PFM-42V1 series Protocol Manual
(Full access version)
Preliminary Ver. 1.1

1. Communication Parameters
Baud Rate 9600
Character length 8 bits
Parity none
Stop bit length 1 bits
Flow Control none
2. Pin Assignment
Monitor side : D-sub 9pin (Female) Host side : D-sub 9pin (male)
Pin number Function Pin number Function
1NC 1NC
2RD 2RD
3TD 3TD
4NC 4NC
5GND 5GND
6NC 6NC
7NC 7NC
8NC 8NC
9NC 9NC
(Straight connection is necessary)

3. Command Table
1. General Function.
(a) Mode Control
Syntax Header Category Function Data1 Data2
Control 0x8C 0x01 Code Table
(1-a)-[b]
Enquiry 0x83 0xFF 0xFF
Execute Judge 0x89
0x00 Code Table (1-a)-
[a]
0xFF 0xFF
Answer Header Answer Return Data Size Return Data1 Return Data2 …
0x70 0x00 Completed
0x70 0x01 Limit Over
0x70 0x02 Limit Under
Control
0x70 0x03 Command Canceled
Enquiry 0x70 0x00 0x01 Code Table
(1-a)-[b]
Completed
0x700x00 Variable Code Table
(1-a)-[b]
……Completed with Enable
Codes
0x70 0x03 Command Disable
Execute Judge
0x70 0x04 Command All Enable

Code table (1-a)
Command Execute Judge ACK
[a] Function [b] Range/Switch Code Control Enquiry Standby Setup
Sequence
Power
On
0x00 OFF0x00 Power
0x01 ON
Yes Yes Enable Enable Enable
0x08 MON RGB1
0x09 MON YUV1
0x0A MON RGB2
0x0B MON YUV2
0x0C MON VIDEO (COMPOSITE)
0x0D MON VIDEO (Y/C)
0x01 Input Select
0x20 MON DVI
Yes Yes Disable Note Note
0x00 OFF0x02 Force Status Display
0x01 ON
Yes Yes Disable Disable Enable
0x00 OFF0x03 Audio Mute
0x01 ON
Yes Yes Disable Disable Enable
0x00 ON0x04 Auto Status Display
0x01 OFF
Yes Yes Disable Disable Enable
0x00 OFF
0x01 Caption1
0x02 Caption2
0x03 Text1
0x05 Closed Caption
0x04 Text2
Yes Yes Disable Disable Note
0x00 Auto
0x01 NTSC
0x02 NTSC 4.43
0x03 PAL
0x04 SECAM
0x05 PAL-M
0x06 PAL-N
0x06 Color System
0x07 PAL60
Yes Yes Disable Disable Note
0x00 NTSC/PAL/SECAM/NTSC4430x07 Auto Color System
0x01 NTSC/PAL-M/PAL-N
Yes Yes Disable Disable Note
0x00 OFF0x08 Power Saving
0x01 ON
Yes Yes Note Note Note
0x00 OFF Timer
0x01 ON Timer
0x02 ON/OFF Timer
0x09 ON/OFF Timer
0x03 OFF
Yes Yes Note Note Note

Code table (1-a)
Command Execute Judge ACK
[a] Function [b] Range/Switch Code Control Enquiry Standby Setup
Sequence
Power
On
0x00 OFF0x0A Timer Repeat
0x01 ON
Yes Yes Enable Enable Enable
0x00 OFF
0x01 AUTO
0x0B Picture Inversion
0x02 ON
Yes Yes Note Note Note
0x00 OFF0x0C Picture Orbit
0x01 ON
Yes Yes Enable Enable Enable
0x00 Small
0x01 Middle
0x0D Orbit Range
0x02 Large
Yes Yes Enable Enable Enable
0x00 10 sec.
0x01 30 sec.
0x02 1 min.
0x0E Orbit Cycle
0x03 5 min.
Yes Yes Enable Enable Enable
0x00 Japanese
0x01 English
0x02 Deutsch
0x03 Francais
0x04 Espanol
0x0F Language
0x05 Italiano
Yes Yes Enable Enable Enable
0x10 Index Number 0x01 –0xFF Yes Yes Enable Enable Enable
0x00 ON
0x01 ON
0x11 Remote Mode
0x02OFF
Yes Yes Enable Enable Enable
0x00 OFF0x12 Remote Only
0x01 ON
Yes Yes Enable Enable Enable
0x00 Standard0x13 Energy Saving
0x01 Reduce
Yes Yes Enable Enable Enable
0x00 ON0x14 Speaker Out
0x01 OFF
Yes Yes Disable Disable Enable
0x00 1080i0x16 HD Mode
0x01 1035i
Yes Yes Disable Disable Enable
0x00 DTV0x17 RGB Mode
0x01 PC
Yes Yes Disable Disable Enable
0x00 H/Comp0x18 Sync Mode
0x01 Video
Yes Yes Disable Disable Enable

Code table (1-a)
Command Execute Judge ACK
[a] Function [b] Range/Switch Code Control Enquiry Standby Setup
Sequence
Power
On
0x00 On/Off0x19 Menu Key
0x01 Return
Yes Yes Disable Disable Enable
0x00 OFF
0x01 30 min
0x02 60 min
0x03 90 min
0x1A Sleep
0x04 120 min
Yes Yes Note Note Note
0x00 OFF0x1B Clock Display
0x01 ON
Yes Yes Enable Enable Enable
0x00 ON0x30 PAP
0x01 OFF
Yes Yes Disable Disable Enable
0x00 Left
0x01 Right
0x31 Active Picture
0x02 Swap
Yes Yes Disable Disable Enable
0x32 Picture Size 0x00 –0x0E Yes Yes Disable Disable Enable

(b) Color matrix
Syntax Header Category Function Data1 Data2 Data3
Control 0x8C 0x02 Code Table
(1-c)
Code Table
(1-b)-[b]
Enquiry 0x83 Code Table
(1-c)
0xFF
Execute Judge 0x89
0x00 Code Table (1-b)-
[a]
0xFF 0xFF
Answer Header Answer Return Data Size Return Data1 Return Data2 …
0x70 0x00 CompletedControl
0x70 0x03 Command Canceled
Enquiry 0x70 0x00 0x02 Code Table
(1-c)
Code Table
(1-b)-[b]
Completed
0x70 0x03 Command DisableExecute Judge
0x70 0x04 Command All Enable
Code Table (1-b)
Command Execute Judge ACK
[a] Function [b] Range/Switch Code Control Enquiry Standby Setup
Sequence
Power
On
0x00 YCbCr0x1D Color Matrix
0x01 YPbPr
Yes Yes Disable Enable Enable
Code Table (1-c)
Format Select
0x00 480p
0x01 1080i
0x02 720p

(c) Time control
Syntax Header Category Function Data1 Data2 Data3
Control 0x8C 0x02 Hour:
0x00 –0x17
Minute:
0x00 –0x3B
Enquiry 0x83 Code Table
(1-c)
0xFF
Execute Judge 0x89
0x00 Code Table (1-d)-
[a]
0xFF 0xFF
Answer Header Answer Return Data Size Return Data1 Return Data2 …
0x70 0x00 Completed
0x70 0x01 Limit Over
0x70 0x02 Limit Under
Control
0x70 0x03 Command Canceled
Enquiry 0x70 0x00 0x02 Hour:
0x00 –0x17
Minute:
0x00 –0x3B
Completed
Execute Judge 0x70 0x04 Command All Enable
Code Table (1-d)
Command Execute Judge ACK
[a] Function [b] Range/Switch Code Control Enquiry Standby Setup
Sequence
Power
On
ON/OFF Timer
0x1E Power ON Time Yes Yes Enable Enable Enable
0x1F Power OFF Time Yes Yes Enable Enable Enable
Picture Inversion
0x20 Invert Start Time Yes Yes Enable Enable Enable
0x21 Invert End Time Yes Yes Enable Enable Enable
Time Set
0x22 Time Set Yes Yes Enable Enable Enable

2. Picture/Sound
(a) Picture/sound
Syntax Header Category Function Data1 Data2
Control 0x8C 0x01 Code Table
(2-a)-[b]
Enquiry 0x83 0xFF 0xFF
Execute Judge 0x89
0x10 Code Table (2-a)-
[a]
0xFF 0xFF
Answer Header Answer Return Data Size Return Data1 Return Data2 …
0x70 0x00 Completed
0x70 0x01 Limit Over
0x70 0x02 Limit Under
Control
0x70 0x03 Command Canceled
Enquiry 0x70 0x00 0x01 Code Table
(2-a)-[b]
Completed
0x70 0x00 Variable (Data
Size)
Code Table
(2-a)-[b]
……Completed with Enable
Codes
0x70 0x03 Command Disable
Execute Judge
0x70 0x04 Command All Enable
Code table (2-a)
Command Execute Judge ACK
[a] Function [b] Range/Switch Code Control Enquiry Standby Setup
Sequence
Power
On
0x00 Contrast 0x00 –0x64 Yes Yes Disable Disable Enable
0x01 Brightness 0x00 –0x64 Yes Yes Disable Disable Enable
0x02 Chroma 0x00 –0xC8 Yes Yes Disable Disable Enable
0x03 Phase 0x00 –0x64 Yes Yes Disable Disable Enable
0x00 Cool
0x01 Neutral
0x02 Warm
0x03 User1
0x04 User2
0x04 Color Temp
0x05 User3
Yes Yes Disable Disable Enable
0x09 Sharpness 0x00 –0x14 Yes Yes Disable Disable Enable
0x00 Off
0x01 Low
0x02 Mid
0x0A NR
0x03 High
Yes Yes Disable Disable Enable

Code table (2-a)
Command Execute Judge ACK
[a] Function [b] Range/Switch Code Control Enquiry Standby Setup
Sequence
Power
On
0x00 On0x0C Dynamic Picture
0x01 Off
Yes Yes Disable Disable Enable
0x00 High
0x01 Mid
0x0E Gamma Correct
0x02 Low
Yes Yes Disable Disable Enable
0x00 Standard
0x01 Vivid
0x02 User1
0x03 User2
0x10 Picture Mode
0x04 User3
Yes Yes Disable Disable Enable
0x30 Volume 0x00 –0x64 Yes Yes Disable Disable Enable
0x31 Treble 0x00 –0x64 Yes Yes Disable Disable Enable
0x32 Bass 0x00 –0x64 Yes Yes Disable Disable Enable
0x33 Balance 0x00 –0x64 Yes Yes Disable Disable Enable
0x00 Off
0x01 Hall
0x34 Surround
0x02 Simulate
Yes Yes Disable Disable Enable

(b) Color temperature
Syntax Header Category Function Data1 Data2 Data3
Control 0x8C 0x02 Code Table
(2-c)
Code Table
(2-b)-[b]
Enquiry 0x83 Code Table
(2-c)
0xFF
Execute Judge0x89
0x10 Code Table (2-b)-
[a]
0xFF 0xFF
Answer Header Answer Return Data Size Return Data1 Return Data2
0x70 0x00 CompletedControl
0x70 0x03 Command Canceled
Enquiry 0x70 0x00 0x02 Code Table
(2-c)
Code Table
(2-b)-[b]
Completed
0x70 0x03 Command DisableExecute Judge
0x70 0x04 Command All Enable
Code table (2-b)
Command Execute Judge ACK
[a] Function [b] Range/Switch Code Control Enquiry Standby Setup
Sequence
Power
On
0x05 Red Gain 0x00 –0x1E Yes Yes Disable Disable Disable
0x06 Green Gain 0x00 –0x1E Yes Yes Disable Disable Disable
0x07 Blue Gain 0x00 –0x1E Yes Yes Disable Disable Disable
Code Table (2-c)
Format Select
0x03 User1
0x04 User2
0x05 User3

(c) Color temperature name
Syntax Header Category Function Data1 Data2 Data3 to Data8
Control 0x8C 0x07 Code Table (2-c)
Temp Select
0x00 –0xFF
Enquiry 0x83 Code Table (2-c)
Temp Select
0xFF
Execute Judge 0x89
0x10 0x08
0xFF 0xFF
Answer Header Answer Return Data Size Return Data1 to Data6
0x70 0x00 Completed
0x70 0x01 Limit Over
0x70 0x02 Limit Under
Control
0x70 0x03 Command Canceled
Enquiry 0x70 0x00 0x06 Character Data (0x00-0xFF) Completed
0x70 0x03 Command DisableExecute Judge
0x70 0x04 Command All Enable

3. Size/Shift
(a) 16bit register
Syntax Header Category Function Data1 Data2 Data3
Control 0x8C 0x02 Code Table
(3-a)-[b]
Code Table
(3-a)-[b]
Enquiry 0x83 0xFF 0xFF
Execute Judge 0x89
0x20 Code Table (3-a)-
[a]
0xFF 0xFF
Answer Header Answer Return Data Size Return Data1 Return Data2
0x70 0x00 Completed
0x70 0x01 Limit Over
Control
0x70 0x02 Limit Under
Enquiry 0x70 0x03 0x02 Code Table
(3-a)-[b]
Code Table
(3-a)-[b]
Completed
0x70 0x03 Command DisableExecute Judge
0x70 0x04 Command All Enable
Code table (3-a)
Command Execute Judge ACK
[a] Function [b] Range/Switch Code Control Enquiry Standby Setup
Sequence
Power
On
0x0A H Total Pixel 0x0190 –0x09C4 (default +/-50) Yes Yes Disable Disable Disable
(b) 8bit register
Syntax Header Category Function Data1 Data2
Control 0x8C 0x01 Code Table
(3-b)-[b]
Enquiry 0x83 0xFF 0xFF
Execute Judge 0x89
0x20 Code Table (3-b)-[a]
0xFF 0xFF
Answer Header Answer Return Data Size Return Data1 Return Data2 …
0x70 0x00 Completed
0x70 0x01 Limit Over
0x70 0x02 Limit Under
Control
0x70 0x03 Command Canceled
Enquiry 0x70 0x00 0x01 Code Table
(3-b)-[b]
Completed
0x70 0x00 Variable (Data Size) Code Table
(3-b)-[b]
……Command Disable
0x70 0x03 Command Disable
Execute Judge
0x70 0x04 Command All Enable
Code table (3-b)

Command Execute Judge ACK
[a] Function [b] Range/Switch Code Control Enquiry Standby Setup
Sequence
Power
On
0x00 H Size 0x00 –0x3C Yes Yes Disable Disable Enable
0x01 H Shift 0x00 –0x3C Yes Yes Disable Disable Enable
0x02 V Size 0x00 –0x3C Yes Yes Disable Disable Enable
0x03 V Shift 0x00 –0x3C Yes Yes Disable Disable Enable
0x00 Expd. 4:3
0x01 Letter Box
0x02 16:9
0x03 Subtitle
0x04 Zoom Mode
0x04 4:3
Yes Yes Disable Disable Note
0x00 Standard
0x01 X2
0x02 X3
0x05 Zoom size
0x03 X4
Yes Yes Disable Disable Note
0x06 Auto Pixel Adjust 0xFF Execute Yes No Disable Disable Enable
0x07 Dot Phase 0x00 –0x1F Yes Yes Disable Disable Enable
0x00 Off0x08 Auto Wide
0x01 On
Yes Yes Disable Disable Note
0x00 4:30x09 4:3 Mode
0x01 Expd. 4:3
Yes Yes Disable Disable Enable

4. Status Enquiry
(a) Model name enquiry
Syntax Header Category Function Data1 Data2
Enquiry 0x83 0xFF 0xFF
Execute Judge 0x89
0x30 0x00
0xFF 0xFF
Answer Header Answer Return Data Size Return Data1
Enquiry 0x70 0x00 0x01 Code Table
(4-a)
Completed
Execute Judge 0x70 0x04 Command All Enable
Code Table (4-a)
Format Select
0x20 PFM-42V1
(b) Serial number enquiry
Syntax Header Category Function Data1 Data2
Enquiry 0x83 0xFF 0xFF
Execute Judge 0x89
0x30 0x01
0xFF 0xFF
Answer Header Answer Return Data Size Return Data1 Return Data2 Return Data3 Return Data4
Enquiry 0x70 0x00 0x04 Upper 8bit
Data
Middle
Upper Data
Middle
Lower Data
Lower 8bit
Data
Completed
Execute Judge 0x70 0x04 Command
All Enable
Return Data1 –Data4: 0x00000000 –0x0098967F (0000000 –9999999)
(c) Operation time enquiry
Syntax Header Category Function Data1 Data2
Enquiry 0x83 0xFF 0xFF
Execute Judge 0x89
0x30 0x02
0xFF 0xFF
Answer Header Answer Return Data Size Return Data1 Return Data2 Return Data3 Return Data4
Enquiry 0x70 0x00 0x04 Upper 8bit
Data
Middle
Upper Data
Middle
Lower Data
Lower 8bit
Data
Completed
Execute Judge 0x70 0x04 Command
All Enable
Return Data1 –Data4: 0x00000000 –0xD693A3FF (0 sec. –3,599,999,999 sec.)

(d) Software version enquiry
Syntax Header Category Function Data1 Data2
Enquiry 0x83 0xFF 0xFF
Execute Judge 0x89
0x30 0x03
0xFF 0xFF
Answer Header Answer Return Data Size Return Data1 Return Data2
Enquiry 0x70 0x00 0x02 Upper 8bit
Data
Lower 8bit
Data
Completed
Execute Judge 0x70 0x04 Command All Enable
Return Data1 –Data2: 0x0000 –0xFFFF
(e) H/V frequency enquiry
Syntax Header Category Function Data1 Data2
Enquiry 0x83 0xFF 0xFF
Execute Judge 0x89
0x30 Code Table (4-b)
0xFF 0xFF
Answer Header Answer Return Data Size Return Data1 Return Data2
0x70 0x00 0x02 Upper 7bit
Data
Lower 7bit
Data
CompletedEnquiry
0x70 0x03Command Cancel
0x70 0x03 Command DisableExecute Judge
0x70 0x04 Command All Enable
Return Data1 –Data2: 0x0000 –0xFFFF H Frequency = Return Data X 10 [Hz]
V Frequency = Return Data / 100[Hz]
Code Table (4-b)
Execute Judge ACK
Function Standby Setup
Sequence
Power
On
0x04 H Frequency Disable Disable Enable
0x05 V Frequency Disable Disable Enable

(f) Sync polarity enquiry
Syntax Header Category Function Data1 Data2
Enquiry 0x83 0xFF 0xFF
Execute Judge 0x89
0x30 0x06
0xFF 0xFF
Answer Header Answer Return Data Size Return Data1
0x70 0x00 0x01 Code Table
(4-c)
CompletedEnquiry
0x70 0x03 Command Cancel
0x70 0x03 Command DisableExecute Judge
0x70 0x04 Command All Enable
Code Table (4-c)
Execute Judge ACK
Function Standby Setup
Sequence
Power
On
0x00 H:Nega / V:Nega Disable Disable Enable
0x01 H:Nega / V:Posi Disable Disable Enable
0x02 H:Posi / V:Nega Disable Disable Enable
0x03 H:Posi / V:Posi Disable Disable Enable
0x04 SonG Disable Disable Enable
0x05 No H/V Sync Disable Disable Enable

5. User Memory
(a) Load/save
Syntax Header Category Function Data1 Data2
Control 0x8C 0x01 Code Table
(5-b)
Execute Judge 0x89
0x40 Code Table (5-a)-[a]
0xFF 0xFF
(b) Memory name
Syntax Header Category Function Data1 Data2 Data3 to Data8
Control 0x8C 0x07 Code Table (5-b) Character Data
(0x00 –0xFF)
Enquiry 0x83 Code Table (5-b) 0xFF
Execute Judge 0x89
0x40 0x02
0xFF 0xFF
Answer Header Answer Return Data Size Return Data1 to Data6
0x70 0x00 Completed
0x70 0x01 Limit Over
0x70 0x02 Limit Under
Control
0x70 0x03 Command Canceled
Enquiry 0x70 0x00 0x06 Character Data (0x00 –0xFF) Complete
0x70 0x03 Command DisableExecute Judge
0x70 0x04 Command All Enable
Code table (5-a)
Command Execute Judge ACK
[a] Function [b] Range/Switch Code Control Enquiry Standby Setup
Sequence
Power
On
0x00 Memory Load Execute Yes No Disable Disable Enable
0x01 Memory Save Execute Yes No Disable Disable Enable
0x02 Memory Name Execute Yes No Enable Enable Enable
Code Table (5-b)
Memory Number
0x00 User Memory 1 0x0A User Memory 11
0x01 User Memory 2 0x0B User Memory 12
0x02 User Memory 3 0x0C User Memory 13
0x03 User Memory 4 0x0D User Memory 14
0x04 User Memory 5 0x0E User Memory 15
0x05 User Memory 6 0x0F User Memory 16
0x06 User Memory 7 0x10 User Memory 17
0x07 User Memory 8 0x11 User Memory 18
0x08 User Memory 9 0x12 User Memory 19
0x09 User Memory 10 0x13 User Memory 20

6. User Reset
Syntax Header Category Function Data1 Data2
Control 0x8C 0x01 0xFF
Execute Judge 0x89
0x50 Code Table (6)
0xFF 0xFF
Answer Header Answer
0x70 0x00 CompletedControl
0x70 0x03 Command Canceled
0x70 0x03 Command DisableExecute Judge
0x70 0x04 Command All Enable
Code Table (6)
Command Execute Judge ACK
Function Range/Switch Code Control Enquiry Standby Setup
Sequence
Power
On
0x00 Picture Reset Yes No Disable Disable Enable
0x01 Audio Reset Yes No Disable Disable Enable
0x02 Size Reset Yes No Disable Disable Enable
0x03 PLL Reset Yes No Disable Disable Enable

7. Answer
(a) Normal message
Answer
Header 0x70 Normal answer header
Category 0xXX Code table (7-a): Normal code
Code table (7-a)
Normal code
0x00 Completed Normal response.
0x01 Limit over The packet was received normally, but the data value was over the upper limit.
Forcedly the monitor adjusted the data to maximum value.
0x02 Limit under The packet was received normally, but the data value was under the lower limit.
Forcedly the monitor adjusted the data to minimum value.
0x03 Command cancelled The packet was received normally, but the command was cancelled because
the function was not in adjustable mode, such as a function displayed as “—“
in user menu.
0x04 Command all enable The packet was received normally.
The command function is all enable.
0x05 Fail The packet was received normally, but the command was cancelled.
Please retry.
(a) Error message
Answer
Header 0xE0 Error answer header
Category 0xXX Code table (7-b): Error code
Code table (7-b)
Error code
0x00 No function error Packet header, category or function codes do not exist in this protocol.
0x02 Data number error The data value in “Data num”area of received packet was different from the function’s
own number
0x06 Mode error The monitor is already in the service mode via remote commander operation.
(The service mode through IR remote has priority over the serial remote command.)
0x07 Time out Packet communications are interrupted by some error, and did not return to normal
communication within 2 seconds.
