Sony DAV-DZ20 User manual

©2007 Sony Corporation
2-895-955-12(2)
DVD Home Theatre
System
Operating Instructions
DAV-DZ20

2GB
To reduce the risk of fire or electric
shock, do not expose this apparatus to
rain or moisture.
Caution – The use of optical instruments
with this product will increase eye
hazard.
Do not install the appliance in a confined space, such
as a bookcase or built-in cabinet.
To prevent fire, do not cover the ventilation of the
apparatus with news papers, table-cloths, curtains, etc.
And don’t place lighted candles on the apparatus.
To prevent fire or shock hazard, do not place objects
filled with liquids, such as vases, on the apparatus.
Do not expose the battery to excessive heat such as
direct sunlight, fire, or the like.
Don’t throw away the battery with
general house waste, dispose of it
correctly as chemical waste.
This appliance is
classified as a CLASS 1
LASER product. This
marking is located on the
rear exterior.
NOTICE FOR THE CUSTOMERS IN THE
UNITED KINGDOM
A moulded plug complying with BS1363 is fitted to
this equipment for your safety and convenience.
Should the fuse in the plug supplied need to be
replaced, a fuse of the same rating as the supplied one
and approved by ASTA or BSI to BS1362, (i.e.,
marked with mark or mark) must be used.
If the plug supplied with this equipment has a
detachable fuse cover, be sure to attach the fuse cover
after you change the fuse. Never use the plug without
the fuse cover.
If you should lose the fuse cover, please contact your
nearest Sony service station.
Disposal of Old
Electrical & Electronic
Equipment (Applicable
in the European Union
and other European
countries with separate
collection systems)
This symbol on the product or on
its packaging indicates that this
product shall not be treated as household waste. Instead
it shall be handed over to the applicable collection
point for the recycling of electrical and electronic
equipment. By ensuring this product is disposed of
correctly, you will help prevent potential negative
consequences for the environment and human health,
which could otherwise be caused by inappropriate
waste handling of this product. The recycling of
materials will help to conserve natural resources. For
more detailed information about recycling of this
product, please contact your local Civic Office, your
household waste disposal service or the shop where
you purchased the product.
Precautions
On power sources
• AC power cord (mains lead) must be changed only at
the qualified service shop.
• The unit is not disconnected from the AC power
source (mains) as long as it is connected to the wall
outlet (mains), even if the unit itself has been turned
off.
• Install this system so that the AC power cord (mains)
can be unplugged from the wall socket immediately
in the event of trouble.
Thank you for purchasing Sony DVD Home
Theatre System. Before operating this system,
please read this manual thoroughly and retain it
for future reference.
WARNING
Welcome!

3GB
Welcome!................................................ 2
About This Manual .................................5
This System Can Play the Following
Discs .................................................6
Getting Started – BASIC –
Step 1: Connecting the System and
TV ............................................... 9
Step 2: Positioning the System... 13
Step 3: Performing the Quick
Setup........................................ 13
Getting Started
– ADVANCED –
Turning off the Demonstration .............16
Installing the Speakers on a Wall.......... 17
Basic Operations
Playing Discs ................................ 18
Enjoying the Radio or Other
Components............................ 19
Enjoying TV Sound from All
Speakers.................................. 20
Selecting the Movie or Music
Mode ........................................ 21
Sound Adjustments
Enjoying Surround Sound by Using Sound
Field ................................................ 22
Various Functions for Playing
Discs
Searching for a Particular Point on
a Disc ..............................................24
(Scan, Slow-motion Play, Freeze
Frame)
Searching for a Title/Chapter/Track/
Scene, etc. ....................................... 25
Searching by Scene ............................... 26
(Picture Navigation)
Resuming Playback from the Point Where
You Stopped the Disc .....................26
(Resume Play)
Creating Your Own Program ................27
(Program Play)
Playing in Random Order .....................29
(Shuffle Play)
Playing Repeatedly ............................... 30
(Repeat Play)
Using the DVD’s Menu........................ 31
Changing the Sound.............................. 31
Selecting [ORIGINAL] or [PLAY LIST]
on a DVD-R/DVD-RW.................. 33
Viewing Information About the Disc ... 34
Changing the Angles ............................ 36
Displaying the Subtitles........................ 37
Adjusting the Delay Between the Picture
and Sound....................................... 37
(A/V SYNC)
About MP3 Audio Tracks and JPEG
Image Files ..................................... 38
Playing DATA CDs or DATA DVDs with
MP3 Audio Tracks and JPEG Image
Files ................................................ 40
Playing Audio Tracks and Images as a
Slide Show with Sound .................. 42
Enjoying DivX® Videos ...................... 44
(Except for United Kingdom and
North American models)
Playing VIDEO CDs with PBC Functions
(Ver.2.0) ......................................... 46
(PBC Playback)
Tuner Functions
Presetting Radio Stations...................... 47
Listening to the Radio........................... 48
Using the Radio Data System (RDS) ... 49
Other Operations
Controlling the TV with the Supplied
Remote ........................................... 50
Using the THEATRE SYNC
Function.......................................... 50
Using the Sound Effect......................... 51
Using the Sleep Timer .......................... 52
Changing the Brightness of the Front
Panel Display.................................. 52
Deactivating the Buttons on the Unit ... 53
(Child Lock)
Table of Contents
cont
i
nue
d

4GB
Advanced Settings and
Adjustments
Locking Discs ....................................... 54
(CUSTOM PARENTAL
CONTROL, PARENTAL
CONTROL)
Getting Optimal Surround Sound for a
Room .............................................. 57
(SPEAKER FORMATION)
Using the Setup Display........................59
Setting the Display or Sound Track
Language ........................................ 60
[LANGUAGE SETUP]
Settings for the Display......................... 61
[SCREEN SETUP]
Custom Settings .................................... 62
[CUSTOM SETUP]
Settings for the Speakers....................... 63
[SPEAKER SETUP]
Returning to the Default Settings..........65
Additional Information
Precautions ............................................ 66
Notes about the Discs............................67
Troubleshooting .................................... 67
Self-diagnosis Function ........................71
(When letters/numbers appear in
the display)
Specifications ........................................ 71
Glossary ................................................ 73
Language Code List .............................. 76
Index to Parts and Controls................... 77
Guide to the Control Menu Display......79
DVD Setup Display List ....................... 82
System Menu List ................................. 83
Index .....................................................84

5GB
• The instructions in this manual describe the
controls on the remote. You can also use the
controls on the unit if they have the same or
similar names as those on the remote.
• The Control Menu items may vary depending
on the area.
• “DVD” may be used as a general term for
DVD VIDEOs, DVD+RWs/DVD+Rs, and
DVD-RWs/DVD-Rs.
• Measurements are expressed in feet (ft) for
North American models.
• The following symbols are used in this
manual.
1)MP3 (MPEG1 Audio Layer 3) is a standard format
defined by ISO/MPEG which compresses audio data.
2)Except for United Kingdom and North American
models.
3) DivX®is a video file compression technology,
developed by DivX, Inc.
4) DivX, DivX Certified, and associated logos are
trademarks of DivX, Inc. and are used under license.
About This Manual
Symbol Meaning
Functions available for DVD
VIDEOs, DVD-Rs/DVD-RWs in
video mode, and DVD+Rs/
DVD+RWs
Functions available for DVD-Rs/
DVD-RWs in VR (Video
Recording) mode
Functions available for VIDEO
CDs (including Super VCDs or CD-
Rs/CD-RWs in video CD format or
Super VCD format)
Functions available for music CDs
or CD-Rs/CD-RWs in music CD
format
Functions available for DATA CDs
(CD-ROMs/CD-Rs/CD-RWs)
containing MP31) audio tracks,
JPEG image files, and DivX2)3)4)
video files
Functions available for DATA
DVDs (DVD-ROMs/DVD-Rs/
DVD-RWs/DVD+Rs/DVD+RWs)
containing MP31) audio tracks,
JPEG image files, and DivX2)3)4)
video files

6GB
“DVD-RW,” “DVD+RW,” “DVD+R,”
“DVD VIDEO,” and the “CD” logos are trademarks.
Note about CDs/DVDs
The system can play CD-ROMs/CD-Rs/CD-
RWs recorded in the following formats:
– audio CD format
– VIDEO CD format
– MP3 audio tracks, JPEG image files, and
DivX video files* of format conforming to
ISO 9660 Level 1/Level 2, or its extended
format, Joliet
The system can play DVD-ROMs/DVD+RWs/
DVD-RWs/DVD+Rs/DVD-Rs recorded in the
following formats:
– MP3 audio tracks, JPEG image files, and
DivX video files* of format conforming to
UDF (Universal Disc Format)
* Except for United Kingdom and North American
models.
Example of discs that the
system cannot play
The system cannot play the following discs:
• CD-ROMs/CD-Rs/CD-RWs other than those
recorded in the formats listed on page 6
• CD-ROMs recorded in PHOTO CD format
• Data part of CD-Extras
• DVD Audios
• Super Audio CD
• DATA DVDs that do not contain MP3 audio
tracks, JPEG image files, or DivX video files*
* Except for United Kingdom and North American
models.
• DVD-RAMs
Also, the system cannot play the following
discs:
• A DVD VIDEO with a different region code
(page 7, 74)
• A disc that has a non-standard shape (e.g.,
card, heart)
• A disc with paper or stickers on it
• A disc that has the adhesive of cellophane tape
or a sticker still left on it
Notes about CD-R/CD-RW/DVD-R/
DVD-RW/DVD+R/DVD+RW
In some cases, CD-R/CD-RW/DVD-R/DVD-
RW/DVD+R/DVD+RW cannot be played on
this system due to the recording quality or
physical condition of the disc, or the
characteristics of the recording device and
authoring software.
The disc will not play if it has not been correctly
finalized. For more information, see the
operating instructions for the recording device.
Note that some playback functions may not
work with some DVD+RWs/DVD+Rs, even if
they have been correctly finalized. In this case,
This System Can Play the
Following Discs
Format of
discs Disc logo
DVD VIDEO
DVD-RW/
DVD-R
DVD+RW/
DVD+R
VIDEO CD
(Ver. 1.1 and
2.0 discs)/
Audio CD
CD-RW/CD-R
(audio data)
(MP3 files)
(JPEG files)

7GB
view the disc by normal playback. Also some
DATA CDs/DATA DVDs created in Packet
Write format cannot be played.
Music discs encoded with
copyright protection
technologies
This product is designed to play back discs that
conform to the Compact Disc (CD) standard.
Recently, various music discs encoded with
copyright protection technologies are marketed
by some record companies. Please be aware that
among those discs, there are some that do not
conform to the CD standard and may not be
playable by this product.
Note on DualDiscs
A DualDisc is a two sided disc product which
mates DVD recorded material on one side with
digital audio material on the other side.
However, since the audio material side does not
conform to the Compact Disc (CD) standard,
playback on this product is not guaranteed.
About Multi Session CD
• This system can play Multi Session CDs when
an MP3 audio track is contained in the first
session. Any subsequent MP3 audio tracks
recorded in later sessions can also be played
back.
• This system can play Multi Session CDs when
a JPEG image file is contained in the first
session. Any subsequent JPEG image files
recorded in later sessions can also be played
back.
• If audio tracks and images in music CD format
or video CD format are recorded in the first
session, only the first session will be played
back.
Region code
Your system has a region code printed on the
rear of the unit and will only play DVDs labeled
with the same region code.
DVD VIDEOs labeled will also play on this
system.
If you try to play any other DVD VIDEO, the
message [Playback prohibited by area
limitations.] will appear on the TV screen.
Depending on the DVD VIDEO, no region code
indication may be given even though playing the
DVD VIDEO is prohibited by area restrictions.
Note about playback
operations of DVDs and
VIDEO CDs
Some playback operations of DVDs and VIDEO
CDs may be intentionally set by software
producers. Since this system plays DVDs and
VIDEO CDs according to the disc contents the
software producers designed, some playback
features may not be available. Be sure to read the
operating instructions supplied with the DVDs
or VIDEO CDs.
Copyrights
This product incorporates copyright protection
technology that is protected by U.S. patents and
other intellectual property rights. Use of this
copyright protection technology must be
authorized by Macrovision, and is intended for
home and other limited viewing uses only unless
otherwise authorized by Macrovision. Reverse
engineering or disassembly is prohibited.
This system incorporates with Dolby* Digital
and Dolby Pro Logic (II) adaptive matrix
surround decoder and the DTS** Digital
Surround System.
* Manufactured under license from Dolby
Laboratories.
“Dolby”, “Pro Logic”, and the double-D symbol are
trademarks of Dolby Laboratories.
** Manufactured under license from DTS, Inc.
“DTS” and “DTS Digital Surround” are registered
trademarks of DTS, Inc.
ALL

8GB
Getting Started – BASIC –
See Unpacking in Specifications, page 71.
Inserting batteries into the remote
You can control the system using the supplied remote. Insert two R6 (size AA) batteries by matching
the 3and #ends on the batteries to the markings inside the compartment. To use the remote, point it
at the remote sensor on the unit.
Note
• Do not leave the remote in an extremely hot or humid place.
• Do not use a new battery with an old one.
• Do not drop any foreign object into the remote casing, particularly when replacing the batteries.
• Do not expose the remote sensor to direct sunlight or lighting apparatus. Doing so may cause a malfunction.
• If you do not intend to use the remote for an extended period of time, remove the batteries to avoid possible damage
from battery leakage and corrosion.
Getting Started – BASIC –

9GB
Getting Started – BASIC –
The following is the connection of the unit to the speakers and TV.
Refer to the connection diagram below, and read the additional information from 1to 4on the
following pages.
Step 1: Connecting the System and TV
SPEAKER
ANTENNA
FRONT R FRONT L SUR R SUR L CENTER WOOFER
EURO AV
OUTPUT(TO TV)
COAXIAL
AM
FM75
AM loop antenna (aerial)
Subwoofer
AC power cord (mains lead)
FM wire antenna
(aerial)
TV
Front speaker (R) Center speaker Front speaker (L)
Surround speaker (R) Surround speaker (L)
:Signal flow
cont
i
nue
d

10GB
Getting Started – BASIC –
1Connecting the Speakers
Required cords
The connector and color tube of the speaker cords are the same color as the label of the jacks to be
connected.
Note
• Do not catch the speaker cord insulation in the SPEAKER jack.
To avoid short-circuiting the speakers
Short-circuiting of the speakers may damage the system. To prevent this, be sure to follow these
precautions when connecting the speakers. Make sure the bare wire of each speaker cord does not touch
another speaker terminal or the bare wire of another speaker cord, such as shown below.
After connecting all the components, speakers, and AC power cord (mains lead), output a test tone to
check that all the speakers are connected correctly. For details on outputting a test tone, see page 64.
If no sound is heard from a speaker while outputting a test tone, or a test tone is output from a speaker
other than the one currently displayed on the Setup Display, the speaker may be short-circuited. If this
happens, check the speaker connection again.
Note
• Be sure to match the speaker cord to the appropriate terminal on the components: 3to 3, and #to #. If the cords
are reversed, the sound will lack bass and may be distorted.
(–)
(+)
To the SPEAKER jack
Color tube Black
Gray
Stripped speaker cord is touching
another speaker terminal.
Stripped cords are touching each other
due to excessive removal of insulation.

11GB
Getting Started – BASIC –
2Connecting the TV
Required cords
SCART (EURO AV) cord (not supplied)
.
Be sure to connect the SCART (EURO AV) cord to the EURO AV TOUTPUT (TO TV) jack on the
unit.
When you connect using the SCART (EURO AV) cord, check that the TV conforms to S video or RGB
signals. If the TV conforms to S video, change the input mode of the TV to RGB signals. Refer to the
operating instructions supplied with the TV to be connected.
Ti
p
• When you want to output the TV sound or stereo sound of a 2 channel source from the 6 speakers, select the “Dolby
Pro Logic,” “Dolby Pro Logic II MOVIE,” or “Dolby Pro Logic II MUSIC” sound field (page 22).
3Connecting the Antenna (Aerial)
To connect the AM loop antenna (aerial)
The shape and the length of the antenna (aerial) is designed to receive AM signals. Do not dismantle
or roll up the antenna (aerial).
1Remove only the loop part from the plastic stand.
2Set up the AM loop antenna (aerial).
3Connect the cords to the AM antenna (aerial) terminals.
Cord (A) or cord (B) can be connected to either terminal.
Note
• Do not place the AM loop antenna (aerial) near the unit or other AV equipment, as noise may result.
Ti
p
• Adjust the direction of the AM loop antenna (aerial) for best AM broadcast sound.
AB
Insert until this
part.
Insert the cord pushing
down the terminal clamp.
cont
i
nue
d

12GB
Getting Started – BASIC –
4Make sure the AM loop antenna (aerial) is connected firmly by pulling softly.
To connect the FM wire antenna (aerial)
Connect the FM wire antenna (aerial) to the COAXIAL FM 75 Ωjack.
Note
• Be sure to fully extend the FM wire antenna (aerial).
• After connecting the FM wire antenna (aerial), keep it as horizontal as possible.
Ti
p
• If you have poor FM reception, use a 75-ohm coaxial cable (not supplied) to connect the unit to an outdoor FM
antenna (aerial) as shown below.
4Connecting the AC power cord (mains lead)
Before connecting the AC power cord (mains lead) of this unit to a wall outlet (mains), connect the
speakers to the unit.
FM wire antenna (aerial)
(supplied)
COAXIAL FM 75 Ωjack
or
FM wire antenna (aerial)
(supplied)
COAXIAL FM 75 Ωjack
Outdoor FM antenna (aerial)
Unit

13GB
Getting Started – BASIC –
Positioning the speakers
For the best possible surround sound, all the
speakers other than the subwoofer should be
placed at the same distance from the listening
position (A).
However, this system allows you to place the
center speaker up to 1.6 meters (5 ft) closer (B)
and the surround speakers up to 5.0 meters (16
ft) closer (C) to the listening position.
The front speakers can be placed from 1.0 to
7.0 meters (3 to 23 ft) (A) from the listening
position.
Place speakers as illustrated below.
Note
• Do not set the speakers in an inclined position.
• Do not place the speakers in locations that are:
– Extremely hot or cold
– Dusty or dirty
– Very humid
– Subject to vibrations
– Subject to direct sunlight
• When cleaning, use a soft cloth such as a cleaning
cloth for glasses.
• Do not use any type of abrasive pad, scouring
powder, or solvent such as alcohol or benzine.
Ti
p
• When you change the positions of the speakers, it is
recommended that you change the settings. For
details, see “Getting Optimal Surround Sound for a
Room” (page 57).
Follow the steps below to make the minimum
number of basic adjustments for using the
system.
1Turn on the TV.
2Press [/1.
Note
• Make sure that the function is set to “DVD”
(page 18).
3Switch the input selector on your TV so
that the signal from the system
appears on the TV screen.
[Press [ENTER] to run QUICK SETUP.]
appears at the bottom of the TV screen. If
this message does not appear, recall the
Quick Setup display (page 15) and perform
again.
Step 2: Positioning the
System
Step 3: Performing the
Quick Setup
"/1
DISPLAY
C/X/x/c,
cont
i
nue
d

14GB
Getting Started – BASIC –
4Press without inserting a disc.
The Setup Display for selecting the
language used in the on-screen display
appears.
5Press X/xto select a language.
The system displays the menu and subtitles
in the selected language.
6Press .
The Setup Display for selecting the aspect
ratio of the TV to be connected appears.
7Press X/xto select the setting that
matches your TV type.
xIf you have a wide-screen TV or a 4:3
standard TV with a wide-screen mode
[16:9] (page 61)
xIf you have a 4:3 standard TV
[4:3 LETTER BOX] or [4:3 PAN SCAN]
(page 61)
8Press .
The Setup Display for selecting the speaker
formation appears.
9Press C/cto select the speaker
formation image as the speakers are
actually positioned.
For details, see “Getting Optimal Surround
Sound for a Room” (page 57).
10 Press .
The Setup Display for selecting the speaker
distance appears.
11 Press X/xto select the front speaker
distance from the listening position,
then press .
12 Press X/xto select the center speaker
distance from the listening position,
then press .
LANGUAGE SETUP
OSD:
MENU:
AUDIO:
SUBTITLE: PORTUGUESE
FRENCH
ENGLISH
ENGLISH
SPANISH
SCREEN SETUP
TV TYPE: 16:9
4:3 PAN SCAN
4:3 LETTER BOX
SCREEN SAVER:
BACKGROUND:
16:9
SPEAKER FORMATION
STANDARD
SPEAKER SETUP
TEST TONE:
LEVEL(FRONT):
LEVEL(SURROUND):
OFF
CENTER:
3.0m
3.0m
SURROUND:
DISTANCE:
CONNECTION:
FRONT: 3.0m
SPEAKER SETUP
TEST TONE:
LEVEL(FRONT):
LEVEL(SURROUND):
OFF
3.0m
SURROUND:
DISTANCE:
CONNECTION:
FRONT: 3.0m
CENTER: 3.0m
SPEAKER SETUP
TEST TONE:
LEVEL(FRONT):
LEVEL(SURROUND):
OFF
DISTANCE:
CONNECTION:
FRONT: 3.0m
CENTER: 3.0m
3.0m
SURROUND:

15GB
Getting Started – BASIC –
13 Press X/xto select the surround
speaker distance from the listening
position, then press .
Quick Setup is finished. All connections
and setup operations are complete.
To quit the Quick Setup
Press DISPLAY in any Step.
Ti
p
• If you change the position of the speakers, reset the
speaker settings. See “Getting Optimal Surround
Sound for a Room” (page 57).
• If you want to change any of the settings, see “Using
the Setup Display” (page 59).
To recall the Quick Setup display
1Press DISPLAY when the system is in
stop mode.
The Control Menu display appears.
2Press X/xto select [SETUP], then
press .
The options for [SETUP] appear.
3Press X/xto select [QUICK], then press .
The Quick Setup display appears.
Selecting the output method for
video signals
Selects the output method for video signals from
the EURO AV TOUTPUT (TO TV) jack on
the rear panel of the unit.
1Press FUNCTION repeatedly to select
“DVD.”
2Press VIDEO FORMAT.
Each time you press VIDEO FORMAT, the
display changes as follows:
• “LINE VIDEO”: outputs video signals.
• “LINE RGB”: outputs RGB signals.
Note
• If your TV does not accept RGB signals, no
picture appears on the TV screen even if you
select “LINE RGB.” Refer to the operating
instructions supplied with your TV.
1 2 ( 2 7 )
QUICK
QUICK
RESET
DVD VIDEO
BNR
T 0 : 0 0 : 0 2
1 8 ( 3 4 )
CUSTOM
VIDEO
FORMAT
FUNCTION
tLINE VIDEO
r
LINE RGB

16GB
After connecting the AC power cord (mains
lead), the demonstration appears in the front
panel display. When you press "/1 on the
remote, the demonstration turns off.
Note
• When you press "/1on the unit, the demonstration
does not turn off.
• When you set the demonstration mode in the system
menu to on, the demonstration does not turn off even
though you press "/1on the remote. To turn off the
demonstration, set the demonstration mode to off,
then press "/1on the remote. When the
demonstration mode is set to off, the system saves
power in standby mode.
• If the system is at its factory default settings (ex. after
performing “COLD RESET” (page 65)), you can turn
off the demonstration simply by pressing "/1on the
remote. Otherwise, to stop the demonstration, you
need to set “DEMO” to “DEMO OFF.”
Setting the demonstration
mode to on/off
1Press SYSTEM MENU.
2Press X/xrepeatedly until “DEMO”
appears in the front panel display, then
press or c.
3Press X/xto select a setting.
The default setting is underlined.
• “DEMO ON”: sets the demonstration
mode to on.
• “DEMO OFF”: sets the demonstration
mode to off.
4Press .
The setting is made.
5Press SYSTEM MENU.
The system menu turns off.
Getting Started – ADVANCED –
Turning off the
Demonstration
SYSTEM
MENU
"/1
X/x/c,

Getting Started – ADVANCED –
17GB
You can use the speakers by installing on the
wall.
Installing the speakers on a
wall
1Prepare screws (not supplied) that are
suitable for the hole on the back of
each speaker. See the illustrations
below.
2Fasten the screws to the wall.
3Hang the speakers on the screws.
Note
• Use screws that are suitable for the wall material and
strength. As a plaster board wall is especially fragile,
attach the screws securely to a beam and fasten them
to the wall. Install the speakers on a vertical and flat
wall where reinforcement is applied.
• Contact a screw shop or installer regarding the wall
material or screws to be used.
• Sony is not responsible for accident or damage
caused by improper installation, insufficient wall
strength or improper screw installation, natural
calamity, etc.
Installing the Speakers on
a Wall
25 mm (1inch)
4 mm (5/32 inch)
Hole on the back of
the speaker (except
for the center
speaker)
4.6 mm
(3/16 inch)
10 mm
(13/32 inch)
6 to 9 mm
(1/4
to 3/8 inch )
4.6 mm
(3/16 inch)
10 mm
(13/32 inch)
Rear of speaker

18GB
Basic Operations
Depending on the DVD VIDEO or VIDEO CD,
some operations may be different or restricted.
Refer to the operating instructions supplied with
your disc.
1Turn on your TV.
2Switch the input selector on the TV to
this system.
3Press "/1.
The system turns on.
Unless the system is set to “DVD,” press
FUNCTION to select “DVD.”
4Press A.
5Load a disc.
Place one disc on the tray, and then press A.
Note
• When you play an 8 cm disc, place it on the
inner circle of the tray. Be careful that the disc is
not skewed on the inner circle of the tray.
• Do not forcibly press the disc tray closed with
your finger, as this may cause malfunction.
• Do not place more than one disc on the tray.
6Press H.
The system starts playback (continuous
play).
Adjust the volume on the unit.
The volume level appears on the TV screen
and in the front panel display.
Note
• Depending on the system status, the volume level
may not appear on the TV screen.
To save the power in standby
mode
Press "/1while the system turns on. To cancel
standby mode, press "/1once.
Additional operations
Basic Operations
Playing Discs
"/1
Disc tray
FUNCTION
Adjust the
volume
H
A
"/1
FUNCTION
x
H
X
./>
MUTING
VOLUME +/–
/
Z
To Press
Stop x
Pause X
Resume play after pause Xor H
Go to the next chapter,
track, or scene
>(except for JPEG)
Go back to the preceding
chapter, track, or scene
.(except for JPEG)
Turn off the sound
temporarily
MUTING. To cancel,
press it again or
VOLUME + to adjust
the sound volume.

19GB
Basic Operations
* DVD VIDEOs/DVD-RWs/DVD-Rs only. The
button can be used except for DivX video files
(except for United Kingdom and North American
models).
** DVD VIDEOs/DVD-RWs/DVD-Rs/DVD+RWs/
DVD+Rs only. The button can be used except for
DivX video files (except for United Kingdom and
North American models).
Note
• You may not be able to use the instant replay or
instant advance function with some scenes.
Selecting the connected
component
Press FUNCTION repeatedly until the
desired function name appears in the front
panel display.
Each time you press FUNCTION, the mode of
the system changes in the following sequence.
DVD tTUNER FM tTUNER AM t
TV t…
Changing the input level of
the sound from connected
components
Distortion may occur when listening to a TV
connected to the EURO AV TOUTPUT (TO
TV) jack on the rear panel. This is not a
malfunction and will depend on the connected
TV.
To prevent this, you can change the input level.
1Press FUNCTION repeatedly until “TV”
appears in the front panel display.
2Press SYSTEM MENU.
Stop play and remove the
disc
Zon the remote or A
on the unit.
Replay the previous scene* (instant
replay) during
playback.
Briefly fast forward the
current scene**
(instant
advance) during
playback.
To Press Enjoying the Radio or
Other Components
FUNCTION
SYSTEM
MENU
X/x/c,
cont
i
nue
d

20GB
Basic Operations
3Press X/xrepeatedly until
“ATTENUATE” appears in the front
panel display, then press or c.
4Press X/xto select a setting.
The default setting is underlined.
• “ATT ON”: attenuates the input level.
The output level is changed.
• “ATT OFF”: normal input level.
5Press .
The setting is made.
6Press SYSTEM MENU.
The system menu turns off.
You can enjoy TV sound from all the speakers in
this system.
For details, see “Step 1: Connecting the System
and TV” (page 9).
1Press FUNCTION repeatedly until “TV”
appears in the front panel display.
2Press SOUND FIELD repeatedly until
the sound field you want appears in the
front panel display.
When you want to output the TV sound or
stereo sound of a 2 channel source from the
6 speakers, select the “PRO LOGIC,” “PLII
MOVIE,” or “PLII MUSIC” sound field.
For details of sound field, see page 22.
Enjoying TV Sound from All
Speakers
SOUND
FIELD
FUNCTION
