VGN-SR210J/S
VAIO® SR Series Notebook PC
Serious power, uncompromising class
POWERFUL PC PERFORMANCE
Intel ® Core™2 Duo T5800 processor (2.0GHz ) with 3GB of pre - installed
system memory.
The VAIO ® SR notebook comes pre - installed with Genuine Microsoft ®
Windows Vista ® Home Premium 64 - bit .
Thin, lightweight and durable Classic Silver magnesium alloy chassis weighs
just over 4 pounds (with standard battery).
A 13.3" LED backlit, widescreen display with power - efficient XBRITE - ECO™
LCD technology delivers dazzling colors and stunning picture clarity.
Built - in Wireless - N technology offers a boost in wireless connection speed
and range .
Store your important documents, business presentations and corporate
projects on the roomy 250GB Serial ATA hard disk drive.
SERIOUS SECURITY
A built - in biometric fingerprint scanner makes authentication and secure
access quick and easy –you only need your fingerprint.
G - Sensor™Shock Protection technology locks up your hard disk drive
during sudden movement to secure its position and help protect the disk
from scratching.
“SWITCH”YOUR PERSPECTIVE
Separate your business workspace from your personal workspace. VAIO ®
Switch mode is a set of buttons above the keyboard that lets you set three
distinct usage “personalities”, or modes, to your SR notebook.
The VAIO ® SR notebook features an innovative keyboard design with keys
that are individually raised above a solid, one - piece layer providing a
quieter keyboard and more durable panel.
Editing digital video and images is quick and easy with VAIO ® Movie Story
software. You choose the supplied template and professional - looking
cutaways, cross - fades and soundtrack syncing are automatically done for
you.
The powerful, portable and durable VAIO ® SR notebook features a
magnesium alloy casing, Intel ® Centrino ® processor technology, long
battery life and a 13.3 ” LED backlit widescreen display with XBRITE - ECO™
LCD technology. Customize your SR notebook with completely different on -
screen “ personalities ” for home, work and play using the ingenious new
“ Switch ” mode.
1
16
7
6
3
2
6
ECO
-

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 10/21/2008
VGN-SR210J/S
VAIO® SR Series Notebook PC
Specifications
General
Computer Type: Notebook
Type of Use: Ultra-portable
Action Buttons: Switch Mode, WLAN / Bluetooth® on/off
Pointing Device: Electro-static touch pad
Security: Biometric Fingerprint Sensor
Trusted Platform Module (TPM) TCG Ver.1.2 compliant
Hardware
Keyboard: QWERTY, 82 keys with 2.0mm stroke and
19.05mm pitch
Camera: Built -in 1.3 megapixel MOTION EYE® camera
and microphone
Processor
Type: Intel® Core™2 Duo Processor T5800
Speed: 2.0GHz
Front Side Bus Speed: 800MHz
L2 Cache: 2MB
Technology: Intel® Centrino® processor technology
Memory
Type: DDR2
Installed: 3GB PC2 - 6400 (2GBx1 + 1GBx1)
Maximum: 4GB
Speed: 800MHz
Hard Drive
Capacity: 250GB
Speed: 5400rpm
Interface: Serial ATA
Impact Protection: G -Sensor™Shock Protection -Hard
Disk Drive Protection
Optical Drive #1
DVD+R DL Write: 4x max
DVD+R Write: 8x max
DVD+RW Write: 8x max
DVD -R Write: 8x max
DVD -RW Write: 6x max
CD -R Write: 24x max
CD -RW Write: 16x max
DVD ±RW: Yes (DVD±R DL/DVD±RW/RAM)
CD Read: 24x max
DVD Read: 8x max
DVD -RAM Write: 5x max
DVD -R DL Write: 4x max
DVD -RAM Read: 5x max
Expansion Slots
Multimedia Card Reader: One Memory Stick PRO™
(Standard / Duo) media slot with MagicGate®
functionality
One ExpressCard® / 34 media slot
One Secure Digital (SD™memory card) media slot
Audio
Sound System: Intel® High Definition Audio
Display
Screen Size: 13.3"
Resolution: 1280 x 800
XBRITE-ECO™Technology: Yes
Technology: WXGA
Back Light Technology: LED
Graphics
Processor: Mobile Intel® Graphics Media Accelerator
4500MHD with Intel ® Clear Video Technology
Total Available Graphics Memory: 1750MB (max.)
Chipset: Mobile Intel® GM45 Express Chipset
Interface: VGA out with Smart Display Sensor
Inputs and Outputs
Headphone Jack: 1
Modem Jack: 1
Microphone Input: 1
1
2
6
10
Port Replicator Connector(s): 1 (Bottom)
USB Port(s): 2 (2.0 compliant)
VGA Output(s): 1
DC -In: 1
i.LINK® Connection: 1 (4pin) i.LINK® connector (IEEE
1394)
Ethernet Connection (s): 1
Networking/Modem
Ethernet Protocol: 10Base - T/100Base -TX
Ethernet Speed: Fast Ethernet (RJ- 45)
Modem Type: Integrated V.92/V.90 Modem (RJ- 11)
Wireless LAN: Intel® WiFi Link 5100AGN (802.11a/b/g/n)
Bluetooth® Technology: Integrated Stereo A2DP
Bluetooth® Technology (2.1 + EDR)
Power
Battery Type: Standard Capacity Lithium-ion Battery
(VGP- BPS13A/B)
Estimated Battery Life: 2.5 to 6.0 hours Standard
Capacity Battery
3.5 to 9.0 hours Large Capacity Battery
Power Requirements: 100W + 10%
Software
Operating System: Genuine Microsoft® Windows Vista®
Home Premium 64- bit
Internet Services: AOL® 90 -Day Risk Free Trial -New Users
Only
Anti -Virus and Recovery Software: Microsoft® Windows
Live™OneCare™Trial Version
Supplied Software: Microsoft® Works SE 9.0 w/ 60 - Day
Trial Version of Microsoft® Office Home and Student
2007
The VAIO® Software Experience: Click to Disc Editor -
DVD Creation
VAIO ® Movie Story -Movie Creation
VAIO ® MusicBox -Playlist Creation
VAIO ® Media plus -Multimedia Streaming Software
*Please access VAIO® Help and Support from your
PC for a complete list of software applications and
trials.
Service and Warranty Information
Telephone Support: 1 year toll -free technical telephone
assistance, available 24/7
Online and Email Support: Support available from
http://www.esupport.sony.com/EN/VAIO
Limited Warranty Term: 1 year limited warranty . See
actual warranty for details.
Environmental Information
RoHS®: Compliant
For more information: www.sony.com/vaioeco
Regulation and Standard Compliance
Energy Star® Compliant: 4.0
Dimensions
Weight: 4.23 lbs (with standard battery)
Measurements: 12.4"(W) x 0.99 - 1.33"(H) x 9.2"(D)
Supplied Accessories
Standard Lithium-ion battery (VGP- BPS13A/B)
AC Adapter
Power Cord
Optional Accessories
Stick AC Adapter (VGP- AC19V21)
Additional Standard Capacity Battery (VGP- BPS13A/B)
Large Capacity Battery (VGP- BPL13)
VAIO ® Protection Case (VGP-CKSR1)
USB Optical Mouse (VGP- UMS20/B)
Bluetooth Laser Mouse (VGP- BMS33/B)
Neoprene Case (VGP-AMC1)
Notebook Backpack (VGP-CCP4/L)
Color: Classic Silver
UPC Code: 27242751170
1.GHzdenotesmicroprocessorinternalclockspeed;otherfactorsmay
affectapplication performance. CPU speed will be reduced under
certain operating conditions.
9
3
15
11
11
16
5
14
13
12
7
7,8
15
2.GBmeansonebillionbytes when referring to hard drive capacity.
Accessiblecapacitymayvary.Aportionofharddisk space is
reservedasarecoverypartition.
3.Requires802.11ncompatibleaccesspoint.Somefunctionalitymay
requireInternetservices.
4.BroadbandInternetservicerequiredalongwiththirdpartyservices
whichmay require a subscription or other service fee.
5.Microsoft® WindowsLive ™ OneCare ™ TrialVersion – Thistrialsoftware
willworkforninety(90)daysafteryoufirstuseit.Youwillnotbeableto
usethesoftwareifyoudonotactivateitasdescribedthefirsttimeyou
usethe software. You canactivatethesoftware by Internet: Internet
servicechargesmayapply.Ifyouwanttokeepusing the software
afterthe90 - daytrialperiod,you must buy a subscription. You can
subscribeonlinebyfollowingtheconversioninstructionspresented
during setup and paying the required fees.
6. Viewable area measured diagonally.
7.Non - metricweights and measures are approximate and mayvary.
8.Measuredatthenarrowestpoint
9.i.LINKisatrademark of Sony used only to designate that a product
containsanIEEE1394 connector. All products with an i.LINK
connectormaynotcommunicatewitheachother.
10.Total Available Graphics Memory refers to the new WindowsVista ®
classificationofgraphics memory, which varies depending on the
operatingcondition, version of device driver and system memory size.
11.Actualbatterylifemayvarybasedonproductsettings,usage
patternsand environmental conditions.
12.Seeactuallimitedwarrantyfordetails.ForacopyofSony'swarranty,
pleasevisit www.sony.com/pcsupport, call toll - free888 - 476 - 6972
(888 - 4SONYPC)or write toSonyElectronics, 12451 Gateway
Boulevard,FortMyers,FL33913.
13.Forcertainthirdpartysoftware applications, Sony provides first level
phonesupport.Additionaltelephone support may be available from
theapplicable3rdpartyvendor.Availabilityand schedule for any
suchsupport is determined by the aplicable software vendor.
14.60 - DayTrial Version of Microsoft ® Office2007 - Thistrial softwarewill
workonlyfor60daysafteryoufirstuseit. You will not be able to use
thesoftwareifyoudon'tactivateitasdescribedthefirsttimeyouuse
thesoftware. You can activatethesoftwareby Internet: Internet
servicechargesmayapply.Ifyouwanttokeepusing the software
afterthe60 - daytrial period, you mustconvertto the perpetual
version.Youcanconvertonlinebyfollowingtheconversion
instructions presented during setup and paying the required fees.
15.Interoperability and compatibility among Bluetooth ®devicesvarry.
16.Compatibility and performance ina64bit environment may vary.
Checkwith the manufacturer ofyoursoftwareor accessory to ensure
youhave the latest updates.
ComputerInterface: For this producttherearea multitude of varying
software packages and add - onhardwareoptions.Thisproductisnot
manufacturedtoworkwith any specific software, and Sony does not and
cannotmake any warranty orrepresentationwithrespect to the
performanceofthisproductwithanyparticularsoftwarepackages
and/or non - Sony add - onhardwareoptionsexceptthosementioned here.
Sonyhereby disclaims any representationsorwarranties that this
product is compatible with any combination of non - Sonyproductsyou
maychoose to connect toit.WhileSony representatives or Sony
authorizeddealersmaybeabletoassist you and may make
recommendations,they are NOT authorizedtovaryor waive this
disclaimer.Purchasersmust determine for themselves the suitability and
compatibilityofthehardwareandsoftwareineachandeveryparticular
instance.Softwaretitles pre - installedonthe Sony computer are subject
tochangewithoutnotice.Preinstalledsoftwaremaynotbeidenticalto
retailversionsorhave all documentation. Features and specifications are
subjecttochangewithout notice. This product meets the standards of the
InternationalEnergyStarProgramforenergyefficiency.
©2008Sony Electronics Inc. Allrightsreserved.Reproduction in whole or
inpartwithoutwrittenpermissionisprohibited.Sony,Sonylogo,VAIO,
VAIO logo, XBRITE - ECO,MemoryStickDuo,MOTIONEYE,G - Sensor,
MagicGateandi.LINKaretrademarks of Sony in the U.S. and in other
countries.Microsoft,WindowsLive,OneCareandWindowsVistaare
trademarksoftheMicrosoftCorporation in the U.S. and in other
countries.IntelandCentrinoareregisteredtrademarksandCoreisa
trademarkoftheIntelCorporationintheU.S.andinother countries.
Bluetoothis a registered trademark ofSIG,Inc.ENERGY STAR is a
registeredU.S. mark. All othertrademarksaretrademarks of their
respectiveowners.
PrintedinU.S.A.08/08.
