Sony PlayStation PSP-1003 User manual

filename G:\#Sagyo\#SONY\03 PSP\PSP-
1003_UK\1025_PSP-1003\265788332 PSP-
1003K_UK\1025\265788332 PSP-
1003K_UK\01EN01COV.fm
masterpage:Right
2-657-883-32(1)
Instruction manual
PSP-1003
TM
option 1-1 model name1PSP-1003K
2-657-883-32(1)
01PSP-1003 EN.book Page 1 Tuesday, October 25, 2005 12:34 PM

masterpage:Left
filename G:\#Sagyo\#SONY\03 PSP\PSP-
1003_UK\1025_PSP-1003\265788332 PSP-
1003K_UK\1025\265788332 PSP-
1003K_UK\01EN02WAR.fm
model name1PSP-1003K
2-657-883-32(1)
2WARNINGS
option 1-1
To avoid electrical shock, do not open the cabinet. Refer
servicing to qualified personnel only.
CAUTION - Use of controls or adjustments or performance
of procedures other than those specified herein may
result in hazardous radiation exposure.
This appliance is classified as a CLASS 1 LASER product under IEC60825-1:
2001.
• This product is intended for ages 6 and up.
• Avoid prolonged use of the PSP™ system. To help prevent eye strain, take a
break of about 15 minutes during every hour of play.
• If you experience any of the following health problems, discontinue use of the
system immediately. If symptoms persist, consult with your physician.
– Dizziness, nausea, fatigue or symptoms similar to motion sickness
– Discomfort or pain in a part of the body, such as eyes, ears, hands or arms
Regulatory information
• The nameplate is located in the battery compartment of the unit.
• This equipment has been tested and found to comply with the limits set out in
the R&TTE Directive using a connection cable shorter than 3 meters.
• This equipment complies with EN55022 Class B and EN55024 for use in
following areas: residential, commercial and light-industrial.
WARNINGS
CLASS 1 LASER PRODUCT
LASER KLASSE 1 PRODUKT
01PSP-1003 EN.book Page 2 Tuesday, October 25, 2005 12:34 PM

3
filename G:\#Sagyo\#SONY\03 PSP\PSP-
1003_UK\1025_PSP-1003\265788332 PSP-
1003K_UK\1025\265788332 PSP-
1003K_UK\01EN02WAR.fm
model name1PSP-1003K
2-657-883-32(1)
WARNINGS
masterpage:Right
option 1-1
A molded plug complying with BS1363 is fitted to this equipment for your
safety and convenience. Should the fuse in the plug supplied need to be
replaced, a 3AMP fuse approved by ASTA or BSI to BS1362, (i.e., marked
with or mark) must be used .If the plug supplied with this equipment has
a detachable fuse cover, be sure to attach the fuse cover after you change the
fuse. Never use the plug without the fuse cover. If you should lose the fuse
cover, please contact your nearest Sony service station.
Photosensitivity
Always play in a well lit environment. Take regular breaks, 15 minutes every
hour. Avoid playing when tired or suffering from lack of sleep. Some
individuals are sensitive to flashing or flickering lights or geometric shapes and
patterns, may have an undetected epileptic condition and may experience
epileptic seizures when watching television or playing videogames. Consult
your doctor before playing videogames if you have an epileptic condition and
immediately should you experience any of the following symptoms whilst
playing: dizziness, altered vision, muscle twitching, other involuntary
movement, loss of awareness, confusion and/or convulsions.
Repetitive Motion Injuries
Avoid prolonged use of the PSP™ system. Take a 15 minute break every hour.
Stop using the PSP™ system immediately if you experience an unpleasant
sensation or pain in your hands, wrists or arms. If the condition persists, consult
a doctor.
Headphones
Adjust your headphone volume so that surrounding sounds can be heard. If you
experience ringing or any discomfort in your ears, discontinue use of your
Headphones.
01PSP-1003 EN.book Page 3 Tuesday, October 25, 2005 12:34 PM

masterpage:Left
filename G:\#Sagyo\#SONY\03 PSP\PSP-
1003_UK\1025_PSP-1003\265788332 PSP-
1003K_UK\1025\265788332 PSP-
1003K_UK\01EN02WAR.fm
model name1PSP-1003K
2-657-883-32(1)
4WARNINGS
option 1-1
Radio waves
Radio waves may affect electronic equipment or medical devices (for example,
pacemakers), which may cause malfunctions and possible injuries.
• If you use a pacemaker or other medical device, consult your physician or the
manufacturer of your medical device before using the wireless networking
feature.
• Keep the PSP™ system at least 20 cm away from a pacemaker or other
medical devices when using the wireless networking feature.
• Do not carry the PSP™ system in a breast pocket if you use a pacemaker.
• Turn off your PSP™ system immediately, if you have any reason to suspect
that interference is occurring with your pacemaker.
• Do not use the wireless networking feature in the following locations:
– Areas where its use is prohibited, such as in airplanes or hospitals. Abide by
medical institution regulations when using the PSP™ system on their
premises. Additionally, you may be violating air safety regulations
punishable by fines by using the wireless networking feature in an airplane
or by using the PSP™ system during takeoff or landing.
– Crowded areas.
– Areas near fire alarms, automatic doors and other types of automated
equipment.
• Use caution when using the wireless networking feature in a vehicle, as radio
waves may affect electronic equipment in some vehicles.
Where you see this symbol on any of our electrical products or packaging, it
indicates that the relevant electrical product should not be disposed of as
general household waste in Europe. To ensure the correct waste treatment of
the product, please dispose of it in accordance with any applicable local laws or
requirements for disposal of electrical equipment. In so doing, you will help to
conserve natural resources and improve standards of environmental protection
in treatment and disposal of electrical waste.
01PSP-1003 EN.book Page 4 Tuesday, October 25, 2005 12:34 PM

5
filename G:\#Sagyo\#SONY\03 PSP\PSP-
1003_UK\1025_PSP-1003\265788332 PSP-
1003K_UK\1025\265788332 PSP-
1003K_UK\01EN02WAR.fm
model name1PSP-1003K
2-657-883-32(1)
WARNINGS
masterpage:Right
option 1-1
01PSP-1003 EN.book Page 5 Tuesday, October 25, 2005 12:34 PM

masterpage:Left
filename G:\#Sagyo\#SONY\03 PSP\PSP-
1003_UK\1025_PSP-1003\265788332 PSP-
1003K_UK\1025\265788332 PSP-
1003K_UK\01EN03HOM.fm
model name1PSP-1003K
2-657-883-32(1)
6
option 1-1
GAME page 42
• Playing games
• Managing saved data
VIDEO page 46
• Playing UMD™VIDEO
• Playing videos saved on a Memory Stick Duo™
MUSIC page 59
• Playing UMD™MUSIC
• Playing music saved on a Memory Stick Duo™
PHOTO page 72
• Displaying images saved on a Memory Stick
Duo™
• Playing slideshows
SETTINGS page 90
• Adjusting PSP™ system settings
• Creating video, photo or network settings
• Connecting to devices using the USB connector
NETWORK page 86
• Using the Internet
• Using the LocationFree™ Player
01PSP-1003 EN.book Page 6 Tuesday, October 25, 2005 12:34 PM

7
masterpage:Right
filename G:\#Sagyo\#SONY\03 PSP\PSP-
1003_UK\1025_PSP-1003\265788332 PSP-
1003K_UK\1025\265788332 PSP-
1003K_UK\01EN03HOM.fm
model name1PSP-1003K
2-657-883-32(1)
option 1-1
Basic button operations
U
s
i
ng t
h
e
H
ome
M
enu
The basic operation of the PSP™ system starts from the Home Menu. Press the
HOME button to display the Home Menu and use the directional buttons to
navigate the horizontal and vertical icon bars.
Select a category
Select an item
POWER
HOLD
SELECT
HOME VOL START
Directional buttons:
HOME button:
button:
Used to select on-screen items
Displays the options
menu for selected items
button: Cancels selected
operations
button: Confirms selected items
Displays the Home Menu
01PSP-1003 EN.book Page 7 Tuesday, October 25, 2005 12:34 PM

masterpage:Left
filename G:\#Sagyo\#SONY\03 PSP\PSP-
1003_UK\1025_PSP-1003\265788332 PSP-
1003K_UK\1025\265788332 PSP-
1003K_UK\01EN04TOC.fm
model name1PSP-1003K
2-657-883-32(1)
8Table of contents
option 1-1
WARNINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Battery Pack precautions . . . . . . . . . . . . . . . . . . . . . . . . . . 17
xPreparation
Checking the package contents . . . . . . . . . . . . . . . . . . . . . 18
Part names and functions . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Preparing the PSP™ system for use . . . . . . . . . . . . . . . . . 25
Connecting the Headphones with Remote Control . . . . . . 28
xBasic operations
Turning the PSP™ system on and off . . . . . . . . . . . . . . . . 29
Using Sleep Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Inserting a UMD™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Inserting a Memory Stick Duo™ . . . . . . . . . . . . . . . . . . . . . 34
Avoiding unintended operation of the PSP™ system . . . . . 35
Using the sound button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Using the display button . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
xGame
Playing a game . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Game options menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Copying and deleting saved data . . . . . . . . . . . . . . . . . . . . 45
xVideo
Watching a video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Using the control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Operating with PSP™ system buttons
or the Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . 55
Video options menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Saving videos on a Memory Stick Duo™ . . . . . . . . . . . . . . 57
Table of contents
01PSP-1003 EN.book Page 8 Tuesday, October 25, 2005 12:34 PM

9
masterpage:Right
filename G:\#Sagyo\#SONY\03 PSP\PSP-
1003_UK\1025_PSP-1003\265788332 PSP-
1003K_UK\1025\265788332 PSP-
1003K_UK\01EN04TOC.fm
model name1PSP-1003K
2-657-883-32(1)
Table of contents
option 1-1
xMusic
Listening to music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Using the control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Operating with PSP™ system buttons
or the Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . 66
Music options menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Transferring and saving music on a
Memory Stick Duo™ . . . . . . . . . . . . . . . . . . . . . . . . . . 69
xPhoto
Viewing images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Using the control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Operating with PSP™ system buttons
or the Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . 77
Photo options menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Playing slideshows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Saving images on a Memory Stick Duo™ . . . . . . . . . . . . . 84
xNetwork
Using the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Connecting to the Internet . . . . . . . . . . . . . . . . . . . . . . . . . 87
xSettings
Settings for the PSP™ system . . . . . . . . . . . . . . . . . . . . . . 90
Video Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Photo Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
System Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Theme Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Date & Time Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Power Save Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Sound Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Security Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
USB Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Network Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Network Update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
01PSP-1003 EN.book Page 9 Tuesday, October 25, 2005 12:34 PM

masterpage:Left
filename G:\#Sagyo\#SONY\03 PSP\PSP-
1003_UK\1025_PSP-1003\265788332 PSP-
1003K_UK\1025\265788332 PSP-
1003K_UK\01EN04TOC.fm
model name1PSP-1003K
2-657-883-32(1)
10 Table of contents
option 1-1
How to use the keyboard . . . . . . . . . . . . . . . . . . . . . . . . . 118
xAdditional information
PSP™ updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Compatible media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
GUARANTEE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
For further details about the PSP™ system, please visit
http://www.yourpsp.com
01PSP-1003 EN.book Page 10 Tuesday, October 25, 2005 12:34 PM

11
filename G:\#Sagyo\#SONY\03 PSP\PSP-
1003_UK\1025_PSP-1003\265788332 PSP-
1003K_UK\1025\265788332 PSP-
1003K_UK\01EN05PCT.fm
model name1PSP-1003K
2-657-883-32(1)
Precautions
masterpage:Right
option 1-1
Carefully read the supplied instructions before use. Retain them for future
reference.
Safety
This product has been designed with the highest concern for safety. However,
any electrical device, if used improperly, has the potential for causing fire,
electrical shock or personal injury. To help ensure accident-free operation,
follow these guidelines:
• Observe all warnings, precautions and instructions.
• Regularly inspect the AC Adaptor and AC Power Cord for damage and for
dust build-up around the power plug or electrical outlet.
• Stop use, unplug the AC Power Cord from the electrical outlet and disconnect
any other cables immediately if the device functions in an abnormal manner,
produces unusual sounds or smells or becomes too hot to touch.
Use and handling
• Use in a well-lit area and keep the screen a safe distance from your face.
• Avoid prolonged use of the PSP™ system. To help prevent eyestrain, take a
break of about 15 minutes during every hour of play.
• Keep the system and accessories out of the reach of small children, as small
children may swallow small parts such as Memory Stick Duo™.
• Do not use the system while driving or riding a bicycle. Looking at the screen
or operating the system while driving an automobile or riding a bicycle may
result in a traffic accident.
• Do not use the system or accessories near water.
• Use only attachments/accessories specified by the manufacturer.
• Do not expose the system or accessories to high temperatures, high humidity,
or direct sunlight.
• Do not leave the system or accessories in a car with the windows closed
(particularly in summer).
• Do not expose the system or accessories to dust, smoke or steam.
• Do not allow liquid or small particles to get into the system or accessories.
• Do not place the system or accessories on surfaces that are tilted, unstable or
subject to vibration.
Precautions
01PSP-1003 EN.book Page 11 Tuesday, October 25, 2005 12:34 PM

masterpage:Left
filename G:\#Sagyo\#SONY\03 PSP\PSP-
1003_UK\1025_PSP-1003\265788332 PSP-
1003K_UK\1025\265788332 PSP-
1003K_UK\01EN05PCT.fm
model name1PSP-1003K
2-657-883-32(1)
12 Precautions
option 1-1
• Do not throw, drop or step on the system or accessories, and do not subject
the devices to strong physical shock. Sitting down with the PSP™ system in
a pocket or placing the system in the bottom of a backpack along with heavy
objects may cause damage to the system.
• Do not forcibly twist the PSP™ system or expose the system to strong
physical shock during gameplay, as doing so can damage the system or cause
the disc cover to open, ejecting the disc. Handle the analog stick with care.
• Do not put heavy objects on the system or accessories.
• Do not touch or insert foreign objects into the connectors of the system or
accessories.
• Do not touch the system or AC Adaptor for an extended period of time while
in use. Depending on the conditions of use, the system or the AC Adaptor may
reach temperatures of 40° C or more. Extended contact under these conditions
may cause low-temperature burns*.
* Low-temperature burns are burns that occur when the skin is in contact with objects of
the AC relatively low temperatures (40° C or more) for an extended period of time.
AC Adaptor and AC Power Cord use
• Do not touch the plug of the AC Power Cord with wet hands.
• Do not touch the AC Power Cord, AC Adaptor or the system, if connected to
an electrical outlet, during an electrical storm.
• Do not use a power source other than the supplied Battery Pack, AC Adaptor
and AC Power Cord.
• Do not allow dust or foreign matter to build up around the system or accessory
connectors. If there is dust or foreign matter on the system's connectors or the
AC Power Cord, wipe it off with a dry cloth before connecting. Dust or other
matter on the connectors can result in fire or electrical shock.
• Unplug the AC Power Cord from the electrical outlet and remove the Battery
Pack from the system before cleaning or when you do not intend to use the
system for an extended period of time.
• Protect the AC Power Cord from being walked on or compressed particularly
at plugs and the point where they exit from the system.
• When disconnecting the AC Power Cord, hold it by the plug and pull straight
out from the electrical socket. Never pull by the cord and do not pull at an
angle.
• Do not use the system to play games, video or music when the system is
covered with any type of fabric. If you want to pause or temporarily store the
system while playing games, video or music, put the system in Sleep Mode
before placing it in the Pouch.
01PSP-1003 EN.book Page 12 Tuesday, October 25, 2005 12:34 PM

13
filename G:\#Sagyo\#SONY\03 PSP\PSP-
1003_UK\1025_PSP-1003\265788332 PSP-
1003K_UK\1025\265788332 PSP-
1003K_UK\01EN05PCT.fm
model name1PSP-1003K
2-657-883-32(1)
Precautions
masterpage:Right
option 1-1
• Do not connect the AC Power Cord to a voltage transformer or inverter.
Connecting the AC Power Cord to a voltage transformer for overseas travel
or an inverter for use in an automobile may cause heat to build up in the AC
Adaptor and may cause burns or a malfunction.
LCD screen
• The LCD screen is made of glass and may crack if subjected to excessive
force.
• Red, blue or green spots (bright spots) or black spots (dark spots) may appear
in certain locations on the LCD screen. The appearance of such spots is a
normal occurrence associated with LCD screens and is not a sign of a
malfunction. LCD screens are made using highly precise technology.
However, a very small number of dark pixels or continuously lit pixels exist
on each screen. Also, a distorted image may remain on the screen for several
seconds after the system has been turned off.
• Direct exposure to sunlight may damage the system's LCD screen.
• When using the system in a cold environment, you may notice shadows on
the graphics or the screen may appear darker than usual. This is not a
malfunction, and the screen will return to normal when the temperature rises.
• Do not leave still images displayed on the screen for an extended period of
time. This may cause a faint image to be left permanently on the screen.
Memory Stick Duo™
For best results, follow these guidelines:
• Do not touch the connector area (A) with your hands or with metal objects.
• Do not press hard when writing on the memo area (B).
• Do not insert a Memory Stick Duo™ into a device designed to accept only
standard-size Memory Stick™ media.
• Do not use or store a Memory Stick Duo™ in the following:
– Places subject to high temperatures, such as in a hot vehicle
– Locations exposed to direct sunlight
– Locations that are very humid or conducive to corrosion
01PSP-1003 EN.book Page 13 Tuesday, October 25, 2005 12:34 PM

masterpage:Left
filename G:\#Sagyo\#SONY\03 PSP\PSP-
1003_UK\1025_PSP-1003\265788332 PSP-
1003K_UK\1025\265788332 PSP-
1003K_UK\01EN05PCT.fm
model name1PSP-1003K
2-657-883-32(1)
14 Precautions
option 1-1
• Use the supplied case to carry or store the Memory Stick Duo™.
• When using Memory Stick Duo™ media without an erasure prevention
switch, take care not to overwrite or delete data by accident. If your Memory
Stick Duo™ media has an erasure prevention switch, you can prevent data
from being saved, edited, or deleted by setting the switch in the LOCK
position.
xRecorded data
Do not use the Memory Stick Duo™ in the following ways, as doing so may
result in data loss or corruption:
• Removing the Memory Stick Duo™ or turning off the system while it is
loading or saving data or being formatted.
• Using it in a location that is exposed to static electricity or electrical
interference.
Pouch
• If you want to pause or temporarily store the system while playing games or
video, put the system in Sleep Mode before placing it in the Pouch. This may
help to avoid overheating.
• Put both the PSP™ system and the Remote Control in Hold Mode to help
prevent unintended operation.
Never disassemble the system or supplied accessories
Use the PSP™ system and accessories according to the instructions in this
manual. No authorisation for the analysis or modification of the system, or the
analysis and use of its circuit configurations, is provided. Disassembling will
void the system warranty and may be harmful. The LCD screen, in particular,
contains dangerous, high-voltage parts, and the laser beam for reading UMD™
may cause visual impairment if exposed directly to the eyes.
Using the access point
When using the PSP™ system's 'Scan' function to select the wireless LAN
access point, access points that are not intended for public use may be
If, for any reason, software or data loss or corruption occurs, it is usually
not possible to recover the software or data. Sony Computer Entertainment
Inc. and its subsidiaries and affiliates accept no liability for damages, costs
or expenses arising from software, data loss or corruption.
01PSP-1003 EN.book Page 14 Tuesday, October 25, 2005 12:34 PM

15
filename G:\#Sagyo\#SONY\03 PSP\PSP-
1003_UK\1025_PSP-1003\265788332 PSP-
1003K_UK\1025\265788332 PSP-
1003K_UK\01EN05PCT.fm
model name1PSP-1003K
2-657-883-32(1)
Precautions
masterpage:Right
option 1-1
displayed. Only connect to a personal access point that you are authorized to
use, or one that is available through a public wireless LAN or hotspot service.
Overseas use
When travelling note any applicable wireless regulations.
Moisture condensation
If the PSP™ system or UMD™ is brought directly from a cold location to a
warm one, moisture may condense on the lens inside the system or on the
UMD™. Should this occur, the system may not operate properly. In this case,
remove the UMD™ and turn off and unplug the system. Do not put the UMD™
back in until the moisture evaporates (this may take several hours). If the
system still does not operate properly, contact the appropriate PSP™ customer
service helpline which can be found within every PSP™ format software
manual.
UMD™ handling
• Do not touch the opening on the rear of the disc (recorded surface of the disc)
with your fingers.
• Do not allow dust, sand, foreign objects or other types of dirt to get on the
disc.
• If the UMD™ becomes dirty, gently wipe the exterior and recorded surfaces
of the UMD™ using a soft cloth. Do not use solvents or other chemicals.
Cleaning
For safety reasons, unplug the AC Power Cord from the electrical outlet and
remove the Battery Pack from the system before cleaning.
xCleaning the exterior surface excluding LCD screen
Wipe gently with a soft cloth. Do not use solvents or other chemicals to clean
the exterior of the PSP™ system.
xCleaning the LCD screen
Wipe gently with a soft cloth.
xCleaning the connectors
• Do not use when the connectors of the system, AC Adaptor or the AC Power
Cord are not clean. Remove the dirt with a dry cloth. If used when dirty, the
flow of electrical current may be obstructed.
01PSP-1003 EN.book Page 15 Tuesday, October 25, 2005 12:34 PM

masterpage:Left
filename G:\#Sagyo\#SONY\03 PSP\PSP-
1003_UK\1025_PSP-1003\265788332 PSP-
1003K_UK\1025\265788332 PSP-
1003K_UK\01EN05PCT.fm
model name1PSP-1003K
2-657-883-32(1)
16 Precautions
option 1-1
• If the Headphones or Remote Control connectors become dirty, this could
cause noise or interruptions in sound. Wipe the connectors with a dry, soft
cloth to keep in a clean condition.
01PSP-1003 EN.book Page 16 Tuesday, October 25, 2005 12:34 PM

17
filename G:\#Sagyo\#SONY\03 PSP\PSP-
1003_UK\1025_PSP-1003\265788332 PSP-
1003K_UK\1025\265788332 PSP-
1003K_UK\01EN05PCT.fm
model name1PSP-1003K
2-657-883-32(1)
Precautions
masterpage:Right
option 1-1
Battery Pack precautions
Do not handle a damaged or leaking Battery Pack.
Contact with the material can result in injury or burns to the eyes or skin. Even
if foreign substances are not immediately visible, chemical changes in the
material can result in injuries occurring at a later time.
Handle the Battery Pack with care.
The Battery Pack may explode or present a fire or chemical burn hazard if it is
not handled carefully.
• Do not allow the Battery Pack to come into contact with fire or subject it to
extreme temperatures such as in direct sunlight, in a vehicle exposed to the
sun or near a heat source.
• Do not cause the Battery Pack to short-circuit.
• Do not disassemble or tamper with the Battery Pack.
• Prevent damage to the Battery Pack. Do not carry or store the Battery Pack
with metal items such as coins or keys. If damaged, discontinue use.
• Do not throw or drop the Battery Pack or subject it to strong physical shock.
• Do not put heavy objects on or apply pressure to the Battery Pack.
• Do not allow the Battery Pack to come into contact with liquids. If it becomes
wet, discontinue use until it is completely dry.
• Keep the Battery Pack out of the reach of small children.
• If the PSP™ system will not be used for an extended period of time, remove
the Battery Pack and store it in a cool, dry place out of the reach of children.
• Use only the supplied Battery Pack or a replacement marked for use with the
PSP™ system.
• Use only the designated AC Adaptor to charge the Battery Pack.
Warnings
If you come into contact with material from a leaking Battery Pack, take the
following actions:
• If the material gets into the eyes, do not rub. Immediately rinse the eyes
with clean water and seek medical attention.
• If the material comes into contact with the skin or clothes, immediately
rinse the affected area with clean water. Consult your physician if
inflammation or soreness develops.
01PSP-1003 EN.book Page 17 Tuesday, October 25, 2005 12:34 PM

masterpage:Left
filename G:\#Sagyo\#SONY\03 PSP\PSP-
1003_UK\1025_PSP-1003\265788332 PSP-
1003K_UK\1025\265788332 PSP-
1003K_UK\01EN06PPT.fm
model name1PSP-1003K
2-657-883-32(1)
18 Checking the package contents
option 1-1
Check that you have all of the following items. If any items are missing, contact
the appropriate PSP™ customer service helpline which can be found within
every PSP™ format software manual.
Preparation
Checking the package contents
POWER
HOLD
SELECT
HOME
VOL
START
5V
sBattery Pack
sPSP™ (PlayStation®Portable) system
sAC Adaptor
sPouch
sCloth
sUMD™ software
sPrinted Materials
sHeadphones*with Remote Control
* Ear Friendly Headphones
sMemory Stick Duo™ (32 MB)
sWrist strap
Supplied with the Value Pack:
sMemory Stick PRO Duo™ (1 GB)
sStand
sUSB cable
Supplied with the Giga Pack:
01PSP-1003 EN.book Page 18 Tuesday, October 25, 2005 12:34 PM

19
filename G:\#Sagyo\#SONY\03 PSP\PSP-
1003_UK\1025_PSP-1003\265788332 PSP-
1003K_UK\1025\265788332 PSP-
1003K_UK\01EN06PPT.fm
Preparation
model name1PSP-1003K
2-657-883-32(1)
Part names and functions
masterpage:Right
option 1-1
System front
Part names and functions
AL button
Bdirectional buttons
CMemory Stick Duo™ access
indicator
Lights up when saving and loading
data
DWLAN access indicator
Lights up when using the wireless
networking feature
Eanalog stick
Can be used with games that
support analog operation.
To optimize the analog stick's
functionality, with the "System
Information" screen under "System
Settings" ( page 96) displayed,
you can rotate the analog stick in a
circular motion to adjust its range of
movement.
Fstrap holder
Attach as shown in the diagram.
Gleft speaker
HHOME button
Displays the Home Menu
Ivolume – button
Turns the volume down
Jvolume + button
Turns the volume up
POWER
HOLD
SELECT
HOME VOL START
HOMEVOL
01PSP-1003 EN.book Page 19 Tuesday, October 25, 2005 12:34 PM

masterpage:Left
filename G:\#Sagyo\#SONY\03 PSP\PSP-
1003_UK\1025_PSP-1003\265788332 PSP-
1003K_UK\1025\265788332 PSP-
1003K_UK\01EN06PPT.fm
model name1PSP-1003K
2-657-883-32(1)
20 Part names and functions
option 1-1
System rear
KLCD screen
Ldisplay button
Adjusts screen brightness
(page38)
Msound button
Adjusts the tone ( page 36)
NSELECT button
OSTART button
PR button
Qbutton
Rbutton
Sbutton
Tbutton
UPOWER indicator
Lights up, flashes or changes colour
to indicate system status
( page 29)
VHOLD indicator
Turns yellow when in Hold Mode
( page 35)
Wright speaker
Abattery cover Cdisc cover
BPUSH button
PUSH
UMD
01PSP-1003 EN.book Page 20 Tuesday, October 25, 2005 12:34 PM
