Yes No Enable Enable
0x01 Error 1 (UART Commu.)
0x02 Error 2 (Duplication)
0x03 Error 3 (IP Add Setting)
0x04 Error 4 (GW Add setting)
0x05 Error 5 (DNS1 Setting)
0x06 Error 6 (DNS2 Setting)
0x07 Error 7 (Sbnt Msk Setting)
0x68 Speed Setting 0x00 100Mbps/Full Duplex Yes Yes Enable Enable
0x01 100Mbps/Half Duplex
0x02 10Mbps/Full Duplex
0x03 10Mbps/Half Duplex
0x04 Auto
0x70 Input Skip bit0 HD15 Yes Yes Disable Enable
bit1 DVI
bit2 Reserved
bit3 Reserved
bit4 Reserved
bit5 Reserved
bit6 Reserved
bit7 Reserved
0x71 Default Input 0x00 Last Memory Yes Yes Enable Enable
0x01 Option1
0x72 Input Detect 0x00 FW12 (HD15) No Yes Disable Enable
(Option3)*30x01 FW10 (VIDEO, S-VIDEO) BNC
0x02 FW11 (BNC)
0x03 Reserved
0x04 FW31/32
0x05 FW50 (RGB)
0x06 FW20 (UART +CTRL-S)
0x07 FW13 (COMPONENT) RCA
0x08 FW15 (HDMI x 2)
0x09 FW16 (Digital x 1)
0x0A Reserved
0x0B Reserved
0x0C Reserved
0x0D Reserved
0x0E Reserved
0x0F Not Connect (Continued)

9
FWD-50PX3
Code Table (1-a)
[a]Function [b]Range/Switch Code Command
Control Enquiry Standby Power On
0x74 Digital Signal Detect 0x00 VIDEO No Yes Disable Enable
(DVI/HDMI/etc.) *60x01 PC
0x75 Signal Status*70x00 Stable No Yes Disable Enable
0x01 Unstable/No Signal
0x76 VIDEO Signal Detect 0x00 NTSC No Yes Disable Enable
0x01 PAL (SECAM)
*3: Option3 Slot is Not Connect Now.
*4: Auto Signal Detect becomes Disable. When Option Slot is connected, Option command is Enable.
*5: Restricts a part of keys operation following below.
[Remote Commander]
Menu, Picture, Sound, ECO (Power Saving), Sleep, Freeze, Contrast+/_,Brightness, Chroma, H Shift, V Shift, V size, PAP
[Main]
Menu
*6: Digital Signal Status is Enable for Digital Input Signal Detect Function only in Stable.
*7: Digital Signal or VIDEO Signal is Enable. Return Signal Status of Active Window.
NOTE: modified RS-232 protocol
If “everyday”is selected, the enable bit for “everyday”should be copied to the bit for each day of week.
5. Analog Signal Detect Function
(a) Mode Control
Syntax Header Category Function Data1 Data2 Check Sum
Enquiry 0x83 0x00 Code Table (1-a) [a] Code Table (1-d) 0xFF 0xXX
Answer Header Answer Return to Data Size Return Data1 Data2 Check Sum
Enquiry 0x70 0x00 0x02 Code Table (1-a) [b] 0xFF 0xXX Completed
Code Table (1-a)
[a]Function [b]Range/Switch Code Command
Control Enquiry Standby Power On
0x78 Analog Signal Detect 0x00 VIDEO No Yes Disable Enable
0x01 PC
Code Table (1-d)
Input Select
0x00 Main
0x01 Sub
0xFF Present input
1-a[b]
When input is no signal or not supported signal, return value is Video(0x00).

10 FWD-50PX3
6. Priority Signal Select Function
(a) Mode Control
Syntax Header Category Function Data1 Data2 Check Sum
Enquiry 0x83 0x00 Code Table (2-a) [a] Code Table (2-d) 0xFF 0xXX
Answer Header Answer Return to Data Size Return Data1 Data2 Check Sum
Enquiry 0x70 0x00 0x02 Code Table (2-a) [b] 0xFF 0xXX Completed
Code Table (2-a)
[a]Function [b]Range/Switch Code Command
Control Enquiry Standby Power On
0x77 Priority Signal Select 0x00 Input1 Auto No Yes Disable Enable
0x01 Input1 RGB
0x02 Input1 YPbPr
Code Table (2-d)
Input Select
0x00 HD15
0x01 Option1
0xFF Option2
(b) Color Matrix
Syntax Header Category Function Data1 Data2 Data3 Data4 Check Sum
Control 0x8C 0x00 Code Table 0x04 Code Table Code Table Code Table 0xXX
(1-b) [a] (1-c) (1-b) [b] (1-d)
Syntax Header Category Function Data1 Data2 Check Sum
Enquiry 0x83 0x00 Code Table (1-b) [a] Code Table (1-c) Code Table (1-d) 0xXX
Answer Header Answer Check Sum
Control 0x70 0x00 0x70 Completed
0x70 0x03 0x73 Command Canceled
Answer Header Answer Return to Return Data1 Return Data2 Return Data3 Check
Data Size Sum
Enquiry 0x70 0x00 0x04 Code Table (1-c) Code Table (1-b) [b] Code Table (1-d) 0xXX Completed
Code Table (1-b)
[a]Function [b]Range/Switch Code Command
Control Enquiry Standby Power On
0x1D Color Matrix 0x00 YCbCr Yes Yes Disable Enable
0x01 YPbPr

11
FWD-50PX3
Code Table (1-c)
Format Select
0x00 480P
0x01 1080i
0x02 720P
0x03 480i
Code Table (1-d)
Input Select
0x00 HD15 (Component)
0x01 Option1
0x02 Option2
(c) Time Control
Clock Set (Hour, Minute)
Syntax Header Category Function Data1 Data2 Data3 Check Sum
Control 0x8C 0x00 0x22 0x03 Hour: 0x00-0x17 Minute: 0x00-0x3B 0xXX
Syntax Header Category Function Data1 Data2 Check Sum
Enquiry 0x83 0x00 0x22 0xFF 0xFF 0xA3
Answer Header Answer Check Sum
Control 0x70 0x00 0x70 Completed
0x70 0x01 0x71 Limit Over
0x70 0x02 0x72 Limit Under
0x70 0x03 0x73 Command Canceled
Answer Header Answer Return to Data Size Return Data1 Return Data2 Check Sum
Enquiry 0x70 0x00 0x03 Hour: *0x00-0x17 Minute: 0x00-0x3B 0xXX Completed
Clock Set (Week)
Syntax Header Category Function Data1 Data2 Check Sum
Control 0x8C 0x00 0x23 0x02 Week: Code Table (1-e) 0xXX
Syntax Header Category Function Data1 Data2 Check Sum
Enquiry 0x83 0x00 0x23 0xFF 0xFF 0xA4

12 FWD-50PX3
Answer Header Answer Check Sum
Control 0x70 0x00 0x70 Completed
0x70 0x01 0x71 Limit Over
0x70 0x02 0x72 Limit Under
0x70 0x03 0x73 Command Canceled
Answer Header Answer Return to Data Size Return Data1 Check Sum
Enquiry 0x70 0x00 0x02 Week: Code Table (1-e) 0xXX Completed
Code Table (1-e)
Week Select
0x00 Sunday
0x01 Monday
0x02 Tuesday
0x03 Wednesday
0x04 Thursday
0x05 Friday
0x06 Saturday
On Timer, Off Timer
Syntax Header Category Function Data1 Data2 Data3 Check Sum
Control 0x8C 0x00 Code Table (1-f) [a] 0x03 Hour: 0x00-0x17 Minute: 0x00-0x3B 0xXX
Syntax Header Category Function Data1 Data2 Check Sum
Enquiry 0x83 0x00 Code Table (1-f) [a] 0xFF 0xFF 0xXX
Answer Header Answer Check Sum
Control 0x70 0x00 0x70 Completed
0x70 0x01 0x71 Limit Over
0x70 0x02 0x72 Limit Under
0x70 0x03 0x73 Command Canceled
Answer Header Answer Return to Data Size Return Data1 Return Data2 Check Sum
Enquiry 0x70 0x00 0x03 Hour: 0x00-0x17 Minute: 0x00-0x3B 0xXX Completed

13
FWD-50PX3
Code Table (1-f)
[a]Function [b]Range/Switch code Command
Control Enquiry Standby Power On
Invert Timer
0x20 Invert Start Time _Yes Yes Disable Enable
0x21 Invert End Time _
On Timer
0x50 Sunday _Yes Yes Disable Enable
0x51 Monday _
0x52 Tuesday _
0x53 Wednesday _
0x54 Thursday _
0x55 Friday _
0x56 Saturday _
0x57 Every day _
Off Timer
0x58 Sunday _Yes Yes Disable Enable
0x59 Monday _
0x5A Tuesday _
0x5B Wednesday _
0x5C Thursday _
0x5D Friday _
0x5E Saturday _
0x5F Every day _
(d) IP Address Setting
IP Address
Syntax Header Category Function Data1 Data2 Data3 Data4 Data5 Check Sum
Control 0x8C 0x00 0x42 0x05 Address 0 Address 1 Address 2 Address 3 0xXX
0x00-0xFF 0x00-0xFF 0x00-0xFF 0x00-0xFF
Subnet Mask
Syntax Header Category Function Data1 Data2 Data3 Data4 Data5 Check Sum
Control 0x8C 0x00 0x61 0x05 Address 0 Address 1 Address 2 Address 3 0xXX
0x00-0xFF 0x00-0xFF 0x00-0xFF 0x00-0xFF
Gateway Address
Syntax Header Category Function Data1 Data2 Data3 Data4 Data5 Check Sum
Control 0x8C 0x00 0x62 0x05 Address 0 Address 1 Address 2 Address 3 0xXX
0x00-0xFF 0x00-0xFF 0x00-0xFF 0x00-0xFF
DNS Primary
Syntax Header Category Function Data1 Data2 Data3 Data4 Data5 Check Sum
Control 0x8C 0x00 0x63 0x05 Address 0 Address 1 Address 2 Address 3 0xXX
0x00-0xFF 0x00-0xFF 0x00-0xFF 0x00-0xFF

14 FWD-50PX3
DNS Secondary
Syntax Header Category Function Data1 Data2 Data3 Data4 Data5 Check Sum
Control 0x8C 0x00 0x64 0x05 Address 0 Address 1 Address 2 Address 3 0xXX
0x00-0xFF 0x00-0xFF 0x00-0xFF 0x00-0xFF
Answer Header Answer Check Sum
Control 0x70 0x00 0x70 Completed
0x70 0x03 0x73 Command Canceled
IP Address ex)
192.128.14.1 →192 (0xC0) Address 0
128 (0x80) Address 1
14 (0x0E) Address 2
1 (0x01) Address 3
*IP address command can be carried out even in the standby state.
Code Table (1-a)
[a]Function [b]Range/Switch code Command
Control Enquiry Standby Power On
0x42 IP Address _Yes Yes Enable Enable
0x61 Subnet Mask _
0x62 Gateway Address _
0x63 DNS Primary _
0x64 DNS Secondary _
7. Picture/Sound
(a) Picture/Sound
Syntax Header Category Function Data1 Data2 Check Sum
Control 0x8C 0x10 Code Table (2-a) [a] 0x02 Code Table (2-a) [b] 0xXX
Enquiry 0x83 0xFF 0xFF 0xXX
Answer Header Answer Check Sum
Control 0x70 0x00 0x70 Completed
0x70 0x01 0x71 Limit Over
0x70 0x02 0x72 Limit Under
0x70 0x03 0x73 Command Canceled
Answer Header Answer Return to Data Size Return Data1 Check Sum
Enquiry 0x70 0x00 0x02 Code Table (2-a) [b] 0xXX Completed

15
FWD-50PX3
Code Table (2-a)
[a]Function [b]Range/Switch code Command
Control Enquiry Standby Power On
0x00 Contrast 0x00-0x64 Yes Yes Disable Enable
0x01 Brightness 0x00-0x64 Yes Yes Disable Enable
0x02 Chroma 0x00-0x32 Yes Yes Disable Enable
0x03 Phase 0x00-0x64 Yes Yes Disable Enable
0x04 Color Temp 0x00 Cool Yes Yes Disable Enable
0x01 Neutral
0x02 Warm
0x03 Custom
0x09 Sharpness 0x00-0x14 Yes Yes Disable Enable
0x0A NR 0x00 OFF Yes Yes Disable Enable
0x01 Low
0x02 Mid
0x03 High
0x0B Cinema Drive 0x00 Auto Yes Yes Disable Enable
0x01 OFF
0x0C Dynamic Picture 0x00 OFF Yes Yes Disable Enable
0x01 ON
0x02 Reserve
0x0D Color Correct 0x00 ON Yes Yes Disable Enable
0x01 OFF
0x0E Gamma Correct 0x00 High Yes Yes Disable Enable
0x01 Mid
0x02 Low
0x10 Picture Mode 0x00 Standard Yes Yes Disable Enable
0x01 Vivid
0x02 Custom
0x05 Reserve
0x06 Conference
Camera
0x30 Volume 0x00-0x64 Yes Yes Enable Enable
0x31 Treble*10x00-0x64 Yes Yes Disable Enable
0x32 Bass*10x00-0x64 Yes Yes Disable Enable
0x33 Balance 0x00-0x64 Yes Yes Disable Enable
0x34 Surround 0x00 OFF Yes Yes Disable Enable
0x01 Hall
0x02 Simulate
0x35 Sound Mode 0x00 Dynamic Yes Yes Disable Enable
0x01 Standard
0x02 Reserve
0x03 Custom (Continued)

16 FWD-50PX3
Code Table (2-a)
[a]Function [b]Range/Switch code Command
Control Enquiry Standby Power On
0x36 Default Volume Set 0x00-0x64 Yes Yes Enable Enable
0x37 Volume Select 0x00 Last Memory Yes Yes Enable Enable
0x01 Default Setting
0x38 Max Volume Set 0x32 50 Yes Yes Enable Enable
0x46 70
0x64 100
*1 Sound Mode = Custom Only is Enabled.
(b) Color Temp
Syntax Header Category Function Data1 Data2 Data3 Check Sum
Control 0x8C 0x10 Code Table (2-b) [a] 0x03 Code Table (2-c) Code Table (2-b) [b] 0xXX
Syntax Header Category Function Data1 Data2 Check Sum
Enquiry 0x83 0x10 Code Table (2-b) [a] Code Table (2-c) 0xFF 0xXX
Answer Header Answer Check Sum
Control 0x70 0x00 0x70 Completed
0x70 0x03 0x73 Command Canceled
Answer Header Answer Return to Data Size Return Data1 Return Data2 Check Sum
Enquiry 0x70 0x00 0x03 Code Table (2-c) Code Table (2-b) [b] 0xXX Completed
Code Table (2-b)
[a]Function [b]Range/Switch code Command
Control Enquiry Standby Power On
0x05 Red Gain 0x00-0x1E Yes Yes Disable Enable
0x06 Green Gain
0x07 Blue Gain
Code Table (2-c)
Format Select
0x00 Cool
0x01 Neutral
0x02 Warm
0x03 Custom

17
FWD-50PX3
8. Size/Shift
(a) 8Bits Register
Syntax Header Category Function Data1 Data2 Check Sum
Control 0x8C 0x20 Code Table (3-b) [a] 0x02 Code Table (3-b) [b] 0xXX
Enquiry 0x83 0xFF 0xFF 0xXX
Answer Header Answer Check Sum
Control 0x70 0x00 0x70 Completed
0x70 0x01 0x71 Limit Over
0x70 0x02 0x72 Limit Under
0x70 0x03 0x73 Command Canceled
Answer Header Answer Return to Data Size Return Data1 Check Sum
Enquiry 0x70 0x00 0x02 Code Table (3-b) [b] 0xXX Completed
Code Table (3-b)
[a]Function [b]Range/Switch code Command
Control Enquiry Standby Power On
0x00 H Size 0x00-0x3C Yes Yes Disable Enable
0x01 H Shift 0x00-0x3C Yes Yes Disable Enable
0x02 V Size 0x00-0x0A Yes Yes Disable Enable
0x03 V Shift 0x00-0x3C Yes Yes Disable Enable
0x04 Aspect 0x00 Wide Zoom Yes Yes Disable Enable
(VIDEO Only)
0x01 Zoom
(VIDEO Only)
0x02 Full
(VIDEO Only)
0x04 Normal
(PC:Real, VIDEO: 4:3)
0x05 Full 1 (PC Only)
0x06 Full 2 (PC Only)
0x05 Multi Display 0x00 OFF Yes Yes Disable Enable
0x01 2 x2
0x02 3 x3
0x03 4 x4
0x04 1 x2
0x05 1 x3
0x06 1 x4
0x07 2 x1
0x08 3 x1
0x09 4 x1 (Continued)

18 FWD-50PX3
Code Table (3-b)
[a]Function [b]Range/Switch code Command
Control Enquiry Standby Power On
0x06 Auto Pixel Adjust 0xFF Execute Yes No Disable Enable
0x07 Dot Phase 0x00-0x1F Yes Yes Disable Enable
0x0B Multi Position 0x00 Position1 Yes Yes Disable Enable
(2 x2 ,1 x2, 2 x1) 0x01 Position2
*10x02 Position3
0x03 Position4
0x0C Multi Position 0x00 Position1 Yes Yes Disable Enable
(3 x3, 1 x3, 3 x1) 0x01 Position2
*10x02 Position3
0x03 Position4
0x04 Position5
0x05 Position6
0x06 Position7
0x07 Position8
0x08 Position9
0x0D Multi Position 0x00 Position1 Yes Yes Disable Enable
(4 x4, 1 x4, 4 x1) 0x01 Position2
*10x02 Position3
0x03 Position4
0x04 Position5
0x05 Position6
0x06 Position7
0x07 Position8
0x08 Position9
0x09 Position10
0x0A Position11
0x0B Position12
0x0C Position13
0x0D Position14
0x0E Position15
0x0F Position16
0x0E Over Scan 0x00 OFF Yes Yes Disable Enable
0x01 ON
0x0F Multi Display 0x00 Tiles Yes Yes Disable Enable
Output Format 0x01 Window
