Sony VAIO VPCSB11FX/P User manual

At just over 3.8 lbs. the all new VAIO® S Series laptop oers a step up to the
performance and portability you demand. From its seamless contours to advanced
technology that oers up to 15 hours of combined battery life (with optional
extended battery)9 the S combines bold design and mobile performance in a way
only Sony can.
VPCSB11FX/P
Perfectly portable
Lightweight and easy to handle at 3.8 lbs. with a thin 1” prole, the VAIO® S Series laptop is crafted for those on
the move. Featuring 2nd generation Intel® Core™ i5 technology, dedicated AMD graphics, a backlit keyboard
and a durable magnesium alloy casing, the S Series laptop has everything it takes to get you through the most
demanding of days - all in a thin-and-light 13.3” form factor.
Plus a host of energy-saving features deliver up to 7.5 hours of standard battery life, and up to 15 hours of total
combined battery life with the all new large capacity sheet battery (sold separately) – helping to keep you
unplugged longer9.
Free yourself from the cord
Leveraging the latest innovations in lithium polymer technology, the battery of the S Series is integrated into the
PC and conforms to the contours of the chassis oering a thinner battery prole while still supplying up to 7.5
hours of battery life9.
This concept even extends to the all-new large capacity sheet battery and leaves behind the traditional bulky and
protruding long-life batteries of the past.
Attaching directly to the standard capacity battery and by working in tandem with it, you’ll enjoy up to 15 hours
of total combined battery life (with optional extended battery) – helping to keep you unplugged longer9.
Premium graphics performance
An AMD Radeon™ HD 6470M dedicated graphics card with 512MB of VRAM gives a performance boost to your
day-to-day processor functions for an optimized overall computing experience regardless of the task.
Plus, the S Series puts you in control by oering a Hybrid Graphics system that allows you to easily set your
graphics performance to deliver power when you need it and energy savings when you don’t. You can even set
your performance level on the y without needing to reboot.
A simple hardware switch enables you to choose between two settings:
1.Select Speed for maximum power while multi-tasking or running heavier applications
2.Select Stamina to conserve energy and extend battery life for light computing and mobile scenarios
Convenient backlit keyboard
Practical innovation is a cornerstone of Sony’s vision, and our keyboards are no exception. Designed for ease
of use, the S Series laptop features precisely engineered keys to create a comfortable and intuitive typing
experience. And to make it even easier to nd the right keys – whether typing day or night, in the dark or light –
an LED backlight creates a pleasant glow, framing the individual keys and illuminating the lettering.
Take it to the big screen - wirelessly
Now it’s easy to wirelessly stream content to your HDTV with the Intel® Wireless Display enabled S Series laptop.
Sit back and experience your favorite online TV shows and movies from the comfort of your couch. Access
personal video, music and photos from your hard drive or home network and immediately send it wirelessly to
the biggest display in up to full 1080p HD and 5.1 surround sound.
With integrated Intel® Wireless Display technology, searching for cables and stringing them across your living
room or oce is a thing of the past8.
LED backlit display

Developed by the same people you trust to engineer amazing at-panel HDTVs, the VAIO® S Series laptop
features exceptional picture quality. The 13.3” (1366 x 768) widescreen display includes an LED backlight that
helps ensure a bright display while conserving battery power. Plus, with100% color saturation you’ll enjoy a
wider spectrum of color for more true-to-life images.
Hardware Buttons
The S Series laptop also comes with three special hardware buttons: VAIO, ASSIST and WEB to help you get where
you want to go with a simple touch of a button.
•Select the WEB button for one touch access to the web without full boot up into Windows®.
•Press the VAIO button and instantly launch Media Gallery™ software to enjoy all your photos and music in a
whole new way.
•ASSIST button links directly to VAIO Care™ software that helps maintain and troubleshoot any PC issues for
optimal performance.
Specications
Processor
Processor Type Intel® Core™ i5-2410M
Processor Technology Dual Core
Processor Speed 2.30GHz1 with Intel® Turbo Boost Technology up to 2.90GHz2
Processor Cache 3MB
Display
Screen Size 13.3"
Resolution 1366 x 768
Backlight Technology LED
Memory
Installed Memory 4GB (onboard)
Memory Type/Speed DDR3/1333MHz
Max. Memory 8GB
Graphics
Graphics Processor AMD Radeon™ HD 6470M
Graphics Video RAM 512MB dedicated
Graphics Technology Hybrid Graphics
Storage
Storage Type Serial ATA
Storage Capacity 500GB4
Storage Technology 5400rpm
Optical Drive
Optical Drive Type CD/DVD Player / Burner
Optical Drive Support - CD/DVD Read / Write
Hardware
Camera Built-in MOTION EYE® camera and microphone
Keyboard QWERTY, 82 keys with 2.0mm stroke and 19.05mm pitch
Backlit Keyboard Yes

Audio
Sound System Intel® High Denition Audio with Dolby® Home Theater® Technology v3
Inputs and Outputs
DC-In 1
USB 3.0 1
USB 2.0 2
VGA Output(s) 1
Headphone Output 1
Secure Digital (SD) Slot 1
Port Replicator Connector(s) 1
HDMI® Output(s) 1
Memory Stick Duo™ 1
Wireless/Networking
Bluetooth® Technology Bluetooth Integrated Stereo A2DP (2.1 + EDR)
Ethernet Protocol 1000BASE-T/100BASE-TX/10BASE-T
WiFi Adapter Intel® Centrino® Wireless-N 1000
WiDi Ready Yes - Intel® Wireless Display Technology8
Software
Operating System Genuine Windows® 7 Home Premium 64-bit
Supplied Software Microsoft® Oce Starter with reduced-functionality versions of Word and Excel®6, VAIO Care™, Media Gallery™, PMB -
VAIO Edition
Adobe® Creative Software Adobe Acrobat® Standard 9.0, Adobe Photoshop® Elements 8.0, Adobe Premiere® Elements 8.0
Anti-Virus Software Norton Internet Security™ 2011 30-Day Trial Oer11
Service and Warranty Information
Toll-Free Phone Support 888-476-69727
Onsite/In-Home Service Yes12
International Service Yes
Limited Warranty Term 1 Year
Priority Phone Support 239-768-76057
Environmental Information
ENERGY STAR® 5.0
EPEAT™ Gold
ROHS® Compliant
Weights and Measurements
Dimensions (Approx.) 13.04" (W) x 0.95" (H) x 8.84" (D)
Weight (Approx.) 3.80 lbs. (with Standard Battery)
Power
Battery Type Internal Lithium Polymer Battery (4400mAh)
DVD Playback up to 4.5 hours9
Default Brightness up to 7.5 hours9
Maximum Brightness up to 6.5 hours9
Start-up Times
Average Resume Time from Suspend 2 seconds
Average Boot Time 60 seconds
First Boot Time 5 minutes, excluding end user interaction

1. GHz denotes microprocessor internal clock speed and may vary.
2. Requires a system with Intel® Turbo Boost Technology capability. Intel Turbo Boost Technology 2.0 is available only on 2nd generation Intel® Core™ i5 and i7 processors. Performance varies depending on hardware,
software and system conguration.
3. Available on select Intel® Core™ processors. Requires an Intel® HT Technology enabled system. Performance will vary depending on the specic hardware and software used.
4. 1 GB = 1 billion bytes. Actual formatted capacity will be less.
6.This PC is preloaded with reduced-functionality versions of Word and Excel that include advertising. Purchase an Oce 2010 Product Key to activate full-featured Oce software on this PC.
7. For certain third party software applications, Sony provides rst level phone support. Additional telephone support may be available from the applicable 3rd party vendor. Availability and schedule for any such
support is determined by the aplicable software vendor. Long distance charges may apply.
8. Requires TV Adapter and compatible television. Does not support Blu-ray Disc™ or other protected content playback.
9. Estimates only based upon Sony engineering testing. Actual performance will vary based on notebook settings, environmental conditions, and usage. Battery capacity decreases over time and use.
11. Norton Internet Security™ 2011 30-day subscription is pre-installed on your Sony VAIO PC. You need to activate the software for the product to work. After your 30-days are nished, buy Norton Internet Security to
continue to be protected from viruses, hackers and identify theft.
12.Availability may be limited. See limited warranty for details.
Specications subject to change. Non-metric weights and measures are approximate.
Certain Microsoft products included with this computer may use technological measures for copy protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE
PRODUCT ACTIVATIONPROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software product(s) or
recongurations of the computer and may be completed by Internet or telephone (toll charges may apply).
This product meets the standards of the International Energy Star Program for energy eciency.
©2011 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without written permission is prohibited. Sony, VAIO, Memory Stick Duo, Motion Eye, VAIO Care and Media Gallery are trademarks of
Sony in the U.S. and in other countries. Intel and Core are trademarks of the Intel Corporation in the U.S. and in other countries. Microsoft, Windows and Excel are registered trademarks of the Microsoft Corporation in
the U.S. and in other countries. Blu-ray Disc and its logo is a trademark. Bluetooth and the Bluetooth logo are registered trademarks of Bluetooth SIG, Inc. Dolby and Dolby Home Theater are registered trademarks of
Dolby Laboratories. Norton Internet Security is a trademark of Symantec Corporation or its aliates in the U.S. and other countries. All other trademarks are trademarks of their respective owners.
Certain restrictions apply. See www.sonystyle.com/pcwarranty for more information.
Updated: June 16, 2011
General
Action Buttons VAIO, ASSIST, WEB, Eject, Speed/Stamina, Wireless On/O
Pointing Device Touchpad (Gesture supported)
Accessories
Supplied Accessories Internal Lithium Polymer Battery (4400mAh), AC Adapter, Power Cord
