Sony PCG-GRX520 User manual

Confidential
SERVICE MANUAL
NOTEBOOK COMPUTER
9-874-542-02
For American Area
US Model
Canadian Model
• Design and specifications are subject to
change without notice.
PCG-GRX520/GRX520K/GRX520P/GRX560/GRX560K/
PCG-GRX560P/GRX580/GRX580K/GRX580P/GRX650
Lineup : PCG-GRX580P
PCG-GRX580K
PCG-GRX580
PCG-GRX560P
PCG-GRX560K
PCG-GRX560
PCG-GRX520P
PCG-GRX520K
PCG-GRX520
PCG-GRX650
S400
Ver 2-2002I
Revision History
Illust : PCG-GRX580P

— 2 —
Information in this document is subject to change without notice.
Sony, VAIO and CLIE are trademarks or registered trademarks of
Sony. Microsoft, Windows, Windows Media, Outlook, Bookshelf
and other Microsoft products are trademarks or registered trademarks
of Microsoft Corporation in the United States and other countries.
The word Bluetooth and the Bluetooth logo are trademarks of
Bluetooth SIG, Inc. AMD, AMD logo, AMD Duron and
combinations thereof, 3DNow!, are trademarks of Advanced Micro
Devices, Inc. Intel Inside logo, Pentium and Celeron are trademarks
or registered trademarks of Intel Corporation. Transmeta, the
Transmeta logo, Crusoe Processor, the Crusoe logo and
combinations thereof are trademarks of Transmeta Corporation in
the USA and other countries. Graffiti, HotSync, PalmModem, and
Palm OS are resistered trademarks, and the Hotsync logo and Palm
are trademarks of Palm, Inc. or its subsidiaries. (M) and Motrola
are trademarks of Motrora, Inc. Other Motrola products and services
with (R) mark like Dragomball are the trademarks of Motrola, Inc.
All other names of systems, products and services in this manual
are trademarks or registered trademarks of their respective owners.
In this manual, the (TM) or (R) mark are not specified.
Service and Inspection Precautions
1. Obey precautionary markings and instructions
Labels and stamps on the cabinet, chassis, and components identify areas
requiring special precautions. Be sure to observe these precautions, as well
as all precautions listed in the operating manual and other associated
documents.
2. Use designated parts only
The set’s components possess important safety characteristics, such as
noncombustibility and the ability to tolerate large voltages. Be sure that
replacement parts possess the same safety characteristics as the originals.
Also remember that the 0mark, which appears in circuit diagrams and
parts lists, denotes components that have particularly important safety
functions; be extra sure to use only the designated components.
3. Always follow the original design when mounting
parts and routing wires
The original layout includes various safety features, such as inclusion of
insulating materials (tubes and tape) and the mounting of parts above the
printer board. In addition, internal wiring has been routed and clamped so
as to keep it away from hot or high-voltage parts. When mounting parts or
routing wires, therefore, be sure to duplicate the original layout.
4. Inspect after completing service
After servicing, inspect to make sure that all screws, components, and wiring
have been returned to their original condition. Also check the area around
the repair location to ensure that repair work has caused no damage, and
confirm safety.
5. When replacing chip components...
Never reuse components. Also remember that the negative side of tantalum
capacitors is easily damaged by heat.
6. When handling flexible print boards...
• The temperature of the soldering-iron tip should be about 270C.
• Do not apply the tip more than three times to the same pattern.
• Handle patterns with care; never apply force.
Caution: Remember that hard disk drives are easily damaged by
vibration. Always handle with care.
Caution Markings for Lithium/Ion Battery - The following or similar
texts shall be provided on battery pack of equipment or in both the
operating and the service instructions.
CAUTION: Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by
the manufacturer. Discard used batteries according to the
manufacturer’s instructions.
CAUTION: The battery pack used in this device may present a fire
or chemical burn hazard if mistreated. Do not disassemble, heat
above 100°C (212°F) or incinerate.
Dispose of used battery promptly.
Keep away from children.
CAUTION: Changing the back up battery.
• Overcharging, short circuiting, reverse charging, multilation or
incineration of the cells must be avoided to prevent one or more of
the following occurrences; release of toxic materials, release of
hydrogen and/or oxygen gas, rise in surface temperature.
• If a cell has leaked or vented, it should be replaced immediately
while avoiding to touch it without any protection.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFÉS PAR UNE MARQUE 0SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT
CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE
REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY
DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU
DANS LES SUPPÉMENTS PUBLIÉS PAR SONY.
Confidential
PCG-GRX520/GRX520K/GRX520P/
PCG-GRX560/GRX560K/GRX560P/
PCG-GRX580/GRX580K/GRX580P/GRX650 (AM)

—3 —
TABLE OF CONTENTS
CHAPTER 1. BLOCK DIAGRAM ............................... 1-1
(to 1-2)
CHAPTER 2. FRAME HARNESS DIAGRAM ........ 2-1
(to 2-2)
CHAPTER 3. EXPLODED VIEWS AND
PARTS LIST............................................ 3-1
3-1. Main Section .................................................................... 3-3
3-2. LCD Section (GRX560/GRX560K/RX560P/GRX580/
GRX580K/GRX580P/GRX650) –Made by HI –........... 3-7
3-3. LCD Section
(GRX520/GRX520K/GRX520P) –Made by HI–........... 3-9
3-4. Connector Section (CH Type only) ............................... 3-11
(to 3-12)
CHAPTER 4. OTHERS
4-1. Replacing the CPU .......................................................... 4-1
1. Removing the CPU .......................................................... 4-1
2. Installing the CPU ............................................................ 4-1
Section Title Page
Confidential
History of the changes is shown as the
“Revision History”at the end of this data.
PCG-GRX520/GRX520K/GRX520P/
PCG-GRX560/GRX560K/GRX560P/
PCG-GRX580/GRX580K/GRX580P/GRX650 (AM)

Confidential
PCG-GRX520/GRX520K/GRX520P/
PCG-GRX560/GRX560K/GRX560P/
PCG-GRX580/GRX580K/GRX580P/GRX650 (AM)
(END)
1-21-1
CHAPTER 1.
BLOCK DIAGRAM
Video Memory
K4D623238B
x 2pcs
Video Memory
K4D623238B
x 2pcs
Memory
CONTROLLER
HUB (MCH)
593 FCBGA
Memory
CONTROLLER
HUB (MCH)
593 FCBGA
IO Control Hub
ICH3-m
FW82801CAM
IO Control Hub
ICH3-m
FW82801CAM
Internal
HDD
PCG-GRX Series BLOCK DIAGRAM Rev.0.10
PHONE
OUT
RJ11
MIC
IN
RJ45
MS
CONN
Pentium 4
Processor
512KB L2
478pins
uFCPGA
Pentium 4
Processor
512KB L2
478pins
uFCPGA
PCI BUS(3.3V)
AGP x 4
266MHz Memory Bus
(DDR)
CardBus/16bitCard
PC Card
Connector
2 Slot
H8S/2149
KBC/EC
SPIC
H8S/2149
KBC/EC
SPIC
Graphics
M7-P
(ATI)
Graphics
M7-P
(ATI)
LCD CONN
Cable
Ether
PHY
Ether
PHY
Internal KeyBoard
Membra ne
JOG
Controller
JOG
Controller
VGA DSUB-15
LPC
Memory
Stick
Module
Memory
Stick
Module
i.LINK0
AC LINK
Headphone
MIC
Speaker
Speaker
L&R
Super I/O
SMsC
LPC47N227
Super I/O
SMsC
LPC47N227
I/O Expander
& SMBUS MUX
I/O Expander
& SMBUS MUX
LID
Seri al
Parallel
Refer to Clock Generator
Block Diagram
SMBUS2
USB Right
CONN
TouchPad JOG
EEPROM
EEPROM
For VID
EEPROM
EEPROM
For i.LINK
MDC
(Modem
Daughter
Card)
Module
MDC
(Modem
Daughter Card)
Module
CPU Local Bus
EEPROM
EEPROM
For Password
USB Left
CONN
USB Rear
CONN i.LINK
Dock-VGA D B-15
Dock-VGA D B-15
Seri al
Parallele
RJ-45
RJ45
VGA
DB-15
Video-
Out
USB
CONN
USB
CONN
LineOut
Port0-5
Optical
Drive
Primary
Secondary
IDE(ATA100)
AMP, etc.
Line Out
RJ-45
RJ-45
Parallel
PS/2
CLKGEN
IMI
9870GTD Port Repricator
Parallel
Parallele
i.LINK0
Port-4
Port-0
Port-3
Port-2
Port-1
Port-5
RJ-45
RJ-11
RJ-11
1st
Battery
Power
Circuit
Power
Circuit
DC Jack
DDR(SO-DIMM)
SMBUS2
SMBUS2
SMBUS1
SMBUS0
PS/2
Reserved
Reserved
Port-3
Port-2
DC Jack
Serial
DCin
DCin
BATTERY1 BATTERY2
BATTERY1
2nd
Battery
BATTERY2
FAN0 AT F0
FAN1 AT F1
PS/2
Other
Control
DDR(SDRAM)
FWH
8Mb
(Flash BIOS
ROM)
FWH
8Mb
(Flash BIOS
ROM)
Multi PurposeBay
LINE-OUT
AV
Out
Audio-Out
S-Video-Out
Audio
L-out
Audio
R-out
TV-O ut
TV-O ut
S-Video-Out
TV-O ut
USB3
USB2
USB3
USB2
Audio
YMF753
(Yamaha)
Audio
YMF753
(Yamaha)
SONY
TV-O ut
CARDBUS
& i.LINK
RICOH
R5C552
CARDBUS
& i.LINK
RICOH
R5C552
Bus #2 Dev #5
EEPROM
EEPROM
For LAN
EEPROM
EEPROM
For Clock GEN
EEPROM
On DIMM1
EEPROM
On DIMM1
For SPD
EEPROM
On DIMM2
EEPROM
On DIMM2
For SPD
16inch UXGA
15inch XGA

Confidential
PCG-GRX520/GRX520K/GRX520P/
PCG-GRX560/GRX560K/GRX560P/
PCG-GRX580/GRX580K/GRX580P/GRX650 (AM)
2-22-1
CHAPTER 2.
FRAME HARNESS DIAGRAM
CN8001
39
40
1
2
CN8402
IEEE 1394 i.LINK
CPU
PWS-17 Board
(Side-B)
BATTERY PACK
CN8401
2nd BATTERY PACK
(OPTION)
From board to connector (direct connection)
Harness (connector at both end)
Harness (soldered at one end)
Connectors soldered on board and appearing on the panel
PHONE PRINTER NETWORK MONITOR DC-INUSB
AV OUT
HARD DISK
44
1 2
13 14
2
43
1
CN2201
CN1126
PC CARD
CONNECTOR
CN1202
CN8002
77 1
78
154
139
40
2
CN7501
CN7001
CN7002
CN4001
2 1
50 49
60 59
2 1
CN2301
Combination
DRIVE
CNX-161 Board
(Side-A)
LEX-34 Board
(Side-A)
SWX-91 Board
(Side-A)
SWX-90 Board (JP Type)
SWX-111 Board (CH Type)
(Side-A)
IFX-193 Board
(Side-A)
CNX-158 Board
(Side-A)
CNX-159 Board
(Side-A)
CNX-157 Board
(Side-A)
CN7502
59 60
1 2
114
12
112 1 12
21
22
1
2
CN3102
CN1601
1
1
2
2
29
30
MODEM
CARD
J1
1
2
29
30
CN1301 CN851
CN855
CN1111
CN1501
CN3501
CN2005
CN2007
CN101
21
NICKEL HYDROGEN
BATTERY
CN3101
CN852
228
27
1
CN3004
120 2
1
119
CN1401
11 1
2
12
CN1124
11 1
21
2
12
112
1
120
12
CN2001
CN5001
HARNESS (2P)
CN5602
CN5603
CN5601
MBX-65 Board
(Side-A)
199
200
1
24 1
31
42
14 2 13 1
10 1
10 1
114
1
1
2
19
20 199
2
2 200
CN501
CN6002
CN6001
CN4691
CN4602
CN502
CN3103
CN1901
CN853
CN2901
99
100
1
2
PCGA-PRGX1
Port Replicator
FFC
CN5530 CN5510CN5540
114
CN5500
FFC
USB
EXTERNAL
MICROPHONE
HEADPHONE
USB
LCD HARNESS
INVERTER
LCD
21
SPEAKER
MEMORY
STICK
L Side
L Side
R Side
CN4601
RAM
RAM
DDR266 SO-DIMM
256MB
DDR266 SO-DIMM
256MB
KEY BOARD
Rear Panel
121
TOUCH PAD
J1
DC FAN
2nd FAN
JOG DIAL
CN2009
(END)

Confidential
PCG-GRX520/GRX520K/GRX520P/
PCG-GRX560/GRX560K/GRX560P/
PCG-GRX580/GRX580K/GRX580P/GRX650 (AM)
CHAPTER 3.
EXPLODED VIEWS AND PARTS LIST
NOTE:
•The mechanical parts with no reference number in the
exploded views are not supplied.
•Items marked “*”are not stocked since they are seldom
required for routine service. Some delay should be
anticipated when ordering these items.
•When two or more parts are shown in parallel, use the
part described first as the main part.
•The indication [CH] is used for identification of part type.
•Regarding the boards of this model, the discrete parts
on the boards cannot be replaced. However, Some
connectors can be replaced.
The components identified by mark 0or
dotted line with mark 0are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
How to use properly the repair parts.
There are some parts that use the 2 types ; the [CH] parts or alternately the [JP] parts, in this series.
Use the [CH] repair parts for the [CH] type product, vice versa.
[ How to identify the parts ]
[ Repair part description example ]
Ref.No. Part No. Description
999 A-8110-582-A [CH]...MBX-65 ASSY (C) (S)
999 4-8067-424-A [JP]...MBX-65 ASSY (S)
∗About Repair level of mounted board.
JP type... Component level service is possible. Refer to this manual for details.
CH type... Do not execute the component level service in principle.
However, some of the connectors can be repaired by the component level service.
Refer to “Connector Section”of this manual for details.
A-xxx-xxx-A x xxxxxxxxx
Serial No.
2DIMM Door
1M2X4
Special Head (Black)
Identfication Seal
1 : Using [JP] type
6 : Using [CH] type
Identification seal is attached on the
expansion memory connector.
3-1 3-2

Confidential
PCG-GRX520/GRX520K/GRX520P/
PCG-GRX560/GRX560K/GRX560P/
PCG-GRX580/GRX580K/GRX580P/GRX650 (AM)
Ref.No. Part No. Description Ref.No. Part No. Description
3-1. Main Section
1 4-660-888-01 ESCUSHON TACHPAD
2 1-796-166-21 PAD, TOUCH
3 X-4624-531-4 ASSY PALMREST
4 4-660-904-01 CUSHION PALMREST
5 4-660-906-01 SPRING BLIND
6 4-660-906-11 SPRING BLIND
* 7 4-660-900-01 PLATE ARM LEFT
* 8 4-660-901-01 PLATE ARM RIGHT
9 1-761-518-11 PWB, FLEXIBLE PRINT
10 4-662-607-01 THERMAL SHEET FET
* 11 4-660-903-01 BRACKET TOUCHPAD
12 X-4624-620-2 ASSY BEZEL COMBO (CNC)
13 8-458-828-71 RW DRIVE CRX810E-VN
14 4-664-561-01 ADHESIVE TAPE
15 4-662-272-01 LAVEL COMBO DRIVE
16 4-654-837-01 SHEET BAY BOARD
17 A-8059-942-A [JP]...COMPLETE PWB CNX-161
17 A-8067-477-A [CH]...CNX-161 ASSY (C) (S)
18 4-660-860-03 CASE BAY
19 X-4624-533-2 ASSY PLATE KEYBOARD
20 X-4624-528-1 ASSY BRACKET BAY
21 1-823-721-12 CABLE, FLEXIBLE FLAT
22 4-661-289-01 INSULATOR PWS
23 A-8059-944-A [JP]...COMPLETE PWB PWS-17
23 A-8067-479-A [CH]...PWS-17 ASSY (C) (S)
24 1-815-594-21 CONNECTOR, PC CARD(EJECT,RIGHT)
25 4-660-831-01 INSULATOR PCMCIA
26 1-761-380-23 CARD, MODEM
27 1-761-519-11 PWB, FLEXIBLE PRINT
* 28 4-660-852-02 HEATSINK GHC
* 29 1-763-828-11 2ND FAN
30 4-660-836-01 THERMAL SHEET GHC
31 1-756-281-11 BATTERY, NICKEL HYDROGEN
32 4-642-711-01 SHEET (BATTERY), ADHESIVE
33 4-660-835-01 THERMAL SHEET CPU
34 6-702-112-01 (GRX580/GRX580P/GRX580K)...
IC RH80532GC029512 (P4 1700MHz)
34 6-702-111-01 (GRX520/GRX520P/GRX520K/
GRX560/GRX560P/GRX560K)...
IC RH80532GC025512 (P4 1600MHz)
34 6-702-580-01 (GRX650)...
IC RH80532GC033512 (P4 1800MHz)
35 1-960-827-61 HARNESS (2 PIN)
36 A-8059-939-A [JP]...COMPLETE PWB CNX-157
36 A-8067-474-A [CH]...CNX-157 ASSY (C) (S)
37 4-660-876-01 PLATE DC JACK
38 4-660-853-01 THERMAL FIN
* 39 1-763-829-11 CPU FAN
40 4-660-796-01 THERMAL SHEET COIL
41 4-660-445-02 BRACKET BATTERY
* 42 X-4624-936-1 ASSY (SUBFRAME) (BOTTOM) (RIGHT)
43 A-8059-940-A [JP]...COMPLETE PWB CNX-158
43 A-8067-475-A [CH]...CNX-158 ASSY (C) (S)
44 4-660-823-02 BRACKET DOOR R
45 4-661-272-02 INSULATOR BOARD AUDIO
* 46 4-660-905-01 HOLDER HDD
* 47 4-660-451-01 PLATE GND HDD
48 4-663-115-01 FOOT REAR FIXED
49 4-660-861-02 DOOR BATTERY
50 4-660-443-01 SPRING DOOR BATTERY
51 4-660-862-21 DOOR DIMM
* 52 4-660-447-01 SUB-FRAME BATTERY
53 A-8059-943-A [JP]...COMPLETE PWB LEX-34
53 A-8067-480-A [CH]...LEX-34 ASSY (C) (S)
* 54 X-4624-529-2 [JP]...ASSY BRACKET IO
* 54 X-4624-902-1 [CH]...ASSY BRACKET IO
55 1-823-725-12 CABLE, FLEXIBLE FLAT
56 1-823-723-13 CABLE, FLEXIBLE FLAT
57 A-8059-945-A [JP]...COMPLETE PWB SWX-91
57 A-8067-478-A [CH]...SWX-91 ASSY (C) (S)
58 4-653-745-01 SPRING BAY
59 4-659-630-02 LATCH BAY
60 X-4624-530-2 ASSY DOOR MODEM
61 4-661-288-01 INSULATOR DOOR MODEM
* 62 4-660-448-01 SUB-FRAME BAY
63 X-4624-538-2 ASSY DOOR L
64 4-660-822-03 BRACKET DOOR L
65 4-660-452-01 HINGE BASE LEFT
66 4-660-872-01 INSULATOR HEATSINK BOTTOM
67 A-8059-941-A [JP]...COMPLETE PWB CNX-159
67 A-8067-476-A [CH]...CNX-159 ASSY (C) (S)
68 4-660-544-02 CAP MODEM
69 4-660-864-02 DOOR IO
70 4-660-874-01 LABELIO
71 1-823-724-12 CABLE, FLEXIBLE FLAT
72 4-660-887-02 DISPLAY BASE
73 1-477-285-21 KEYBOARD UNIT (U)
74 X-4624-605-4 ASSY HOOD KEYBOARD
75 1-825-081-11 SPEAKER, (2.8CM) BOX WITH
76 1-823-719-12 CABLE, FLEXIBLE FLAT
77 A-8059-936-A [JP]...COMPLETE PWB IFX-193
78 1-823-720-12 CABLE, FLEXIBLE FLAT
79 A-8059-934-A [JP]...COMPLETE PWB SWX-90
79 A-8110-249-A [CH]...COMPLETE PWB SWX-111A2
80 A-8059-666-A (GRX580/GRX580P/GRX580K)...
ASSY HDD 40GB (T,20,F) (S)
80 A-8059-344-A (GRX520/GRX520P/GRX520K/
GRX560/GRX560P/GRX560K/GRX650)...
ASSY HDD 30GB (T,20,F) (S)
* 81 4-653-799-02 BRACKET HDD
82 X-4624-536-2 ASSY DOOR HDD
83 4-653-801-02 SHEET HDD
84 X-4624-532-2 ASSY ESCUSHION JOG
85 X-4624-539-2 ASSY DOOR R
* 87 4-660-449-01 SUB-FRAME BOTTOM LEFT
88 6-600-080-01 IC M470L3224BT0-CB0
(DDR266 SO-DIMM 256MB)
88 6-600-093-01 IC HYMD232M6466-H
(DDR266 SO-DIMM 256MB)
89 4-662-961-01 SHEET BLIND L
90 4-654-953-01 SHEET PORT
91 4-662-926-02 INSULATOR HDD PWB
92 4-660-868-01 FOOT FRONT
93 X-4624-527-4 ASSY BOTTOM
94 4-660-866-02 DOOR PORT
95 4-662-798-01 PLATE GND PWS
96 A-8067-472-A [JP]...MBX-65 ASSY (S)
96 A-8067-473-A [CH]...MBX-65 (C) ASSY (S)
97 4-654-380-21 CAP BAY
98 4-664-333-01 CUSHEET DOOR R
99 4-664-547-01 SHEET FPC
100 4-664-632-01 SPACER K
105 4-664-561-01 ADHESIVE TAPE
110 1-793-365-11 [JP]...CONNECTOR, USB (A)
Ref.No. Part No. Description Ref.No. Part No. Description
111 1-793-162-11 [JP]...JACK, SMALL TYPE
112 1-695-514-21 [JP]...JACK (SMALL TYPE) 1P
113 1-779-745-21 [JP]...JACK, DC
114 1-815-221-22 [JP]...CONNECTOR, USB (A)
115 1-694-761-11 [JP]...JACK, SMALL TYPE
116 1-794-548-11 [JP]...CONNECTOR, USB(A)
117 4-662-984-01 INSULATOR DOOR DIMM
120 4-664-060-31 (GRX560P)...LABEL ID (U)
120 4-664-060-41 (GRX560)...LABEL ID (U)
120 4-664-060-51 (GRX560K)...LABEL ID (U)
120 4-664-060-61 (GRX520P)...LABEL ID (U)
120 4-664-060-71 (GRX520)...LABEL ID (U)
120 4-664-060-81 (GRX520K)...LABEL ID (U)
120 4-665-654-11 (GRX580P)...LABEL ID (U)
120 4-665-654-21 (GRX580)...LABEL ID (U)
120 4-665-654-31 (GRX580K)...LABEL ID (U)
120 4-665-654-51 (GRX650)...LABEL ID (U)
121 4-663-828-02 SPACER PC CARD
122 4-663-827-01 CUSHION KEYBOARD
126 4-663-230-02 CUSHION HOOD
127 4-663-227-01 CUSHION IO
128 4-664-048-01 INSULATOR FAN
129 4-664-308-02 SHEET JOG
130 4-655-927-03 SPRING (DVD-ROM)
131 4-664-285-01 CUSHION KEYBOARD R
132 4-661-644-01 SHEET, EYE CONVERTER
133 4-664-362-01 CUSHION IO LEFT
134 4-664-363-01 CUSHION SPRING BLIND R
135 4-664-482-01 SPACRER HINGE L
136 FILAMENT TAPE (W12X30) ( ∗1 )
138 4-665-909-01 INSULATOR BAY2
139 4-666-111-01 SHEET AUDIO GND
140 4-666-114-01 SHIELD TAPE BRACKET IO A
141 4-665-467-01 SPACER BATTERY (K)
∗1Use the FILAMENT TAPE.
3-3 3-4
B1 4-641-726-41 SCREW (M2), SPECIAL HEAD
B2 4-641-726-12 SCREW (M2), SPECIAL HEAD
B3 7-621-772-70 SCREW +B 2X14
B4 4-654-387-01 SCREW (MBX)
B5 4-641-656-12 SCREW (M2.5), 0 PLATE P
B6 4-656-703-01 SCREW M2
B7 4-635-301-01 SCREW M3X4
B8 4-639-112-01 SCREW M2X4
B9 4-635-966-01 SCREW (HEX)
B10 4-642-852-01 +B M2
B11 4-654-386-01 SPACER (PWS)
B12 7-622-205-05 NUT M2 TYPE2
B13 4-651-989-01 SPACER (MBX)
B14 4-661-248-01 SPACER 4MM
B15 4-641-726-81 SCREW (M2), SPECIAL HEAD
B16 4-654-811-01 SCREW M3
B17 4-657-192-01 SCREW, TAPPING, SPECIAL
The GRX650 uses only the [CH] Type parts and assemblies.
The [JP] Type parts and assemblies are not used.

Confidential
PCG-GRX520/GRX520K/GRX520P/
PCG-GRX560/GRX560K/GRX560P/
PCG-GRX580/GRX580K/GRX580P/GRX650 (AM)
3-5 3-6
A
I
A
BI
R
J
K
L
M
K
J
L
M
B
Q
C
R
U
S
T
Y
Y
W
W
X
X
C
E
D
E
F
G
H
H
F
N
D
G
N
O
P
O
O
Q
S
T
U
Supplied
with 3
Supplied
with 93
Supplied
with 60 Supplied
with 67
Supplied
with 43
1
2
3
4
4
5
6
7
8
9
11
12
13
16
17
130
18
15
19
89
20
99
21
22
23
24
25
26
27
29
128
28
30
31
32
33
34 35
36
133
138
127
37
38
39
40
41
139
B1
B2
B8
B8
B8
B8
B8
B7
B7
B16
B1
B1
B2
B2
B2
B2
B15
B2
B2
B2
B2
B2
B2
B6
B2
B2
B2
B2
B17
B17
B17
B17
B6
B2
B2
B2
B16
112
111
110
B16
116
B2
B1
B15
B2
B15
42 43
44 98
85
45
46
47
49
92
93
117
50
51
52
53
55
134
56
57
58
59
60
61
62
88
88
87
63
64
65
135
66
68 69
70
94
71
72
73
74 120
75
126
76
77
78
79
80
81
82
83
84
129
67
131
122
131
B3
B3
B1
14
B1
B1
B1
B1
B4
B1
95
B1
B14 B12
B11
90 10
91
B2
113
114
115
B1
B1
B2
B10
B1
B5
B1
B9
54
B13
B6 B12
B12
B1
B2
805
(Refer to page 3-10.)
132
96
140
126
97
Supplied
with 96
136
136
B2
B2
48
48
B2
100
100
121
105
141

Confidential
PCG-GRX520/GRX520K/GRX520P/
PCG-GRX560/GRX560K/GRX560P/
PCG-GRX580/GRX580K/GRX580P/GRX650 (AM)
Ref.No. Part No. Description Ref.No. Part No. Description
3-2. LCD Section (GRX560/GRX560K/GRX560P/GRX580/
GRX580K/GRX580P/GRX650) –Made by HI –
3-7 3-8
201 4-660-847-01 CAP LCD L
202 4-660-851-01 LCD SCREW COVER S
203 4-660-897-01 COVER HINGE
204 4-660-850-01 LCD SCREW COVER T
205 X-4624-525-3 ASSY BEZEL
206 4-660-846-02 LATCH RUBBER
207 A-8059-922-A ASSY LCD 16U (HI) (S)
* 208 4-660-839-02 BRACKET LCD L
* 209 4-660-840-02 BRACKET LCD R
210 1-961-573-12 HARNESS (LCD)
211 4-660-844-02 LATCH HOLDER LCD
212 4-660-828-01 LATCH GUIDE
213 4-660-907-01 LATCH_BOTTON
214 4-660-843-02 LATCH LEVER
215 1-477-101-11 INVERTER UNIT
216 4-663-929-02 SPRING (LCD) (16)
217 4-663-477-02 SPACER LATCH
* 218 X-4624-534-2 ASSY HINGE L
219 X-4624-847-1 ASSY DISPLAY (F)
220 4-660-849-02 CAP LCD C
* 221 X-4624-535-2 ASSY HINGE R
222 4-662-783-03 INSULATOR INVERTER
223 4-660-848-01 CAP LCD R
224 FILAMENT TAPE (W19X50) ( ∗1 )
225 4-664-545-01 SPACER (HINGE) (16) (R)
226 4-664-314-01 SHEET (LCD) (BEZEL UP)
227 4-664-062-01 SHEET LCD LATCH
∗1Use the FILAMENT TAPE.
201
B
B
A
D
E
A
D
E
202
202
B19 B18
B18
B18
B2
B2
B2
B18
B18
B18
B20
B21
B21
B20
Supplied
with 205
203
204
205
206
206
223
208 207
209
210
211
212
212
213
214
215
222
227
216 217
218
219
225
220
221
226
B18
224(
∗ 1)
NOTE :
Set the DIP switch on the MBX-65 board (Main board)
to match with the LCD that is used in this computer.
The upper position where ON indication is shown is the
ON position . The lower position is the OFF position.
1 2 3 4 5 6 7 8
O
N
12345678
10111011
0 : ON 1: OFF
No.
ON/OFF
B2 4-641-726-12 SCREW (M2), SPECIAL HEAD
B18 4-645-214-61 GRIP, M2
B19 4-644-637-01 GRIP, M2 EG
B20 7-621-259-25 SCREW +P 2.6X4
B21 4-663-482-11 M2 SCREW (HARDENING)

Confidential
PCG-GRX520/GRX520K/GRX520P/
PCG-GRX560/GRX560K/GRX560P/
PCG-GRX580/GRX580K/GRX580P/GRX650 (AM)
Ref.No. Part No. Description Ref.No. Part No. Description
3-3. LCD Section (GRX520/GRX520K/GRX520P)
–Made by HI–
3-9 3-10
NOTE :
Set the DIP switch on the MBX-65 board (Main board)
to match with the LCD that is used in this computer.
The upper position where ON indication is shown is the
ON position . The lower position is the OFF position.
1 2 3 4 5 6 7 8
O
N
12345678
01111011
0 : ON 1: OFF
No.
ON/OFF
The components identified by
mark 0or dotted line with mark
0are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
ACCESSORIES
************
0801 1-477-205-41 ADAPTOR, AC
802 A-8067-482-A BP2NX SKD (U) ASSY (S)
0803 1-757-562-21 CORD, POWER
804 4-660-884-02 WEIGHT SAVER (Refer to page 3-5.)
4-664-802-01 QUICK START
4-664-799-01 SPECIFICATION SHEET
4-646-847-11 W2K FIRST STEP GUIDE
801
AC Adaptor (1)
802
Battery Pack (1)
803
Power Cord (1)
804
Weight Saver (1)
301 4-660-897-01 COVER HINGE
302 X-4624-586-3 ASSY BEZEL DISPLAY 15
303 4-660-919-01 COVER SCREW LOWER 15
304 A-8067-507-A ASSY LCD 15HI AP(S)
* 305 4-660-912-01 BRACKET LCD L 15
* 306 4-660-913-01 BRACKET LCD R 15
307 1-961-573-21 HARNESS (LCD)
* 308 4-660-914-01 BRACKET LCD UPPER 15
309 4-660-911-02 LATCH LEVER 15
310 4-653-745-01 SPRING BAY
* 311 4-660-916-01 PLATE LCD UPPER 15
* 312 X-4624-534-2 ASSY HINGE L 15
* 313 X-4624-535-2 ASSY HINGE R 15
* 314 4-660-915-01 PLATE LCD LOWER 15
315 4-660-918-01 SEALED LCD 15
316 X-4624-587-3 ASSY HOUSING DISPLAY 15
317 1-476-316-11 INVERTER UNIT
318 FILAMENT TAPE (W19X50) ( ∗1 )
320 4-664-546-01 SPACER (HINGE) (15) (R)
321 4-660-921-02 TAPE LCD 15
B1 4-641-726-41 SCREW (M2), SPECIAL HEAD
B19 4-644-637-01 GRIP, M2 EG
B22 4-641-726-81 SCREW (M2), SPECIAL HEAD
∗1Use the FILAMENT TAPE.
B
B
A
A
B1
B22
B1
B1
B1
305 304
306
307
308 309
317
314
311
310
312
316
313
320
B1
318(
∗ 1)
303
302
B19
301
B22
D
B1
311
C
C
315
314
E
E
D

Confidential
PCG-GRX520/GRX520K/GRX520P/
PCG-GRX560/GRX560K/GRX560P/
PCG-GRX580/GRX580K/GRX580P/GRX650 (AM)
901 1-779-745-21 [CH]...JACK, DC
DC IN connector
902 1-815-221-22 [CH]...USB CONNECTOR (VERTICAL)
USB connector
Ref.No. Fig. Part No. Description
3-11 3-12
(END)
3-4. Connector Section (CH Type only)
∗Among the parts that are used on the boards of this model, only the connectors
that are show in the list can be replaced.
(The parts other that the specified connectors cannot be replaced.)
902
901
901
902
901 902
∗Before replacing the connector of
reference number 901 and 902
remove the bracket I/O.

4-1
Confidential
PCG-GRX520/GRX520K/GRX520P/
PCG-GRX560/GRX560K/GRX560P/
PCG-GRX580/GRX580K/GRX580P/GRX650 (AM)
CHAPTER 4.
OTHERS
4-1. Replacing the CPU
1. Removing the CPU
1Insert a flat-blade screwdriver into the notch as shown in the illustration
and rotate it so that the protrusion comes to the lock release position.
2Pull the CPU gently upward to lift it out of the CPU socket.
2. Installing the CPU
1Align the triangle reference mark of the CPU with that of the CPU socket
and insert all the pins of the CPU to the corresponding holes of the CPU
socket.
2Insert a flat-blade screwdriver into the notch as shown in the illustration
and rotate it so that the protrusion comes to the lock position.
NOTE:
Rotate a flat-blade screwdriver to the lock position securely. If not, the operation of the CPU may become unstable.
(END)
1
1
2
2
2
CPU
Lock release position
Lock position
Lock release position
Lock position
1
CPU
CPU socket
Reference
marks
CPU socket

Sony Corporation
—26 —
9-874-542-02
This manual and the constituent data may not be
replicated, copied nor reprinted in whole or in part
without prior written authorization of Sony Corporation.
English
2002F1600-1
© 2002 Sony Corporation
Published by Sony EMCS VAIO-GSC [SNT]
PCG-GRX520/GRX520K/GRX520P/GRX560/GRX560K/
PCG-GRX560P/GRX580/GRX580K/GRX580P/GRX650 (AM)
List of PCG-GRX Series (As of September, 2002)
Model Name
PCG-GRX590
PCG-GRX570
PCG-GRX550
PCG-GRX510
PCG-GRX580P
PCG-GRX580K
PCG-GRX580
PCG-GRX560P
PCG-GRX560K
PCG-GRX560
PCG-GRX520P
PCG-GRX520K
PCG-GRX520
PCG-GRX650
Service Manual
Part No.
9-874-524-01
9-874-542-02
: Additional Models

Revision Histor
y
Suffix Ver. Date Contents QM No.
-01 Ver. 1 2002.06.10 First
Edition
-02 Ver. 2 2002.09.03 Front Page (Model Line Up), Page 3-3, Page 3-4, Page 3-7, Back Cover 2002_100AK#01
< Remarks >
[Confidential]
PCG-GRX520/GRX520K/GRX520P/GRX560/GRX560K/
PCG-GRX560P/GRX580/GRX580K/GRX580P/GRX650 (AM)
