Sony KLV-55EX500 User manual

D:\Cmeng's JOB\SONY TV\SY0251_T1 (Rev-3)\4167239131_GB\010COV.fm
4-167-239-13(1)
KLV-40/32EX600/55/46/40/32EX500/46/40/32EX400/32/26/22EX300/40/32NX500/32/26NX400
4-167-239-13(1)
LCD Colour TV
Operating Instructions
Start-up Guide
Operating the TV
Using Optional Equipment
Using MENU Functions
Additional Information
KLV-55EX500 / 46EX500 / 46EX400 / 40EX600 / 40EX500 / 40EX400 / 40NX500 / 32EX600 / 32EX500
KLV-32EX400 / 32EX300 / 32NX500 / 32NX400 / 26EX300 / 26NX400 / 22EX300

2GB
KLV-40/32EX600/55/46/40/32EX500/46/40/32EX400/32/26/22EX300/40/32NX500/32/26NX400
4-167-239-13(1)
Thank you for choosing this Sony product.
Before operating the TV, please read this manual
thoroughly and retain it for future reference.
The illustrations used in this manual are of the
KLV-32EX300 unless otherwise stated.
The Euro/South Africa converter plug should be fitted
as follows.
1Insert the power
supply or CEE7
plug in to the
converter plug.
2Use an appropriate
screwdriver to
attach the screw
tightly without
damaging the
screw head.
3TEST: Grip the
converter plug, and
pull the VDE cord
set/transformer to
ensure it is fully
secure, if not then
increase the torque
setting and further
tighten.
Re-test.
The converter plug
is now ready for
use.
Attach the supplied plug adaptor.
• HDMI, the HDMI logo and High-Definition
Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC.
• “BRAVIA” and are trademarks of Sony
Corporation.
Introduction
Notice for customers in South Africa
Notice for customers in India
Trademark information

D:\Cmeng's JOB\SONY TV\SY0251_T1 (Rev-
3)\4167239131_GB\010COVTOC.fm
masterpage:Left
KLV-40/32EX600/55/46/40/32EX500/46/40/32EX400/32/26/22EX300/40/32NX500/32/26NX400
4-167-239-13(1)
3GB
Table of Contents
Start-up Guide
Checking the accessories ..................................4
1: Attaching the stand.........................................4
2: Connecting an antenna/cable/VCR ................5
3: Preventing the TV from toppling over .............5
4: Bundling the cables ........................................6
5: Performing the initial set-up............................6
Watching TV.......................................................6
Adjusting the viewing angle of the TV ................6
Adjust the angle left and right (swivel) ............. 6
Adjust the angle back and forth (tilt) ................ 6
Detaching the stand from the TV........................7
Safety information ..............................................8
Precautions ........................................................9
Operating the TV
Overview of the remote ....................................10
Overview of the TV buttons and indicators.......12
Using Optional Equipment
Connecting optional equipment........................13
Viewing pictures from the connected
equipment.........................................................14
Viewing Twin Picture ........................................15
Viewing PIP (Picture in Picture)........................15
Using MENU Functions
Navigating through menus ............................... 16
Playing back photo/music/video via USB......... 16
Using BRAVIA Sync with Control for HDMI ..... 17
Settings adjustment.......................................... 18
Picture .............................................................18
Sound..............................................................19
Screen.............................................................20
Channel Set-up ...............................................22
Parental Lock ..................................................23
Set-up..............................................................23
Eco ..................................................................25
Additional Information
Installing the accessories (Wall-Mount
Bracket)............................................................ 26
TV installation dimensions table......................26
Screw and hook locations diagram/table .......28
Troubleshooting ............................................... 29
Specifications................................................... 31
Before operating the TV, please read “Safety information” (page 8). Retain this manual for future reference.

D:\Cmeng's JOB\SONY TV\SY0251_T1 (Rev-
3)\4167239131_GB\030STU.fm
masterpage:Left
4GB
KLV-40/32EX600/55/46/40/32EX500/46/40/32EX400/32/26/22EX300/40/32NX500/32/26NX400
4-167-239-13(1)
Start-up Guide
Checking the accessories
AC power cord (For KLV-40/32EX600/
KLV-55/46EX500/KLV-46EX400)
Cable holder (1) (For KLV-40/32EX600/
KLV-40/32NX500/KLV-32/26NX400)
Stand (1) and screws (8) (For KLV-40/32EX600/
KLV-40/32EX500/KLV-40/32NX500/
KLV-32/26NX400)
Stand (1) and screws (7) (For KLV-40/32EX400/
KLV-32/26EX300)
Stand (1) and screws (6) (For KLV-22EX300)
Stand (1) and screws (4) (For KLV-55/46EX500/
KLV-46EX400)
Remote RM-GA018 (1) (For KLV-40/32EX600/
KLV-55/46/40/32EX500/KLV-40/32NX500/
KLV-32/26NX400)
Remote RM-GA019 (1) (For KLV-46/40/32EX400/
KLV-32/26/22EX300)
Size AAA batteries (R03 type) (2)
To insert batteries into the remote
BKLV-40/32EX600/KLV-55/46/40/32EX500/
KLV-40/32NX500/KLV-32/26NX400
BKLV-46/40/32EX400/KLV-32/26/22EX300
1: Attaching the stand
• Refer to the supplied stand leaflet for proper
attachment for some TV models.
BKLV-40/32EX600
BKLV-55/46/40/32EX500/KLV-46/40/32EX400/
KLV-32/26EX300/KLV-40/32NX500/
KLV-32/26NX400
Slide the cover to
open
Push and lift the cover to open

5GB
Start-up Guide
KLV-40/32EX600/55/46/40/32EX500/46/40/32EX400/32/26/22EX300/40/32NX500/32/26NX400
4-167-239-13(1)
BKLV-22EX300
• Fix the TV to the stand according to the arrow marks
that guide the screw holes using the supplied
screws.
• This TV is very heavy, so two or more people should
place the TV onto the stand.
• If using an electric screwdriver, set the tightening
torque at approximately 1.5 N·m (15 kgf·cm).
• Ensure the AC power cord is away from screw holes
during stand installation to avoid damage to the AC
power cord.
2: Connecting an antenna/
cable/VCR
• Connecting cables are not supplied.
Connecting an antenna/cable
3: Preventing the TV from
toppling over
1Install a wood screw (4 mm in diameter, not
supplied) in the TV stand.
2Install a machine screw (M4 × 16, not
supplied) into the screw hole of the TV.
3Tie the wood screw and the machine screw
with a strong cord (not supplied).
z• An optional Sony support belt kit is used to secure the
TV. Contact your nearest Sony service centre to
purchase a kit. Have your TV model name ready for
reference.
8
Antenna cable
8
Connecting an antenna/cable and VCR
Antenna cable
Antenna cable
AV cable
VCR
