Sony HT-SS360 User manual

HT-SS360
Blu - ray Disc ™Player Matching Component Home Theater System
Key Features
Slim Receiver Design to Match Blu -ray Disc™
Player (sold separately)
A/V Receiver with HDMI ™ Active Intelligence (3
In/1 Out)
5.1 Channel Home Theater System
Accepts 1080p signal and Linear PCM via
HDMI™
DIGITAL MEDIA PORT
3
1000W RMS Rating (1KHz,<10%THD)
Digital Cinema Auto Calibration (Mono Mic
Included)
5 Speakers + Passive Sub
Key Technologies
3 HDMI™ inputs Offers simple solution for consumers to access and connect HD sources. Gives
consumer the ability to use one cable connection to included A/V receiver and then only one HDMI
cable to the TV
Cosmetic match to Sony Blu- ray Disc ™ players Slim appearance and cosmetic coloring
represents the products go together
HDMI™ Active Intelligence The receiver detects and receives the best possible video and audio
signals from all connected devices; making connection and performance as simple as plugging in
a single wire. Sony's HDMI Active Intelligence
1080p output via HDMI™ Supports any 1080p video signal transferred though the audio system to
the TV.
LPCM 8 ch uncompressed audio Full resolution audio is supported with this system. The Blu - ray
Disc player can decode the audio information and send to system, the system can play the full
bandwidth requirements from the Blu - ray Disc player/movie
DIGITAL MEDIA PORT Play and control your favorite stored music seamlessly from your home
theater system. Connect accessories to play back music from Bluetooth - enabled mobile phones,
networked computers or select iPod ® or Walkman™digital music players (optional accessories sold
separately). The DMP accessories include a PC Client Ready device (TDM - NC1), Bluetooth ® receiver
(TDM - BT1) and Docking Stations compatible with select Network Walkman™players (TDM - NW1) and
iPod ® products (TDM - iP10).
3
1
3
1000W RMS Rating (1KHz,<10%THD) Enough power to get the most from the included speakers
and subwoofer

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 10/09/2009
HT-SS360
Blu - ray Disc ™Player Matching Component Home Theater System
Please visit the Dealer Network for current
information at www.sony.com/dn
Features
General
Convenience
Digital Cinema Auto Calibration: Yes
HDMI™ActiveIntelligence: Yes
AM/FM Memory Presets: 20 FM 10 AM
Receiver
Audio
Dolby ® DigitalDecoding: Yes
Dolby ® Pro Logic ® IIDecoding: Yes
dts ® - ES Decoding: no
DigitalAmplifier: Yes (S - Master ® Digital
Amplifier)
96k/24bitPCM: Yes
LPCM: 2CH/5.1CH thru HDMI™
AudioModes: 11 (2 Movie, 3 Music, 5
A.F.D., 1 2ch)
Dolby ® Pro Logic ® Decoding: yes
dts ® Decoding: Yes
Dolby ® Digital EX Decoding: no
Specifications
General
Audio
Channel Power Rating: 5.1 Channel
SoundEnhancer: Yes (Portable Audio
Enhancer)
Inputs and Outputs
HDMI™ConnectionInput(s): Yes
Service and Warranty Information
LimitedWarranty: 1 year parts / 1 year
labor
Amplifier
Inputs and Outputs
Digital Media Port (Input): Yes
Receiver
Audio
Audio Power Output: 1000W (143w x 5 +
285w (1KHz, 10% THD))
Impedance: 3 ohms
Inputs and Outputs
Analog Audio Input(s): 3 (Rear)
Coaxial Audio Digital Input(s): 1 (Rear)
Optical Audio Input(s): 2 (Rear)
HDMI™ConnectionInput(s): 3 (Rear) up
to 1080/24p
HDMI™ConnectionOutput(s): 1 (Rear) up
to 1080/24p
Digital Media Port (Input): 1 (Rear)
3
Power
PowerRequirements: AC 120V, 60 Hz
Power Consumption (in Operation): 165W
Power Consumption (in Standby): 0.3W
Weights and Measurements
Dimensions(Approx.): 17 ” x 2.6 ”
x13.1" (430 x 66.5 x 333mm)
Weight(Approx.): 7.5 lbs (3.4kg)
Tuner
Audio
Tuner Frequency Range: AM: 530 - 1,710 kHz,
FM: 87.5 - 108.0 MHz
TunerType: AM, FM
Inputs and Outputs
Antenna Terminal (AM Loop): Yes
Antenna Terminal (FM 75 Ohm): Yes
Center Speaker
Speaker
SpeakerType: Enclosure - Bass Reflex
SpeakerSystem: bass reflex
Weights and Measurements
Dimensions(Approx.): 15 x 2 x 2 5/8 (with
foot) (380 x 50 x64mm)
Weight(Approx.): 0 lb 14oz (.38kg)
Front Speaker
Speaker
SpeakerType: Enclosure - Bass Reflex
SpeakerUnit: Magnetically Shielded
SpeakerSystem: bass reflex
Weights and Measurements
Dimensions(Approx.): 4 1/8 x 6 1/2 x 3
1/8 (with foot) (102 x 163 x 77mm)
Weight(Approx.): 1lb 32oz (.52kg)
Surround Speaker
Speaker
SpeakerType: Enclosure - Bass Reflex
Weights and Measurements
Dimensions(Approx.): 4 1/8 x 6 1/2 x 3
1/8 (with foot) (102 x 163 x 77mm)
Weight(Approx.): 1lb 32oz (.52kg)
Subwoofer Speaker
Speaker
SpeakerUnit: Magnetically Shielded
SpeakerType: Enclosure - Bass Reflex
SpeakerDimensions: 6 3/8" (160mm)
Weights and Measurements
Dimensions(Approx.): 8 3/4 x 16 5/8 x 12
7/8 (with foot) (220 x 395 x 325mm)
Weight(Approx.): 12lb 6oz (5.6kg)
Supplied Accessories
Remote (RM - AAU057)
Speaker Cable (3m x 2) (10m x 2) (3m x 1)
(2m x 1)
Waranty Card
Users Guide
FM Wire Antenna
AM Loop Antenna
Microphone (EMC - AC2)
Color: Black
UPC Code: 027242753938
1.iPodsupportislimitedbaseduponwhichoptionalDigitalMediaPortis
being used. The TDM - IP20willsupportthefollowingplayers:iPodtouch,
iPodclassic,iPodNano1st,2nd&3rdgeneration,iPod4th&5th
generation&iPodMini.TheTDM - IP 50 adds iPhone support as well.
2.WorkswithBRAVIA®SyncTMorTheatreSyncTM labeledhome
audio/videoproducts when connected via HDMI.
3.RequiresDigitalMedia Port accessory compatible withthedevice
(sold separately).
©2009SonyElectronicsInc.All rights reserved.
Reproductioninwholeorin part without written permission isprohibited.
Sony,BRAVIA,DigitalCinema Sound, Bravia Sync, and "like.no.other"are
trademarksofSony.Blu - rayDiscis atrademark.Dolby,Dolby Digital,
ProLogicareregisteredtrademarksof Dolby Laboratories. dts is a
trademarkofDigitalTheaterSystems,L.P. HDMI, the HMDI logo and High -
DefinitionMultimediaInterface aretrademarksorregistered trademarks
ofHDMILicensingLLC.Bluetoothisa Tradmarke of Bluetooth SIG. All other
trademarksarepropertyoftheir respective owners.
Features and specifications are subject to change without notice. Non -
metricweights and measures are approximate.
