VGN-NS205N/S
VAIO® NS Notebook PC
Form and function delivered in style
EVERYDAY PC PERFORMANCE
Enjoy an Intel ® Core™2 Duo Processor T6570 (2.10GHz ) with 2GB of pre -
installed system memory.
The VAIO ® NS notebook comes pre - installed with Genuine Microsoft ®
Windows Vista ® Business 32 - bit.
Work and play online from almost anywhere within your home or on - the - go
using 802.11a/b/g/n integrated wireless LAN technology .
Store virtually all of your data on a roomy 160GB (5400rpm) Serial ATA hard
disk drive .
MULTIMEDIA ENTERTAINMENT
Enjoy a 15.4" widescreen display with XBRITE - ECO™LCD technology that
delivers razor - sharp details and bold colors.
Editing digital video and digital images is quick and easy with VAIO ® Movie
Story software. You choose the supplied template and professional - looking
cutaways, cross - fades and soundtrack syncing are automatically done for
you.
STYLISH YET FUNCTIONAL DESIGN
Clean lines, a textured exterior, a rich Granite Silver hue and an aesthetic
yet functional design give this notebook a very contemporary look and
feel.
Connect to useful peripherals with 4 conveniently located USB ports.
The 15.4 ” VAIO ® NS notebook exemplifies contemporary style in an easy -
to - handle mobile PC. With such great performance features as an Intel ®
Core™2 Duo processor, and loads of RAM, the VAIO ® NS is a great PC for
all your day - to - day computing and entertainment endeavors.
1
3
2
6
6
ECO
-

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 03/23/2009
VGN-NS205N/S
VAIO® NS Notebook PC
Specifications
General
Computer Type: Notebook
Type of Use: Portable
Action Buttons: AV Mode, Mute
Pointing Device: Electro-static touch pad
Hardware
Keyboard: QWERTY, 86 keys with 2.5mm stroke
and 19.05mm pitch
Camera: Built-in 1.3 megapixel MOTION EYE®
camera and microphone
Processor
Type: Intel® Core™2 Duo Processor T6570
Speed: 2.10GHz
Front Side Bus Speed: 800MHz
L2 Cache: 2MB
Memory
Type: DDR2
Installed: 2GB PC2-6400 (2GBx1)
Maximum: 4GB
Speed: 800MHz
Hard Drive
Capacity: 160GB
Speed: 5400rpm
Interface: Serial ATA
Optical Drive
CD Support: Read / Write (CD/-R/- RW)
DVD Support: Read / Write (DVD ± R/ ± RW/ ± R DL/-
RAM)
Expansion Slots
Multimedia Card Reader: One Memory Stick
PRO™ ( Standard/Duo) media slot with
MagicGate® functionality
One ExpressCard ® /34 media slot
One Secure Digital (SD memory card) media
slot
Audio
Sound System: Intel® High Definition Audio
Display
Screen Size: 15.4"
Resolution: 1280 x 800
XBRITE-ECO™Technology: Yes
Technology: WXGA
Graphics
Processor: Mobile Intel® Graphics Media
Accelerator 4500MHD. Total Available
Graphics Memory: 820MB (max.)
Chipset: Mobile Intel® GM45 Express Chipset
Max. External Resolution via VGA: 2048x1536
Inputs and Outputs
Modem Jack: 1
Microphone Input: 1
USB Port(s): 4 (2.0 compliant)
VGA Output(s): 1
DC- In: 1
i.LINK ® Connection: 1 (4pin) i.LINK® connector
(IEEE 1394)
Headphone Output(s): 1
Ethernet Connection (s): 1
1
4
2
6
10
9
Networking/Modem
Ethernet Protocol: 10Base-T/100Base- TX/1000Base -
T (Gigabit)
Ethernet Speed: Fast Ethernet (RJ -45)
Modem Type: Integrated V.92/V.90 Modem (RJ-
11)
Wireless LAN: Intel® WiFi Link 5100AGN
(802.11a/b/g/n)
Power
Battery Type: Standard Capacity Lithium-ion
Battery (VGP-BPS13/S)
Estimated Battery Life: 1.5- 4.0 hours Standard
Capacity Battery
2.0- 5.5 hours Large Capacity Battery
Power Requirements: 95W + 10%
Software
Operating System: Genuine Microsoft ® Windows
Vista® Business 32 -bit
Supplied Software: Microsoft® Works SE 9.0 w/
60-Day Trial Version of Microsoft® Office Small
Business 2007
VAIO® Multimedia Suite: Click to Disc Editor -
Import, Edit, Burn
VAIO® Movie Story -Simplel Movie Creation
VAIO® MusicBox -Music by Mood
VAIO® Media plus -Multimedia Streaming
Software
*Please access VAIO® Help and Support from
your PC for a complete list of software
applications and trials.
Anti - Virus & Recovery Software: Microsoft®
Windows Live™ OneCare ™Trial Version
Service and Warranty Information
Telephone Support: 1 year toll- free technical
telephone assistance, available 24/7
Online and Email Support: Support available
from http://www.esupport.sony.com/EN/VAIO
Limited Warranty Term: 1 year limited warranty .
See actual warranty for details.
Environmental Information
EPEAT™ : Silver
RoHS® : Compliant
For more information:
www.sony.com/vaioeco
ENERGY STAR® : 4.0
Dimensions
Weight: 6.4 lbs (with standard battery)
Measurements: 14.18"(W) x 1.24-1.5"(H) x
10.63"(D)
Supplied Accessories
Standard Lithium-ion battery (VGP-BPS13/S)
AC Adapter
Power Cord
Optional Accessories
Large Capacity Battery (VGP-BPL13)
Additional Standard Lithium-ion Battery (VGP-
BPS13A/S)
Stick AC Adapter (VGP-AC19V30)
USB Optical Mouse(VGP-UMS55/S)
USB Portable Speaker (VGP-USP1)
Neoprene Notebook and AC Adapter Case
(VGP-AMC3)
Notebook Backpack (VGP-CCP3/S)
Sport Backpack (VGP-CCP4/S)
Color: Granite Silver
3
11
11
14
5
13
12
7
7,8
UPC Code: 27242769212
1.GHzdenotesmicroprocessorinternalclockspeed;otherfactorsmay
affectapplication performance. CPU speed will be reduced under
certain operating conditions.
2.GBmeansonebillionbytes when referring to hard drive capacity.
Accessiblecapacitymayvary.Aportionofharddisk space is
reservedasarecoverypartition.
3.Requires802.11ncompatibleaccesspoint.Somefunctionalitymay
requireInternetservices.
4.Aportionofthesystemmemoryover3GB may not be availableto
theoperatingsystem.
5.Microsoft® WindowsLive ™ OneCare ™ TrialVersion – Thistrialsoftware
willworkforninety(90)daysafteryoufirstuseit.Youwillnotbeableto
usethesoftwareifyoudonotactivateitasdescribedthefirsttimeyou
usethe software. You canactivatethe software by Internet:Internet
servicechargesmayapply.Ifyouwanttokeepusing the software
afterthe90 - daytrialperiod,you must buy a subscription. You can
subscribeonlinebyfollowingtheconversion instructions presented
during setup and paying the required fees.
6. Viewable area measured diagonally.
7.Non - metricweights and measures are approximate and mayvary.
8.Measuredatthe narrowestpoint
9.i.LINKisatrademark of Sony used only to designate that a product
containsan IEEE 1394 connector. All products with an i.LINK
connectormaynotcommunicate witheach other.
10.Total Available Graphics Memory refers to the new Windows Vista
classificationofgraphics memory, which varies depending on the
operatingcondition, version of device driver and system memory size.
11.Actualbatterylifemay vary based on product settings, usage
patternsand environmental conditions.
12.Seeactuallimited warranty for details. For a copy of Sony's warranty,
pleasevisit www.sony.com/pcsupport, call toll - free888 - 476 - 6972
(888 - 4SONYPC)or write toSonyElectronics, 12451 Gateway
Boulevard,FortMyers,FL 33913.
13.Forcertain third party software applications, Sony provides first level
phonesupport.Additionaltelephone support may be available from
theapplicable3rdpartyvendor.Availabilityand schedule for any
suchsupport is determined by the aplicable software vendor.
14.60 - DayTrial Version of Microsoft ® Office2007 - Thistrial softwarewill
workonlyfor60daysafteryoufirstuseit. You will not be able to use
thesoftwareifyoudon'tactivateit as described the first time you use
thesoftware. You canactivatethesoftware by Internet:Internet
servicechargesmayapply.Ifyouwanttokeepusing the software
afterthe60 - daytrial period, youmustconvert to theperpetual
version.Youcan convert online by following the conversion
instructions presented during setup and paying the required fees.
ComputerInterface: For this product,there are a multitude of varying
software packages and add - onhardwareoptions.Thisproductisnot
manufacturedtoworkwith any specific software, and Sony does not and
cannotmake any warrantyorrepresentationwith respect tothe
performanceofthisproductwithanyparticular software packages
and/or non - Sony add - onhardware options except those mentioned here.
Sonyhereby disclaims anyrepresentationsor warranties thatthis
product is compatible with any combination of non - Sonyproductsyou
maychoose to connect toit.While Sony representatives orSony
authorizeddealersmaybeabletoassist you and may make
recommendations,they are NOTauthorizedtovary or waivethis
disclaimer.Purchasers must determine for themselves the suitability and
compatibilityofthehardwareandsoftwareineachandeveryparticular
instance.Softwaretitles pre - installedon the Sony computer are subject
tochangewithoutnotice.Preinstalledsoftwaremay not be identical to
retailversionsorhave all documentation. Features and specifications are
subject to change without notice.
Lampinthisproductcontainsmercury.Disposalofthesematerialsmay
beregulateddueto environmental considerations. For disposal or
recyclinginformation, please contact your local authorities or the
Electronic Industries Alliance (www.eiae.org).
©2008Sony Electronics Inc. Allrightsreserved. Reproduction in wholeor
inpartwithoutwritten permission is prohibited. Sony, Sony logo, VAIO,
VAIO logo, XBRITE - ECO,MagicGate, MOTION EYE,MemoryStick PRO and
i.LINKaretrademarksofSonyintheU.S.andinothercountries.Microsoft,
WindowsLive,OneCareandWindowsVistaaretrademarksofthe
MicrosoftCorporationinthe U.S. and in other countries. Intel, Centrino
andCorearetrademarksoftheIntelCorporationintheU.S.and in other
countries.ENERGY STAR anditslogoare trademarks. Allother
trademarksaretrademarksof their respective owners.
PrintedinU.S.A.12/08.
