Sony BRAVIA KDL-52V5100 Installation and operation manual

KDL- 52V5100
52" BRAVIA V Series LCD TV
®
Key Features
16:9 Full HD 1080p Resolution Panel
(1920x1080)
Dynamic Contrast Ratio: 50,000:1
BRAVIA Engine ™2 fully digital video processor
Motionflow ™ 120Hz technology
USB with photos and music
BRAVIA Link compatibility
®
7 HD Inputs (HDMI x4/ Component x2/ PC x1)
BRAVIA Sync capable
®
3
ACE (Advanced Contrast Enhancer)
Light Sensor ™ technology
24p True Cinema™capable
Favorites Menu
VESA compatible hole spacing
®
ATSC™ / NTSC tuner with QAM
4
Key Technologies
16:9 Full HD 1080p Resolution Panel (1920x1080) 16:9 Full HD 1080p resolution panel (1920x1080) accepts any
HDTV signal and renders it with optimum resolution, so you can take full advantage of Blu - ray Disc™ players and Sony
PLAYSTATION 3 entertainment systems that can deliver 1080p content.
®
®
Dynamic contrast Dynamic contrast involves real - time image processing that results in deep blacks in darker
scenes, as well as fine details in shadows and other dark areas of the picture for a difference you can truly see.
Motionflow™120Hz technology Motionflow™120HZ technology doubles the frame rate to help remove judder in
film sources, HD content, and broadcast movies and primetime programming, creating smoother, more fluid motion
that delivers a natural and realistic viewing experience.
BRAVIA Engine™2 fully digital video processor The BRAVIA Engine 2 fully digital video processor uses a
collection of unique Sony technologies to significantly reduce noise, enhance overall image detail, and optimize
contrast so every scene produces sharp, vibrant, life - like images and color.
HD input x 7 Get versatile HD connection options with seven HD inputs. Four HDMI™inputs (up to 1080/60p
capable)1 let you connect a Sony PLAYSTATION 3 entertainment system, Blu - ray Disc™player, or any other HDMI -
capable equipment and get uncompressed digital video and multi - channel digital audio on a single cable. An HD
component input and an HD combo input (1080/60i capable) provide added HD - capable connectivity, and a PC
input2 (HD - 15 pin) offers the added versatility of using your HDTV as a computer monitor.
®
®
USB with photos and music Connect your camera, USB - enabled MP3 player, or USB storage device directly to your
HDTV's USB input to view photos on the big screen or listen to your favorite MP3 ’ s.
BRAVIA Link compatibility BRAVIA Link compatibility expands your HDTV ’ s capabilities by letting you connect
optional BRAVIA Link modules, including the BRAVIA DVD Link, BRAVIA Wireless Link, and BRAVIA Input Link (all sold
separately).
®
BRAVIA ® Sync capable BRAVIA Sync capability combines the one - touch access and control functionality of
BRAVIA Theatre Sync™with the ability to control CEC - enabled Sony Handycam camcorders and Cyber - shot digital
still cameras using the TV ’ s remote and an on - screen display.BRAVIA ® SyncTM capable: BRAVIA Sync capability
combines the one - touch access and control functionality of BRAVIA Theatre Sync™with the ability to control CEC -
enabled Sony ® Handycam ® camcorders and Cyber - shot ® digital still cameras using the TV ’ s remote and an on - screen
display via an HDMI ™connecting.
®
®
®
3

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 02/10/2009
KDL- 52V5100
52" BRAVIA V Series LCD TV
®
Please visit the Dealer Network for current
information at www.sony.com/dn
Features
General
Closed Captions (CC): Analog, Digital
On-Screen Display: Traditional
Finish (Surface Color): Piano Black
Display
Backlight Type: CCFL
Display Device: LCD
Video
Video Processing: BRAVIA Engine 2 ™Technology
CineMotion® Reverse 3:2 Pulldown Technology: Yes
Game Mode: Yes
Wide Mode: Full, Normal, Wide Zoom, Zoom, Full Pixel
3D Comb Filter: Yes
Auto Wide: Yes
4:3 Default: Yes
24p True Cinema™Technology: Yes
Picture Mode: Vivid, Standard, Cinema, Custom, Photo-
Vivid, Photo-Standard, Photo-Original, Photo-Custom
Advanced Contrast Enhancer (ACE): Yes
Motionflow™Technology: Motionflow™ 120Hz
Audio
Digital Amplifier: Standard
Auto SAP: Yes
Auto Mute (on no signal): Yes
Steady Sound® Automatic Volume Control: Yes
Audio Out: Fixed
Stereo System: MTS
Dolby ®: Dolby ® Digital (for broadcasting)
Alternate Audio (Digital): Yes
SRS ®: SRS® TruSurround XT®
Sound Mode: Clear Voice, Dynamic, Custom, Standard
Convenience
Channel Jump: Yes
Favorite Channel: Standard
Multiple Language Display: English, Spanish, French
Info Banner: PSIP, XDS
Sleep Timer: Yes
Clock: Yes
Input Skip: Manual
Channel Surf: Yes
Channel Block (with password): Yes
Edit Channel Labels: Yes
Label Inputs: Yes
ID-1 Detection: Yes
Initial Setup: Yes
On/Off Timer: Yes
USB Application(s): Photo Viewer (JPEG), Music Player
(MP3)
Theatre Mode (Theatre Button): Yes
Show/Hide Channels: Yes
Auto Shut-off: Yes
BRAVIA® Sync™: Yes
Parental Control: Yes
BRAVIA® Sync™Menu Button: Yes (on remote control)
PIP (Picture in Picture): PC Input/TV
Channel Labels: Yes
Control for HDMI™(HDMI™CEC): Yes
Auto Photo Mode: Yes (via USB)
On-Screen Clock: Yes
Start Up BRAVIA® Logo Display: Yes
Specifications
Display
Native Resolution: 1920 x 1080
Display Resolution: 1920 x 1080p (Full HD)
Aspect Ratio: 16:9
Color Range (xy): 72% of NTSC
TV System
Tuner (Cable): Clear QAM
Tuner (Terrestrial): ATSC™ / NTSC
Channel Coverage: VHF: 2- 13ch
UHF: 14 - 69ch
CATV (analog): 1- 135ch
CATV (digital) : 1- 135ch
TV System (Analog): M
Number of Tuners (Digital): 1(Hybrid)
TV System (Digital): ATSC
Color System: NTSC
Video
Video Signal: 1080/60P (HDMI ™ / COMPONENT), 1080/60I,
1080/24P (HDMI ™ ONLY), 720/60P, 480/60P, 480/60I
Audio
Audio Power Output: 20W (10W X 2)
Speaker Configuration: 2.0
Inputs and Outputs
Component Video (Y/Pb/Pr ) Input(s): 2 (Rear) (1 Fix /
1 Selectable)
Composite Video Input(s): 2 (1 Side / 1 Rear
(Selectable))
Digital Audio Output(s): Optical Digital Output -1 (Rear)
RF Connection Input(s): 1 (Rear)
S -Video Input(s): 1 (Side)
Analog Audio Input(s) (Total): 5 (2 Side, 3 Rear)
Audio Out: 1 (Rear)
HDMI™Connection(s) (Total): 4 (3 Side /1 Rear)
PC In (D-Sub) + Audio In (Stereo Mini): 1 (Side)
USB 2.0: 1 (Side)
HDMI™Connection(s) (w/ Analog Audio In): 1 (Rear)
HDMI™PC Input: Yes
S -Video Detection: Yes
AC Power Input: 1 (Rear)
Analog Audio Input(s) for HDMI™: 1 (Rear)
USB 1.1: 1 (Rear) (Service only)
Power
Power Consumption (in Operation): 295 W max
Power Consumption (in Standby): Less than 1W
Power Requirements (voltage): AC 120V
Power Requirements (frequency): 60HZ
Regulation and Standard Compliance
VESA ® Hole Spacing Compatible: Yes
VESA ® Hole Pitch: Yes
Service and Warranty Information
Limited Warranty Term: 1 Year Labor / 1 Year Parts
Online Instruction Manual: Yes
Energy Saving & Efficiency
LightSensor™Technology: Yes
Power Saving Modes: Yes
Energy Star® compliant: Meets Energy Star® Version 3.0
Eco Settings: Yes
Dynamic Backlight Control: Yes
Backlight Off Mode: Yes
PC Power Management: Yes
Dimensions
Weight: 76.3 lbs. (34.6kg) with pedestal; 66.1 lbs. (30kg)
without pedestal
Measurements: 49.75 x 34.25 x 14.375 in (1262 x 869 x
362mm) with pedestal; 49.75 x 32.5 x 4.625 in (1262 x
823 x 115mm) without pedestal
Supplied Accessories
Remote Control RM- YD028
Batteries (Type AA x2)
AC Power Cord (attached)
Screws (4) for pedestal
Operating Instructions
Quick Setup Guide
Warranty Card
Table Top Stand (separate, pre-assembled)
Optional Accessories
SU-WL500 Wallmount Bracket
BRAVIA DVD Link
BRAVIA Input Link
BRAVIA Wireless Link
UPC Code: 027242752948
1.HDMI™ connectorrequired and sold separately
2.Limited to resolutions supported by both the PCandtheSony ® TV.See
SonyTVuser'smanualand PC documentation for the supported
resolutions.
3.BRAVIA®SyncworkswithselectSonyHDTVs, home theater,and
digital imaging products. Theatre Sync ™ featuremustbeinall
products for one - touchaccess and control. Check owner ’ smanuals
forcompatibility.
4.Checkwithyour local TV station or cable company for details on
accessing or subscribing to HD content.
