Sony Vaio PCG-C1XD User manual

nN
Sony Notebook
Computer
User Guide
PCG-C1XD
© 2000 by Sony Corporation.

Sony Notebook Computer User Guide
2
nN
Notice to Users
©2000 Sony Corporation. All rights reserved. This manual and the software described herein, in whole or
in part, may not be reproduced, translated, or reduced to any machine-readable form without prior written
approval.
Sony Corporation provides no warranty with regard to this manual, the software, or other information
contained herein and hereby expressly disclaims any implied warranties or merchantability or fitness for
any particular purpose with regard to this manual, the software or such other information. In no event shall
Sony Corporation be liable for any incidental, consequential, or special damages, whether based on tort,
contract, or otherwise, arising out of or in connection with this manual, the software, or other information
contained herein or to use thereof.
Sony Corporation reserves the right to make any modification to this manual or the information contained
herein at any time without notice. The software described herein is governed by the terms of a separate
user license agreement.
Sony, DVgate, i.LINKTM, Mavica, PictureGear, Memory Stick and the Memory Stick logo, VAIO and the
VAIO logo are trademarks of Sony Corporation. Windows and the Windows 98 logo are registered
trademarks of Microsoft Corporation.
Intel, MMX, Celeron and Pentium are trademarks of Intel Corporation.
All other trademarks are trademarks of their respective owners.
Specifications are subject to change without notice.

Sony Notebook Computer User Guide
3
nN
Safety Information
Owner’s Record
The model number and serial number are located on the bottom of your Sony Notebook Computer. Record
the serial number in the space provided here. Refer to the model and serial number when you call VAIO-
Link.
Serial number:________________________
Model number:
PCG-C1XD
WARN ING
❏Opening the unit, for whatever reason, could lead to damages that are not covered by the guarantee.
❏To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only.
❏Audio and picture distortion may occur if this equipment is positioned in close proximity to any
equipment emitting electromagnetic radiation.
❏To prevent fire or shock hazard, do not expose your Sony Notebook Computer to rain or moisture.
❏Never install modem or telephone wiring during a lightning storm.
❏Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations
❏Never touch uninsulated telephone wire or terminals unless the telephone line has been disconnected
at the network interface.
❏Use caution when installing or modifying telephone lines.
❏Avoid using the modem during an electrical storm.
❏Do not use the modem or a telephone to report a gas leak in the vicinity of the leak.
❏Use your notebook only with the supplied AC adapter. To disconnect your notebook completely from
mains voltage, unplug the AC-adapter.
❏Please make sure that the socket outlet is easily accessible.

Sony Notebook Computer User Guide
4
nN
Regulatory Information
This product conforms to the following European Directives:
73/23/EEC (Low Voltage Directive)
89/336/EEC, 92/31/EEC (EMC Directives)
93/68/EEC (CE Marking Directive)
This product complies with EN 55022 Class B and EN 50082-1 for use in following areas: residential,
commercial and light-industrial.
This product has been tested and found compliant with the limits set out in the EMC Directive for using
connection cables shorter than 3 metres (9.8 feet)
DISPOSAL OF LITHIUM ION BATTERY
!Do not handle damaged or leaking Lithium ion batteries. Dispose of promptly and properly.
!Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type
recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions (see
below).
!The battery pack used in this device may present a fire or chemical burn hazard if mistreated. Do not
disassemble, heat above 100°C (212°F) or incinerate. Dispose of used battery promptly.
!Keep away from children.
!Your notebook is equipped with an internal backup memory battery. For changing this battery, please
contact VAIO-Link.
✍Disposal of Lithium ion
batteries
Dispose of properly at end-of-
life.
In some areas the disposal of
lithium ion batteries in
household or business waste
may be prohibited.
Please use the public
collection system.

Sony Notebook Computer User Guide
5
nN
As an ENERGY STAR Partner, Sony has determined that this product meets the ENERGY STAR guidelines for
energy efficiency.
The International ENERGY STAR Office Equipment Program is an international program that promotes
energy saving through the use of computers and their office equipment. The program backs the
development and dissemination of products with functions that effectively reduce energy consumption. It
is an open system in which business proprietors can participate voluntarily. The targeted products are
office equipment such as computers, displays, printers, facsimiles and copiers. Their standards and logos
are uniform among participating nations.
ENERGY STAR is an U.S. registered mark.

Sony Notebook Computer User Guide
6
nN
Contents
Welcome
About the User Guides .......................................................................... 9
Unpacking Your Notebook Computer............................................. 11
Ergonomic Considerations................................................................. 12
Using Your Notebook Computer
Locating the Controls and Connectors.............................................. 14
Connecting a Power Source ............................................................... 18
Using Battery Power ........................................................................... 19
Starting Your Computer ..................................................................... 22
Shutting Down Your Computer........................................................ 23
Registering Your Computer............................................................... 24
Using the Keyboard ............................................................................ 25
Using the Pointing Device.................................................................. 31
Using the Jog Dial................................................................................ 32
Using the MOTION EYE built-in camera ........................................ 34
Using the Floppy Disk Drive ............................................................. 35
Using PC Cards.................................................................................... 36
Using Smart Connect .......................................................................... 39
Using Infrared Communication Devices ......................................... 40
Using Power Saving Modes............................................................... 42

Sony Notebook Computer User Guide
7
nN
Connecting peripheral devices
PC card modem*.................................................................................. 46
CD-ROM Drive .................................................................................... 48
Printer.................................................................................................... 49
External Display .................................................................................. 50
Memory Sticks™.................................................................................. 53
i.LINK™ device ................................................................................... 54
External Speakers ................................................................................ 55
External Microphone ........................................................................... 55
Universal Serial Bus (USB) Device.................................................... 56
Getting Help
About Sony’s Support Options .......................................................... 57
Troubleshooting................................................................................... 59
Using the Product Recovery CD-ROMs........................................... 72
Notes on Use
Placing a key top.................................................................................. 76
Other precautions ................................................................................ 77
Specifications .....................................................................83
Index ..................................................................................86

Welcome
Sony Notebook Computer User Guide
8
nN
Welcome
Congratulations on purchasing a Sony VAIO Notebook Computer. Sony has
combined leading-edge technology in audio, video, computing and communications
to provide you with state-of-the-art personal computing.
Here are just some of the features your Sony Notebook Computer has to offer (read
the details in the Specifications chapter of this guide).
❑Exceptional performance - Your PC includes a fast Intel®processor.
❑Portability - The rechargeable battery pack provides hours of use without AC
power.
❑Sony audio and video quality - A high-resolution LCD screen enables you to
take advantage of today’s advanced multimedia applications, games, and
entertainment software.
❑Windows®98 Second Edition - Your system includes the latest operating system
from Microsoft.
❑Communications - Connect an optional modem and access popular online
services, send and receive e-mails, browse the Internet...
❑Excellent customer support- If you have any problem with your computer, you
can contact VAIO-Link by telephone, fax or e-mail (see your Customer Service
Guide for phone numbers and addresses). Before calling VAIO-Link, you may try
to solve the problem by reading your User Guide (troubleshooting chapter) or the
manuals and Help files for the peripherals or software.

Welcome
Printed Documentation:
Sony Notebook Computer User Guide
9
nN
About the User Guides
Your Documentation Pack contains paper and on-line user guides on a
Documentation floppy disc:
Printed Documentation:
❑A Setting Up poster in colour and a Getting Started brochure; a Customer
Guide, where you will find all the basic information to start using your Notebook
Computer;
❑A complete Regulatory and safety information poster;
❑Your Sony Guarantee conditions.
On-line Documentation:
1This User Guide:
❑Using Your Sony Notebook Computer shows you how to use the standard
components of your system.
❑Connecting Peripheral Devices explains how you can add functionality by
connecting various peripherals.
❑Getting Help explains the support options available to you, and offers basic
troubleshooting tips.
❑Notes on Use provides facts and advice about using your notebook computer.
❑Specifications provides details of your computer, drivers and accessories.
2Refer to your Software Guide for information on the bundled software and the
Sony applications:

Sony Notebook Computer User Guide
Welcome 10
nN
❑About the Software is a short description of the features of the software pre-
installed on your system
❑Customizing your notebook explains how to set your system and power
management with Sony Notebook Setup, PPK Setup, PowerPanel, BatteryScope,
etc.
Learn how to set your display with NeoMagic®and enjoy the Dual Screen
Display option.
3Consult the On-line Help files of the software you're using for detailed
information on features and troubleshooting.

Sony Notebook Computer User Guide
Welcome
Unpacking Your Notebook Computer
11
nN
Unpacking Your Notebook Computer
Remove the following hardware items from the box:
Rechargeable
battery pack
Floppy disk drive
Product Recovery
CD-ROMs
AC adapter
Power cord
Main unit
Display Adapter
Spare stick covers
Documentation Pack

Welcome
About the User Guides
Sony Notebook Computer User Guide
12
nN
Ergonomic Considerations
You will be using your notebook computer as a portable device in a variety of
environments. Whenever possible, you should attempt to take account of the
following ergonomic considerations to both stationary and portable environments:
❑Position of your computer – Place the computer directly in front of you as you
work. Keep your forearms horizontal, with your wrists in a neutral, comfortable
position while using the keyboard, touchpad, or external mouse. Let your upper
arms hang naturally at your sides. Take breaks during sessions with your
computer. Excessive use of the computer may strain muscles or tendons.
Computer positioned directly
in front of you
Arms at desk
level
Wrists relaxed and flat

Welcome
About the User Guides
Sony Notebook Computer User Guide
13
nN
❑Furniture and posture – Sit in a chair with good back support. Adjust the level of
the chair so your feet are flat on the floor. A footrest may make you more
comfortable. Sit in a relaxed, upright posture and avoid slouching forward or
leaning far backwards.
❑Viewing angle of the computer’s display – Use the display’s tilting feature to
find the best position. You can reduce eye strain and muscle fatigue by adjusting
the tilt of the display to the proper position. Adjust the brightness setting of the
display as well.
❑Lighting – Choose a location where windows and lights do not create glare and
reflection on the display. Use indirect lighting to avoid bright spots on the
display. You can also purchase accessories for your display that help reduce
glare. Proper lighting adds to your comfort and work effectiveness.
❑Placement of an external display – When using an external display, set the
display at a comfortable viewing distance. Make sure the display screen is at eye
level or slightly lower when you are sitting in front of the monitor.

Using Your Notebook Computer
Locating the Controls and Connectors
Sony Notebook Computer User Guide
14
nN
Using Your Notebook Computer
This section describes how to start using your computer and how to use your
computer’s internal and external devices, such as the pointing device and the floppy
disk drive.
Locating the Controls and Connectors
Left
S400 i.LINKTM connector (page 54) PC card slot (page 36)
Ventilation slot
✍There is a ventilation slot
located near the PC card slot.
Do not cover the ventilation
slot when your computer is on.
3
1 2
3

Using Your Notebook Computer
Locating the Controls and Connectors
Sony Notebook Computer User Guide
15
nN
Front
Built-in Camera (Motion Eye)
(Page 34) Pointing device (page 31) Caps Lock indicator (page 28) Power indicator (page 22)
Microphone Speaker Scroll Lock indicator (page 28) Battery indicator (page 28)
LCD screen (page 29) Left / center / right buttons
(page 31) 1 Power button (page 22) Hard disk drive indicator (page 28)
Keyboard (page 25) Num Lock indicator (page 28) Capture button (page 34) Information indicator (page 28)
15 9 13
2610 14
3711 15
4 8 12 16

Using Your Notebook Computer
Locating the Controls and Connectors
Sony Notebook Computer User Guide
16
nN
Right
Infrared port (page 40) DC In (page 18)
iHeadphone connector (page 55) Mini VGA / TV Out Connector (page 51)
mMicrophone connector (page 55) Jog Dial (page 32)
USB connector (page 56)
1 5
2 6
3 7
4

Using Your Notebook Computer
Locating the Controls and Connectors
Sony Notebook Computer User Guide
17
nN
Bottom
Reset switch Battery release lever (pages 19, 21)
Battery lock lever (pages 19, 21) Battery connector (page 19)
✍AC adapter mains connector
and power cord: hazardous
voltage, according to
EN 60950.
All other connectors for this
notebook are SELV (Safety
Extra Low Voltage), according
to EN 60950.
1 3
2 4

Sony Notebook Computer User Guide
Using Your Notebook Computer
Connecting a Power Source
18
nN
Connecting a Power Source
You can use either AC power or a rechargeable battery pack as a power source.
Using the AC Adapter
1Plug the cable attached to the AC adapter into the DC In connector on the
computer.
2Plug one end of the power cord into the AC adapter.
3Plug the other end of the power cord into an AC outlet.
✍Use your notebook only with
the supplied AC adapter.
To disconnect your notebook
completely from mains
voltage, unplug the AC
adapter.
Please make sure that the
socket outlet is easily
accessible.
SELV according to EN 60950
AC adapter
(supplied)
DC in
Power cord (hazardous voltage
according to EN 60950)
(supplied)
Notebook computer

Sony Notebook Computer User Guide
Using Your Notebook Computer
Using Battery Power
19
nN
Using Battery Power
You can use a battery pack as a source of power. The PCGA-BP51 battery pack
supplied with your computer is not fully charged at the time of purchase. Follow the
steps below to insert and charge the battery pack.
To insert the battery pack
1Make sure that the Lock lever on the bottom of the computer is on the Release
position.
2Align the grooves on the battery with the tabs and notches on the back of the
computer, and then slide the battery towards the computer until it clicks into
place.
3Slide the lock lever into the LOCK position to secure the battery on the computer.
To charge the battery pack
1Connect the AC adapter to the computer.
2Insert the battery pack.
The computer automatically charges the battery (the battery indicator light flashes in
a double blink pattern as the battery charges). When the battery is 85% full, the
battery indicator light turns off. This process takes approximately one to one and half
hour. To charge the battery completely, continue charging for an additional hour.
A fully charged battery pack provides power for hours.
The time varies based on your system configuration and the software you use. See
your Software guide, in "Displaying Battery Information ".

Sony Notebook Computer User Guide
Using Your Notebook Computer
Using Battery Power
20
nN
Battery indicators
The ebattery indicator light indicates the status of the battery pack:
Battery Indicator
Light Status
Meaning
On The computer is using battery power.
Single blink The battery is running out of power.
Double blink The battery is charging.
Off The computer is using AC power.
