Sony KP-53HS30 - 53" Hi-scan 1080i™ Projection... User guide

24 5/8"
5 3/8"
32 5/8"
DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
KP-53HS20/30 46 1/2" x 55 5/8" x 24 5/8"
POWER
REQUIREMENTS:
POWER
CONSUMPTION:
120V AC
60Hz
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
53" Hi-Scan
Projection TV
157 Lbs (approx.) 250w(max)
1w(stby)
NOTE:
WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION WE
RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL
MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX [phone] • b2b.sel.sony.com
TOP VIEW
21 3/4"
FRONT VIEW
37 5/8"
55 5/8"
42 1/8 "
31 5/8"
46 1/2 "
19 7/8"
SIDE VIEW
JACK PACK
RM-Y908 REMOTE CONTROL
AUX
VHF/UHF
Video
Audio
S-
Video
IN
Video 1 Video 3
Y
Pr
Pb
L
MONO
R
Audio
L
MONO
R
Video
Video 4 Video 5 Video 6
Control S
IN OUT
OUT
TV OUT AUDIO
Fix/Var
CONV
24 5/8"
2 3/4 "
Ir Receiver
under Power
button
R
53"
