CPD-100ES
•15" Trinitron® CRT (14.0" viewable image size)
•Super Fine Pitch™ 0.25mm Aperture Grille
•Vertically flat short-neck CRT design
•Compact, redesigned cabinet
features reduced depth
with detachable tilt-swivel base
•Digital Multiscan Technology
supports multiple PC and Mac resolutions
up to 1280 x 1024 @ 60Hz
•On-screen digital controls
•Built-in self-diagnosis function
•Designed for Windows® 95
and Windows NT®
•Macintosh® compatible
•International Energy Star compliant
•MPR II approved
Multiscan®Computer Display
CPD-100ES
Affordability
Without
Compromise

Multiscan® Computer Display
CPD-100ES
The Sony CPD-100ES provides the budget-conscious computer user a better option over
monitors based on shadow mask CRT technology. This entry level 15" computer display
(14" VIS) provides features normally found on high-end Sony Computer displays, including
the crispness of Sony’s legendary Trinitron CRT technology, a 0.25mm aperture grille pitch,
and precise, convenient on-screen digital controls. Easy-to-use on-screen controls for
brightness/contrast, horizontal and vertical size and centering, pincushion, raster rotation
and color temperature reflect Sony’s passion for outstanding image quality. The CPD-100ES
also features a short neck CRT and new cosmetic design, complete with detachable tilt-
swivel base for more placement options on the desktop.
SPECIFICATIONS
CRT
15" Trinitron CRT with Short Neck CRT Design
90°deflection
Viewable Image Size
14.0" measured diagonally
Aperture Grille Pitch
0.25mm
Horizontal Scan Range
30-70kHz
Vertical Scan Range
50-120Hz
Maximum Resolution and Refreshed Rate
1024 x 768 @ 85Hz
1280 x 1024 @ 60Hz
Preset Resolutions
640 x 480 @ 60Hz VGA Graphics
640 x 480 @ 85Hz VESA
800 x 600 @ 75Hz VESA
800 x 600 @ 85Hz VESA
832 x 624 @75Hz Macintosh 16"
1024 x 768 @ 75Hz VESA
1024 x 768 @ 85Hz VESA
1280 x1024 @ 60 Hz VESA
Color Temperature Presets
5000 Kelvin
9300 Kelvin
User Adjustable (5000-9300K)
Signal Inputs
Analog RGB: 0.7Vp-p, 75 ohm termination
External Sync Signals:
Composite 1-5 Vp-p, polarity-free TTL
Sync on Green: 0.3Vp-p, negative
Power Requirements
100-120/220-240V AC; 50/60Hz
Power Management
International Energy Star, NUTEK, and VESA
DPMS compliant
Operation: 110 watts (maximum)
Suspend: 15 watts (maximum)
Active off: 8 watts (maximum)
Dimensions (WxHxD)
14.5" x 15.4" x 15.3"
Weight
30.9 lbs
Operating Temperature
50°F-104°F (10°C-40°C)
Operating Humidity
10%-80%, non-condensing
Regulation Compliance
Safety: UL 1950
CSA 950
EN60950 (TUV, GS mark/CE mark)
SEMKO, NEMKO,
DEMKO, FIMCO, NOM, EI
Emission/EMI: FCC Class B
IC Class B
MPR II (TUV) (full compliance)
X-ray: DHHS, DNHW
PTB
Ergonomic: ZH1/618, ISO9241-3, -8
ISO9241-8
Designed for: Microsoft® Windows NT® and
Windows® 95
Macintosh® Compatible
Plug and Play: DDC-1, DDC-2B
Front Panel Digital Controls
Power On/Off
Reset
Brightness
Contrast
On Screen Displays (OSD)
Horizontal Size and Centering
Vertical Size and Centering
Pincushion Distortion Correction
Raster Rotation
Pin Cushion
Color Temperature
Supplies Accessories
Detachable Tilt Base/Wide Angle Swivel (±90°) Stand
AC Power cord
Windows® 95 inf. diskette
Optional Accessories
Macintosh Adaptor available by calling
1.800.352.7669
Input Cable
Captive 15-pin mini D-sub (attached)
Limited Warranty
1 year Parts, Labor and CRT
Sony Electronics Inc.
Information Technologies of America
3300 Zanker Road, San Jose, California 95134
For more information: 1.800.4SONYPC (7669)
Web address: http://www.sony.com/displays
Computer Interface: The computer industry lacks standards, and therefore, there
are a multitude of varying software packages and add-on hardware options. This
display is not manufactured to any specific software, and Sony does not and
cannot make any warranty or representation with respect to the performance
of this product with any particular software packages and/or non-Sony add-on
hardware option except those mentioned in this document. Sony hereby dis-
claims any representations or warranty that this product is compatible with
any combination of non-Sony products you may choose to connect. While
Sony representatives or Sony authorized dealers may be able to assist you
and may make recommendations, they are NOT authorized to vary or waive this
disclaimer. Purchasers must determine for themselves the suitability and com-
patibility of the hardware and software in each and every particular instance.
Simulated graphic shown on display.
©1997 Sony Electronics Inc. All rights reserved. Reproduction in whole or
in part without written permission is prohibited. Sony, Multiscan, Super
Fine Pitch, the Trinitron logo, and Trinitron are trademarks of Sony. Microsoft,
the Windows logo and Windows NT are registered trademarks of Microsoft
Corporation. Macintosh is a trademark of Apple Computer Inc. Features and
specifications are subject to change without notice. Non-metric weights and
measurements are approximate.
This monitor is Energy Star Compliant when used with a computer equipped
with VESA Display Power Management Signaling (DPMS). As an International
Energy Star Partner, Sony Corporation has determined that this product meets
the International Energy Star Program for energy efficiency. The Energy Star
emblem does not represent EPA endorsement of any product or service.
D143
Printed in U.S.A. 10/97
