Sony BRAVIA KDL-40S2000 User manual

KDL-40S2000
BRAVIA ™ S - SeriesDigitalLCDTelevision
Key Features
HDTVwithATSCDigitalTuner
BRAVIAEngine™full digitalvideoprocessor
Digitalaudio amplifier
1366x 768HDPanel Resolution
Lightsensor backlightingcontrol
Spacesaving bottomspeakerdesign
PictureFreeze function
Timer(On/Off/Sleep)
VESAcompliant mountingholes
Key Technologies
BRAVIA Engine ™ Full Digital Video Processor BRAVIA™ S -Series LCD televisions use Sony's BRAVIA Engine™ full digital
video processor for crisp and clear images. Several special picture enhancement technologies are integrated into the
processor to create better gradations and details, enhance contrast, dynamically improve color, and reduce image flicker.
HDMI ™ and PC Connectivity Designed for maximum versatility, Sony’s BRAVIA S-Series Digital LCD TV line is equipped with
a comprehensive range of input interfaces. The HDMI (High-Definition Multimedia Interface) is the first industry-supported,
uncompressed, all-digital audio/video interface. HDMI technology supports enhanced or High Definition video, together with
multi-channel digital audio to provide matchless image and sound reproduction. The PC input (HD-15-pin) offers easy
connection to your PC, allowing you to use your high resolution BRAVIA S-Series Digital TV as a computer monitor.
Light Sensor Intelligently adjusts the screen brightness to match the ambient light in a room, ensuring a comfortable
viewing experience. In a dim room for example the screen automatically reduces brightness making it much more comfortable
for viewing.
SRS®TruSurround®XT Building on the success of TruSurround technology, TruSurround XT audio adds three new audio
enhancement technologies to produce an amazingly immersive sound experience. Dialog Clarity™brings movie dialog into
“ focus ” during the playback of any surround-encoded material to make speech much clearer and crisper. TruBass creates
incredible deep rich bass allowing a person to perceive significantly deeper, richer low bass tones that are far beyond the
physical low frequency capabilities of the speaker itself. And WOW widens the soundstage by processing standard two-
channel stereo material as well as multi-channel encoded material for a dramatic improvement in the playback of any stereo
audio over a two-speaker system.
Freeze Function Sony’s Freeze Function is a useful function that allows you to temporarily freeze the picture in a separate
screen while the programming continues to display. This comes in handy when you want to copy a recipe, phone number,
etc. that flashes too quickly across your screen. Simply touch the “ Freeze ” button on the remote control and copy the details
down at your convenience.

SonyElectronicsInc. • 16530ViaEsprillo • SanDiego,CA92127 • 1-800-222-7669 • www.sony.com
LastUpdated:03/06/2007
KDL-40S2000
BRAVIA ™ S - SeriesDigitalLCDTelevision
PleasevisittheDealerNetworkforcurrent
informationatwww.sony.com/dn
Features
General
Auto SAP: Yes
Closed Caption (CC): Yes
ID1 Detection: Yes
Video Label: Yes
Video
Tuner: ATSC
Video Processing: Yes (BRAVIA Engine™System)
Noise Reduction: Yes
Comb Filter: 3D Digital Comb Filter
Light Sensor: Yes
Picture Modes: Vivid, Standard, Custom
Wide Mode: Yes
Display Technology: LCD (178 ° wide viewing
angle LCD display panels)
Convenience
Channel Skip/Add: Yes
Favorite Channel: Yes
Parental Control (V-Chip): Yes
Sleep Timer: 15, 30, 45, 60, 90, Off
Timer Events: Timer 1, Timer 2
Clock: Yes
Power Save Mode: Standard, Reduced, Picture
Off
Picture Freeze: Yes
On Screen Display: Menu
Input Skip: Yes
Specifications
General
Aspect Ratio: 16:9
Screen Size: 40" measured diagonally
Television Type: Flat Panel
Video
Native Resolution: 720p
Contrast Ratio: 1300:1
Display Resolution: 1366 x 768
Viewing Angle: Right/Left: 178 ° , Up/Down: 178 °
Panel Response Time: 8ms (gray to gray)
Advanced Video Processor:
CineMotion®/Film Mode/Cinema Drive,
Contrast enhancer circuit, Green and blue
enhancer, Motion and edge adaptive I/P
converter, MPEG noise reduction
Convenience
Timer Clock: Yes
Inputs and Outputs
Analog Audio Input(s): 5 (4 Rear/1 Side)
Audio Out (Variable/Fixed): 1 (Rear)
Component Video (Y/Pb/Pr ) Input(s): 2 (Rear)
Composite Video Input(s): 3 (2 Rear/1 Side)
Digital Audio Output(s): 1 (Rear)
RF Connection Input(s): 1 (Rear)
S -Video Input(s): 2 (1 Rear/1 Side)
Headphone Output(s): 1 (Side)
PC Video Input(s): 1 (Rear)
HDMI ™ Connection(s): 1 (Rear) with L/R RCA
audio connections
Power
Power Consumption (in Operation): 200W
Power Consumption (in Standby): Less than
0.1W
Power Requirements: AC 120-240V, 50/60Hz
Regulation and Standard Compliance
Energy Star ®Compliant: Yes
Service and Warranty Information
Limited Warranty: 1 Year Parts / 1 Year Labor
Dimensions
Weight: 59.52lbs (27.0kg) with pedestal;
46.30lbs (21.0kg) without pedestal
Measurements: 38.90" x 28.19" x 13.15" (988 x 716
x 334mm) with pedestal; 38.90" x 26.14" x
4.06" (988 x 664 x 103mm) without pedestal
Supplied Accessories
Tabletop Stand
RM-YD005 Remote Control
AA x 2 Batteries
Coaxial Cable (x1)
HD-15 to HD15 Cable (x1)
Support belt and screws
Operation Manual
Optional Accessories
SU -WL51 Wall Mount Bracket
SU -PW2 Wall Mount Bracket
Color: Medium Silver
UPC Code: 027242690462
1.ScreenSizemeasureddiagonally.
2.LimitedtoresolutionssupportedbyboththePCandtheSony TV. See
SonyTVusersmanualandPCdocumentationforsupportedresolutions
©2006SonyElectronicsInc.Allrightsreserved.
Sony,BRAVIA,BRAVIAEngine,andCineMotionaretrademarksofSony.SRS
andtheSRSsymbol,TruSurroundaretrademarksofSRSLabs,Inc.Dolby
DigitalisaregisteredtrademarkofDolbyLaboratories.ThisTVincorporates
High - DefinitionMultimediaInterface(HDMI™ ) technology.HDMI,theHMDI
logoandHigh - DefinitionMultimediaInterfacearetrademarksorregistered
trademarksofHDMILicensingLLC.Allothertrademarksarepropertyof
theirrespectiveowners.
Featuresandspecificationsaresubjecttochangewithoutnotice.Non -
metricweightsandmeasuresareapproximate.
