HISTORY INFORMATION FOR THE FOLLOWING MANUAL:
LCD Digital Color TV
9-88 -540-01
RB1TK Chassis
Segment: BA
Version Date Subject
1.0 09/19/2013 Original Manual Release Date.
MODEL COMMANDER DESTINATION
KDL-32R434A RM-YD093 BRAZIL
KDL- 2R4 4A

KDL-32R434A i
TABLE OF CONTENTS
Cautions and Warnings ...................................................................................ii
Section 1 - Specifications and Layouts .........................................................1
S ecifications ................................................................................................1
Board Layout .................................................................................................2
Wire Dressing ................................................................................................3
Section 2 - Troubleshooting ...........................................................................4
Diagnosing the Error .....................................................................................4
Viewing the Self Check Diagnosis History .............................................................4
Triage Chart ...................................................................................................5
Flowcharts and Diagrams ..............................................................................6
Overall Block Diagram ...........................................................................................6
Standby LED Blinking Flowchart ...........................................................................7
No Video Flowchart ...............................................................................................8
Video Distortion Flowchart .....................................................................................9
Section - Repair Information ......................................................................10
Re airing the TV ..........................................................................................10
Removing the Table-To Stand ............................................................................10
Removing the Lower Cover .................................................................................10
Re lacing the Main Board ........................................................................... 11
Removing the S eakers ..............................................................................14
Removing the Bezel and H Board ...............................................................14
Section 4 - Exploded View/Part Number Information .................................15
KDL-32R434A .............................................................................................15
Connectors ..................................................................................................17
Screws .........................................................................................................18
Section 5 - Accessories/Part Number Information .....................................19
Accessories and Packaging ........................................................................19
O tional Accessories ...................................................................................19
Remote Commander ...................................................................................19
Appendix A: Encryption Key Components ............................................... A-1

KDL-32R434A ii
CAUTION!!
These servicing instructions are for use by qualified service ersonnel only.
To reduce the risk of electric shock, do not erform any servicing other than
that contained in the o erating instructions unless you are qualified to do so.
WARNING!!
An isolation transformer should be used during any service to avoid ossible
shock hazard, in case of live chassis.
!SAFETY-RELATED COMPONENT WARNING!!
There are critical com onents used in LCD color TVs that are im ortant for
safety. These com onents are identified with shading and !mark on the
schematic diagrams and the arts list. It is essential that these critical arts
be re laced only with the art number s ecified in the arts list to revent
electric shock, fire or other hazard.
NOTE: Do not modify the original design without obtaining written ermission
from the manufacturer or you will void the original arts and labor warranty.
ATTENTION!!
For safety reasons, com onent level re air of the Power Su ly Boards
and/or the Inverter Boards is rohibited.
CAUTIONS AND WARNINGS
SAFETY CHECK-OUT
After correcting the original service roblem, erform the following safety
checks before releasing the set to the customer:
1. Check the area of your re air for unsoldered or oorly soldered
connections. Check the entire board surface for solder s lashes
and bridges.
2. Check the interboard wiring to ensure that no wires are “ inched” or
touching high-wattage resistors.
3. Check that all control knobs, shields, covers, ground stra s and
mounting hardware have been re laced. Be absolutely certain that
you have re laced all the insulators.
4. Look for unauthorized re lacement arts, articularly transistors,
that were installed during a revious re air. Point them out to the
customer and recommend their re lacement.
5. Look for arts which, though functioning, show obvious signs of
deterioration. Point them out to the customer and recommend their
re lacement.
6. Check the line cords for cracks and abrasion. Recommend the
re lacement of any such line cord to the customer.
7. Check the antenna terminals, metal trim, “metallized” knobs, screws
and all other ex osed metal arts for AC leakage. Check leakage
as described in “Leakage Test”.

KDL-32R434A iii
CAUTIONS AND WARNIN S
LEAKAGE TEST
The AC leakage from any ex osed metal art to earth ground and from all
ex osed metal arts to any ex osed metal art having a return to chassis,
must not exceed 0.5 mA (500 microam eres). Leakage current can be
measured by any one of three methods.
1. A commercial leakage tester.
Follow the manufacturers’ instructions rovided with the tester.
2. A battery-o erated AC milliammeter.
3. Measuring the voltage dro across a resistor by means of a VOM
or battery-o erated AC voltmeter. The “limit” indication is 0.75 V, so
analog meters must have an accurate low voltage scale. Nearly all
battery-o erated digital multimeters that have a 2 VAC range are
suitable. (see Figure A)
To Exposed Metal
Parts on et
0.15 µF
Earth Ground
AC
Voltmeter
(0.75V)
Figure A. Use an AC voltmeter to check AC leakage.
HOW TO FIND A GOOD EARTH GROUND
The cover- late retaining screw on most AC outlet boxes is at earth ground.
Verify the AC outlet box retaining screw ground by connecting a 60W to
100W incandescent (not a neon or fluorescent lam ) between the hot side
of the rece tacle and the retaining screw. Try both slots, if necessary, to
locate the hot side on the line; the lam should light at normal brilliance if
the screw is at ground otential. (see Figure B)
Figure B. Checking for earth ground.
Trouble Light
AC Outlet Box

KDL-32R434A 1
SPECIFICATIONS
Siste ma
Sistema de televisão Analógico: NTSC PAL-M PAL-N
Digital: SBTVD-T
Cobertura de canal VHF: 2-13
UHF: 14-69
CATV: 1-135
Sistema do painel Painel LCD (Tela de Cristal Líquido) Backlight de LED
Potência de saída dos
Alto-falantes (RMS)
5 W + 5 W
Entradas/Saídas
CABLE ANTENNA Terminal externo de 75 ohms para entradas RF
VIDEO IN VÍDEO: 1 V p-p, 75 ohms não balanceados, sincronização negativa
ÁUDIO: 500 mVrms (Típico) Impedância: 47 Kohms
COMPONENT IN (Vídeo componente): Y: 1,0 Vp-p, 75 ohms não balanceado, sincronizaç ão negativa
PB: 0,7 Vp-p, 75 ohms
Formato do sinal: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
ÁUDIO: 500 mVrms (Típico) Impedância: 47 Kohms
HDMI IN 1 MHL HDMI: Vídeo: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 1080 24p
MHL: Vídeo: 480i, 480p, 576i, 576p, 720p, 720 30p, 1080i, 1080 30p, 1080 24p
Áudio: Dois canais lineares PCM 32, 44,1 e 48 kHz, 16, 20 e 24bits, Dolby Digital
Entrada do PC
AUDIO OUT Saída de áudio, Fones de ouvido (minitomada)
USB Foto, Música e Vídeo
Entrada DC Entrada do adaptador AC
YPB PR P R
: 0,7 V p-p, 75 ohms
* Distorção Harmônica Total.
(127 V CA, THD* 10 % sinal 1 KHz, A lto-falante de 8 Ohms, Nível de entrada 500 mVrms)
SECTION 1 - SPECIFICATIONS AND LAYOUTS
Nome do modelo KDL- 2R4 4A
Energia e outros
Requisito de energia 110-220 V CA, 60 Hz
Consumo de energia 61 W
em uso
em modo de espera Menos do que 1 W
Tamanho da tela Aprox. 80,0
(polegadas medidas diagonalmente) 31,5 (Classe 32)
linhas (vertical)867×pontos (horizontal)663,1
Alto-falantes Á rea total (2) 40 × 100
735 × 471 × 171
735 × 446 × 75,5
100 × 100
M4 (6.5 - 10 mm)
Peso
5,2
sem pedestal 5,0
Acessórios fornecidos
Guia Rápido (1) Folheto de Instruções de Segurança (1) Licença de Sof tw are (1) Folheto Ginga (1)
Guia de Montagem do Pedestal (1) Pedestal (1 conjunto) Parafuso (2) Adaptador AC
Suporte de Cabo (1) Fixador do Adaptador A C (2)
Acessórios opc ionais
(cm)
(mm)
(mm)
(mm)
(mm)
(mm)
padrão de f uro de montagem
da parede
Resolução de tela
(kg)
(kg)
Controle Remoto RM-YD093 (1) Pilhas tamanho AAA (2) Manual de Instruções (1)
Cabos de Conexão Kit de Cinto de Segurança
• A disponibilidade dos acessórios opcionais depende do estoque.
• Projeto e especificações técnicas sujeitos a alterações sem aviso prévio.
• Pesos e dimensões são aproximados.
Dimensões
tamanho de parafuso de
montagem da parede
com pedestal
sem pedestal
com pedestal

KDL-32R434A 2
SECTION 1 - SPECIFICATIONS AND LAYOUTS
BOARD LAYOUT
KDL- 2R4 4A
TCON
H BOARD
MAIN BOARD
(A BOARD)
SIDE JACK
COVER

KDL-32R434A 3
SECTION 1 - SPECIFICATIONS AND LAYOUTS
WIRE DRESSING
KDL- 2R4 4AKDL- 2R4 4A

KDL-32R434A 4
DIAGNOSING THE ERROR
Before servicing the Television:
1. Verify the TV has the symptom the customer indicated.
2. Check to see if the latest Software is installed.
a. If not, install the latest version.
3. Determine the replacement part required.
VIEWING THE SELF CHECK DIAGNOSIS HISTORY
When an error is detected, the Self Check screen records the number of
times the error occurred. This is helpful in confirming past occurrences of
an error and for determining if an error is intermittent when the customer is
not sure what is causing the television to shut down. If the screen displays
a “0”, no error has occurred.
1. Press POWER to turn on the TV and then turn it off again.
2. Press the following buttons on the Remote Commander within 1
second of each other:
DISPLAY Channel 5 Volume -POWER
NOTE: This differs from accessing Service Adjustments Mode (Volume +).
SECTION 2 - TROUBLESHOOTING Sel Diagnosis
Supported model
Back <<
002 MAIN_ POWER 001
00 DC_ALERT1 000
00 AUDIO_PROT
000R_ERRECNALAB400
000
000
000RRE_NOCT500
005 PANEL_ID_NVM_ERR
000TILKCAB600
000RRE_PMET700
[Home] Exit
SELF CHECK
Indicates
an error
has occurred
Indicates
no error
has occurred
00116 00024 00115
SAMPLE SELF CHECK DIAGNOSIS PAGE

KDL-32R434A 5
SECTION 2 - TROUBLESHOOTING
TRIAGE CHART
Use this general Triage Chart to determine what may possibly be ausing the error before going out to the ustomers lo ation.
1. Confirm the symptom from the customer. Red Dot: (Primary) Most likely defective part.
2. elect that symptom from the chart. Blue Triangle: ( econdary) Possible defective part.
3. Bring the primary component listed for that symptom.
5. Chart Color Code.
Power Audio
2X 3X 6X Dead set No
Video
Whole
creen
Distortion
Isolated
Area
Distortion
No Audio
MAIN BOARD ▲ ▲
LCD PANEL
TCON
Video Protection Modes
4. Follow the associated flowcharts in the Training Manual to isolate the board.
Board
*NOTE: REFER TO LCD PANEL SERVICE MANUAL IN REFERENCE LIBRARY DATABASE
FOR CORRECT REPLACEMENT PARTS BASED ON SERIAL NUMBER.
▲ ▲

KDL-32R434A 6
SECTION 2 - TROUBLESHOOTING
FLOWCHARTS AND DIAGRAMS
OVERALL BLOCK DIAGRAM
COMPONENT/
COMPOSITE
RF
COMPOSITE
AUDIO L/R IN
AC ADAPTER
LED
IR RX
LCD PANEL, TCON
LED BACKLIGHTS
A
H
L
R
AUDIO OUT
MT5580
A/V DECODER
A/V PROCESS
TUNER
USB
HDMI 1
LVDS
AC IN
CLASS D
AUDIO
AMP
MAIN BOARD
&
CONTROL
KEYS
CABLE/ANTENNA

KDL-32R434A 7
SECTION 2 - TROUBLESHOOTING
TANDBY LED BLINKING FLOWCHART
Prote t
Shutdown.
Standby LED
Blinking
No
Yes
Yes
Yes
2X
Main Board*3X
No
6X
“SONY” logo
appears before
shutdown?
Yes
No
LCD Panel*
AC Adapter*
AC Adapter*
*For Part Number information, refer to “Se tion 4 - Exploded View/Part Number Information” on page 15 .

KDL-32R434A 8
SECTION 2 - TROUBLESHOOTING
NO VIDEO FLOWCHART
No Video
Ba klights
turned on?
Unplug LVDS
onne tor at
TCON while unit
is running. This
may need to be
done more than
on e.
Any flashes
seen on
s reen?
Yes
No
Any OSD
graphi s
present?
No
Main Board*
No
LCD Panel*
Yes
Yes
Main Board*
LCD Panel*
*For Part Number information, refer to “Se tion 4 - Exploded View/Part Number Information” on page 15 .

KDL-32R434A 9
SECTION 2 - TROUBLESHOOTING
*For Part Number information, refer to “Section 4 - E ploded View/Part Number Information” on page 15 .
VIDEO DISTORTION FLOWCHART
Video Distortion
Is distortion
across entire
screen?
Any horizontal
lines?
No
No
Yes
Yes
Improper of
missing colors?
Yes
Main Board*
No Vertical lines
or bars?
No
Yes Lines move
when wide-mode
changed?
Yes
No
LCD Panel*
Main Board*
LCD Panel*
Any single or
isolated vertical
lines?
Yes LCD Panel*
More than 1
vertical band?
No
Yes
LCD Panel*
Uneven
brightness? LCD Panel*
Yes
No

KDL-32R434A 10
SECTION 3 - REPAIR INFORMATION
REPAIRING THE TV
If the latest Software does not correct the issue, complete the following:
1. Verify the television has the symptom the customer indicated.
2. Replace part causing the symptom.
3. Install the latest version of Software (Required for ALL repairs).
4. Perform the required service adjustments and checks.
5. Verify the repair resolved the issue.
REMOVING THE TABLE-TOP STAND
1. Place TV face down on a soft and flat surface.
2. Remove 2 screws from Table-Top Stand and carefully detach from
Lower Cover.
REMOVING THE LOWER COVER
1. Locate and disconnect AC Power Cord.
2. Locate and remove all screws from the Lower Cover.
3. Grasp the areas shown on the Lower Cover to release the clips and lift
upwards to detach.
CAUTION: Do not use the Table-Top Stand
to hold or carry the TV.

KDL-32R434A 11
SECTION 3 - REPAIR INFORMATION
REPLACING THE MAIN BOARD
The Main Board used in these models is available for repair. For Part
Number information refer to Section 4 - E ploded View/Part Number
Information on page 15.
1. Disconnect all connectors from the Main Board.
2. Remove 6 screws from Main Board and Side Bracket.
3. Slide Side Bracket, then lift Main Board to detach.
4. Install the new Main Board, screws and all connectors.
5. Update the Software.
After ALL repairs UPDATE the SOFTWARE to the latest version.
Instructions are included with the Software package on the Sony
Authorized website.
a. Insert the USB device with the latest Software into the TV.
b. Press POWER to turn on the TV.
c. Wait until the Software update is complete and TV turns OFF.
6. Access Service Mode by pressing the following buttons within 1 second
of each other:
DISPLAY Channel 5Volume +POWER
Sound Ad ustment >>
Wide Band Tuning >>
Range Scan' >>
Self diagnosis history >>
Status Information' >>
LVDS Spectrum(%0) <[ 30 ]>
Low of HPD <[ 5 ]>
TVD_MCDONE_CNT <[ 20 ]>
Demo Special >>
Bypass AVI Info Detect <[ On ]>
Panel Selection <[ 192_TPT315B5-XVN03 ]>
UART Selection No Log
SERIAL NUMBER EDIT
MODEL NAME EDIT
[</>]Set [Home] Exit
Service Mode
7. Press until Panel Selection is selected.
Sound Ad ustment >>
Wide Band Tuning >>
Range Scan' >>
Self diagnosis history >>
Status Information' >>
LVDS Spectrum(%0) <[ 30 ]>
Low of HPD <[ 5 ]>
TVD_MCDONE_CNT <[ 20 ]>
Demo Special >>
Bypass AVI Info Detect <[ On ]>
Panel Selection <[ 192_TPT315B5-XVN03 ]>
UART Selection No Log
SERIAL NUMBER EDIT
MODEL NAME EDIT
[</>]Set [Home] Exit
Service Mode

KDL-32R434A 12
SECTION 3 - REPAIR INFORMATION
8. Press or to select the correct Panel Code for theTV model.
(Use the table below for reference).
Model Name Panel Code
KDL-32R434A 192_TPT315B5-XVN03
CAUTION: Select ONLY the correct Panel Code.
9. Locate the Serial Number for the TV on the side of the Rear Cover.
MODEL NO
KDL-32R434A
SERIAL NO
8500001
10. Press until SERIAL NUMBER EDIT is selected.
Sound Ad ustment >>
Wide Band Tuning >>
Range Scan' >>
Self diagnosis history >>
Status Information' >>
LVDS Spectrum(%0) <[ 30 ]>
Low of HPD <[ 5 ]>
TVD_MCDONE_CNT <[ 20 ]>
Demo Special >>
Bypass AVI Info Detect <[ On ]>
Panel Selection <[ 192_TPT315B5-XVN03 ]>
UART Selection No Log
SERIAL NUMBER EDIT
MODEL NAME EDIT
[</>]Set [Home] Exit
Service Mode
11. Press to be able to select the first digit.
Sound Ad ustment >>
Wide Band Tuning >>
Range Scan' >>
Self diagnosis history >>
Status Information' >>
LVDS Spectrum(%0) <[ 30 ]>
Low of HPD <[ 5 ]>
TVD_MCDONE_CNT <[ 20 ]>
Demo Special >>
Bypass AVI Info Detect <[ On ]>
Panel Selection <[ 192_TPT315B5-XVN03 ]>
UART Selection No Log
SERIAL NUMBER EDIT _ _ _ _ _ _ _
MODEL NAME EDIT
[</>]Set [Home] Exit
Service Mode
12. Press or to select numbers and then to move to the ne t
space until Serial Number is complete.
Sound Ad ustment >>
Wide Band Tuning >>
Range Scan' >>
Self diagnosis history >>
Status Information' >>
LVDS Spectrum(%0) <[ 30 ]>
Low of HPD <[ 5 ]>
TVD_MCDONE_CNT <[ 20 ]>
Demo Special >>
Bypass AVI Info Detect <[ On ]>
Panel Selection <[ 192_TPT315B5-XVN03 ]>
UART Selection No Log
SERIAL NUMBER EDIT 8500001
MODEL NAME EDIT
[</>]Set [Home] Exit
Service Mode
CAUTION: The Serial Number can only be selected once. Be sure
to verify the information is correct before saving the changes.

KDL-32R434A 13
SECTION 3 - REPAIR INFORMATION
13. When the complete Serial Number displa s, press .
14. On the confirmation screen, press to select YES and then .
Input Data Correct?
Yes No
Selected text displa s in black
15. Press until MODEL NAME EDIT is selected.
Sound Adjustment >>
Wide Band Tunin >>
Ran e Scan" >>
Self dia nosis history >>
Status Information" >>
LVDS Spectrum(%0) <[ 30 ]>
Low of HPD <[ 5 ]>
TVD_MCDONE_CNT <[ 20 ]>
Demo Special >>
Bypass AVI Info Detect <[ On ]>
Panel Selection <[ 192_TPT315B5-XVN03 ]>
UART Selection No Lo
SERIAL NUMBER EDIT 8500001
MODEL NAME EDIT
[</>]Set [Home] Exit
Service Mode
16. Press to be able to select the first character.
Sound Adjustment >>
Wide Band Tunin >>
Ran e Scan" >>
Self dia nosis history >>
Status Information" >>
LVDS Spectrum(%0) <[ 30 ]>
Low of HPD <[ 5 ]>
TVD_MCDONE_CNT <[ 20 ]>
Demo Special >>
Bypass AVI Info Detect <[ On ]>
Panel Selection <[ 192_TPT315B5-XVN03 ]>
UART Selection No Lo
SERIAL NUMBER EDIT 8500001
MODEL NAME EDIT _ _ _ _ _ _ _ _ _ _ _
[</>]Set [Home] Exit
Service Mode
17. Press or to select characters and then to move to the next
space until Model Name is complete.
NOTE: Make sure to include dash in Model Name.
Sound Adjustment >>
Wide Band Tunin >>
Ran e Scan" >>
Self dia nosis history >>
Status Information" >>
LVDS Spectrum(%0) <[ 30 ]>
Low of HPD <[ 5 ]>
TVD_MCDONE_CNT <[ 20 ]>
Demo Special >>
Bypass AVI Info Detect <[ On ]>
Panel Selection <[ 192_TPT315B5-XVN03 ]>
UART Selection No Lo
SERIAL NUMBER EDIT 8500001
MODEL NAME EDIT KDL-32R434A
[</>]Set [Home] Exit
Service Mode
CAUTION: The Model Name can onl be selected once. Be sure
to verif the information is correct before saving the changes.

KDL-32R434A 14
SECTION 3 - REPAIR INFORMATION
18. When the complete Model Name displa s, press .
19. On the confirmation screen, press to select YES and then .
Input Data Correct?
Yes No
Selected text displa s in black
20. Press POWER to exit Service Mode.
REMOVING THE SPEAKERS
1. Lift and remove Speakers, then disconnect connectors to detach.
2. Locate and remove 2 screws from Speaker Cover. Twist downwards to
release clips from the Bezel.
REMOVING THE BEZEL AND H BOARD
1. Use a small and narrow tool to release H Board from Bezel.
2. Disconnect the connector from the H Board to detach.
3. Place the TV face up, then grasp the Bezel carefull on the shown areas
to release from LCD Panel and lift to detach.

KDL-32R434A 15
Compone nts not ide ntified by a part numbe r or de scription
are not stocked be cause the y are se ldom require d for routine
se rv ice .
The component parts of an asse mbly are indicate d by the refe re nce numbers in
the far ri ht column of the parts list and within the dotte d line s of the dia ram.
NOTE: The compone nts ide ntifie d by shadin and
!
mark are critical for safe ty.
Re place only with part numbe r spe cifie d.
NOTE: The compone nts ide ntifie d by a re d ou tline and a mark contain confide ntial
information. Spe cific instructions must be adhe re d to whe never these co mpo nents are
re p aired and/or re placed. (Se e Appe ndix A)
SECTION 4 - EXPLODED VIEW/PART NUMBER INFORMATION
KDL-32R434A
1 NA LCD PANEL
FOR ALL LCD PANEL AND TCON BOARD PART NUMBER
INFORMATION REFER TO THE LCD PANELS SERVICE MANUAL
2 4-485-012-01 SIDE JACK COVER
3 1-895-502-11 A BOARD, COMPLETE
AFTER REPLACING THE MAIN BOARD, YOU MUST UPDATE
THE SOFTWARE TO THE LATEST VERSION.
4 1-492-702-11 AC ADAPTER
! 5 1-848-037-11 POWER SUPPLY CORD
6 4-485-011-01 LOWER COVER (UNDER COVER)
7 4-479-429-01 STAND SHAFT
REF. NO. PART NO. DESCRIPTION
4
5
7
2
3
6
1

KDL-32R434A 16
SECTION 4 - EXPLODED VIEW/PART NUMBER INFORMATION
NOTE: The compone nts ide ntifie d by shadin and
!
mark are critical for safe ty.
Re place only with part numbe r spe cifie d.
NOTE: The compone nts ide ntifie d by a re d ou tline and a mark contain confide ntial
information. Spe cific instructions must be adhe re d to whe never these co mpo nents are
re p aired and/or re placed. (Se e Appe ndix A)
KDL-32R434A
56
56
52
Bracket MB Btm*
Brac ket MB Top*
53
54
55
51
51
REF. NO. PART NO. DESCRIPTION
51 4-470-954-01 BRACKET VESA
52 4-485-009-01 BEZEL
53 1-895-413-11 H BOARD, MOUNTED
54 4-470-953-01 BRACKET STAND
55 4-485-010-01 SP COVER
56 1-858-956-11 LOUD SPEAKER
*Reinstall Bracket MB Top and Bracket
MB Btm w hen replacing the Main Board.
