Sony HCD-C900 User manual

DAV-C700/C900
US Model
Canadian Model
DAV-C700/C900
AEP Model
UK Model
Australian Model
E Model
DAV-C700
SERVICE MANUAL
COMPACT AV SYSTEM
Sony Corporation
Home Audio Company
ShinagawaTec Service Manual Production Group
9-873-277-01
2001H1600-1
© 2001.8
• DAV-C700/C900 are composed of following models.As
for the service manual, it is issued for each component
model, then, please refer to them.
Ver 1.0 2001. 08
PARTS LIST
Part No. Description Remarks
1-476-785-11 REMOTE COMMANDER (RM-SS900)
01-569-008-21 ADAPTOR, CONVERSION 2P (E32, SP)
1-573-291-11 CONNECTOR, CONVERSION (AEP, UK)
1-754-060-11 ANTENNA (FM) (MX)
1-754-147-11 ANTENNA (FM) (EXCEPT MX)
1-754-149-11 LOOP ANT (AM)
1-769-108-11 CORD, CONNECTION(VIDEO)
01-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK, HK)
1-823-352-11 CORD (WITH CONNECTOR) (RED, 5m)
1-823-352-21 CORD (WITH CONNECTOR) (PURPLE, 5m)
1-823-352-31 CORD (WITH CONNECTOR) (WHT, 5m)
1-823-352-41 CORD (WITH CONNECTOR) (GRY, 15m)
1-823-352-51 CORD (WITH CONNECTOR) (BLU, 15m)
1-823-352-61 CORD (WITH CONNECTOR) (GRN, 5m)
4-228-654-01 CUSHION (SPK) (FOR SS-RS500/TS500)
4-235-055-01 COVER, BATTERY (FOR RM-SS900)
4-235-691-12 MANUAL, INSTRUCTION (ENGLISH) (C700)
4-236-529-11 MANUAL, INSTRUCTION (ENGLISH) (C700)
4-236-529-21 MANUAL, INSTRUCTION (FRENCH) (C700)
4-236-529-31 MANUAL, INSTRUCTION (GERMAN, SPANISH, DUTCH,
SWEDISH, ITALIAN, POLISH) (C700)
4-236-529-41 MANUAL, INSTRUCTION
(DANISH, FINNISH, PORTUGUESE) (C700)
4-236-529-51 MANUAL, INSTRUCTION (CHINESE) (C700)
4-236-529-61 MANUAL, INSTRUCTION (SPANISH) (C700)
4-237-230-11 MANUAL, INSTRUCTION (ENGLISH) (C900)
4-237-230-21 MANUAL, INSTRUCTION (ENGLISH, FRENCH) (C900)
Part No. Description Remarks
DAV-C700
HCD-C700
SS-TS500
SS-RS500
SS-RS500
SS-WS500
DAV-C900
HCD-C900
SS-TS550
SS-CT550
SS-RS550
SS-WS550
COMPACT DISC DECK RECEIVER SYSTEM
FRONT SPEAKER SYSTEM
CENTER SPEAKER SYSTEM
REAR SPEAKER SYSTEM
SUBWOOFER SPEAKER SYSTEM
COMPONENT MODEL NAME
• Abbreviation
E32 : 110-240V AC area in E model
HK : Hong Kong model
MX : Mexican model
SP : Singapore model
The components identified by
mark 0or dotted line with mark
0are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0sont critiques
pour la sécurité.
Ne les remplacer que par une
pièceportantle numéro spécifié.

DAV-C700/C900
REVISION HISTORY
Clicking the version allows you to jump to the revised page.
Also, clicking the version at the upper right on the revised page allows you to jump to the next revised
page.
Ver. Date Description of Revision
1.0 2001.08 New

SS-CT550
US Model
Canadian Model
AEP Model
UK Model
E Model
Australian Model
SERVICE MANUAL
SPEAKER SYSTEM
Sony Corporation
Home Audio Company
Published by Sony Engineering Corporation
9-873-286-02
2001J1600-1
© 2001.10
SPECIFICATIONS
Ver 1.1 2001. 10
Speaker system Bass reflex
Speaker unit 50 mm (2 inches) dia. cone type
Rated impedance 6 ohms
Dimensions (approx.) 260 ×83.5 ×82.7 mm (10 1/4×3 3/8×3 3/8inches) (w/h/d)
Mass (approx.) 0.65 kg (2 lb 2 oz)
• SS-CT550 is the speaker system
in DAV-C900/S800.

2
SS-CT550
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
EXPLODED VIEW AND PARTS LIST
#1
#1
#1
#1
#1
#1
#2
#2
not
supplied
not
supplied
not
supplied
not
supplied
4
18
6
7
5
5
2
3
2
SP1
SP1
SP2
9
1 X-4954-185-1 BRACKET NET (CENTER) SUB ASSY
2 4-237-441-01 RUBBER (SPK), CUSHION
3 4-236-935-01 PANEL, BUFFLE (CENTER)
4 A-4735-531-A ALMINUM CENTER ASSY
5 4-236-755-01 FOOT (CENTER)
6 1-694-836-11 TERMINAL, SPEAKER
7 4-236-934-01 COVER (JACK)
8 4-237-867-01 SCREW (3.5X10), +BTP TAPPING
9 4-237-082-01 SCREW (2-6X10), PWH TAPPING
SP1 1-544-955-11 SPEAKER (56mm)
SP2 1-544-942-11 LOUD SPEAKER (1.1cm)
#1 7-685-535-14 SCREW +BTP 2.6X10 TYPE2 N-S
#2 7-685-105-14 TAPPING +P 2X8 NON-SLIT
Ver 1.1 2001.10

3
SS-CT550
MEMO

SS-CT550
REVISION HISTORY
Clicking the version allows you to jump to the revised page.
Also, clicking the version at the upper right on the revised page allows you to jump to the next revised
page.
Ver. Date Description of Revision
1.1 2001.10 Correction of exploded view and add Ref.No.9 on parts list (ENG-01005)
1.0 2001.08 New

SS-WS550
US Model
Canadian Model
AEP Model
UK Model
E Model
Australian Model
SERVICE MANUAL
SPEAKER SYSTEM
Sony Corporation
Home Audio Company
Shinagawa Tec Service Manual Production Group
9-873-287-01
2001H16001
© 2001.8
SPECIFICATIONS
Ver 1.0 2001. 08
Speaker system Bass reflex
Speaker unit 200 mm (7 7/8inches) dia. cone type
Rated impedance 3 ohms
Dimensions (approx.) 230 ×433 ×400 mm (9 1/8×17 1/8×15 3/4inches) (w/h/d)
Mass (approx.) 9.5 kg (21 lb 10 oz)
• SS-WS550 is the speaker system
in DAV-C900/S800.

2
SS-WS550
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
EXPLODED VIEW AND PARTS LIST
1
not
supplied
2
3
4
5
5
5
6
7
7
SP1
#4
#4
#3
#3
#3 #3
#5 #5
#4
#2
#1
8
9
#2
1 4-949-384-11 EMBLEM (NO.6), SONY
2 4-237-097-01 PANEL, FRONT
3 4-237-104-01 PANEL, TOP
4 4-237-098-01 PANEL, BACK
5 4-237-100-01 FOOT
6 4-237-105-01 COVER (BOTTOM)
7 4-237-101-01 FOOT (FELT)
8 4-237-102-01 CABINET (R)
9 4-237-103-01 CABINET (L)
SP1 1-544-962-11 SPEAKER (20cm)
#1
#2
#3
#4
#5

3
SS-WS550
MEMO

SS-WS550
REVISION HISTORY
Clicking the version allows you to jump to the revised page.
Also, clicking the version at the upper right on the revised page allows you to jump to the next revised
page.
Ver. Date Description of Revision
1.0 2001.08 New

SS-TS550
US Model
Canadian Model
AEP Model
UK Model
E Model
Australian Model
SERVICE MANUAL
SPEAKER SYSTEM
Sony Corporation
Home Audio Company
Shinagawa Tec Service Manual Production Group
9-873-288-01
2001H16001
© 2001.8
SPECIFICATIONS
Ver 1.0 2001. 08
Speaker system Bass reflex
Speaker unit 50 mm (2 inches) dia. cone type, 15 mm (
5
/ 8 inches) dia. balance dome
Rated impedance 6 ohms
Dimensions (approx.) 82.7 ×1053 ×68 mm (3
3
/ 8 ×41
1
/ 2 ×2
3
/ 4 inches) (w/h/d)
Mass (approx.) 3.28 kg (7 lb 15 oz)
• SS-TS550 is the speaker system
in DAV-C900/S800.

2
SS-TS550
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
EXPLODED VIEW AND PARTS LIST
1. SPEAKER SECTION
#1
#2
#1
#1
#1
#1
#1
#1
1
1
2
SP1
SP2
510
11
14
13
12
6
7
7
3
9
8
4
not
supplied
not
supplied
1 4-237-441-01 RUBBER (SPK), CUSHION
2 4-236-936-01 PANEL, BUFFLE (FRONT)
3 X-4954-186-1 BRACKET NET (FRONT) SUB ASSY
4 A-4735-535-A AL, FRONT ASSY
5 4-237-867-01 SCREW (3.5X10), +BTP TAPPING
6 4-236-938-01 HOLDER TEMINAL (FRONT)
7 4-236-758-01 FOOT (FRONT)
8 1-694-836-11 TERMINAL, SPEAKER
9 1-823-531-11 CORD (WITH CONNECTOR)
10 4-237-437-01 CUSHION (HOLDER. TERMINAL)
11 4-237-811-01 CHSHION 1, AL (FRONT)
12 4-237-812-01 CHSHION 2, AL (FRONT)
13 4-237-813-01 CHSHION 3, AL (FRONT)
14 4-236-948-02 CUSHION, CAP (FRONT)
SP1 1-544-955-11 SPEAKER (56mm)
SP2 1-544-942-11 LOUD SPEAKER (1.1cm)
#1 7-685-535-14 SCREW +BTP 2.6X10 TYPE2 N-S
#2 7-685-136-14 SCREW +P 2.6X12 TYPE2 NON-SLIT

3
SS-TS550
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
2. STAND SECTION
#3
#5
#4
not
supplied
51
52
52
53
54
56
57
64
60
63
63
63
63
58
61
62
59
65
51 A-4735-542-A HOLDER SPK ASSY
52 3-831-441-99 CUSHION, SPEAKER
53 1-823-532-11 CORD (WITH CONNECTOR)
54 4-236-941-01 NET PUNCHING (SS)
56 4-236-173-01 ALUMINUM (STAND)
57 4-236-178-01 FOOT (STAND)
58 1-694-836-11 TERMINAL, SPEAKER
59 4-237-867-01 SCREW (3.5X10), +BTP TAPPING
60 4-236-180-01 SLIDER (TERMINAL)
61 4-236-179-01 HOLDER (TERMINAL)
62 4-237-806-01 SCREW (3X6), +KTT TAPPING
63 4-236-757-01 FOOT (STAND)
64 4-237-810-01 CUSHION (STAND. AL)
65 4-237-807-01 SCREW +BTP 3X40
#3 7-685-651-79 SCREW +BTP 3X20 TYPE2 N-S
#4 7-685-546-19 SCREW +BTP 3X8 TYPE2 N-S
#5 7-685-544-14 SCREW +BTP 3X5 TYPE2 N-S

SS-TS550
REVISION HISTORY
Clicking the version allows you to jump to the revised page.
Also, clicking the version at the upper right on the revised page allows you to jump to the next revised
page.
Ver. Date Description of Revision
1.0 2001.08 New

SS-RS550
US Model
Canadian Model
AEP Model
UK Model
E Model
Australian Model
SERVICE MANUAL
SPEAKER SYSTEM
Sony Corporation
Home Audio Company
Shinagawa Tec Service Manual Production Group
9-873-289-01
2001H16001
© 2001.8
SPECIFICATIONS
Ver 1.0 2001. 08
Speaker system Bass reflex
Speaker unit 50 mm (2 inches) dia. cone type
Rated impedance 6 ohms
Dimensions (approx.) 82.7 ×1053 ×68 mm (3
3
/8×41
1
/2×2
3
/4inches) (w/h/d)
Mass (approx.) 3.28 kg (7 lb 15 oz)
• SS-RS550 is the speaker system
in DAV-C900/S800.

2
SS-RS550
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
EXPLODED VIEW AND PARTS LIST
1. SPEAKER SECTION
#1
#7
#1
#8
#1
#8
1
2
4
10
4
5
6
7
7
9
8
3
not
supplied
not
supplied
not
supplied
SP1
SP1
SP2
a
a
1 4-236-937-01 CAP, REAR
2 4-236-155-01 REFLECTOR (REAR)
3 X-4954-216-1 BRACKET (REAR.R) SUB ASSY, NET
3 X-4954-217-1 BRACKET (REAR.L) SUB ASSY, NET
4 4-229-428-01 SCREW, +BVTP TAPPING
5 4-237-867-01 SCREW (3.5X10), +BTP TAPPING
6 4-237-080-01 HOLDER (REAR.L), TERMINAL
6 4-237-081-01 HOLDER (REAR.R), TERMINAL
7 4-236-758-01 FOOT (FRONT)
8 1-823-533-11 CORD (WITH CONNECTOR)
9 1-694-836-11 TERMINAL, SPEAKER
10 4-237-868-01 SCREW TAPPING +PWH 2.6X6
SP1 1-544-955-11 SPEAKER (56mm)
SP2 1-544-942-11 LOUD SPEAKER (1.1cm)
#1 7-685-535-14 SCREW +BTP 2.6X10 TYPE2 N-S
#7 7-685-534-14 SCREW +BTP 2.6X8 TYPE2 N-S
#8 7-685-137-19 SCREW +P 2.6X14 TYPE2 NON-SLIT

3
SS-RS550
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
2. STAND SECTION
#3
#5
#4
not
supplied
51
52
52
53
54
56
57
64
60
63
63
63
65
63
58
61
62
59
51 A-4735-542-A HOLDER SPK ASSY
52 3-831-441-99 CUSHION, SPEAKER
53 1-823-532-11 CORD (WITH CONNECTOR)
54 4-236-941-01 NET PUNCHING (SS)
56 4-236-173-01 ALUMINUM (STAND)
57 4-236-178-01 FOOT (STAND)
58 1-694-836-11 TERMINAL, SPEAKER
59 4-237-867-01 SCREW (3.5X10), +BTP TAPPING
60 4-236-180-01 SLIDER (TERMINAL)
61 4-236-179-01 HOLDER (TERMINAL)
62 4-237-806-01 SCREW (3X6), +KTT TAPPING
63 4-236-757-01 FOOT (STAND)
64 4-237-810-01 CUSHION (STAND. AL)
65 4-237-807-01 SCREW +BTP 3X40
#3 7-685-651-79 SCREW +BTP 3X20 TYPE2 N-S
#4 7-685-546-19 SCREW +BTP 3X8 TYPE2 N-S
#5 7-685-544-14 SCREW +BTP 3X5 TYPE2 N-S

SS-RS550
REVISION HISTORY
Clicking the version allows you to jump to the revised page.
Also, clicking the version at the upper right on the revised page allows you to jump to the next revised
page.
Ver. Date Description of Revision
1.0 2001.08 New

HCD-C700/C900
US Model
Canadian Model
HCD-C700/C900
AEP Model
UK Model
E Model
Australian Model
HCD-C700
SERVICE MANUAL
COMPACT AV SYSTEM
HCD-C700/C900aretheamplifier,DVD/CD and
tuner section in DAV-C700/C900.
SPECIFICATIONS
Ver. 1.5 2005.10
Model Name Using Similar Mechanism NEW
Mechanism Type CDM53K-DVBU7
Base Unit Name DVBU7
Optical Pick-up Name KHM-240AAA
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC DISTORTION:
With 6 ohm loads, both channels driven, from 120 – 10,000 Hz; rated
50 watts per channel minimum RMS power, with no more than 10 %
total harmonic distortion from 250 milliwatts to rated output.
Amplifier section
Stereo mode 50 W + 50 W (6 ohms at 1 kHz, THD 10 %)
Surround mode Front: 50 W + 50 W
Center*: 50 W
Rear*: 50 W + 50 W (6 ohms at 1 kHz, THD 10 %)
Subwoofer*: 100 W (3 ohms at 100 Hz, THD 10 %)
*Depending on the sound field settings and the source, there may be no sound output.
Inputs (Analog) VIDEO 1, 2:
Sensitivity: 150 mV
Impedance: 50 kilohms
Inputs (Digital) VIDEO 2 (optical):
Sensitivity: –
Outputs (Analog) VIDEO 1 (AUDIO OUT):
Voltage: 2 V
Impedance: 1 kilohms
PHONES:
Accepts low- and high-impedance headphones
Outputs (Digital) DIGITAL OUT (CD)
Sensitivity: –
SACD/DVD system
Laser Semiconductor laser
Signal format system NTSC or NTSC/PAL
Frequency response (at 2 CH STEREO mode)
DVD (PCM): 2 Hz to 22 kHz (±1.0 dB)
CD: 2 Hz to 20 kHz (±1.0 dB)
Signal-to-noise ratio More than 80 dB (VIDEO 1 (AUDIO) connectors only)
Harmonic distortion Less than 0.03 %
FM tuner section
System PLL quartz-locked digital synthesizer system
North American model: 87.5 – 108.0 MHz (100 kHz step)
Other models: 87.5 – 108.0 MHz (50 kHz step)
Antenna FM wire antenna
Antenna terminals 75 ohms, unbalanced
Intermediate frequency 10.7 MHz
AM tuner section
System Tuner section:
PLL quartz-locked digital synthesizer system
Tuning range
North American model: 530 – 1,710 kHz (with the interval set at 10 kHz)
531 – 1,710 kHz (with the interval set at 9 kHz)
European, Middle Eastern, and Philipinne models:
531 – 1,602 kHz (with the interval set at 9 kHz)
Other models: 531 – 1,602 kHz (with the interval set at 9 kHz)
530 – 1,710 kHz (with the interval set at 10 kHz)
Antenna Loop antenna
Video section
Inputs Video: 1 Vp-p 75 ohms
Outputs Video: 1 Vp-p 75 ohms
S-video:
Y: 1 Vp-p 75 ohms
C: 0.286 Vp-p 75 ohms
General
Power requirements
North American model: 120 V AC, 60 Hz
European model: 220 – 240 V AC, 50/60 Hz
Australian and Asian models: 220 – 240 V AC, 50/60 Hz
Mexican model: 120 V AC, 60 Hz
Other models: 110 – 240 V/ 220 – 240 V AC, 50/60 Hz
Power consumption 105 W (120 V AC), 105 W (230 V AC)
Dimensions (approx.) 355 100 394 mm (14 ×4 ×15
5
/ 8 inches) (w/h/d) incl. projecting
parts
Mass (approx.) 5.7 kg (12 lb 10 oz)
Operating temperature 5˚C to 35˚C (41˚F to 95˚F)
Operating humidity 5 % to 90 %
Design and specifications are subject to change without notice.
C900 MODEL
C700 MODEL
Stereo mode 70 W + 70 W (4 ohms at 1 kHz, THD 10 %)
Surround mode Front: 70 W + 70 W
Center*: 70 W
Rear*: 50 W + 50 W (6 ohms at 1 kHz, THD 10 %)
Subwoofer*: 100 W (3 ohms at 100 Hz, THD 10 %)
Sony Corporation
Home Audio Division
Published by Sony Engineering Corporation
9-873-327-06
2005J16-1
© 2005.10
Photo : HCD-C700

2
HCD-C700/C900
NOTES ON HANDLINGTHE OPTICAL PICK-UP BLOCK
OR BASE UNIT
The laser diode in the optical pick-up block may suffer electrostatic
break-down because of the potential difference generated by the
charged electrostatic load, etc. on clothing and the human body.
During repair, pay attention to electrostatic break-down and also
use the procedure in the printed matter which is included in the
repair parts.
The flexible board is easily damaged and should be handled with
care.
NOTES ON LASER DIODE EMISSION CHECK
The laser beam on this model is concentrated so as to be focused on
the disc reflective surface by the objective lens in the optical pick-
up block. Therefore, when checking the laser diode emission,
observe from more than 30 cm away from the objective lens.
LASER DIODE AND FOCUS SEARCH OPERATION
CHECK
Carry out the “Scurvecheck”in “CDsection adjustment”andcheck
that the S curve waveform is output several times.
Self-diagnosis Function
(When letters/numbers appear in the
display)
When the self-diagnosis function is
activated to prevent the system from
malfunctioning. In this case a five-character
service number (e.g., C 13 00) with a
combination of a letter and digits appears on
the screen and the front panel display. Refer
to the following table.
First three
characters of
the service
number
C 13
C 31
E XX
(xx is a number)
Cause and/or Corrective
Action
The disc is dirty.
,Clean the disc with a soft
cloth (page 9).
The disc is not inserted
correctly.
,Re-insert the disc
correctly.
To prevent a malfunction, the
system has performed the self-
diagnosis function.
,Contact your nearest Sony
dealer or local authorized
Sony service facility and
give the 5-character
service number.
Example: E 61 10
C:13:00
SELF-DIAGNOSIS
