LCD COLOR TELEVISION
SERVICE MANUAL EX1 CHASSIS
MODEL NAME REMOTE COMMANDER DESTINATION
9-883-797-01
KLV-40Z410A RM-YD024 BRAZIL
KLV-46Z410A RM-YD024 BRAZIL
HISTORY INFORMATION FOR THE FOLLOWING MANUAL:
ORIGINAL MANUAL ISSUE DATE: 8/2008
REVISION DATE SUBJECT
8/2008 No revisions or updates are applicable at this time.

LCD COLOR TELEVISION
SERVICE MANUAL EX1 CHASSIS
MODEL NAME REMOTE COMMANDER DESTINATION
9-883-797-01
KLV-40Z410A RM-YD024 BRAZIL
KLV-46Z410A RM-YD024 BRAZIL
Self Diagnosis
Supported model
KLV-46Z410A RM-YD024

3
KLV-40Z410A/46Z410A
KLV-40Z410A/46Z410A
TABLE OF CONTENTS
SECTION TITLE PAGE SECTION TITLE PAGE
Specifications ................................................................................. 4
Warnings and Cautions - English ................................................... 6
Safety-Related Component Warning .............................................. 7
Safety Check-Out ........................................................................... 9
Self-Diagnostic Function............................................................... 10
SECTION 1: DISASSEMBLY............................................................... 12
1-1. Rear Cover and Switch Unit (Contains H1 Board) Removal 12
1-2. Side Jack Bracket, BU Bracket, BU Shield and BU Board
Removal ............................................................................... 12
1-3. Power Unit (G4 Board) and D3Z Board Removal ............... 13
1-4. Table-Top Stand and Under Cover Removal........................ 13
1-5. AC Inlet and AC Bracket Removal ....................................... 14
1-6. Speakers, Under Bar, Screw Caps, H3V Board and
H4 Board Removal .............................................................. 14
1-7. VESA Frames and Bottom Frame Removal......................... 15
1-8. LCD Panel Removal............................................................. 15
1-8-1. Cleaning the LCD Panel .......................................... 16
1-9. Baffles, IR Guide and Clear Panel Removal ........................ 16
SECTION 2: SERVICE ADJUSTMENTS............................................. 17
2-1. Viewing Service Adjustment Data ........................................ 17
2-2. Accessing Service Adjustment Mode ................................... 17
2-3. Viewing the Service Menus.................................................. 17
2-4. Using the Remote Commander to View Service Data ......... 18
2-5. Resetting to Factory Defaults............................................... 18
SECTION 3: DIAGRAMS..................................................................... 19
3-1. Circuit Boards Location ........................................................ 19
3-2. Printed Wiring Boards and
Schematic Diagrams Information ......................................... 19
3-3. Block Diagram...................................................................... 21
3-4. Schematics and Supporting Information .............................. 22
BU Board Schematic Diagram (1 of 12)............................... 22
BU Board Schematic Diagram (2 of 12)............................... 23
BU Board Schematic Diagram (3 of 12)............................... 24
BU Board Schematic Diagram (4 of 12)............................... 25
BU Board Schematic Diagram (5 of 12)............................... 26
BU Board Schematic Diagram (6 of 12)............................... 27
BU Board Schematic Diagram (7 of 12)............................... 28
BU Board Schematic Diagram (8 of 12)............................... 29
BU Board Schematic Diagram (9 of 12)............................... 30
BU Board Schematic Diagram (10 of 12)............................. 31
BU Board Schematic Diagram (11 of 12) ............................. 32
BU Board Schematic Diagram (12 of 12)............................. 33
D3Z-40 Board Schematic Diagram (KLV-40Z410A ONLY) .. 35
D3Z-46 Board Schematic Diagram (KLV-46Z410A ONLY) .. 36
G4 Board Schematic Diagram ............................................ 38
H3V Board Schematic Diagram ........................................... 41
H4 Board Schematic Diagram.............................................. 43
3-5. Semiconductors ................................................................... 45
SECTION 4: EXPLODED VIEWS ........................................................ 46
4-1. Rear Cover Assembly and Table-Top Stand Assembly ....... 46
4-2. Chassis ................................................................................ 47
4-3. Connectors........................................................................... 48
4-4. Bezel Assembly and LCD Panel .......................................... 49
4-5. Screw Legend ...................................................................... 50
SECTION 5: ELECTRICAL PARTS LIST ............................................ 51
APPENDIX A: ENCRYPTION KEY COMPONENTS..........................A-1

4
KLV-40Z410A/46Z410A
KLV-40Z410A/46Z410A
SPECIFICATIONS
Design and specifications are subject to change without notice.
110V - 120V CA, 50/60Hz
225W (KLV-40Z410A only)
285W (KLV-46Z410A only)
Less than 0.1W
VIDEO (IN) 1/2/3:
S Video (4-Pin Mini DIN (VIDEO 1 Only)
Y: 1.0 Vp-p, 75 ohms unbalanced, sync negative
C: 0.286 Vp-p (Burst signal), 75 ohms
Video
1.0 Vp-p, 75 ohms unbalanced, sync negative
Audio
500 mVrms (Typical)
Impedance:47 kilohms
COMPONENT IN 1/2:
YPBPR(Component Video)
Y:1.0 Vp-p, 75 ohms unbalanced, sync negative
P
B:0.7 Vp-p, 75 ohms
P
R:0.7 Vp-p, 75 ohms
Signal format: 480i, 480p, 720p, 1080i, 1080p
AUDIO
500 mVrms (Typical)
Impedance: 47 kilohms
Power Requirements
Power Consumption (W)
In Use (Max)
In Standby
HDMI IN 1/2/3/4:
HDMI: Video: 480i, 480p, 720p, 1080i,1080p, 1080/24p
Audio: Two channel linear PCM 32, 44.1 and
48 kHz, 16, 20 and 24 bits, Dolby Digital
AUDIO (for HDMI IN 4):
500 mVrms (Typical)
Impedance: 47 kilohms
AUDIO OUT:
500 mVrms (Typical)
DIGITAL AUDIO OUT (OPTICAL):
PCM/Dolby Digital optical signal
PC IN:
D-sub 15-pin, analog RGB, 0.7 Vp-p, 75 ohms, positive
PC AUDIO INPUT:
Stereo mini jack, 500 mVrms (Typical)
Impedance: 47 kilohms
LAN (10/100):
10 BASE-T/100 BASE TX
DMPORT:
Video
1.0 Vp-p, 75 ohms unbalanced, sync negative
Audio
500 mVrms (Typical)
Impedance:47 kilohms
USB:
Hi-Speed USB
Licensing Information
Macintosh is a trademark of Apple Inc.,
registered in the U.S. and other countries.
HDMI, the HDMI logo and High-Definition
Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing,
LLC.
Manufactured under license from Dolby
Laboratories. “Dolby” and double-D symbol
are trademarks of Dolby Laboratories.
Blu-ray Disc is a trademark.
“BRAVIA” and , S-Force,
Motionflow, BRAVIA Sync, , DMex,
MICRO VAULT, and “x.v. Color” are
trademarks or registered marks of Sony
Corporation.
“XrossMediaBar” is a trademark of Sony
Corporation. “XMB” is a trademark of Sony
Corporation and Sony Computer
Entertainment Inc.
“PLAYSTATION” is a registered trademark
and “PS3” is a trademark of Sony Computer
Entertainment Inc.
Adobe is a registered trademark or a trademark
of Adobe Systems Incorporated in United
States and/or other countries.
DLNA®, the DLNA Logo and DLNA
CERTIFIED™ are trademarks, service marks,
or certification marks of the Digital Living
Network Alliance.

5
KLV-40Z410A/46Z410A
KLV-40Z410A/46Z410A
Television system
NTSC PAL-M/PAL-N
Channel coverage
VHF: 2-13
UHF: 14-69
CATV: 1-125
Cable/Antenna
75-ohm external terminal for RF inputs
Panel System
LCD (Liquid Crystal Display) Panel
Display Resolution (horizontal x vertical)
1,920 dots x 1,080 lines
Screen Size (measured diagonally)
KLV-40Z410A ~ 102cm/40 inches
KLV-46Z410A ~ 117cm/46 inches
Supplied Accessories
Remote Commander RM-YD024
Two Size AA Batteries
AC Power Cord
Cable Holder (1 attached to the TV)
Operating Instructions
Quick Setup Guide
Safety Flyer
Attaching the Table-Top Stand
Screws (4) +PSW M5x16
Stand Rear Cover
Optional Accessories
Connecting Cables
DMX-DT1
KLV-40Z410A KLV-46Z410A
Speaker Output
mm 45 X 200 mm 45 X 200 mm
in 13/4 x 77/8 in 13/4 x 77/8 in
Dimensions (W x H x D)
with stand
mm 994 x 654 x 279 mm 1,079 x 734 x 307 mm
in 37
1/4
x 25
3/4
x 11 in 42
1/2
x 29 x 12
1/8
in
without stand
mm 994 x 608 x 72 mm 1,079 x 686 x 74 mm
in 371/4 x 24 x 27/8 in 421/2 x 271/8 x 3 in
wall-mount hole pattern
wall-mount screw size
Mass
with stand
kg 21.5 kg 26 kg
lbs 48 lbs 58 lbs
without stand
kg 18 kg 22 kg
lbs 40 lbs 49 lbs
All measurements are approximations.
M6 x 12 - 18
300 x 300 mm
10W+10W

6
KLV-40Z410A/46Z410A
KLV-40Z410A/46Z410A
WARNINGS AND CAUTIONS - ENGLISH
CAUTION
These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any servicing other
than that contained in the operating instructions unless you are qualified to do so.
CARRYING THE TV
Be sure to follow these guidelines to protect your
property and avoid causing serious injury.
•Before carrying the TV, disconnect all cables.
•Carrying the large size TV requires two or more
people.
•When carrying the TV, place your hand as
illustrated and hold it securely. Do not subject the
TV to shocks, vibration, or excessive force.
• Lift the TV by placing your palm directly
underneath the panel but do not:
• put stress on the LCD panel.
•Do not lift the TV from the bottom center.
WARNING!!
An isolation transformer should be used during any service to avoid possible shock hazard, because of live chassis. The chassis of this receiver is
directly connected to the ac power line.
! SAFETY-RELATED COMPONENT WARNING!!
Components identified by shading and ! mark on the schematic diagrams, exploded views, and in the parts list are critical for safe operation. Replace
these components with Sony parts whose part numbers appear as shown in this manual or in supplements published by Sony. Circuit adjustments that
are critical for safe operation are identified in this manual. Follow these procedures whenever critical components are replaced or improper operation is
suspected.

7
KLV-40Z410A/46Z410A
KLV-40Z410A/46Z410A
SAFETY-RELATED COMPONENT WARNING
There are critical components used in LCD color TVs that are important for safety. These components are identified with shading and
!
mark on the sc�
specified in the electrical parts list to prevent electric shock, fire, or other hazard.
NOTE: Do no�
labor guarantee.
USE CAUTION WHEN HANDLING THE LCD PANEL
When repairing the LCD panel, be sure you are grounded by using a wrist band.
When installing the LCD panel on a wall, the LCD panel must be secured using the 4 mounting holes on the rear cover.
To avoid damaging the LCD panel:
 do not press on the panel or frame edge to avoid the risk of electric shock.
 do not scratch or press on the panel with any sharp objects.
 do not leave the module in high temperatures or in areas of high humidity for an extended period of time.
 do not expose the LCD panel to direct sunlight.
 avoid contact with water. It may cause a short circuit within the module.
 disconnect the AC adapter when replacing the backlight (CCFL) or inverter circuit.
(High voltage occurs at the inverter circuit at 650Vrms.)
 always clean the LCD panel with a soft cloth material.
 use care when handling the wires or connectors of the inverter circuit. Damaging the wires may cause a short.
 protect the panel from ESD to avoid damaging the electronic circuit (C-MOS).
LEAKAGE CURRENT HOT CHECK CIRCUIT

8
KLV-40Z410A/46Z410A
KLV-40Z410A/46Z410A
The circuit boards used in these models have been processed using
Lead Free Solder. The boards are identified by the LF logo located
close to the board designation e.g. H1 etc [ see example ]. The
servicing of these boards requires special precautions to be taken as
outlined below.
example 1
It is strongly recommended to use Lead Free Solder material in order to guarantee optimal quality of new solder joints.
Lead Free Solder is available under the following part numbers :
Due to the higher melting point of Lead Free Solder the soldering iron tip temperature needs to be set to 370 degrees centigrade.
This requires soldering equipment capable of accurate temperature control coupled with a good heat recovery characteristics.
For more information on the use of Lead Free Solder, please refer to
http://www.sony-training.com
rebmuntraP retemaiD skrameR
91-500-046-7mm3.0gK52.0
02-500-046-7mm4.0gK05.0
12-500-046-7mm5.0gK05.0
22-500-046-7mm6.0gK52.0
32-500-046-7mm8.0gK00.1
42-500-046-7mm0.1gK00.1
52-500-046-7mm2.1gK00.1
62-500-046-7mm6.1gK00.1

9
KLV-40Z410A/46Z410A
KLV-40Z410A/46Z410A
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer:
1. Check the area of your repair for unsoldered or poorly soldered
connections. Check the entire board surface for solder splashes and
bridges.
2. Check the interboard wiring to ensure that no wires are “pinched” or
touching high-wattage resistors.
3. Check that all control knobs, shields, covers, ground straps, and
mounting hardware have been replaced. Be absolutely certain that
you have replaced all the insulators.
4. Look for unauthorized replacement parts, particularly transistors,
that were installed during a previous repair. Point them out to the
customer and recommend their replacement.
5. Look for parts which, though functioning, show obvious signs of
deterioration. Point them out to the customer and recommend their
replacement.
6. Check the line cords for cracks and abrasion. Recommend the
replacement of any such line cord to the customer.
7. Check the antenna terminals, metal trim, “metallized” knobs, screws,
and all other exposed metal parts for AC leakage. Check leakage as
described below.
Leakage Test
The AC leakage from any exposed metal part to earth ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microamperes).
Leakage current can be measured by any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or RCA
WT-540A. Follow the manufacturers’ instructions to use these
instructions.
2. A battery-operated AC milliampmeter. The Data Precision 245
digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a VOM
or battery-operated AC voltmeter. The “limit” indication is 0.75
V, so analog meters must have an accurate low voltage scale.
The Simpson’s 250 and Sanwa SH-63TRD are examples of
passive VOMs that are suitable. Nearly all battery-operated digital
multimeters that have a 2 VAC range are suitable (see Figure A).
How to Find a Good Earth Ground
A cold-water pipe is a guaranteed earth ground; the cover-plate
retaining screw on most AC outlet boxes is also at earth ground. If the
retaining screw is to be used as your earth ground, verify that it is at
ground by measuring the resistance between it and a cold-water pipe
with an ohmmeter. The reading should be zero ohms.
If a cold-water pipe is not accessible, connect a 60- to 100-watt
trouble- light (not a neon lamp) between the hot side of the receptacle
and the retaining screw. Try both slots, if necessary, to locate the hot
side on the line; the lamp should light at normal brilliance if the screw
is at ground potential (see Figure B).
To Exposed Metal
Parts on Set
0.15 F
Earth Ground
AC
Voltmeter
(0.75V)
Trouble Light
AC Outlet Box Ohmmeter
Cold-water Pipe
Figure A. Using an AC voltmeter to check AC leakage. Figure B. Checking for earth ground.

10
KLV-40Z410A/46Z410A
KLV-40Z410A/46Z410A
SELF-DIAGNOSTIC FUNCTION
Self Diagnosis
Supported model
The units in this manual contain a self-diagnostic function. If an error occurs, the STANDBY LED indicator will automatically begin to flash. The number
of times the LED flashes translates to a probable source of the problem. A definition of the STANDBY LED flash indicators is listed in the instruction
manual for the user’s knowledge and reference. If an error symptom cannot be reproduced, the Remote Commander can be used to review the failure
occurrence data stored in memory to reveal past problems and how often these problems occur.
1. Diagnostic Test Indicators
When an error occurs, the STANDBY LED indicator will flash a set number of times to indicate the possible cause of the problem. If there is more than
one error, the indicator will identify the first of the problem areas.
Control Buttons
  
Description of LED Indictors
LED LED Type Description
* Lights up in green when the TV set is turned on.
* If LED blinks continuously, this may indicate
that the TV needs servicing.
STANDBY LED
PIC OFF/
TIMER
LED
* Lights up in red when TV is in PC standby mode.
* Lights up in green when Picture Off is activated.
* Lights up in orange when the timer is set.
When timer is set, the LED remains lit even
when the TV is turned off.
POWER LED
Green or Orange
LED
Green LED
Red LED
2 times
5 times
LED ON 0.3 sec.
LED OFF 0.3 sec. LED OFF
3 sec.

11
KLV-40Z410A/46Z410A
KLV-40Z410A/46Z410A
Possible Problem Location
Diagnostic Item
Description
Number of times
STANDBY lamp
flashes
Possible Problem Location
Main Power 2 times Power Supply
DC Alert 3 times Main Board
Power Supply
Panel Alert 5 times LCD Panel
Backlight 6 times Power Supply
Temp 7 times Main Board
SP Prot 8 times Main Board
Trident IC 11 times Main Board
TCON Error 12 times LCD Panel
Backlight Balance 13 times
Power Supply
(Balancer Boards) Inverter Boards
LCD Panel
HFR Error 14 times LCD Panel
Viewing the Self Check Diagnostic List
1. TV must be in standby mode. (Power off).
2. Press the following buttons on the Remote Commander within a second of each other:
DISPLAY Channel
5Volume
-
TV POWER .
The Self Check list displays. This differs from accessing Service Adjustments.
Results for all of the following diagnostic items are displayed on screen. No error has occurred if the screen displays a “0”.
NOTE: If the Self Check display text is not completely visible, press the Menu HOME button on the Remote Commander to refresh the display.
3. Press the Channel 1button on the Remote Commander to go to Page 2 of the Self Check list.
SELF CHECK PAGE 1
002 MAIN_POWER 01 Í1 indicates an error was detected
003 DC_ALERT1 00 Í0 indicates no error was detected
005 PANEL_ALERT 00
006 BACKLIGHT 00
013 BACKLIGHT_BALANCE 00
00001 00027 00009 00000
SELF CHECK PAGE 2
007 TEMP 00
008 SP_PROT 00
011 TRIDENT_IC 00
012 HFR_ERROR 00 ÍDisplays as 12 Blinks, but is actually 14 Blinks
012 TCON_ERROR 00
00001 00027 00009 00000
ÏÏÏ Total Panel Hours
ÏÏ Total Hours of Operation
ÏBoot Count
4. Press the Channel 4button on the Remote Commander to go back to Page 1 of the Self Check list.
5. To exit Self Check display, turn the power off.
Clearing the Self Check Diagnostic List
1. In Service Mode, press the Channel 8Channel
0.

12
KLV-40Z410A/46Z410A
KLV-40Z410A/46Z410A
SECTION 1: DISASSEMBLY
1-1. REAR COVER AND SWITCH UNIT (CONTAINS H1 BOARD) REMOVAL
1Release hook and slide out Side Jack Bracket from BU Board
2Remove 2 HEX screws
3Disconnect 5 connectors
4Remove 9 screws
5Remove 3 screws
1Remove 2 screws from Terminal Position
2Remove 4 screws
3Remove 2 Screw Caps from Rear Cover
4Remove 15 screws (KLV-40Z410A ONLY)
Remove 17 screws (KLV-46Z410A ONLY)
5Disconnect 1 connector and slide out Switch Unit
1-2. SIDE JACK BRACKET, BU BRACKET, BU SHIELD AND BU BOARD REMOVAL

13
KLV-40Z410A/46Z410A
KLV-40Z410A/46Z410A
1-3. POWER UNIT (G4 BOARD) AND D3Z BOARD REMOVAL
1Disconnect 3 connectors
2Remove 6 screws
3Release board holders
4Disconnect 4 connectors
5Remove 6 screws
1-4. TABLE-TOP STAND AND UNDER COVER REMOVAL
1Remove 4 screws
2Remove 2 screws
2
3
1
5
4
Power Unit (G4 Board)
D3Z Board
1
2
Under Cover
Table-Top Stand Assembly

14
KLV-40Z410A/46Z410A
KLV-40Z410A/46Z410A
1-5. AC INLET AND AC BRACKET REMOVAL
1Remove 2 Screw Caps from Under Bar
2Remove 2 screws from Under Bar
3Slide out Speaker units from Bezel
4Disconnect 1 connector and release IR Guide hooks to remove H4 Board
5Disconnect 1 connector and Slide out H3V Board from Bezel
1Remove 2 screws
2Remove 2 screws
1-6. SPEAKERS, UNDER BAR, SCREW CAPS, H3V BOARD AND H4 BOARD REMOVAL

15
KLV-40Z410A/46Z410A
KLV-40Z410A/46Z410A
1-7. VESA FRAMES AND BOTTOM FRAME REMOVAL
1Remove 4 screws from VESA Frames
2Remove 4 screws
3Remove 4 screws
2
1
3
VESA Frame
Bottom Frame
1Disconnect 2 connectors
2Remove 3 screws (KLV-40Z410A ONLY)
Remove 5 screws (KLV-46Z410A ONLY)
NOTE: The LVDS cable can only be installed one way. There is colored tape on the cable to determine which side is attached
to the TCON and which side is attached to the BU Board.
1-8. LCD PANEL REMOVAL
2
1
LCD Panel
Bezel

16
KLV-40Z410A/46Z410A
KLV-40Z410A/46Z410A
1-8-1. CLEANING THE LCD PANEL
CAUTION: When cleaning the TV, be sure to unplug the power cord to avoid any chance of electric shock.
1Clean the cabinet of the TV with a dry soft cloth.
2Wipe the LCD screen gently with a soft cloth.
 Stubborn stains may be removed with a cloth slightly moistened with a solution of mild soap and warm water.
 If using a chemically pretreated cloth, please follow the instruction provided on the package.
 Never use strong solvents such as a thinner, alcohol or benzine for cleaning.
 Periodic vacuuming of the ventilation openings is recommended to ensure to proper ventilation.

18
KLV-40Z410A/46Z410A
KLV-40Z410A/46Z410A
2-4. USING THE REMOTE COMMANDER TO
VIEW SERVICE DATA
Use the buttons on the Remote Commander to access the service menu
items and adjust the data values.
1. Access Service Mode.
Press the following buttons on the Remote Commander within a
second of each other:
DISPLAY Channel
5Volume
+
TV POWER
Data Value
Category
Number
Adjustment
Item Number
Category
Adjustment
Item
TVLF CHECK
001 COLOR ADJ
001 R_DRV
SERVICE
DIGITAL PROGRAM
DATA
BE PROGRAM
NVM
PACK
BOOT
: H801.03 0070
: S001000
: TM1.000
: TD1.000
: TP1.000
: TB1.000
00100
The screen displays the first category in the selected service menu.
NOTE: If the Service Menu display text is not completely visible,
press the Menu HOME button on the Remote Commander to refresh
the display.
2. To change the category, press 2or 5on the Remote Commander.
Note: Pressing 2or 5only changes the categories within the service
menu displayed.
To change a category on one of the other service menus, press the
JUMP button until the correct service menu is displayed.
3. To change the adjustment item, press 1or 4on the Remote
Commander.
4. To exit service mode, turn the power off.
$)30,!9
6/, #(
-54).'
2%# 2%#0!53% 2%#34/0
&& -%.54/0-%.5
"$$6$
*5-0
$6$ !-0 34" 46
02%6 2%0,!9 !$6!.#% .%84
4(%!4%2 3/5.$ 0)#452% 7)$%
## &2%%:%
,)'(4 0/7%2
460/7%2
39.#-%.5 0!53%
0,!9
&5.#4)/.
34/0
RM-YD024
2-5. RESETTING TO FACTORY DEFAULTS
Use the following instructions to restore the User Controls and
Channel Memory settings to the preset factory conditions.
1. While holding down the on the Remote Commander, press the
POWER button on the Front Panel of the set.
The set restarts and displays the initial setup screen. This may take
several minutes.
HOME
DISPLAY
JUMP
Displays
Service
Menus
Next item
Previous
item
Next
Category
Previous
Category
TV POWER
2
5
1
4

19
KLV-40Z410A/46Z410A
KLV-40Z410A/46Z410A
SECTION 3: DIAGRAMS
3-1. CIRCUIT BOARDS LOCATION
3-2. PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS INFORMATION
All voltages are in V.
S : Measurement impossibility.
: B+line.
: B-line. (Actual measured value may be different).
: signal path. (RF)
Circled numbers are waveform references.
The components identified by shading and
!
symbol are critical for safety. Replace
only with part number specified.
The symbol indicates a fast operating fuse and is displayed on the component
side of the board. Replace only with fuse of the same rating as marked.
NOTE: The components identified by a red outline and a mark contain confidential
information. Specific instructions must be adhered to whenever these components
are repaired and/or replaced.
See Appendix A: Encryption Key Components in the back of this manual.
All capacitors are in μF unless otherwise noted. pF : μμF 50WV or
less are not indicated except for electrolytics and tantalums.
All electrolytics are in 50V unless otherwise specified.
All resistors are in ohms. kΩ=1000Ω, MΩ=1000kΩ
Indication of resistance, which does not have one for rating
electrical power, is as follows: Pitch : 5mm
Rating electrical power :
1/4 W
1/4 W in resistance, 1/10 W and 1/16 W in chip resistance.
: nonflammable resistor
: fusible resistor
: internal component
: panel designation and adjustment for repair
: earth ground
: earth-chassis
All variable and adjustable resistors have characteristic curve B,
unless otherwise noted.
Readings are taken with a color-bar signal input.
Readings are taken with a 10MΩdigital multimeter.
Voltages are DC with respect to ground unless otherwise noted.
Voltage variations may be noted due to normal production
tolerances.
SWITCH UNIT (Contains H1 Board)
G4 BOARD
(POWER UNIT)
D3Z
H4
H3V
Illumination
Module
BU

20
KLV-40Z410A/46Z410A
KLV-40Z410A/46Z410A
G
D
S
B1 E1
C2
B2 C1E2
2
3
4
5
6
7
8
9
0
!¡
!™
!¢
!§
!¶
!•
–
1
G
D
S
B2 E2
C1
B1 C2
E1
B2 E2C1
B1 C2E1
B2 E2
C1
B1 C2E1
!ª
B1 E1
E2
C1(B2)
C2
@º
B1
E2
C1
C2
@™
@£
(B2)
E1
(B2)
E1
E2
B1
C2C1
@¡
B1
E1
C2
B2
C1
E2
G
SS
D
G
D
B1
E1
C2
B2
C1
E2
B1
E2
C2C1(B2)
E2
B1
C1
C2E1(B2)
C2
B1
C1
E2E1(B2)
C2
B1
C1
E2
B2
E1
C2
Ver.1.6
Transistor
(FET)
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Discrete semiconductot
(Chip semiconductors that are not actually used are included.)
Diode
Diode
Diode
Diode
Diode
Diode
Diode
Diode
Diode
Diode
Source
Source
Anode Anode
(NC)
(NC)
Cathode
Anode
Cathode
Common
Cathode Cathode
Common
Cathode Cathode
Common
Common
Common
Common
Cathode
Anode
Base Emitter
Collector
Base Emitter
Collector
Drain
Gate
Gate
Drain
Device Printed symbol Terminal name Circuit
Terminal name of semiconductors in silk screen
printed circuit ( )
Anode
Anode
Anode Cathode
Anode Anode
Cathode
!£
Transistor
(FET)
Transistor
(FET)
!?
Emitter
Collector
Base
Transistor
Source
Gate
Drain
Cathode
Anode
Anode Cathode
Anode
Anode
*
REFERENCE INFORMATION
RESISTOR
: RN METAL FILM
: RC SOLID
: FPRD NONFLAMMABLE CARBON
: FUSE NONFLAMMABLE FUSIBLE
: RW NONFLAMMABLE WIREWOUND
: RS NONFLAMMABLE METAL OXIDE
: RB NONFLAMMABLE CEMENT
: ADJUSTMENT RESISTOR
COIL
: LF-8L MICRO INDUCTOR
CAPACITOR
: TA TANTALUM
: PS STYROL
: PP POLYPROPYLENE
: PT MYLAR
: MPS METALIZED POLYESTER
: MPP METALIZED POLYPROPYLENE
: ALB BIPOLAR
: ALT HIGH TEMPERATURE
: ALR HIGH RIPPLE


./9=$=$
./9=$=$
%/2&.’,$*5$0
4U
4U !
! - $ - $
X
X  

CPU
Demodu.
MPEG2 Dec.
3D GPX
CC/PL
Sub Chroma
EPG(Gemstar)
USB
Ether
4RIDENT
4RIDENT
78
78
ADC
3D Comb.
Chroma Dec.
IPC
HDMI Rx
ME/MC
YC Process
Scalar
RGB Process
PIP Process
GPX Mix
LVDS Tx
!UDIO
FOR0#
36IDEO
6IDEO
#OMPONENT
!UDIOOUT
6AR&IX
/PTICAL
!UDIO/UT
53"
($-)
#OMPONENT
($-)
($-)
2&
0#($
!UDIO
FOR$6)
2EAR)NPUTS
6IDEO37
6IDEO37
#8!
#8!
H
H
6IDEO
(0
($-)
3IDE)NPUTS
.43#
($-)
956
956
2’"
$IGITAL6IDEO
)452"4
)452"4
$IGITAL’08
2’" <M(6#,+
(63YNC#,+
FOR’08
,#$
&($
T-Con
FHD
&($0ANEL
WITH(&2
,6$3
4!3
4!3H
H
Audio SW
ADC
DSP
Surround
DAC
!UDIO!MP
40!$
!UDIO
#OMPOUND)#
.*-6
30$)&
30$)&
))3($-)
"%-ICRO
-" Buttons
SIRCS
[Control]
Trident
ATI
Video SW
HDMI SW
Power
TAS
HFR
CEC
Audio Mute
$$2
$$2
-"
-"
$$2
$$2
-"
-"
24#
24#
H
H
/NE.!.$
/NE.!.$
-"
-" $$2
$$2
-"
-"
FOR!43#
.43#FOR0!0
.43#FOR##
I9/54FOR##
($-)
($-)
%1?37
%1?37
!$
!$
 TO
TO
EH
EH
LEDs
ECS
BITBUS
5!24
))#
))#
))#
4EMPERATURE
4EMPERATURE
3ENSOR
3ENSOR
H
H
))3
!$#
!$#
FOR5)
SOUND
4#/.
(&2
H
53"
0(9
%THER
%THER
0(9
0(9
53"
%THER
$-PORT
5!24
