Sony BX Series Installation instructions

BX Series
Confidential
Chapter 1. Disassembly & Assembly Guide
1.MS-1-D.1
1-3. Disassembly & Assembly
- Main Section -
MS-1 Main Section Disassembly

BX Series
Confidential
Battery Pack
1)
1.MS-1-D.2
Slide the Release Lever to the right side,
and turn over the Battery Pack to the rear side then remove it.
Battery Pack
2)
Slide the Lock Lever to the UNLOCK side.
Lock Lever Release Lever

BX Series
Confidential
HDD
1) 2)
1.MS-1-D.3
Remove the HDD.Remove the screw.
HDD
Screw:B20

BX Series
Confidential
Parts of the HDD
1)
1.MS-1-D.4
2)
Remove the three screws, and remove the HDD from the Holder (HDD).
HDD
Remove the Door (HDD) while disengaging the detent (two places).
Door (HDD)
Screw:B13 Insulator (HDD)
Peel off the Insulator (HDD).
3)
Holder (HDD)
Holder (HDD)

BX Series
Confidential
Cover (Memory), Memory
1)
1.MS-1-D.5
Remove the screw.
Screw:B7
Remove the Cover (Memory) while disengaging the detent (two places).
2)
3)
Outspread the tabs (arrow 1), and pull out the Memory diagonally upward
(arrow 2).
*When two Memory are installed, remove the other side of the Memory in
the way as above.
12
Memory
1

BX Series
Confidential
Optical Disc Drive, Screws
1.MS-1-D.6
Remove the 12 screws.
2)
Remark Screw:B19
(Special screw)
1)
Push the lever once and pull out it in the direction
of the arrow, then remove the Optical Disc Drive.
Lever
Optical Disc Drive
Screw: Red-B2 / Blue-B11 / Green-B5
When there is a screw in the position of figure, remove
the Optical Disk Drive after removing the screw.

BX Series
Confidential
Hood (Keyboard)
1) 2)
1.MS-1-D.7
3)
Peel off the Rubber (Screw) (two places). Remove the two screws.
Keyboard Keyboard
Turn over the Hood (Keyboard) to the rear side.
* The detents (10 places) are engaged.
Hood (Keyboard)
Disconnect the FFC and the Harness.
*FFC --- Slide the lock lever upward and release the lock.
Harness --- Pull out it upward.
4)
FFC
Harness
Screw:B3
Rubber (Screw)

BX Series
Confidential
Parts of the Hood (Keyboard) -1
1) 2)
1.MS-1-D.8
3)
Disconnect the FFC (two places).
*Slide the lock lever in the direction of the arrow, and release the lock.
Remove the four screws and the SWX Board. Disconnect the Harness.
4)
SWX Board
Screw: B4
FFC
Harness
Kapton Tape
1st Model
Kapton Tape 4[MA]
Peel off the Kapton Tape.
*1st Model --- Five places
Other --- One place

BX Series
Confidential
Parts of the Hood (Keyboard) -2
5) 6)
1.MS-1-D.9
Disconnect the FFC.
*Slide the lock lever in the direction of the arrow and release the lock.
Remove the two screws and the SWX Board.
SWX Board
Screw: B4
Remove the two screws and the IFX Board.
IFX Board
Screw: B11
FFC
7)
The FFC is secured with double side tape (two places).
Remark
2nd Model
4[MA]
FFCDouble Side Tape

BX Series
Confidential
Keyboard -1
1)
1.MS-1-D.10
Release the Harness from the detent (five places). Remove the three screws.
Screw: B5
Release the rib (two places) by sliding the Keyboard in the direction of
the arrow 1, and lift it from the front side lightly.
*Notice : The FPC coming from the Keyboard is connected with
Mother Board.
3) 4)
2)
Camera Model
Harness
FPC
Keyboard
Rib
Rib
1
2
FPC
Slide the lock lever in the direction of the arrow
and release the lock, then disconnect the FPC.

BX Series
Confidential
Keyboard -2
5)
1.MS-1-D.11
Turn over the Keyboard to the front side, and disconnect the FPC.
*Slide the lock lever upward and release the lock.
FPC
Lock Lever

BX Series
Confidential
LCD Section -1
1)
1.MS-1-D.12
Remove the one screw.
* It secures the lug terminal.
Lug Terminal
Peel off the Kapton Tape.
*1st Model --- Three places
2nd Model --- Two places
Kapton Tape
1st Model 4[MA] 2nd Model
Kapton (FPC)
2)
Screw: 1st Model - B4
2nd Model - B3
4[MA]

BX Series
Confidential
LCD Section -2
5)
1.MS-1-D.13
Disconnect the Harness upward and release it from
the detent (four places).
3)
Disconnect the Harness upward.
Camera Model Harness Camera Model
4)
Harness
6)
Peel off the Kapton Tape.
Kapton Tape
Disconnect the Coaxial Cable (two places).
* Disconnect it vertically.
Coaxial Cable
1st Model 2nd Model
4[MA]
1st (Camera) Model
4[MA]

BX Series
Confidential
LCD Section -3
8)
1.MS-1-D.13(a)
AL Foil (Hinge)
1st (WAN (EXT)) Model
7)
4[MA]
4[MA]
Remove the four screws and LCD Section.
Screw: B21
LCD Section
Peel off the AL Foil (Hinge).

BX Series
Confidential
1)
1.MS-1-D.14
Remove the Bracket (KB EX).
Bracket (KB EX)
Bracket (KB EX)
2)
Remove the screws.
*1st Model --- 8 places
2nd Model --- 12 places
1st Model 2nd Model
4[MA]
Screw: Red: 1st Model - B8
2nd Model - B30
Blue-B3
Green: 1st Model - B2
2nd Model - B31

BX Series
Confidential
Palmrest
1)
1.MS-1-D.15
Harness
Turn over the Palmrest to the front side lightly
and disconnect the Harness (one place) vertically.
Disconnect the FFC.
Then remove the Palmrest.
2)
3)
Bluetooth Model
Felica Model
FFC
Turn over the Palmrest to the front side lightly and slide the lock lever
upward to release the lock. And then Disconnect the FFC.
4)
Remove the three screws.
FFC
Palmrest
Screw: 1st Model - B10
2nd Model - B31
4[MA]

BX Series
Confidential
1.MS-1-D.16
2)
Remove the screws.
*INT Model --- Three places
EXT Model --- Five places
Heatsink
Screw: Red-B3 /
Blue-B8
INT Model
EXT Model
3)
Sheet (AL-Bracket Bay)
Peel off the Sheet (AL-Bracket Bay).
Heatsink -1
1) 1st Model
4[MA]
Heatsink
Harness
Disconnect the Harness.
2nd Model
4[MA]
4[MA]
1st Model 4[MA]
4)
4[MA]
Remove the screws.
*INT Model --- Four places
EXT Model --- Five places
Heatsink
Screw: Red-B3 /
Blue-B30
INT Model
EXT Model
2nd Model

BX Series
Confidential
Heatsink -2
1.MS-1-D.16(a) 4[MA]
5) 1st (EXT) Model
Harness
Heatsink
4[MA]
Disconnect the Harness.
6)
Heatsink
2
1
Lift the right side of the Heatsink and remove it in the direction
of the arrow 2.

BX Series
Confidential
Fan
1.MS-1-D.17
Remove the two screws.
*Use a 4 mm socket wrench for B15.
1)
Fan
Remove the Fan.
2)
Harness
Disconnect the Harness.
3)
Screw: Red-B15 / Blue-B24
[CHG]
3
1st (INT) Model
[MA]

BX Series
Confidential
PC Card Connector, Guide (HDD)
1)
1.MS-1-D.18
2)
Screw:B10
Remove the three screws and the Guide (HDD).
Guide (HDD)
Remove the screws, and remove the PC Card Connector
while disconnecting the connector.
* 1st (INT) Model --- Two places
Other --- One place
3)
Remove the two screws, and remove the Sink (Choke).
Screw:B3
2nd Model
4[MA]
Sink (Choke)
PC Card Connector
Connector
1st (INT) Model
Screw: 1st Model - B8
2nd Model - B30
4[MA]
4[MA]
