PCG-FRV23/FRV25/FRV26/FRV27/FRV28
SERVICE MANUAL
NOTEBOOK COMPUTER
9-876-304-04
For American Area
US Model
Canadian Model
Lineup : PCG-FRV28
PCG-FRV27
PCG-FRV26
PCG-FRV25
PCG-FRV23
• Design and specifications are subject to
change without notice.
Ver 4-2003I
Revision History
S400
Illust : PCG-FRV27

—2 —
Information in this document is subject to change without notice.
Sony, VAIO and CLIE are trademarks or registered trademarks of
Sony. Microsoft, Windows, Windows Media, Outlook, Bookshelf
and other Microsoft products are trademarks or registered trademarks
of Microsoft Corporation in the United States and other countries.
The word Bluetooth and the Bluetooth logo are trademarks of
Bluetooth SIG, Inc. AMD, the AMD logo, other AMD product names
and combinations thereof are trademarks of Advanced Micro
Devices, Inc. Intel Inside logo, Pentium and Celeron are trademarks
or registered trademarks of Intel Corporation. Transmeta, the
Transmeta logo, Crusoe Processor, the Crusoe logo and
combinations thereof are trademarks of Transmeta Corporation in
the USA and other countries. Graffiti, HotSync, PalmModem, and
Palm OS are resistered trademarks, and the Hotsync logo and Palm
are trademarks of Palm, Inc. or its subsidiaries. (M) and Motrola
are trademarks of Motrora, Inc. Other Motrola products and services
with (R) mark like Dragomball are the trademarks of Motrola, Inc.
All other names of systems, products and services in this manual
are trademarks or registered trademarks of their respective owners.
In this manual, the (TM) or (R) mark are not specified.
Service and Inspection Precautions
1. Obey precautionary markings and instructions
Labels and stamps on the cabinet, chassis, and components identify areas
requiring special precautions. Be sure to observe these precautions, as well
as all precautions listed in the operating manual and other associated
documents.
2. Use designated parts only
The set’s components possess important safety characteristics, such as
noncombustibility and the ability to tolerate large voltages. Be sure that
replacement parts possess the same safety characteristics as the originals.
Also remember that the 0mark, which appears in circuit diagrams and
parts lists, denotes components that have particularly important safety
functions; be extra sure to use only the designated components.
3. Always follow the original design when mounting
parts and routing wires
The original layout includes various safety features, such as inclusion of
insulating materials (tubes and tape) and the mounting of parts above the
printer board. In addition, internal wiring has been routed and clamped so
as to keep it away from hot or high-voltage parts. When mounting parts or
routing wires, therefore, be sure to duplicate the original layout.
4. Inspect after completing service
After servicing, inspect to make sure that all screws, components, and wiring
have been returned to their original condition. Also check the area around
the repair location to ensure that repair work has caused no damage, and
confirm safety.
5. When replacing chip components...
Never reuse components. Also remember that the negative side of tantalum
capacitors is easily damaged by heat.
6. When handling flexible print boards...
• The temperature of the soldering-iron tip should be about 270C.
• Do not apply the tip more than three times to the same pattern.
• Handle patterns with care; never apply force.
Caution: Remember that hard disk drives are easily damaged by
vibration. Always handle with care.
Caution Markings for Lithium/Ion Battery - The following or similar
texts shall be provided on battery pack of equipment or in both the
operating and the service instructions.
CAUTION: Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by
the manufacturer. Discard used batteries according to the
manufacturer’s instructions.
CAUTION: The battery pack used in this device may present a fire
or chemical burn hazard if mistreated. Do not disassemble, heat
above 100°C (212°F) or incinerate.
Dispose of used battery promptly.
Keep away from children.
CAUTION: Changing the back up battery.
• Overcharging, short circuiting, reverse charging, multilation or
incineration of the cells must be avoided to prevent one or more of
the following occurrences; release of toxic materials, release of
hydrogen and/or oxygen gas, rise in surface temperature.
• If a cell has leaked or vented, it should be replaced immediately
while avoiding to touch it without any protection.
PCG-FRV23/FRV25/FRV26/FRV27/FRV28 (AM)
Confidential
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFÉS PAR UNE MARQUE 0SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT
CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE
REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY
DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU
DANS LES SUPPÉMENTS PUBLIÉS PAR SONY.

—3 —
TABLE OF CONTENTS
Section Title Page
PCG-FRV23/FRV25/FRV26/FRV27/FRV28 (AM)
Confidential
CHAPTER 1. BLOCK DIAGRAM ............................... 1-1
(to 1-2)
CHAPTER 2. FRAME HARNESS DIAGRAM ........ 2-1
(to 2-2)
CHAPTER 3. EXPLODED VIEWS AND
PARTS LIST............................................ 3-1
3-1. Main Section .................................................................... 3-2
3-2. LCD Section (FRV23/FRV25/FRV27 Model)
–Made by HI –................................................................ 3-5
3-3. LCD Section (FRV26/FRV28 Model) –Made by SH –.. 3-7
3-4. LCD Section (FRV26 Model) –Made by AU –............... 3-9
(to 3-10)
CHAPTER 4. OTHERS
4-1. Replacing the CPU .......................................................... 4-1
1. Removing the CPU .......................................................... 4-1
2. Installing the CPU ............................................................ 4-1
History of the changes is shown as the
“Revision History”at the end of this data.
[MA]
3

Confidential
PCG-FRV23/FRV25/FRV26/FRV27/FRV28 (AM)
(END)
1-21-1
CHAPTER 1.
BLOCK DIAGRAM
SLOT0/1
ALI 1535+
RICOH 5C554
CARDBUS+1394LINK/PHY
South Bridge
1394
PCI BUS
DC JACK
AC LINK2
RJ45
RealtekMini PCI
Wirless LAN RTL8100BL AC LINK1
USB*3
USB 2.0
K/B LED
T/P SWITCH
RJ11
FDD
TPA0142
XBUS
BIOSTOUCH
PAD
EXT.MIC.
POWER SWITCH
EXT.SPKR.
MDCAD1981B
LPT
INT.K/B
NS PC87570
INT.SPKR.
Bettery LED
PCU
Power LED
T/P BOARD
PRIMARY IDE BUS
HDDCDROM
SECONDARY IDE BUS
478 PIN mPGA
ATI RS200M+
CRT
LCD
NORTH BRIDGE
System bus
400/533MHz
Intel
Pentium 4 75W
AVOUT
PCI bus(Mux with A-link)
R/G/B
LVDS SIGNAL
TV SIGNAL
266MB/s
SO-DIMM 1/2
DRAM SIGNAL
DDR 266
DDR CLOCK
MAIN POWER BOARD
BATTERY
PWS-XX
VIA
VT6202AL
Power SW BOARD
RTC
TIBQ3285LF
Memory Stick Board LPC
Connector

Confidential
PCG-FRV23/FRV25/FRV26/FRV27/FRV28 (AM)
(END)
2-22-1
CHAPTER 2.
FRAME HARNESS DIAGRAM
PRINTERUSB MONITOR PHONE
NETWORK
IEEE 1394 i.LINK
EXTERNAL
MICROPHONE
HEADPHONE
AV OUT
USB
USB
L Side
Rear Panel
MEMORY STICK
FLOPPY DISK DRIVE
CON7
26 27
1
52
PCN2
CON23
1
2
59
6024
25
1
2
21
22
1
48
2
1
13
124
1
14
13
CON12
CON14
CON1
CON2
CON29
CON26
CON6
CON19
CON10
CON9
CON8
CON18
CON11
CON2
A77
A1
KEY BOARD
2
302 291
1
50 49
CON21
13
CON25
DC FAN
LCD
INVERTER
LCD HARNESS
LCD Block
PC CARD
CONNECTOR
WIRELESS
LAN
1
CON22 CON5
CON24
CON15
CON13
CON16
Optical DRIVE
HARD DISK
BATTERY PACK
PCN3
81
PWS-29 Board
(Side-A)
SWX-128 Board
(Side-A)
IFX-271 Board
(Side-A)
PCN2
PCN1
PCN4
SW1
1
12
2
59
60
28
17
JP2
JP1
112
18
PAD, TOUCH
From board to connector (direct connection)
Harness (connector at both end)
Harness (soldered at one end)
Connectors soldered on board and appearing on the panel
CON4
CON3 1
2
199
200
1
2
199
200
1 2
29 30
J1
J2
12
CARD, MODEM
SWX-127 Board
(Side-A)
12
JP3
JP1
12
CON1
121
22 2
SPEAKER
RAM
DDR SO-DIMM
SLOT A
DC FAN
Twin FAN Model
14 1
MBX-88 Board
(Side-A)

3-1
CHAPTER 3.
EXPLODED VIEWS AND PARTS LIST
Confidential
NOTE:
•Items marked “*”are not stocked since they are seldom
required for routine service. Some delay should be
anticipated when ordering these items.
•The mechanical parts with no reference number in the
exploded views are not supplied.
•When two or more parts are shown, use the part described
first as the main part.
•The parts marked “$ ”are the High Value Modules (HVM).
•The parts marked “# ”are the parts on which
barcode label is attached.
•The parts marked “& ”are the “Customer Replacable
Parts (CRP)”that can be replaced by Field Customer
Support.
Especially the parts with the <&> mark require the special
attention to use them. Here fore, check first whether the
desired part is one of the targetted parts of the Customer
Replaceable Parts(CRP), or the non-targetted parts by
referring to the exploded view.
•Regarding the boards of this model, the discrete parts
on the boards cannot be replaced. However, Some
connectors can be replaced.
The components identified by mark 0or
dotted line with mark 0are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
PCG-FRV23/FRV25/FRV26/FRV27/FRV28 (AM)

3-2
Confidential
PCG-FRV23/FRV25/FRV26/FRV27/FRV28 (AM)
Ref.No. Part No. Description Ref.No. Part No. Description
3-1. Main Section
1 4-677-632-01 INSULATOR BOTTOM
2 6-600-158-01 IC HYS64D32020GDL-7-B
(DDR DIMM 256MB)
2 6-600-116-01 IC M470L3224DT0-CB0
(DDR DIMM 256MB)
* 10 4-674-025-01 BRACKET KEYBOARD
12 4-677-636-01 INSULATOR PC CARD
13 1-761-695-11 NE5.1 PC CARD(EJECTER)
15 6-704-132-01
(FRV25/FRV27)...
IC RK80532PE067512SL6S3
(P4 2.66GHz)
15 6-704-957-01 (FRV23)...IC RH80532NC049256SL73Y
(Mobile Cel 2.2GHz)
15 6-704-665-01 (FRV26/FRV28)...
IC RK80532PE072512SL6PF
(P4 2.8GHz)
16 A-8068-048-A $# COMPLETE PWB MBX-88
17 1-756-148-11 SECONDARY, BATTERY, LITHIUM
18 1-761-606-14 #CARD, MODEM
19 1-827-193-11 NE5.1 CABLE(MDC-MBX)
20 1-827-605-11 JE1.1 FFC(PWR)
21 4-675-849-02 (FRV27)...ID LABEL U
21 4-675-849-12 (FRV25:US)...ID LABEL U
21 4-676-839-01 (FRV23)...ID LABEL CA
21 4-676-839-11 (FRV25:Canadian)...ID LABEL CA
21 4-675-849-31 (FRV28)...ID LABEL U
21 4-675-849-41 (FRV26)...ID LABEL U
22 X-4626-183-1 HOOD KEYBOARD ASSY (S)
23 1-825-426-11 NE5.1 SPEAKER
24 4-644-357-01 CUSHION SPK
25 4-654-631-01 GUARD SPK
26 4-671-631-01 BRACKET SPEAKER
27 4-674-042-01 MEMORY STICK WINDOW
28 1-825-427-11 NE5.1 SPEAKER(R)
29 A-8067-868-A $COMPLETE PWB SWX-128
30 4-670-198-01 ESCUSHION TOUCHPAD
31 1-796-319-31 PAD, TOUCH
32 4-672-077-01 ADHESIVE TAPE TP
* 33 4-674-023-01 BRACKET PALMREST L
34 1-478-086-21 #KEY BOARD UNIT (US)
35 4-671-634-01 &CUSHION PALMREST
36 X-4626-182-1 HOUSING PALMREST ASSY (S)
* 37 4-674-022-01 BRACKET PALMREST R
38 A-8068-049-A $COMPLETE PWB SWX-140
39 1-827-189-11 NE5.1 FFC(TP)
40 1-827-192-11 NE5.1 FFC(PWS-TP)
* 41 4-674-024-01 BRACKET TOUCHPAD
* 42 4-674-028-01 BRACKET DRIVE R
43 X-4626-071-1 (FRV27)...ASSY TOS DVDRW BEZEL
43 X-4626-113-1 (FRV23/FRV25/FRV26)...
ASSY QSI COMBO BEZEL
43 X-4626-070-1 (FRV28)...ASSY KME DVDRW BEZEL
44 1-796-506-11 $# (FRV27)...W-DVD(SD-R6012)
44 1-796-627-11 $# (FRV23/FRV25/FRV26)...
COMBO DRIVE (SBW-241)
44 1-796-480-11 $# (FRV28)...W-DVD(UJ-810B)
45 4-670-244-01 SPRING DRIVE R
* 46 4-674-029-01 BRACKET (DRIVE) (L)
* 47 4-674-033-01 BRACKET HDD
48 A-8113-859-A $# ASSY HDD 40GB (H) (S)
49 4-673-851-01 &COVER HDD
50 4-677-197-01 &FOOT FRONT
51 X-4626-185-1 &COVER MEMORY ASSY (S)
53 X-4626-186-1 &COVER MINIPCI ASSY (S)
55 X-4626-181-1 HOUSING BOTTOM ASSY (S)
56 4-670-193-01 LENS FDD
57 4-677-640-01 CUSHION HDD
58 4-671-645-01 &DOOR BATTERY SPRING
59 4-673-853-01 &DOOR BATTERY
60 4-673-852-01 &COVER MODEM
61 4-670-194-01 COVER HOOD
* 62 4-676-348-01 BRACKET DC
* 63 4-674-019-01 PLATE DC
* 64 4-674-018-01 BRACKET IO
66 4-668-785-01 THERMAL SHEET CPU
67 4-677-635-01 INSULATOR PWS
68 4-673-303-01 SPACER TOUCHPAD BUTTON
69 A-8068-050-A $COMPLETE PWB PWS-29
71 1-827-606-11 JE1.1 DC CABLE (INT)
72 A-8068-051-A $COMPLETE PWB IFX-271
73 4-677-639-01 GASKET USB
74 4-677-637-01 CUPPER TAPE
75 4-672-852-01 SHEET HDD
76 4-672-855-01 GASKET SPEAKER
77 1-860-222-11 JE1.1 FPC (MS)
78 4-672-858-01 SHEET BRACKET TOUCHPAD
79 4-674-041-01 &FOOT REAR
81 4-672-849-01 GASKET LAN
82 4-671-635-01 &FOOT
* 83 4-674-030-01 GUIDE DRIVE
84 A-8115-824-A $(FRV25/FRV27/FRV26/FRV28)...
ASSY COOLING UNIT (DTP) (S)
84 A-8115-823-A $(FRV23)...
ASSY COOLING UNIT (M) (S)
85 4-673-615-01 GASKET SPEAKER R
86 4-677-536-01 &SHEET RUBBER JE1
88 4-677-647-01 INSULATOR DRIVE
89 4-677-259-01 SPRING DRIVE L
91 4-675-126-01 CAP FDD
* 92 4-676-347-01 BRACKET DUMMY FDD
94 4-673-304-01 SPACER PC CARD
95 9-885-029-05 CONNECTOR, USB(A)
B1 4-216-272-01 SCREW (M2), +
B2 4-635-966-01 SCREW (HEX)
B3 4-641-726-12 < & > SCREW (M2), SPECIAL HEAD
B4 4-641-726-41 SCREW (M2), SPECIAL HEAD
B5 4-644-637-01 < & > GRIP, M2 EG
B6 4-644-637-42 GRIP, M2 EG
B10 4-665-205-01 < & > SPECIAL FLAT HEAD (EG GRIP),M2
B11 4-673-018-02 SCREW SPECIAL HEAD
B12 4-673-019-01 SCREW +B
B13 4-673-121-01 SCREW PWS
B14 4-673-655-01 &SCREW +B
B15 4-650-481-01 &SCREW(B1.7),TAPPING
[MA]
1
[MA]
1
[MA]
1
[MA]
1
2
[CHG]
1-962-643-11 HARNESS (FRV MODEM CABLE) (S)
2
[CHG]
A-8068-379-A COMPLETE PWB SWX-141
3
[MA]
3
[MA]
3
[MA]
3
[MA]
3
[MA]

Confidential
PCG-FRV23/FRV25/FRV26/FRV27/FRV28 (AM)3-3 3-4
B15
47
75
48
47
B11
B3
B3
B11
N
Supplied
with 51
49
82
51
50
55
57
58
79
60
59
53
B3
B3
B3
B5 B5
B10
B5 B3
Supplied
with 55
Supplied
with 16
64
79
56
B2
B10
B14
B14
B
B
G
H
I
O
MN
61
B3
B10
B3
J
B6
B3
B3 B5
B3
B10
B6
B3
B5
E
C
A
J
F
S
12
13
D
Q
Q
R
R
1
B12
B12
B3
B3
B3
B3
B4
B3
B3
B3
B3
B3
B10
T
T
G
OH
I
L
F
L
19
20
23
24
25
25
26
76
18
28
24
38
21
22
85
46
44
45
42
B1
B1
B10
43
B3
B5
B10
B10
B10
B3
B1
D
M
A
K
K
E
S
29
39
78
40
41
30
34
31
33
35
35
36
37
32
94
32
66 (*2)
17
B13
15 (*3)
81
P
P
72
77
74
71
62
27
67
68
69
73
81
83
84
63
16
10
* 1
86
86
88
B5
C
U
U
92
91
89
95
95
2
Supplied
with 36
*2 The THERMAL SHEET CPU (Ref. 66) cannot be re-used if it is removed once.
When the COOLING UNIT (Ref. 84) is removed, be sure to replace it with the new one.
*3 When change the CPU (Ref. 15), refer to “Replacing the CPU ”in CHAPTER 4.
*1 NOTE : Set the dip switch on the MBX-88
board (Main board) to match with
the CPU that is used in this
computer.
DTMB
DTMB
CPU: (FRV23)
6-704-957-01
IC RH80532NC049256SL73Y
CPU: (FRV25/FRV27)
6-704-132-01
IC RK80532PE067512SL6S3
(FRV26/FRV28)
6-704-665-01
IC RK80532PE072512SL6PF
[MA]
1
[MA]
3
[MA]
3

Confidential
PCG-FRV23/FRV25/FRV26/FRV27/FRV28 (AM)
3-2. LCD Section (FRV23/FRV25/FRV27 Model)
–Made by HI –
301 302
304 303
305
307
308
309
310
311
314
315
316
312
306
B10
B4
B10
B4
B4
B4
B5
B10
A
A
B4
317
Supplied
with 304
3-5 3-6
Ref.No. Part No. Description
301 4-671-639-01 &CUSHION HINGE
302 4-671-637-01 &CUSHION LATCH
303 4-671-638-01 &CUSHION LCD
304 X-4625-822-1 BEZEL DISPLAY ASSY(15)(S)
305 4-670-228-01 BUTTON LATCH LCD
306 4-671-640-01 SPRING LATCH LCD
* 307 4-671-454-01 BRACKET LCD L (15)
308 4-671-457-01 HINGE L
309 A-8067-507-A $# (FRV27)...ASSY LCD 15HI AP2 (S)
309 A-8113-852-A $# (FRV23/FRV25)...
ASSY LCD 15(H) GT2 (S)
* 310 4-671-453-01 BRACKET LCD R (15)
311 4-671-456-01 HINGE R
312 1-962-514-11 LCD HARNESS
314 4-671-636-01 LCD SHIELDING
315 X-4625-820-1 HOUSING DISPLAY ASSY(S)
316 1-476-316-31 (FRV27)...INVERTER UNIT
316 1-476-317-21 (FRV23/FRV25)...INVERTER UNIT
317 4-673-299-01 INVERTER TAPE
B4 4-641-726-41 < & > SCREW (M2), SPECIAL HEAD
B5 4-644-637-01 &GRIP, M2 EG
B10 4-665-205-01 SPECIAL FLAT HEAD (EG GRIP),M2
ACCESSORIES
***********
0801 1-478-037-12 $&ADAPTOR, AC
802 A-8112-427-A $#& BP2NX SNT (U) ASSY (S)
0803 1-790-732-32 &(FRV25:US/FRV27/FRV26/FRV28)...
CORD, POWER
0803 1-757-562-21 &(FRV23/FRV25:Canadian)...
CORD, POWER
4-676-760-01 $&(FRV23/FRV25/FRV27)...
QUICK START (SD)
4-675-926-11 $&(FRV26/FRV28)...QUICK START (SD)
Ref.No. Part No. Description
The components identified by
mark 0or dotted line with mark
0are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
801
AC Adaptor
802
Battery Pack
803
Power Cord
NOTE :
Set the DIP switch on the MBX-88 board (Main board)
to match with the LCD that is used in this computer.
The upper position where ON indication is shown is the
ON position . The lower position is the OFF position.
1234
ON
56
123456
111011
0 : ON 1: OFF
No.
ON/OFF
[MA]
1
[MA]
1
[MA]
1
[MA]
3
[MA]
3

Confidential
PCG-FRV23/FRV25/FRV26/FRV27/FRV28 (AM)3-7 3-8
3-3. LCD Section (FRV26/FRV28 Model) –Made by SH –
301 302
304 303
305
307
308
409
310
311
314
315
316
312
306
B10
B4
B10
B4
B4
B4
B5
B10
A
A
B4
317
Supplied
with 304
Ref.No. Part No. Description
301 4-671-639-01 &CUSHION HINGE
302 4-671-637-01 &CUSHION LATCH
303 4-671-638-01 &CUSHION LCD
304 X-4625-822-1 BEZEL DISPLAY ASSY(15)(S)
305 4-670-228-01 BUTTON LATCH LCD
306 4-671-640-01 SPRING LATCH LCD
* 307 4-671-454-01 BRACKET LCD L (15)
308 4-671-457-01 HINGE L
* 310 4-671-453-01 BRACKET LCD R (15)
311 4-671-456-01 HINGE R
312 1-962-514-11 LCD HARNESS
314 4-671-636-01 LCD SHIELDING
315 X-4625-820-1 HOUSING DISPLAY ASSY(S)
316 1-476-317-21 INVERTER UNIT
317 4-673-299-01 INVERTER TAPE
409 A-8113-853-A $# ASSY LCD 15(SH) GT2 (S)
B4 4-641-726-41 < & > SCREW (M2), SPECIAL HEAD
B5 4-644-637-01 &GRIP, M2 EG
B10 4-665-205-01 SPECIAL FLAT HEAD (EG GRIP),M2
NOTE :
Set the DIP switch on the MBX-88 board (Main board)
to match with the LCD that is used in this computer.
The upper position where ON indication is shown is the
ON position . The lower position is the OFF position.
56
ON
4312
123456
100011
0 : ON 1: OFF
No.
ON/OFF
[MA]
3

Confidential
PCG-FRV23/FRV25/FRV26/FRV27/FRV28 (AM)3-9 3-10
(END)
3-4. LCD Section (FRV26 Model) –Made by AU –
301 302
304 303
305
507
308
509
510
311
314
315
316
512
306
B10
B4
B10
B4
B4
B4
B5
B10
A
A
B4
317
Supplied
with 304
Ref.No. Part No. Description
301 4-671-639-01 &CUSHION HINGE
302 4-671-637-01 &CUSHION LATCH
303 4-671-638-01 &CUSHION LCD
304 X-4625-822-1 BEZEL DISPLAY ASSY(15)(S)
305 4-670-228-01 BUTTON LATCH LCD
306 4-671-640-01 SPRING LATCH LCD
308 4-671-457-01 HINGE L
311 4-671-456-01 HINGE R
314 4-671-636-01 LCD SHIELDING
315 X-4625-820-1 HOUSING DISPLAY ASSY(S)
316 1-476-317-21 INVERTER UNIT
317 4-673-299-01 INVERTER TAPE
* 507 4-678-902-01 LCD BRKT L AU 15XGA
509 A-8115-791-A $# ASSY LCD 15XGA(AU)(S)
* 510 4-678-903-01 LCD BRKT R AU 15XGA
512 1-962-630-11 HARNESS, LCD (15XGA)
B4 4-641-726-41 < & > SCREW (M2), SPECIAL HEAD
B5 4-644-637-01 &GRIP, M2 EG
B10 4-665-205-01 SPECIAL FLAT HEAD (EG GRIP),M2
NOTE :
Set the DIP switch on the MBX-88 board (Main board)
to match with the LCD that is used in this computer.
The upper position where ON indication is shown is the
ON position . The lower position is the OFF position.
56
ON
4312
123456
010011
0 : ON 1: OFF
No.
ON/OFF
[MA]
3

4-1
Confidential
PCG-FRV23/FRV25/FRV26/FRV27/FRV28 (AM)
CHAPTER 4.
OTHERS
4-1. Replacing the CPU
1. Removing the CPU
1Insert a flat-blade screwdriver into the notch as shown in the illustration
and rotate it so that the protrusion comes to the lock release position.
2Pull the CPU gently upward to lift it out of the CPU socket.
2. Installing the CPU
1Align the triangle reference mark of the CPU with that of the CPU socket
and insert all the pins of the CPU to the corresponding holes of the CPU
socket.
2While pressing the two positions marked by a, insert the flat head (-)
screwdriver into the specified position and rotate the screwdriver to the
LOCK position.
(END)
1
1
2
2
2
CPU
Lock release position
Lock position
1
CPU
CPU socket
Reference
marks
CPU socket
Lock release position
Lock position
Reference
marks
NOTE:
Rotate a flat-blade screwdriver to the lock position securely. If not, the operation of the CPU may become unstable.

—19 —
Sony Corporation
9-876-304-04
PCG-FRV23/FRV25/FRV26/FRV27/FRV28 (AM)
English
2003I1600-1
© 2003 Sony Corporation
Published by Sony EMCS VAIO-GSC [SNT]
This manual and the constituent data may not be
replicated, copied nor reprinted in whole or in part
without prior written authorization of Sony Corporation.
List of PCG-FR Series (As of September, 2003)
: Additional Models
Model Name
PCG-FR130
PCG-FR780
PCG-FRV25
PCG-FRV27
PCG-FRV23
PCG-FRV28
PCG-FRV26
Service Manual
Part No.
9-876-046-03
9-876-048-02
9-876-304-04

Revision History
Suffix Ver. Date Contents QM No.
-01 Ver. 1 2003.06.06 First
Edition
-02 Ver. 2 2003.06.23 Front Page (Model Line Up), Page 3-2, Page 3-3, Page 3-6, Back Cover N2003_040AK
-03 Ver. 3 2003.08.08 Page 3-2 N2003_053CK
Front Page (Model Line Up), Page 3, Page 3-2, Page 3-3, Page 3-5,
Page 3-6, Page 3-7, Page 3-8, Page 3-9, Page 3-10, Back Cover
< Remarks >
N2003_064AK-04 Ver. 4 2003.09.03
[Confidential]
PCG-FRV23/FRV25/FRV26/FRV27/FRV28 (AM)
