Sony VGN-BX560B User manual

VGN-BX560B Series
ADAPTIVEPLUS™ TECHNOLOGIES FOR YOUR BUSINESS.
AdaptivePlus™ technologies combine flexibilty, mobility, security and communications that are designed to
help businesses compete, produce, and grow, giving businesses the necessary tools for success.
VAIO®BX Series Notebook PC
FLEXIBILITY FOR YOUR BUSINESS.
The VAIO® BX Series Notebook features the unique and powerful Multi-Function Bay, enabling simple
swapping out of powerful peripherals such as a DVD±RW Double Layer Bay Unit5, CD-RW/DVD-ROM
Drive Bay Unit, 80GB9HDD Bay Unit (5400rpm SATA), Weight Saver Bay Unit, and an HDD Adapter
Bay Unit. Each of these optional peripherals is compatible with all three size configurations of the BX
Series Notebook, making efficient resource allocation across your team a logical and natural part of your
technology management.
MOBILITY AND COMMUNICATION FOR YOUR BUSINESS.
The VAIO® BX Series Notebooks are designed with mobility in mind. Integrated Bluetooth® technology3
and optional Intel® Centrino™ Mobile Technology mean all BX Series Notebooks feature integrated
802.11b/g wireless LAN2, and efficient power and application management, which provide extended
battery life6when you’re on the go. VAIO® BX Series Notebooks also offer communication technology to
keep you wirelessly connected, networked and conferenced in. With Gigabit Ethernet, optional Bluetooth®
headset, and an optional built-in camera for instant real-time video conferencing (video conferencing
software needs to be obtained separately)16, you can communicate in whatever style makes you the most
productive.
The Sony VAIO BX Series Notebook has been tested in accordance with criteria set by Cisco and is
compatible with Cisco’s Aironet 1200AG Series Access Point platform and Cisco’s Access Control Server
v3.3.14
SECURITY FOR YOUR BUSINESS.
Security is a top priority with the VAIO® BX Series Notebook. All BX Series Notebooks feature an
integrated biometrics fingerprint sensor, delivering personal security and the IT cost-savings and
convenience of not having to remember your passwords. The Trusted Platform Module (TPM) chip is
compliant with TCG v1.1b, enabling companies to set the level of security on a specific client/user basis.
Data can be encrypted over the local network, within the system, and over the Internet, giving you the
ability with a single platform to dial in the specific level of client security required.
Flexibility, mobility, security, superior communications functionality and VAIO®Care full-service
support. The VAIO®BX Series Notebook makes productivity truly scalable, enabling you to
empower your business with Sony technology. With your choice of screen sizes featuring
XBRITE-ECO™ LCD technology, swappable optional peripherals, leading-edge security
components, and powerful communication options, the BX Notebook enables businesses to
better manage resources, equip employees, and maximize value.

VGN-BX560B Series
VAIO®BX Series Notebook PC
Hardware
Processor (Configurable)
Intel®Celeron®M Processor 370 (1.50GHz1, 1MB L2 Cache)
Intel®Pentium®M Processor 740 (1.73GHz1, 2MB L2 Cache)
Intel®Pentium®M Processor 760 (2.00GHz1, 2MB L2 Cache)
Intel®Pentium®M Processor 780 (2.26GHz1, 2MB L2 Cache)
Front Side Bus
533MHz (Intel®Pentium®M) or 400MHz (Intel®Celeron®M)
Chipset
Intel®915PM or Intel®915GM
LCD10 (Configurable)
15.4” WXGA LCD (1280x800) XBRITE-ECO™ Technology
Hard Drive (Configurable)
40GB9(5400RPM) SATA, 9.5mm Height
60GB9(5400RPM) SATA, 9.5mm Height
80GB9(5400RPM) SATA, 9.5mm Height
100GB9(5400RPM) SATA, 9.5mm Height
120GB9(5400RPM) SATA, 9.5mm Height
Memory (Configurable)
256MB (256MB/DDR2/533/SO-DIMMx1)
512MB (256MB/DDR2/533/SO-DIMMx2)
512MB (512MB/DDR2/533/SO-DIMMx1)
1GB (512MB/DDR2/533/SO-DIMMx2)
1GB (1GB/DDR2/533/SO-DIMMx1)
2GB (1GB/DDR2/533/SO-DIMMx2)
(Expandable to 2GB - On-board memory configured at time of purchase)
Graphics (Configurable)
Intel®915GM Integrated 128MB dynamically allocated shared video memory (Intel®
915GM) or
ATI Mobility™ Radeon®X700 PCI Express 128MB Dedicated Memory with
HyperMemory™12 supporting up to 256MB (Intel®915PM)
Graphics Interface
VGA out w/ Smart Display Sensor
Optical Drive (Configurable)
DVD±RW5DL/CD-RW Multi-Bay Unit
DVD+R Write (8x MAX), DVD+R DL Write (4x MAX), DVD+RW (8x MAX)
DVD-R Write (8x MAX), DVD-RW (6x MAX)
CD-R Write (24x MAX), CD-RW Write (24x MAX)
CD-RW/DVD-ROM Combo Drive Multi-Bay Unit
CD-R Write (24x MAX), CD-RW Write (24x MAX)
Modem
Integrated V.90 Modem with RJ-11 interface
Audio
Windows®sound system compatible
Built-in stereo speakers
Audio Interface
Monaural mini microphone jack
Headphone jack
Media Slots
Supports optional Memory Stick®, Memory Stick Duo™ media7and Secure Digital (SD)
media
PC Card Slot
One PCMCIA - Type II/Type I card slot with CardBus support
Other Interfaces
i.LINK®connector (IEEE 1394)8, 3 USB 2.0 ports, docking station connector
Pointing Devices
Electro-Static touch pad and Pointing Stick
Keyboard
QWERTY, 85 keys with 2.5mm stroke and 19.05mm pitch
Action Buttons
Power On, S1, S2, Wireless LAN On/Off, Mute, Camera Off (if configured with optional
camera)
Power Requirements
105W+10%
Battery (Configurable)
Standard 6 cell Battery (VGP-BPS4)
Large Capacity 12 cell Battery (VGP-BPL4)
Estimated Battery Life
1.0 – 2.0 hours6
Communication
Intel®PRO/Wireless 2200BG Network Connection (802.11b/g)2Mini-PCI
Fast Ethernet 10BASE-T/100BASE-TX/1000BASE-T (RJ-45)
Integrated Bluetooth®3 ver 2.0 Technology
Optional Motion Eye®0.3M Built In Camera for video conferencing
Security
Trusted Platform Module (TPM) TCG Ver 1.1b Compliant with Wave Software
Biometric Fingerprint Sensor with Protector Suite QL Software
Cisco™ V3 Compatibility
The Sony VAIO BX Series Notebook has been tested in accordance with test criteria set by
Cisco and is compatible with Cisco’s Aironet 1200AG Series Access Point platform and
Cisco’s Access Control Server v3.314
Weight
6.17lbs.4
Size (W x H x D)10
14.2”(W) x 1.41” (H) x 10.46”(D)
Color
Silver Casing
Supplied Accessories
Standard Lithium-Ion Battery (VGP-BPS4) or Large Capacity Battery (VGP-BPL4)
AC Adapter (VGP-AC19V10)
Power Cord
System Recovery Disc
Optional Accessories
Multi-Function Docking Station with battery charger (VGP-PRBX1)
AC Adapter included (VGP-AC19V9)
Docking Station I/O:
Multi-Function Bay
Battery Charger
Serial Port
Hi Speed USB (USB 2.0) Ports x 4
Security Lock and Lock/Unlock Switch
Printer Port
Monitor (VGA) Port
Monitor (DVI-D) Port
Fast Ethernet 10BASE-T/100BASE-TX/1000BASE-T (RJ-45)
Additional Standard Battery (VGP-BPS4)
Large Capacity Battery (VGP-BPL4)
AC Adapter (VGP-AC19V10)
DVD+R Double Layer/DVD±RW5Multi-Bay unit (VGP-DRWBX1)
CD-RW/DVD-ROM Multi-Bay unit (VGP-CRWBX1)
HDD Adapter Multi-Bay unit (VGP-HDABX1)
Compatible with PATA 2.5” 9.5mm Height
80GB9SATA 5400RPM 9.5mm Height HDD Multi-Bay unit (VGP-HDBX08)

VGN-BX560B Series
VAIO®BX Series Notebook PC
Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 800.222.7669 • www.sony.com/dn Printed 09/05
Standard Software
Operating System
Microsoft®Windows®XP Professional Service Pack 2
Supplied Software
Click to DVD™ - DVD Creation (DVD+R Double Layer/DVD±RW5only)
InterVideo®WinDVD
Roxio®DigitalMedia SE (DVD+R Double Layer/DVD±RW5only)
Microsoft®Works®8.0
Microsoft®Office Small Business Edition (60-Day Trial)15
Anti-Virus and Recovery Software
Norton®Internet Security 2005 90-Day Introductory Subscription
VAIO Help and Support
VAIO Support Central
Optional Software
SonicStage®- Digital Music
VAIO Media™ - Network File Sharing
DVgate Plus™ - Digital Video
SonicStage®Mastering Studio software with MP3 encoder
Microsoft®Office 2003 (Basic, Small Business, or Professional Edition)
Adobe®Photoshop®Elements
Adobe®Photoshop®Album Starter Edition
Adobe®Premiere®(Standard or Professional Edition)
Intuit®Quicken New User Edition 2005
Service and Warranty
Limited Warranty
1 Year Limited Warranty13 with Onsite Service
Telephone Support
1 year toll-free technical telephone assistance, 24-hours, 7-days-a-week11
1-888-476-6972
Online and Email Support
Support available from http://www.sony.com/pcsupport
1GHz denotes microprocessor internal clock speed; other factors may affect application performance.
CPU speed will be reduced under certain operating conditions.
2Requires 802.11b or 802.11g compatible access point. Some functionality may require Internet
services, which may require a fee.
3Interoperability among Bluetooth®devices varies.
4Non-metric weights and measures are approximate with standard battery and weight saver.
5DVD media/formats are not universally compatible.
6Estimated battery life. Actual battery life may vary on usage and configuration options selected.
7Supports Memory Stick®and Memory Stick Duo™ without adaptor.
8i.LINK is a trademark of Sony used only to designate that a product contains an IEEE 1394 connector.
All products with an i.LINK connector may not communicate with each other.
9GB means one billion bytes when referring to hard drive capacity. Accessible capacity may vary.
10 Viewable area measured diagonally.
11 For certain third party software applications, Sony provides first level Phone support. Additional
telephone support may be available from the applicable third party vendor. Availability and schedule
for any such support is determined by the applicable software vendor.
12 ATI Mobility Radeon XYZ model with 128MB Dedicated Memory; with HyperMemory™ supporting
up to 256MB dynamically shared RAM video memory.
13 When available, Sony will provide Onsite Service in fulfillment of its limited warranty obligations. Any
such services are subject to the terms and conditions of the limited warranty. See actual Limited
Warranty for details. Onsite Service will be provided via third-party technician to be dispatched as
needed following phone-based troubleshooting. Some repairs may be accomplished with self repair
kits. Onsite Service may not be available in all locations.
14 Sony VAIO® Professional BX Series has tested compatible with the Cisco Aironet Access Point 1200
Series and the Cisco Access Control Server v3.3. Cisco Compatible signifies that Sony’s product has
undergone interoperability testing by Sony, together with Cisco and a third-party test house, based on
testing criteria set by Cisco. Sony is solely responsible for the support and warranty of its product.
Cisco makes no warranties, express or implied, with respect to Sony’s product or its interoperation
with the listed Cisco product and disclaims any implied warranties of merchantability or fitness for a
particular use, or against infringement.
15 The Microsoft Office 2003 60-day trial software is intended for evaluation purposes only. This trial
software is installed on your system and you must activate the software before you can use it. Product
activation procedures will be detailed during initial launch of the software; activation requires Internet
access. This software has an expiration date of 60 days from date of first use, at which time the
software will operate under reduced-functionality mode, limiting end-user options and operations.
16 A broadband connection is required along with third party services which may require a subscription
fee and other service fees.
Computer interface: The computer industry lacks standards and, therefore, there are a multitude of varying
software packages and add-on hardware options. This personal computer is not manufactured to operate
any specific software, and Sony does not and cannot make any warranty or representation with respect to
the performance of this product with any particular software packages and/or non-Sony add-on hardware
options except those mentioned in this document. Sony hereby disclaims any representations or warranty
that this product is compatible with any combination of products you may choose to connect. While Sony
representatives or Sony authorized dealers may be authorized to vary or waive this disclaimer. Purchasers
must determine for themselves the suitability and compatibility of the hardware and software in each and
every particular instance. Software titles pre-installed on the Sony Notebook Computer are subject to
change without notice. Simulated graphic shown on display. Pre-installed software may not be identical to
retail versions or have all documentation. This product meets the standards of the international Energy Star
Program for energy efficiency. Features and specifications are subject to change without notice.
© 2005 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without written
permission is prohibited. Sony, VAIO, “like.no.other,” AdaptivePlus, Click to DVD, SonicStage, DVgate Plus,
i.Link, MOTION EYE, Memory Stick, Memory Stick Duo, Memory Stick PRO, VAIO Media, SmartWi and
XBRITE are trademarks of Sony. Intel and Pentium are registered trademarks, and Centrino is a trademark
of Intel Corporation. Microsoft and Windows are registered trademarks of Microsoft Corporation. Cisco,
Cisco Systems, the Cisco Systems logo, and the Cisco Square Bridge logo are registered trademarks or
trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. The Bluetooth
word mark and logo are registered trademarks and are owned by Bluetooth SIG, Inc. All other trademarks
are trademarks of their respective owners.
Please visit the Dealer Network for more
information at www.sony.com/dn
