Sony HT-6500DP User manual

IN OUT IN
CD MD/TAPE
R
L
CENTERSURROUND
RL
RL
SPEAKERSSPEAKERS
IMPEDANCE USE 8 – 16 Ω IMPEDANCE USE 8 – 16 Ω
ANTENNA
AM
FM
75
Ω
COAXIAL
DVD/LD
IN
COAXIAL
AUDIO IN AUDIO IN AUDIO OUT
AUDIO OUT
AUDIO IN
VIDEO 1
VIDEO IN VIDEO IN VIDEO OUT VIDEO IN VIDEO OUT
DVD / LD
MONITOR
VIDEO 2
SUB
WOOFER
OPTICAL
VIDEO 2
IN
DIGITAL
FRONT
RL
RL
AUDIO
INPUT COMPONENT
VIDEO
VIDEO IN
SUB
WOOFER
FRONT SURROUND
R
L
CENTER
MULTI CH IN
INPUT
HT-6500DP
HOME THEATER SYSTEM
Speakers – Connection and Installation
4-239-992-31(2)
Front speaker
SS-MSP2
Front speaker
SS-MSP2
Center speaker
SS-CNP2
Surround
speaker
SS-MSP2
Surround
speaker
SS-MSP2
Subwoofer
SA-WMSP4
DVP-NC655P
Sony Corporation 2002 Printed in Malaysia
STR-K840P
Speaker installation
For best performance, we recommend speaker placement as shown.
See the Operating Instructions for more information.
For greater flexibility in the positioning of the speakers, use the optional WS-FV10C floor stand
(available only in certain countries).
Center speaker
Place on the top of or below the TV.
Surround speakers
Place right beside or slightly behind your
listening position, and a little higher than
your ears.
B
C
DD
Subwoofer
Can be placed anywhere.
Front speakers
Place on both sides of the TV equal distances
apart.
A
A
A A
TV monitor
COMPONENT VIDEO HOOKUP
If your TV monitor have COMPONENT VIDEO INPUT jacks, use a component video cord to connect to the
DVD player (DVP-NC655P) for better picture quality.
When you make the component video hookup
• Set SCAN SELECT on the DVD player to “PROGRESSIVE”.
• Set your TV’s video input to match your selection.
• You do not have to connect the LINE OUT VIDEO 1 jack (on DVD player) to the DVD/LD VIDEO 1 jack (on receiver).
