Sony KDL-32BX326 User manual

2
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
TABLE OF CONTENTS
SECTION TITLE PAGE
Safety-Related Component Warning .......................................................................................................................................................................... 3
Safety Check-Out ....................................................................................................................................................................................................... 5
SECTION 1: DIAGRAMS................................................................................................................................................................................................... 6
1-1. Circuit Boards Location ...................................................................................................................................................................................... 6
1-2. Printed Wiring Boards and Schematic Diagrams Information ............................................................................................................................ 7
1-3. Block Diagram.................................................................................................................................................................................................... 9
1-4. Connector Diagrams ........................................................................................................................................................................................ 10
1-5. Schematics and Supporting Information .......................................................................................................................................................... 14
A Board Schematic Diagram (1 of 18).............................................................................................................................................................. 14
A Board Schematic Diagram (2 of 18).............................................................................................................................................................. 15
A Board Schematic Diagram (3 of 18).............................................................................................................................................................. 16
A Board Schematic Diagram (4 of 18).............................................................................................................................................................. 17
A Board Schematic Diagram (5 of 18).............................................................................................................................................................. 18
A Board Schematic Diagram (6 of 18).............................................................................................................................................................. 19
A Board Schematic Diagram (7 of 18).............................................................................................................................................................. 20
A Board Schematic Diagram (8 of 18).............................................................................................................................................................. 21
A Board Schematic Diagram (9 of 18).............................................................................................................................................................. 22
A Board Schematic Diagram (10 of 18)............................................................................................................................................................ 23
A Board Schematic Diagram (11 of 18)............................................................................................................................................................ 24
A Board Schematic Diagram (12 of 18)............................................................................................................................................................ 25
A Board Schematic Diagram (13 of 18)............................................................................................................................................................ 26
A Board Schematic Diagram (14 of 18)............................................................................................................................................................ 27
A Board Schematic Diagram (15 of 18)............................................................................................................................................................ 28
A Board Schematic Diagram (16 of 18)............................................................................................................................................................ 29
A Board Schematic Diagram (17 of 18)............................................................................................................................................................ 30
A Board Schematic Diagram (18 of 18)............................................................................................................................................................ 31
LIPS22 Board Schematic Diagram (KDL-22BX325 Only)................................................................................................................................33
GT32 Board Schematic Diagram (KDL-32BX325/32BX326/32BX425 Only) (Page 1 of 2)............................................................................. 35
GT32 Board Schematic Diagram (KDL-32BX325/32BX326/32BX425 Only) (Page 2 of 2)............................................................................. 36
GT40 Board Schematic Diagram (KDL-40BX425 Only) (Page 1 of 2)............................................................................................................. 38
GT40 Board Schematic Diagram (KDL-40BX425 Only) (Page 2 of 2)............................................................................................................. 39
H1 Board Schematic Diagram.......................................................................................................................................................................... 41
H2 Board Schematic Diagram.......................................................................................................................................................................... 43
SECTION 2: ELECTRICAL PARTS LIST........................................................................................................................................................................ 45
APPENDIX A: ENCRYPTION KEY COMPONENTS..................................................................................................................................................... A-1

3
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
SAFETY-RELATED COMPONENT WARNING
There are critical components used in LCD color TVs that are important for safety. These components are identied with shading and
!
mark on the schematic diagrams and the electrical parts list. It is essential that these critical parts be replaced only with the part number
specied in the electrical parts list to prevent electric shock, re, or other hazard.
NOTE: Do not modify the original design without obtaining written permission from the manufacturer or you will void the original parts and
labor guarantee.
USE CAUTION WHEN HANDLING THE LCD PANEL
When repairing the LCD panel, be sure you are grounded by using a wrist band.
When installing the LCD panel on a wall, the LCD panel must be secured using the 4 mounting holes on the rear cover.
To avoid damaging the LCD panel:
Údo not press on the panel or frame edge to avoid the risk of electric shock.
Ú do not scratch or press on the panel with any sharp objects.
Údo not leave the module in high temperatures or in areas of high humidity for an extended period of time.
Údo not expose the LCD panel to direct sunlight.
Ú avoid contact with water. It may cause a short circuit within the module.
Ú disconnect the AC adapter when replacing the backlight (CCFL) or inverter circuit.
(High voltage occurs at the inverter circuit at 650Vrms.)
Ú always clean the LCD panel with a soft cloth material.
Ú use care when handling the wires or connectors of the inverter circuit. Damaging the wires may cause a short.
Úprotect the panel from ESD to avoid damaging the electronic circuit (C-MOS).
LEAKAGE CURRENT HOT CHECK CIRCUIT
• Avoid contact with water as it may a short circuit within the module.
• If the surface of panel becomes dirty, please wipe it off with a soft material. (Cleaning with a dirty or rough cloth may
damage the panel.)
• If you want to replace with the new backlight (CCFL) or inverter circuit, must disconnect the AC adapter because high
voltage appears at inverter circuit about 650Vrms.
• Handle with care wires or connectors of the inverter circuit. If the wires are pressed cause short and may burn or take
fire.
Leakage Current Hot Check Circuit
KLV-32U100M (UC) 5

4
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
The circuit boards used in these models have been processed using
Lead Free Solder. The boards are identified by the LF logo located
close to the board designation e.g. H1 etc [ see example ]. The
servicing of these boards requires special precautions to be taken as
outlined below.
example
It is strongly recommended to use Lead Free Solder material in order to guarantee optimal quality of new solder joints.
Lead Free Solder is available under the following part numbers :
Due to the higher melting point of Lead Free Solder the soldering iron tip temperature needs to be set to 370 degrees centigrade.
This requires soldering equipment capable of accurate temperature control coupled with a good heat recovery characteristics.
rebmuntraP retemaiD skrameR
91-500-046-7 mm3.0 gK52.0
02-500-046-7 mm4.0 gK05.0
12-500-046-7 mm5.0 gK05.0
22-500-046-7 mm6.0 gK52.0
32-500-046-7 mm8.0 gK00.1
42-500-046-7 mm0.1 gK00.1
52-500-046-7 mm2.1 gK00.1
62-500-046-7 mm6.1 gK00.1

5
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer:
1. Check the area of your repair for unsoldered or poorly soldered
connections. Check the entire board surface for solder splashes and
bridges.
2. Check the interboard wiring to ensure that no wires are “pinched” or
touching high-wattage resistors.
3. Check that all control knobs, shields, covers, ground straps, and
mounting hardware have been replaced. Be absolutely certain that
you have replaced all the insulators.
4. Look for unauthorized replacement parts, particularly transistors,
that were installed during a previous repair. Point them out to the
customer and recommend their replacement.
5. Look for parts which, though functioning, show obvious signs of
deterioration. Point them out to the customer and recommend their
replacement.
6. Check the line cords for cracks and abrasion. Recommend the
replacement of any such line cord to the customer.
7. Check the antenna terminals, metal trim, “metallized” knobs, screws,
and all other exposed metal parts for AC leakage. Check leakage as
described below.
Leakage Test
The AC leakage from any exposed metal part to earth ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microamperes).
Leakage current can be measured by any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or RCA
WT-540A. Follow the manufacturers’ instructions to use these
instructions.
2. A battery-operated AC milliampmeter. The Data Precision 245
digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a VOM
or battery-operated AC voltmeter. The “limit” indication is 0.75
V, so analog meters must have an accurate low voltage scale.
The Simpson’s 250 and Sanwa SH-63TRD are examples of
passive VOMs that are suitable. Nearly all battery-operated digital
multimeters that have a 2 VAC range are suitable (see Figure A).
How to Find a Good Earth Ground
A cold-water pipe is a guaranteed earth ground; the cover-plate
retaining screw on most AC outlet boxes is also at earth ground. If the
retaining screw is to be used as your earth ground, verify that it is at
ground by measuring the resistance between it and a cold-water pipe
with an ohmmeter. The reading should be zero ohms.
If a cold-water pipe is not accessible, connect a 60- to 100-watt
trouble- light (not a neon lamp) between the hot side of the receptacle
and the retaining screw. Try both slots, if necessary, to locate the hot
side on the line; the lamp should light at normal brilliance if the screw
is at ground potential (see Figure B).
To Exposed Metal
Parts on Set
0.15 µF
Earth Ground
AC
Voltmete
r
(0.75V)
Trouble Light
AC Outlet Box Ohmmeter
Cold-water Pipe
Figure A. Using an AC voltmeter to check AC leakage. Figure B. Checking for earth ground.

6
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
SECTION 1: DIAGRAMS
1-1. CIRCUIT BOARDS LOCATION
LIPS22 (KDL-22BX325 ONLY)
H2 (SWITCH UNIT)
H1
A
GT32 (KDL-32BX325/32BX326/32BX425 ONLY)
GT40 (KDL-40BX425 ONLY)
H2 (SWITCH UNIT)
H1
A
Figure 1-1. KDL-22BX325
Figure 1-2. KDL-32BX325/32BX326/32BX425/40BX425

7
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
1-2. PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS INFORMATION
All voltages are in V.
S : Measurement impossibility.
: B+line.
: B-line. (Actual measured value may be different).
: signal path. (RF)
Circled numbers are waveform references.
The components identied by shading and
!
symbol are critical for safety. Replace
only with part number specied.
The symbol indicates a fast operating fuse and is displayed on the component
side of the board. Replace only with fuse of the same rating as marked.
NOTE: The components identied by a red outline and a mark contain condential
information. Specic instructions must be adhered to whenever these components
are repaired and/or replaced.
See Appendix A: Encryption Key Components in the back of this manual.
All capacitors are in µF unless otherwise noted. pF : µµF 50WV or
less are not indicated except for electrolytics and tantalums.
All electrolytics are in 50V unless otherwise specied.
All resistors are in ohms. kΩ=1000Ω, MΩ=1000kΩ
Indication of resistance, which does not have one for rating
electrical power, is as follows: Pitch : 5mm
Rating electrical power : 1/4 W
1/4 W in resistance, 1/10 W and 1/16 W in chip resistance.
: nonammable resistor
: fusible resistor
: internal component
: panel designation and adjustment for repair
: earth ground
: earth-chassis
All variable and adjustable resistors have characteristic curve B,
unless otherwise noted.
Readings are taken with a color-bar signal input.
Readings are taken with a 10MΩdigital multimeter.
Voltages are DC with respect to ground unless otherwise noted.
Voltage variations may be noted due to normal production
tolerances.

8
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
G
D
S
B1 E1
C2
B2 C1E2
2
3
4
5
6
7
8
9
–
1
G
D
S
B2 E2C1
B1 C2
E1
B2 E2C1
B1 C2E1
B2 E2
C1
B1 C2E1
B1 E1
E2
C1(B2)C2
B1
E2
C1
C2
(B2)
E1
(B2)
E1
E2
B1
C2C1
B1
E1
C2
B2
C1
E2
G
SS
D
G
D
B1
E1
C2
B2
C1
E2
B1
E2
C2C1(B2)
E2
B1
C1
C2E1(B2)
C2
B1
C1
E2E1(B2)
C2
B1
C1
E2
B2
E1
C2
Ver.1.6
Transistor
(FET)
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Discrete semiconductor
(Chip semiconductors that are not actually used are included.)
Diode
Diode
Diode
Diode
Diode
Diode
Diode
Diode
Diode
Diode
Source
Source
Anode Anode
(NC)
(NC)
Cathode
Anode
Cathode
Common
Cathode Cathode
Common
Cathode Cathode
Common
Common
Common
Common
Cathode
Anode
Base Emitter
Collector
Base Emitter
Collector
Drain
Gate
Gate
Drain
Device Printed symbol Terminal name Circuit
Terminal name of semiconductors in silk screen
printed circuit ( )
Anode
Anode
Anode Cathode
Anode Anode
Cathode
Transistor
(FET)
Transistor
(FET)
Emitter
Collector
Base
Transistor
Source
Gate
Drain
Cathode
Anode
Anode Cathode
Anode
Anode
*
18
11
17
16
15
14
13
12
10
21
20
19
23
22
REFERENCE INFORMATION
RESISTOR
: RN METAL FILM
: RC SOLID
: FPRD NONFLAMMABLE CARBON
: FUSE NONFLAMMABLE FUSIBLE
: RW NONFLAMMABLE WIREWOUND
: RS NONFLAMMABLE METAL OXIDE
: RB NONFLAMMABLE CEMENT
: ADJUSTMENT RESISTOR
COIL
: LF-8L MICRO INDUCTOR
CAPACITOR
: TA TANTALUM
: PS STYROL
: PP POLYPROPYLENE
: PT MYLAR
: MPS METALIZED POLYESTER
: MPP METALIZED POLYPROPYLENE
: ALB BIPOLAR
: ALT HIGH TEMPERATURE
: ALR HIGH RIPPLE

9
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
1-3. BLOCK DIAGRAM























































































10
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
1-4. CONNECTOR DIAGRAMS
CN601
CN701
CN408
CN401
CN902
RED
RED
BLU
BLU
CN1
Main Board
Power Board
Panel
Keypad Board
IR/LED Board
CN001
CN201
T-CON Board
Figure 4-1. KDL-22BX325

11
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
Figure 4-2. KDL-32BX325/32BX326
CN601
CN701
CN409 CN401
CN902
CN1
Main Board
Power Board
Panel
Keypad Board
IR/LED Board
CN001
Inverter Board
CN801
CN903
CN201
T-CON Board

12
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
Figure 4-3. KDL-32BX425
CN601
CN701
CN401
CN902
CN1
Main Board
Power Board
Panel
Keypad Board
IR/LED Board
CN001
Inverter Board
CN1
CN903
CN201
CN408
T-CON Board

13
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
Figure 4-4. KDL-40BX425
CN601
CN701
CN401
CN902
CN1
Main Board
Power Board
Panel
Keypad Board
IR/LED Board
CN001
Inverter Board
CN1
CN903
CN201
CN408
T-CON Board

KDL-22BX325/32BX325/32BX326/32BX425/40BX425
14
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
1-5. SCHEMATICS AND SUPPORTING INFORMATION
A BOARD SCHEMATIC DIAGRAM (1 OF 18)
Control Interface
+5V Switch
Detection
FOR
19"22"
16V
SWITCH
+12V
INVERTER ON/OFF
H: OFF
L: ON
INVERTER ON/OFF
1.2 x (1+ 0/110) = 1.2V
Bright_Adj
Max:3.3V
Min: 0V
BRIGHT ADJUST
AC Detect
R2
Vout = 0.9x(R1+R2)/R2
R1
MAIN POWER
(+16V) for 22"
HI = > POWER_ON
LO = > POWER_OFF
del R702
del R711
OPWRSB
BL_DIMMING
BL_ON/OFF
AC_DET
BL_ON/OFF
BL_DIMMING
AC_DET
OPWRSB
AC_DET#
INVERTER_DET#
INVERTER_ON_OFF
BRIGHT_ADJ
AC_DET# INVERTER_DET#
5V
STANDBY_CON24V
INVERTER_ON_OFF
24V
5V
BRIGHT_ADJ
OPWRSB10
BL_DIMMING14
BL_ON/OFF14
AC_DET14
DVDD3V36,9,10,14,15,16,19
3V3SB7,8,10,14,18
GND3,4,5,6,7,8,9,10,11,12,13,14,15,16,17,18,19
VCCK10,14
AVDD3V35,8,11,12,13,14,15
AVDD1V28,9,10,13,15,16
+12V12,15,18
+5VSB4,7,18
+5V_SW6,8,11,13,14,15,16,17,18
+24V12
41 V42
+12VSB14
INVERTER_DET#14
STANDBY 14
AC_DET
3V3SB
AVDD3V3
AVDD1V2
+5VSB
+5V_SW
+5VSB
VCCK
AVDD3V3
DVDD3V3
VCCK
+12V
3V3SB
+5VSB
AVDD1V2
AVDD3V3
+5V_SW
+12V
+12VSB
+5V_SW
DVDD3V3+5V_SW
DVDD3V3
DVDD3V3
+5V_SWDVDD3V3
DVDD3V3
3V3SB
VCCK
+5VSB
+24V
DVDD3V3
+12VSB
24V
+12VSB
+12VSB +24V
+5VSB
R723
NC/4K7 1/10W
FB704
120R/6000mA
12
C708
10uF 10V
+
C703
470uF 16V
Q701
2SK1828
3
1
2
R701
0R01 1/10W
R70322K 1/10W
C712
1uF 25V
R722
2K 1/10W
C717
10uF 10V
FB707
33 OHM
C705
1uF 25V
C725
10uF 10V
U701
G1084-33TU3Uf
32
1
VIN VOUT
GND
R719
100R 1/10W 5%
C701
0.1uF 50V
R727
100R 1/10W 5%
R712
3.24K 1%
R728
100R 1/10W 5% Q704
MMBT3904
R724
4.7K 1/10W
R732
0R05 4A 1/4W
U702
G1117-33T63Uf
32
1 4
VI VO
GND
4
R716
10K 1/10W
R706
100K 1/10W
+
C719
100uF16V
Q702
AON4421
1 2 3 4 5
6 7 8
D D D G S
D D D
R710
0R05 4A 1/4W
R707
2.7K 1/10W
C714
10NF 50V
CN701
CONN
2
4
6
8
10
12
14
1
3
5
7
9
11
13
R717
4.7K 1/10W
R721
NC/4K7 1/10W
R729
68K 1/10W
+
C710
100uF16V
R715
1K 1/10W
+
C704
330UF 25V
C724
NC/0.1uF 50V
R704
51K 1/10W
U703
BD9329EFJ
1
2
3
4
5
6
7
8
9
BST
VIN
SW
GNDFB
COMP
EN
SS
E-Pad C713
0.1uF 50V
C726
NC/22 10V
F700
5A 32V
R714
2K 1/16W
C727
1uF 25V
R731
4.7K 1/10W
R726
10K 1/10W
U705
G912T63U
32
1
VI VO
GND
C711
1uF 25V
FB701
120R/6000mA
12
C720
1uF 25V
R733
NC
C716
0.1uF 50V
C706
NC/4U7 6V3
Q703
BC847C
+
C715
330UF 25V
C721
6.8nF 50V
R730
4.7K 1/10W
C702
1uF25V
R718
0R05 4A 1/4W
R725
4.7K 1/10W
C718
NC/10U 10V
FB702 120R/6000m A
1 2
R708
0R05 4A 1/4W
R713
13K OHM +-1% 1/16W
R720
NC/15K 1/10W
+
C728
100uF/16V
R705
1K 1/10W
R734
0R01 1/10W
Q705
MMBT3904
Q706
NC/MMBT3906 PNP
1
23
L701 4.7uH
C707
1uF 25V
A 1/18
SYSTEM POWER
1-857-922-11 <AZ2TK> A-P1
1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 |
A
—
B
—
C
—
D
—
E
—
F
—
G
—
H
—
I
—
J
—

KDL-22BX325/32BX325/32BX326/32BX425/40BX425
15
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
A BOARD SCHEMATIC DIAGRAM (2 OF 18)
AV OUT AMUTE
Near MT5366Near CONNECTOR
AV_A_MUTE
AV_ROUT
A_MUTE
AV_A_MUTEV_MUTE
AV_VOUT
AV_LOUT
AV_LOUT
AV_ROUT
V_MUTE11,18
A_MUTE11,12,18
TUNER_BYPASS_OUT 13
AV_OUTL_PA 11
AV_OUTR_PA 11
GND2,4,5,6,7,8,9,10,11,12,13,14,15,16,17,18,19
R116
10K 1/10W
Q101
NC/BC847C
R114
470R 1/10W 1%
C110
NC/47pF 50V
Q100
2N3906S-RTK/PS
R118
2.2K 1/10W
R115
47K 1/10W 5%
FB145 NC/80 OHM
12
Q102
NC/BC847C
A
B
C
CN127
NC/JACK
2
1
4
3
6
5
7
A
B
CN125
NC/JACK
2
1
4
3
R112
75R 1/10W 1%
ZD105
NC/VPORT0603100KV05
12
ZD106
NC/VPORT0603100KV05
12
R113
470R 1/10W 1%
C112
NC/470P 50V
C109
NC/47pF 50V
R117
2.2K 1/10W
C111
NC/470P 50V
ZD107
NC/VPORT0603100KV05
12
A 2/18
AV IN OUT
1-857-922-11 <AZ2TK> A-P2
1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 |
A
—
B
—
C
—
D
—
E
—
F
—
G
—
H
—
I
—
J
—

KDL-22BX325/32BX325/32BX326/32BX425/40BX425
16
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
A BOARD SCHEMATIC DIAGRAM (3 OF 18)
Wake Up TV From Power Saving Mode
VGA SYNC SLICER
VGA CONNECTOR
Audio Input
VGA Audio Input
Near CONN.
Other Control Interface
Video Input
VGA Switch
Near MT5366
Near VGA CONN.
I2C
VGA_R_In
VGA_L_In
VGA_PLUGPWR
VSYNC#
VGASCL#
VSYNC#
HSYNC#
VGASDA#
HSYNC#
VGA11
GRN
VSYNC
HSYNC
RP
BP
SOG
VGACOM
GP
GRN
BLU
BLU
RED
RED
VGA11
VGASDA#
VGASCL
VGASDA
UART_SW
VGA_L_In
VGA_R_In
VGASCL
VGASDA
U0TX
U0RX
UART_SW
U0RX
U0TX
G_G
U0TXTX
TX
RX
RX
UART_SW
VGA11
VGA_Audio_L_In
VGA_Audio_R_In
VSYNC
HSYNC
BP
SOG
GP
VGACOM
RP
U0RX
VGASCL#
G_G VGA_L_In13
VGA_R_In13
VSYNC13
HSYNC13
31 PB
SOG13
31 PG
VGACOM13
31 PR
VGASCL13
VGASDA13
U0TX10
U0RX10
UART_SW14
+5VSB2,7,18
GND2,3,5,6,7,8,9,10,11,12,13,14,15,16,17,18,19
81 XR
81 XT
VGA1118
+5VSB
+5VSB
VGA_PLUGPWR
VGA_PLUGPWR VGA_PLUGPW R
VGA_PLUGPWR
VGA_PLUGPWR
R137
100R 1/16W 5%
R129 0R01 1/10W
C114
0.1uF 50V
ZD115
VPORT0603100KV05
12
D101
BAV70
3
1
2
ZD114
VPORT0603100KV05
12
R141
100OHM1/16W
R127
0R05 1/16W
C124
10N 50V
ZD113
VPORT0603100KV05
12
C122
10N 50V
R130
NC/4.7K 1/10W
R124
0R01 1/10W R125
75R 1/10W 1%
C118
1.5nF 50V
CN102
PHONE JACK
1
2
3
Q106
NC/BC847C
R138
NC/10K 1/10W
Q105
NC/2N7002
R134
75R 1/10W 1%
R121
10K 1/10W
C119
NC/5pF
R139
47KOHM +-1% 1/10W
R144
75R 1/10W 1%
R107 10K 1/10W
D100
BAV70
3
1
2
U110
NC7SB3157P6X
1
2
3
4
5
6B1
GND
B0A
VCC
S
CN101
D-SUB 15P
1
6
2
7
3
8
4
9
5
11
12
13
14
15
10
1716
18 19
R126
2.2K 1/10W
R128
0R01 1/10W
R133
100OHM1/16W
R119
10K 1/10W
ZD112
VPORT0603100KV05
12
R135
0R01 1/10W
U111
NC7SB3157P6X
1
2
3
4
5
6B1
GND
B0A
VCC
S
ZD108
VPORT0603100KV05
12
C123
10uF 10V
FB101 0R01 1/10W
12
C125
10uF 10V
R143
47KOHM +-1% 1/10W
R140
NC/1K 1/10W
R120
1K 1/10W
C115
10N 50V
ZD111
VPORT0603100KV05
12
C117
NC/5pF
C126
47pF 50V
R131
2.2K 1/10W
Q103
BC847C
C116
47pF 50V
R132
NC/4.7K 1/10W
C113
0.1uF 50V
FB100 0R01 1/10W
1 2
R123
0R01 1/10W
R122
100OHM1/16W
C120
10N 50V
ZD110
VPORT0603100KV05
12
R136
0R01 1/10W
FB102
0R01 1/10W
1 2 R142
NC/10K 1/10W
Q104
NC/2N7002
R111 10K 1/10W
ZD109
VPORT0603100KV05
12
C121
47pF 50V
A 3/18
VGA
1-857-922-11 <AZ2TK> A-P3
1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 |
A
—
B
—
C
—
D
—
E
—
F
—
G
—
H
—
I
—
J
—

KDL-22BX325/32BX325/32BX326/32BX425/40BX425
17
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
A BOARD SCHEMATIC DIAGRAM (4 OF 18)
YPbPr1 Video Input
NEARLY CONN.
YPbPr1 Audio Input
del zd117 ADD
D107 D108
PR_IN_1
PB_IN_1
YPbPr1R_IN
YPbPr1L_IN
PR1_DET
PR1_DET GPIO1
GPIO9
GPIO1
GPIO9
PR2_DET
Y_IN_1
PB0P 13
PR0P 13
Y0P 13
COM0 13
SOY0 13
YPbPr_L_In1 13
YPbPr_R_In1 13
CVBS0P 13
GND2,3,4,6,7,8,9,10,11,12,13,14,15,16,17,18,19
AVDD3V32,8,11,12,13,14,15
GPIO914
GPIO114
+5VSB4,7,18
AVDD3V3
AVDD3V3
AVDD3V3
+5VSB
+5VSB
C135
10N 50V
C1125
47nF 16V
R166
100OHM1/16W
ZD123
VPORT0603100KV05
12
R163
56R 1/10W 1%
R156
100 OHM 1/10W
C145
10uF 10V
R150
100OHM1/16W
C143
10uF 10V
C138
47pF 50V
R171
47KOHM +-1% 1/10W
R169
47KOHM +-1% 1/10W
C131
47pF 50V
ZD118
VPORT0603100KV05
12
R1152
100 OHM 1/10W
C141
10N 50V
C139
47pF 50V
C134
10N 50V
D108
BAS316
R4057 100R 1/10W 5%
C127
1.5nF 50V
R153
56R 1/10W 1%
E
A
B
C
D
CN111
JACK
1
2
3
4
5
6
7
8
9
10
11
12
FB105 0R01 1/10W
12
D107
BAV99
3
1 2
ZD120
VPORT0603100KV05
1 2
R4056
100K 1/10W
FB103
0R01 1/10W
12
FB107 0R01 1/10W
12
R162
56R 1/10W 1%
R4059 100R 1/10W 5%
R165
18R 1/10W 5%
ZD122
VPORT0603100KV05
12
C129
10N 50V
R157
18R 1/10W 5% R158
100OHM1/16W
R149
18R 1/10W 5%
R4058
100K 1/10W
A 4/18
YPBPR
1-857-922-11 <AZ2TK> A-P1
1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 |
A
—
B
—
C
—
D
—
E
—
F
—
G
—
H
—
I
—
J
—

KDL-22BX325/32BX325/32BX326/32BX425/40BX425
18
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
A BOARD SCHEMATIC DIAGRAM (5 OF 18)
Side AV(CVBS)Video & Audio input
Side AV Video & Audio
Near MT5366
SPDIF
Near Connector
HI = > POWER ON
EQUAL LENGTH and DIFFERENTIAL
IMPEDANCE 90ohm
USB PORT 0
LO = > POWER OFF
USB
OPTICAL
SPDIF OUT
LO=> OC
HI = > NORMAL
DEL ZD126 ADD
D105,D106
FROM CH
CVBS1P
SPDIF_OUT
SIDE_CVBS_IN
SIDE_AudioLIN
SIDE_AudioRIN
AV2_L_In
AV2_R_In
AV2_R_In
CVBS1P
AV2_L_In
USB_DP0
USB_DM0
USB_PWR_EN0
USB_OC_COM
USB_DP0
USB_DM0
CVBS_COM
CVBS_COM
SPDIF_OUT
USB_OC_COM
USB_PWR_EN0
AV2_L_In13
CVBS1P13
AV2_R_In13
SPDIF_OUT8,13
USB_DP015
USB_DM015
USB_PWR_EN014
USB_OC_COM14
+5V_SW2,8,11,13,14,15,16,17,18
GND2,3,4,5,7,8,9,10,11,12,13,14,15,16,17,18,19
DVDD3V32,9,10,14,15,16,19
CVBS_COM13
+5VSB4,7,18
+5V_SW
DVDD3V3
+5V_SW
DVDD3V3
DVDD3V3
+5VSB
+5VSB
R180
4.7K 1/10W
C148
47pF 50V
R177
47KOHM +-1% 1/10W
A
B
C
CN128
JACK
1
2
3
4
5
6
7
R174
75R 1/10W 1%
C151
10uF 10V
C149
1uF 10V
D105
BAV99
3
1 2
R178
10K 1/10W
ZD129
VPORT0603100KV05
12
C153 0.1uF 50V
ZD127
VPORT0603100KV05
12
CN603
CONNNECTOR
1
2
3
GND
VCC
VIN
D106
BAS316
R176
47KOHM +-1% 1/10W
ZD128
VPORT0603100KV05
12
C154 NC/10pF 50V
+
C152 100UF 50V
R175
0R01 1/16W
R173
100OHM1/16W
FB141 0R01 1/10W
1 2
ZD130
VPORT0603100KV05
12
1 2 3 4
CN103
CONN
1
2
3
4
65
R179
100R 1/10W 1%
C155 NC/10pF 50V
C147 47nF 16V
U112
G5250K1T1U
5
2
4
1 3
OUT
GND
IN
EN OC
R699
33R 1/10W 5%
C150
10uF 10V
C699
0.1uF 50V
A 5/18
SIDE AV/SPDIF/USB/SIDE HDMI
1-857-922-11 <AZ2TK> A-P5
1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 |
A
—
B
—
C
—
D
—
E
—
F
—
G
—
H
—
I
—
J
—

KDL-22BX325/32BX325/32BX326/32BX425/40BX425
19
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
A BOARD SCHEMATIC DIAGRAM (6 OF 18)
PORT 2


HDMI 2
HDMI 1
PORT 1


RR1XC-
RR1X2-
RR1X0+
RR1X1-
RR1X0-
RR1X2+
RR1X0-
RR1XC+ RR1X1+
RR1X2+
RR1XC+
RR1X2-
RR1XC-
RR1X0+
RR1X1+
RR1X1-
RR1X1-
HPD1
RR1X0+
RR1X2-
RR1XC+
DDC_SCL1
DDC_SDA1
RR1XC-
RR1X0-
RR1X1+
RR1X2+
RR2X1-
HEC-
RR2X0+
RR2X2-
RR2XC+
DDC_SCL2
DDC_SDA2
RR2XC-
RR2X0-
RR2X1+
RR2X2+
CEC_A2
OPWR2_5V
RR2X1+
RR2X0-
RR2X1-RR2X1-
DDC_SCL2
HPWR2
RR2X0+
RR2X2+
RR2XC+
DDC_SCL2
RR2XC+
RR2X0-
RR2XC-
RR2X2+
RR2XC+
RR2X0+
RR2X2-
RR2X1+
RR2X2-
RR2X1+
RR2X0+
CEC_A2
RR2X2+
RR2X1-
RR2XC-
RR2XC-
DDC_SDA2
HPD2
RR2X2-
RR2X0-
DDC_SDA2DDC_SDA1
HPWR1
DDC_SCL1
RR1X2+
RR1X0+
RR1XC-
RR1XC+
RR1X1-
RR1X2-
HPD1
RR1X0-
RR1X1+
DDC_SDA1
HEC+
HEC+
CEC_A1
CEC_A1
DDC_SCL1
OPWR1_5V
RR1X2+8
RR1X1+8
RR1XC-8
RR1X1-8
DDC_SCL18
RR1X2-8
HPD18
RR1X0+8
RR1X0-8
RR1XC+8
DDC_SDA18
RR2X2+8
RR2X1+8
RR2XC-8
RR2X1-8
DDC_SCL28
RR2X2-8
HPD28
RR2X0+8
RR2X0-8
RR2XC+8
DDC_SDA28
HD_CEC 8
GND2,3,4,5,6,8,9,10,11,12,13,14,15,16,17,18,19
OPWR2_5V8
3V3SB2,8,10,14,18
HEC+8
OPWR1_5V8
+5VSB2,4,18
OPWR2_5V
+5VSB
OPWR2_5V
OPWR2_5V
+5VSB
3V3SB
3V3SB
OPWR1_5V
OPWR1_5V
OPWR1_5V
+5VSB
ZD502
NC/VPORT0603100KV05
1 2
FB502 30R/700mA
12
D503
BAV70
3
1
2
CN502 HDMI
20
21
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
22
23
24
TH1
TH2
D2+
D2 Shield
D2-
D1+
D1 Shield
D1-
D0+
D0 Shield
D0-
CK+
CK Shield
CK-
CE Remote
NC
DDC CLK
DDC DATA
GND
+5V
HP DET
TH3
TH4
TH5
U504
NC/RClam p0524P.TCT
1
2
3
4
5 6
7
8
9
10
IN1
IN2
GND
IN3
IN4 OUT4
OUT3
GND
OUT2
OUT1
ZD510
NC/VPORT0603100KV05
1 2
FB500 30R/700mA
1 2
R508 47K 1/16W 5%
CN503 HDMI
20
21
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
22
23
24
TH1
TH2
D2+
D2 Shield
D2-
D1+
D1 Shield
D1-
D0+
D0 Shield
D0-
CK+
CK Shield
CK-
CE Remote
NC
DDC CLK
DDC DATA
GND
+5V
HP DET
TH3
TH4
TH5
ZD516
NC/VPORT0603100KV05
1 2
C502
100N 16V
ZD513
NC/VPORT0603100KV05
1 2
ZD515
NC/VPORT0603100KV05
1 2
ZD503
NC/VPORT0603100KV05
12
ZD517
NC/VPORT0603100KV05
1 2
ZD511
NC/VPORT0603100KV05
1 2
ZD518
NC/VPORT0603100KV05
1 2
D504
BAV70
3
1
2
D501
BAS316
U506
NC/RClam p0524P.TCT
1
2
3
4
5 6
7
8
9
10
IN1
IN2
GND
IN3
IN4 OUT4
OUT3
GND
OUT2
OUT1
R510 47K 1/16W 5%
U505
NC/RClam p0524P.TCT
1
2
3
4
56
7
8
9
10
IN1
IN2
GND
IN3
IN4 OUT4
OUT3
GND
OUT2
OUT1
R501
27K 1/10W 5%
ZD512
NC/VPORT0603100KV05
1 2
C503
100N 16V
ZD514
NC/VPORT0603100KV05
1 2
U507
NC/RClam p0524P.TCT
1
2
3
4
5 6
7
8
9
10
IN1
IN2
GND
IN3
IN4 OUT4
OUT3
GND
OUT2
OUT1
R509 47K 1/16W 5% R511 47K 1/16W 5%
A 6/18
HDMI CONNECTOR
1-857-922-11 <AZ2TK> A-P7
1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 |
A
—
B
—
C
—
D
—
E
—
F
—
G
—
H
—
I
—
J
—

KDL-22BX325/32BX325/32BX326/32BX425/40BX425
20
KDL-22BX325/32BX325/32BX326/32BX425/40BX425
A BOARD SCHEMATIC DIAGRAM (7 OF 18)
HDMI 3
HDMI 2
HDMI 1
fiflfi 

( 17 mA )
( 61 mA )
Analog Power
MT5366
ARC2(Silicon Image)
HD_CEC
OSCL1
RR1X1-
RR2X2+
RR2XC+
RR1XC+
RR2X1+
RR1X2-
RR2X2-
RR2X0-
RR1X0-
RR2X1-
RR1X0+
RR2X0+
RR2XC-
RR1XC-
RR1X2+
HPD1
HPD2
RR1X1+
OSDA1
DDC_SCL1
DDC_SDA1
M_RX1_1B
M_RX1_2B
M_RX1_2
HDMI_HPD
AVDD33_HDMI
M_RX1_1
AVDD33_HDMI AVDD12_HDMI
M_RX1_C
AVDD12_HDMI
M_RX1_0
M_RX1_0B
M_RX1_CB
HDMI_CEC
HEC+
HD_CEC
HDMI_CEC
SPDIF_OUT
HEC-
HDMISW_RST#
HDMI_SCL
HDMI_SDA
HDMISW_SCL#
M_RX1_2B
HDMI_SCL
DDC_SCL1
M_RX1_0
RR2X1-
DDC_SDA2
RR1X0+
RR2XC+
HDMISW_RST#
RR1X2+
M_RX1_0B
HDMI_SDA
RR2X0+
RR2X2+
RR1X0-
HPD1
RR1X2-
HDMISW_SCL#
M_RX1_1
RR2X2-
HPDIN
DDC_SDA1
M_RX1_C
RPWR2_5V
RR1X1-
M_RX1_1B
HPD2
RPWR1_5V
M_RX1_CB
RR1X1+
M_RX1_2
RR2X1+
DDC_SCL2
RR2XC-
RR2X0-
HDMISW_SDA#
RPWR1_5V
RPWR2_5V
TPWR
TPWR
HDMISW_SDA#
HDMI_HPD
DDC_SCL2
DDC_SDA2
HDMI_SW_RST
HDMI_SW_RST
RR1XC+
RR1XC-
HEC+HECC+
SPDIF_OUT
OPWR1_5V7
OPWR2_5V7
OSDA110,12,15
OSCL110,12,15
RR1XC+7
RR1X0-7
RR1X1+7
RR2X1+7
HPD27
RR2XC+7
RR1XC-7
RR1X2+7
RR2XC-7
RR2X2+7
RR2X2-7
RR2X0+7
RR2X1-7
RR1X1-7
HPD17
RR2X0-7
RR1X2-7
RR1X0+7
HD_CEC7
DDC_SDA17
DDC_SCL17
DDC_SCL27
DDC_SDA27
AVDD3V32,5,11,12,13,14,15
AVDD1V22,9,10,13,15,16
+5V_SW2,6,11,13,14,15,16,17,18
+5VSB2,4,7,18
GND2,3,4,5,6,7,9,10,11,12,13,14,15,16,17,18,19
3V3SB2,7,10,14,18
HEC+7
SPDIF_OUT6,13
HPD27
OSCL1 10,12,15
OPWR1_5V7
OPWR2_5V7
OSDA1 10,12,15
HDMI_SW_RST14
ARC_SW
OPWR1_5V
OPWR2_5V
AVDD3V3
AVDD1V2
AVDD1V2
AVDD3V3
+5V_SW
+5VSB
3V3SB
AVCC1V8
3V3SB_9185
3V3SB_9185
AVCC1V8
3V3SB_9185
AVCC1V8
DVDD1V8
AVCC1V8
AVCC1V8
AVCC1V8
3V3SB_9185
3V3SB_9185
AVCC1V8
AVCC1V8
3V3SB_9185
3V3SB_9185
DVDD1V8
DVDD1V83V3SB_9185
AVCC1V8
AVCC1V8
DVDD1V8
3V3SB_9185
3V3SB_9185
3V3SB_9185 3V3SB
+5V_SW
+5V_SW
AVDD3V3
AVDD3V3
C504
10uF 10V
C522
NC/1uF 25V
C518
10uF 10V
U508
NC/SN74LVC1G125DBVR
1
2
3 4
5
OE
A
GND Y
VCC
R519
0R01 1/10W
C527
0.1uF 50V
R545
NC/180ohm 1/16W +/-5%
R560
0R01 1/10W
R503 0R05 1/16W
R548
10K 1/10W
C524
10uF 10V
C511
0.1uF 50V
R547
NC/82R 1/16W 5%
R523
0R01 1/10W
FB507
220R/2000mA
1 2
C501
1uF 25V
R525
NC/100K 1/10W
C523
10uF 10V
C517
NC/10U 10V
C528
0.1uF 50V
C555
100N 16V
R513 4.7K 1/10W
R533
NC/10K 1/16W 5%
C512
0.1uF 50V
C507
0.1uF 50V
R514
10K 1/16W 5%
R520
NC/100K 1/10W
R528
0R05 1/16W
R543
NC/10K+-5%1/16W
MT5366GSNG
U401G
AD6
AB6
AC6
AC5
AB5
AE1
AA6
AC4
AE3
AD3
AE4
AD4
AE5
AD5
AE2
AD2
PWR5V
HDMI_CEC
HDMI_HPD
HDMI_SCL
HDMI_SDA
AVDD33_HDMI
AVDD12_HDMI
AVSS33_HDMI
RX_0
RX_0B
RX_1
RX_1B
RX_2
RX_2B
RX_C
RX_CB
R524
56R 1/10W 1%
FB505
220R/2000mA
1 2
C529
0.1uF 50V
R505
NC/0R05 1/16W
R542
NC/10K 1/16W
R515
10K 1/16W 5%
R544
NC/100K 1/16W
R502
NC/0R05 1/16W
C510
10uF 10V
C509
0.1uF 50V
R522
120R 1% 1/10W
C521
NC/0.1uF 25V
C530
0.1uF 50V
C505
10uF 10V
R534
0R01 1/10W
R530 0R01 1/10W
R516
10K 1/16W 5%
R556
0R01 1/10W
R529 0R01 1/10W
C525
0.1uF 50V
U502
G1117T63Uf
3
1
2
4
VIN
GND
VOUT
TH
R541
NC/100R 1/16W
C531
0.1uF 50V
R512
1K 1/16W 5%
U501
SiI9185ACTU
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
TX2+
TX2-
AGND
TX1+
TX1-
AVCC18
TX0+
TX0-
AGND
TXC+
TXC-
ExtSWING
RESET#
LSDA/PSEL0
LSCL/PSEL1
HPD0
AVCC18
R0XC-
R0XC+
AGND
R0X0-
R0X0+
AVCC33
R0X1-
R0X1+
AGND
R0X2-
R0X2+
AVCC18
DSDA0
DSCL0
RPWR0
DVDD18
DGND
I2CSEL/INT
HPD1
AVCC18
R1XC-
R1XC+
AGND
R1X0-
R1X0+
AVCC33 R1X1-
R1X1+
AGND R1X2-
R1X2+
AVCC18 DSDA1 DSCL1
RPWR1 CEC_D
CEC_A
AVCC33 HPD2 AVCC18 R2XC-
R2XC+
AGND
R2X0-
R2X0+
AVCC33
R2X1-
R2X1+
AGND
R2X2-
R2X2+
AVCC18
DSDA2
DSCL2
RPWR2
DVDD18
DGND
TEST
HPDIN
TSDA
TSCL
TPWR/I2CADDR
AGND
FB504
220R/2000mA
1 2
R546
NC/1.2K 1/16W
C516
1uF 16V
C526
0.1uF 50V
C506
0.1uF 50V
FB506
220R/2000mA
1 2
C514
NC/1uF 25V
C508
0.1uF 50V
C556
100N 16V
C515
NC/1uF 25V
A 7/18
HDMI SWITCH
1-857-922-11 <AZ2TK> A-P7
1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 |
A
—
B
—
C
—
D
—
E
—
F
—
G
—
H
—
I
—
J
—
