Sony VGN-TT180N - VAIO TT Series User manual

VGN-TT180N/B
VAIO® TT Series Notebook
World ’ s smallest Blu-ray Disc™notebook
MOBILE PC PERFORMANCE
Enjoy the performance of an Intel ® Core™2 Duo SU9400 processor
(1.40GHz ) with Intel ® Centrino ® 2 technology and 4GB of pre - installed
system memory.
The VAIO ® TT series notebook comes pre - installed with Genuine Microsoft ®
Windows Vista ® Business 32 - bit.
Store your important documents, team projects and business
presentations on the roomy 160GB Serial ATA hard disk drive.
ENDLESS FEATURES
Enjoy an 11.1" LED backlit, widescreen display with XBRITE - DuraView™ LCD
technology for a brighter, crisper, tougher display that helps resist
scratches.
A Blu - ray Disc™optical drive lets you playback HD Blu - ray Disc movies in
crystal - clear resolution and store 25 - 50GB of data to a single recordable
Blu - ray Disc media.
An HDMI ™output delivers digital video and audio to external sources via a
single cable letting you enjoy HD entertainment on your compatible HDTV
(cable sold separately) .
A built - in microphone and MOTION EYE ® camera with face - tracking
technology allows for easy communication with friends and family .
A built - in biometric fingerprint scanner makes authentication and secure
access quick and easy –you only need your fingerprint.
WIRELESS FREEDOM
Offering a massive boost in wireless connection speed and range, work
and play quicker virtually anywhere within your office or café hotspot
using next - generation 802.11n integrated wireless LAN technology .
Go beyond LAN networks and café hotspots and find the internet virtually
anywhere with integrated Wireless Wide Area Network (WWAN)
technology through Sprint ® Mobile Broadband service.
Integrated Stereo A2DP Bluetooth ® technology allows you to wirelessly
connect to useful peripherals and stream CD - quality audio to compatible
devices .
The ultraportable VAIO ® TT notebook establishes a new grade in mobility
with its thin - and - light design available in an array of stylish colors. What’ s
more, this PC with a stunning 11.1 ” LCD offers industry - leading mobile
performance, balancing the power of Intel ® Centrino ® 2 processor
technology and Blu - ray Disc™optical dirve with a host of energy -
conserving features that deliver maximum battery life.
1
7
2
8
5
6
2
18
20
4
19
17
8

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 10/24/2008
VGN-TT180N/B
VAIO® TT Series Notebook
Specifications
General
Computer Type: Notebook
Type of Use: Ultra Portable
Action Buttons: Mute, Volume -/ +, S1, Eject, WLAN /
Bluetooth® on / off
Pointing Device: Electro-static touch pad
Security: Biometric Fingerprint Sensor
Trusted Platform Module (TPM) TCG Ver.1.2 compliant
Hardware
Keyboard: QWERTY, 17.0 mm pitch, 1.7 mm stroke
Camera: Built -in MOTION EYE® camera and microphone
Processor
Type: Intel® Core™2 Duo Processor SU9400
Speed: 1.40 GHz
Front Side Bus Speed: 800MHz
L2 Cache: 3MB
Technology: Intel® Centrino® 2 processor technology
Memory
Type: DDR3
Installed: 4GB PC3 - 6400 (2GBx2)
Maximum: 4GB
Speed: 800MHz
Hard Drive
Capacity: 160GB
Speed: 5400rpm
Interface: Serial ATA
Impact Protection: G -Sensor™Shock Protection -Hard
Disk Drive Protection
Optical Drive #1
DVD+R Write: 8x max.
DVD+RW Write: 4x max.
DVD -R Write: 8x max.
DVD -RW Write: 4x max.
CD -R Write: 16x max.
CD -RW Write: 10x max.
CD Read: 24x max.
DVD Read: 8x max.
DVD -RAM Write: 5x max.
BD-R Read: 2x max.
BD-R Write: 2x max.
BD-RE Write: 2x max.
BD-ROM Read: 2x max.
BD-RE Read: 2x max.
BD-R DL Read: 2x max.
BD-R DL Write: 1x max.
DVD -RAM Read: 5x max.
Blu-Ray Disc™Support: Yes (read / write ) (BD-R/-RE/-
ROM/ DVD±RW/±R DL/RAM Drive)
BD-RE DL Read: 2x max.
BD-RE DL Write: 1x max.
Expansion Slots
Multimedia Card Reader: One Memory Stick PRO™
(Standard/Duo) media slot with MagicGate®
functionality
One ExpressCard® / 34 slot
One Secure Digital (SD memory card) media slot
Audio
Sound System: Intel® High Definition Audio
Display
Screen or Display Technology: WXGA
Screen Size: 11.1"
Resolution: 1366 x 768
XBRITE- DuraView ™Technology: Yes
Back Light Technology: LED
Graphics
Processor: Mobile Intel® Graphics Media Accelerator
4500MHD with Intel ® Clear Video Technology
Total Available Graphics Memory: 1300MB (max.)
Chipset: Mobile Intel® GS45 Express Chipset
Interface: HDMI™ and VGA out with Smart Display Sensor
1
7
7
2
5
6
8
12
Inputs and Outputs
Microphone Input: 1
Port Replicator Connector(s): 1 (Bottom)
USB Port(s): 2 (2.0 compliant)
VGA Output(s): 1
DC -In: 1
i.LINK® Connection: 1 (4pin) i.LINK® connector (IEEE
1394)
Headphone Output(s): 1
Ethernet Connection (s): 1
HDMI™Output: 1
Networking/Modem
Ethernet Protocol: 10Base - T/100Base - TX/1000Base -T
(Gigabit)
Ethernet Speed: Fast Ethernet (RJ- 45)
Wireless LAN: Intel® WiFi Link 5100AGN(802.11a/b/g/n)
Wireless WAN: Optional Sprint® Mobile Broadband
service
Bluetooth® Technology: Integrated Stereo A2DP
Bluetooth® Technology (2.1 + EDR)
Power
Battery Type: Standard Capacity Lithium-ion Battery
(VGP- BPS14/B)
Estimated Battery Life: 4.5 to 7.5 hours Standard
Capacity Battery
6.5 to 12.0 hours Large Capacity Battery
Power Requirements: 68W + 10%
Input Voltage: 100 - 240V
Software
Operating System: Genuine Microsoft® Windows Vista®
Business 32- bit
Internet Services: AOL® 90 -Day Risk Free Trial -For new
users only
Anti -Virus and Recovery Software: Microsoft® Windows
Live™OneCare™Trial Version
Supplied Software: Microsoft® Works SE 9.0 w/ 60 - Day
Trial Version of Microsoft® Office Small Business 2007
The VAIO® Software Experience: VAIO ® Startup Assistant
Click to Disc Editor -Import, Edit, Burn
VAIO ® Movie Story -Simple Movie Creation
VAIO ® MusicBox -Music by Mood
VAIO ® Media plus -Multimedia Streaming Software
*Please access VAIO® Help and Support from your
PC for a complete list of software applications and
trials.
Service and Warranty Information
Telephone Support: 1 year toll -free technical telephone
assistance, available 24/7 .
Online and Email Support: Support available from
http://www.esupport.sony.com/EN/VAIO
Limited Warranty Term: 1 year limited warranty with
International Repair Service Program . See actual
warranty for details.
Environmental Information
RoHS®: Compliant
For more information: www.sony.com/vaioeco
Regulation and Standard Compliance
Energy Star® Compliant: 4.0
Dimensions
Weight: 2.96 lbs.
Measurements: 10.99"(W) x 0.93"(H) x 7.87"(D)
Supplied Accessories
Power Cord
AC Adapter (VGP- AC16V13)
Standard Capacity Lithium-ion Battery (VGP- BPS14/B)
Noise Canceling Headphones
Optional Accessories
Large Capacity Battery (VGP- BPL14/B)
Stick AC Adapter (VGP- AC16V10)
Port Replicator (VGP-PRTT1)
Carrying Case (VGP-CKTT1)
Carrying Pouch (VGP- CP11)
Bluetooth® Laser Mouse (VGP- BMS33/B)
Bluetooth® Presentation Controller (VGP-BRMP10)
11
4
19
17
3
3
16
15
14
13
9
9,10
17
17
USB Portable Speaker (VGP- USP1)
100GB Portable Hard Drive with Wireless Keys (VGP-
UHDM10/B)
Privacy Filter (VGP-FL13)
Color: Black
UPC Code: 27242751378
1.GHzdenotesmicroprocessorinternalclockspeed;otherfactorsmay
affectapplication performance. CPU speed will be reduced under
certain operating conditions.
2.GBmeansone billion bytes when referring to hard drive capacity. TB
meansonetrillionbyteswhenreferringtoharddrivecapacity.
Accessiblecapacitymayvary.Aportionof hard disk space is
reservedasarecoverypartition.
3.Actualbatterylifewillvary based on product settings, usage patterns,
batteryand environmental conditions.
4.Requires802.11ncompatibleaccesspoint.Somefunctionalitymay
requireInternetservices.
5.Certaincircumstancesmaylimit/preventBlu - rayDisc™ media
playback.Foroptimal performance, download all updates from
http://esupport.sony.com/EN/DRIVERS.
6. Video recording to Blu - rayDisc™ mediaisdoneinMPEG2andAVC
formatsonly.
7.Aportionofthesystemmemoryover3GBmay not be available to
theoperatingsystem.
8. Viewable area measured diagonally.
9.Non - metricweights and measures are approximate and mayvary.
10.Measuredatthenarrowestpoint
11.i.LINKisatrademark of Sony used only to designate that a product
containsanIEEE 1394 connector. All products with an i.LINK
connectormaynotcommunicatewitheachother.
12.Total Available Graphics Memory refers to the newWindowsVista ®
classificationofgraphics memory, which varies depending on the
operatingcondition, version of device driver and systemmemory size.
13.Seeactuallimitedwarrantyfordetails.ForacopyofSony'swarranty,
please visit www.esupport.sony.com, call toll - free888 - 476 - 6972(888 -
4SONYPC),or write toSonyElectronics,12451 Gateway Boulevard,
FortMyers,FL33913.
14.Forcertainthirdparty software applications, Sony provides first level
phonesupport.Additional telephone support may be available from
theapplicable3rdpartyvendor. Availability and schedule for any
such support is determined by the applicable software vendor.
15.60 - DayTrial Version of Microsoft ® Office2007 - Thistrial softwarewill
workonlyfor60daysafteryou first use it. You will not be able to use
thesoftwareifyoudonotactivateitasdescribedthefirsttimeyou use
thesoftware. You can activatethesoftware by Internet: Internet
servicechargesmayapply.Ifyouwant to keep using the software
afterthe60 - daytrial period, youmustconvertto the perpetual
version.Youcanconvertonlinebyfollowingtheconversion
instructions presented during setup and paying the required fees.
16.Microsoft® WindowsLive ™ OneCare ™ TrialVersion - Thistrial
softwarewill work for ninety (90) daysafteryoufirstuse it. You will not
beableto use the software if you do not activateitasdescribed the
firsttime you use the software.Youcanactivate the software by
Internet:Internet service charges mayapply.Ifyou want to keep
usingthe software after the 90 - daytrial period, you must buy a
subscription.Youcan subscribe online by following the conversion
instructions presented during setup and paying the required fees.
17.Interoperability and compatibility among Bluetooth ®devicesvary.
18. Requires high definition - capable display with HDMI ™ connector.
Imagequality will vary.
19.FreeMonth Offer: Limited time offer. Subject to change. You willbe
chargedaregularmonthlyfeeforyourselectedconnectioncard
plan.Aonemonthservice credit will be applied to your account
within1 - 3billcycles.Servicecredit will be for the amount of the
monthlyrate charge only.Seewww.sony.com/sprint for complete
offerdetails, price plans, service terms and conditions,andcoverage
map.ClicktheSprinticononyourVAIOnotebook ’ sdesktopfor
serviceactivation. Coveragenotavailable everywhere – see
coveragemapfordetails.Credit approval and $200 early termination
feeappliesif not cancelled within the first 30 days. Servicedefaultsto
NationwideSprint PCS Network,whereavailable,if Sprint Mobile
BroadbandNetworkisunavailable.Notavailablewhile roaming.
Terms&Conditionsandadditionalrestrictionsapply. May not be
combinedwith other offers.
20.Broadband Internet service requiredalongwith third party services
whichmay require a subscription or other servicefee.
ComputerInterface:For this product,there are a multitude of varying
software packages and add - onhardwareoptions.Thisproductisnot
manufacturedtoworkwith any specific software, and Sony does not and
cannotmake any warranty orrepresentationwith respect to the
performanceofthisproductwithanyparticularsoftwarepackages
and/or non - Sony add - onhardwareoptionsexceptthose mentioned here.
Sonyhereby disclaims anyrepresentationsorwarranties that this
product is compatible with any combination of non - Sonyproductsyou
maychoose to connect toit.WhileSony representatives or Sony
authorizeddealersmaybeableto assist you and may make
recommendations,they are NOT authorizedtovary or waive this
disclaimer.Purchasersmust determine for themselves the suitability and
compatibilityofthehardwareandsoftwareineachandevery particular
instance.Software titles pre - installedon the Sony computer are subject
tochangewithoutnotice.Preinstalledsoftwaremaynotbeidenticalto
retailversionsorhave all documentation. Features and specifications are
subject to change without notice.
Lampinthisproductcontainsmercury.Disposalofthesematerialsmay
beregulateddue to environmental considerations. For disposal or
recyclinginformation,pleasecontact your local authorities or the
Electronic Industries Alliance (www.eiae.org).
©2008Sony Electronics Inc. Allrightsreserved.Reproduction in whole or
inpart without written permission is prohibited. Sony,i.LINK, VAIO, XBRITE -
DuraView,Sonylogo,VAIOlogo,MemoryStick Duo and MagicGate are
trademarksofSonyintheU.S.and in other countries. Intel and Core are
trademarksoftheIntelCorporationintheU.S.andinothercountries.
MicrosoftandWindows Vista are registered trademarks of the Microsoft
Corporationin the U.S. and in othercountries. Blu - rayDiscand the
Bluetoothlogoarea regestered trademark of SIG, Inc. All other
trademarksaretrademarksoftheirrespectiveowners.
Printed08/08.
2
