ISSUED
A
B
C
D
E
F
G
H
I
J
K
L
23456789
10 11 12 13 14 15 16
A
B
C
D
E
F
G
H
I
J
K
L
SCALE
(E)
(J)
UNIT
ANGLE
SHEET
6
1
2
3
4
5
TOLERANCE
FAMILY
RANK
X
X
X
X
X
X
HISTORY
X COUNT
SUFFIX
REPL. REVISION
SIGN.
DRAWN BY
PLANNED BY CHECKED BY
APPROVED BY
TENTATIVE
MODEL
PART NO.
PART NO.
MATERIAL(COLOR)
FINISH(COLOR)
ORIGINAL
MODEL
USED 0N
mm
SONY STANDARD DRAWING
TITLE/DESCRIPTION
F spec - D12
1
1
'09.4
A1
DATE
ECN-NO.
THIS PART SHOULD NOT CONTAIN ANY SUB STANCES WHICH ARE
SPECIFIED IN SS-00259-01.
PURCHASE RECYCLED RESINS AND WIRE RODS ONLY FROM
THE BUSINESS PARTNERS THAT SONY APPROVES AS GREEN PARTNERS.
1
CONFIDENTIAL
THISDOCUMENT IS THE PROPRIETARY PRO PERTYOF SONY. ITS USE IS AUTHORIZED ONLYFOR RESPONDING TO A REQUEST FO R QUOTATION,OR FOR THE PERFORMANCE O FWORK FOR SONY. ALL QUESTIONS MUST BE REFERRED TO
ISPROHIBITED. OFFENDERS WILL BE HEL DLIABLE FOR THE PAYMENT OF DAMAGES. ALL RIGHTS RESERVED IN THE EVENT OF THEGRANT OF A PATENT, UTILITY MODE L OR DESIGN.COPYRIGHT RESERVED.
THELOCAL PURCHASING DEPARTMENT OF S ONY. THE REPRODUCTION, DISTRIBUTION ANDUTILIZATION OF THIS DOCUMENT AS WELLAS THE COMMUNICATION OF ITS CON TENTS TO OTHERS WITHOUT EXPRESS AUTH ORIZATION
753(753:SPEC)
(29 3/4 inch:SPEC)
700.4
(27 5/8 inch)
509.5(510:SPEC)
(20 1/8 inch:SPEC)
394.8
(15 5/8 inch)
85.9
(3 1/2 inch)
213(213:SPEC)
(8 1/2 inch:SPEC)
200(200:SPEC)
(7 7/8 inch:SPEC)
100(100:SPEC)
(4 inch:SPEC)
107.4 (108:SPEC)
(4 3/8 inch:SPEC) 150.3
(6 inch) 191.1
(7 5/8 inch)
231.1
(9 1/8 inch) 268.1 (269:SPEC)
(10 5/8 inch:SPEC)
471(471:SPEC)
(18 5/8 inch:SPEC)
39(39:SPEC)
(1 9/16 inch:SPEC)
( 45.5 )
(1 13/16 inch)
( 187.4 )
(7 1/2 inch)
( 167.4 )
(6 5/8inch)
( 121.2 )
(4 7/8 inch)
208(208:SPEC)
(8 1/4 inch:SPEC)
465.3
(18 3/8 inch)
204.3
(8 1/8 inch)
199.8
(7 7/8 inch)
456.1
(18 inch)
443.3
(17 1/2 inch)
193.9
(7 3/4 inch)
192(192:SPEC)
(7 5/8 inch:SPEC)
431.8 (432:SPEC)
(17 1/8 inch:SPEC)
( 120.5 )
(4 3/4 inch)
( 126.5 )
(5 inch)
( 189.1 )
(7 1/2 inch)
( 78.5 )
(3 1/8inch)
( 207.9 )
(8 1/4)
( 94.7 )
(3 3/4)
( 308.8 )
(12 1/4 inch)
( 87.9 )
(3 1/2 inch)
( 67.7 )
(2 3/4 inch)
471(471:SPEC)
(18 5/8 inch:SPEC)
449.1 (450:SPEC)
(17 3/4 inch:SPEC)
70.8 (71:SPEC)
(2 7/8 inch:SPEC)
125(125:SPEC)
(5 inch:SPEC)
46.6 (46.6:SPEC)
(1 7/8 inch:SPEC)
247
(9 3/4 inch)
197.4
(7 7/8 inch)
NA / LA EU EU
KDL-32EX340 KDL-32EX343 KDL-32EX340
SV-22799 SV-22797 SV-22668
D
I
M
E
N
S
I
O
N
TV only (WxHxD) 753x471x71(46.6) [mm]
29 3/4x18 5/8x2 7/8(1 7/8) [inch] APPROX. 75.3x47.1x7.1(4.7) [cm] APPROX. 75.3x47.1x7.1(4.7) [cm]
TV with Stand (WxHxD) 753x510x213 [mm]
29 3/4x20 1/8x8 1/2 [inch] APPROX. 75.3x51.0x21.3 [cm] APPROX. 75.3x51.0x21.3 [cm]
Media Receiver (WxHxD) - - -
Monitor Only (WxHxD) - - -
Monitor with Stand (WxHxD) - - -
Media Receiver with Stand (WxHxD) - - -
Satellite Speaker (WxHxD) - - -
Stand Width 450 [mm] / 17 3/4 [inch] APPROX. 45.0 [cm] APPROX. 45.0 [cm]
VESA Hole Pitch 200x100 [mm] / 7 7/8x4 [inch] 20.0x10.0 [cm] 20.0x10.0 [cm]
W
E
I
G
H
T
TV Only 7.1 [Kg.] / 15.7 [lb.] APPROX. 7.2[Kg.] APPROX. 7.2[Kg.]
TV with Stand 7.7 [Kg.] / 17.0 [lb.] APPROX. 7.8[Kg.] APPROX. 7.8[Kg.]
Media Receiver - - -
Monitor Only - - -
Monitor with Stand - - -
Media receiver with Stand - - -
Satellite Speaker - - -
Remarks
ANGLE: 5 ANGLE: 10 ANGLE: 15 ANGLE: 20
ANGLE: 0
VARIATIONS WALL MOUNTING
M4x (6.5 to 10+T) (T:VESA PLATE THICKNESS)
or +PSW4x16 (FOR SONY WALL MOUNT)
Area
Model name
SV No.
1:1
ATOM
Pro/E
-
-
- -
-
-
-
-
