30" FD Trinitron® WEGA® Hi-Scan® TV
• Super Fine Pitch CRT
• Hi-Scan 1080i™ Display
• ATSC Integrated Tuner and Digital Cable Ready with CableCARD™ Slot
• DRC™ Digital Reality Creation™ MultiFunction circuitry
• Cinemotion™ Reverse 3-2 Pulldown Technology
• HD Detailer™ Wideband Video Amp
• ClearEdge VM™ (Wideband Velocity Modulation Scanning)
• Memory Stick® Media* Enhanced Playback (JPEG,MPEG1,MP3)
• HDMI/HDCP Interface
SuperFine Pitch provides better image detail with high definition sources. The Aperture Grill was
improved by making the vertical slits a finer pitch that increases the number of slits by up to 65%(16 x 9
base). Also improved were the High Precision Deflection Yoke, Fine Focus Electron Gun and the
inclusion of higher intensity Luminescent Phosphors. The result is a more detailed image for both
moving and still images, higher resolution picture quality, and better edge detail.
KD-30/34/36XS955

30" FD Trinitron® WEGA® Hi-Scan® TV
For more information:
http://www.sony.com/dn
KD-30/34/36XS955
Features
Video
• Dynamic Focus™ Circuitry
• Dynamic Picture™ Circuitry
• Trinitone® Color Temperature
• ClearEdge VM™ (Wideband
Velocity Modulation Scanning)
• Vertical Aperture Compensation
• Vertical Center Adjustment
• 3 D Digital Comb Filter
• Wide Modes:
(Normal/Full/Zoom/Wide Zoom)
• Auto Pedestal Clamp
• Auto White Balance
• High Voltage Regulator
• HD Detailer™ Wideband Video
Amplifier
• NTSC Color System
• ID1 Detection
• Magnetic Quadruple Pole
• Tilt Correction
• Vertical Correction
• Vertical Size Adjustment
Audio
• TruSurround® SRS® Audio (7.5W
x 2 With 15W Sub)
• Steady Sound® Automatic Volume
Control With BBE® Audio Effect
• Auto Mute Tuner
• Auto SAP
• Audio Output (Variable/Fixed)
Convenience
• Auto Channel Program
• Caption Vision (CC)
• Channel Fix
• Channel Skip/Add
• Video Label
• V Chip Parental Control
• Speed Surf™ Channel Selection
• Sleep Timer Function
• Tilt Correction
• Program Palette™
(Vivid/Movie/Standard/Sports)
presets
• On Screen Display
(English/Spanish/French)
• Channel Jump
• Front Button Menu Control
• Favorite Channel
• Energy Star® Compliant
• Clock/Timer Two Event
• Antenna Level for DTV
• PSIP Program Information
• DTV Auto Add
Specifications
General
• Power Requirements AC 120V
60Hz
Tuner
• 8 VSB
• ATSC, NTSC
• Clear QAM
• Digital Cable
Inputs and Outputs
• Component Video Input (Y/PB/PR)
2 Rear
• Composite Input 1 Front/3 Rear
• S-Video Input (With Detection): 1
Front/2 Rear
• Control S 1 Rear
• HDMI 1 rear
Supplied Accessories
• Remote Control (RM-Y200)
• AA Battery (2)
• Instruction Manual
Weights & Measures
• KD-30XS955: 154 lbs (69.8kg)
• KD-34XS955: 198 lbs (89.8kg)
• KD-36XS955: 234 lbs 6 oz
(106.3kg)
• KD-30XS955: 35 3/8" x 23 3/4" x
22 1/4" (898 x 604 x 564.5mm)
• KD-34XS955: 39 1/8" x 25 3/4" x
23 3/4" (994 x 654 x 604mm)
• KD-36XS955: 39 1/8" x 30 5/8" x
25" (994 x 776.5 x 634mm)
UPC Codes
• KD-30XS955: 0272426451030
• KD-34XS955: 0272426451890
• KD-36XS955: 0272426452400
©2004 Sony Electronics Inc. All rights
reserved. Features and specifications are
subject to change without notice. All
trademarks referenced herein are trademarks
of Sony or their respective owners.
*All Sony digital still cameras and camcorders
except models DSCD-700, DSCD-770,
DCR-TRV900 and DSR-PD100A store images
on a Memory Stick in the DCF file format,
which is required for playback on these
projectors. If the image file is renamed or
manipulated, the DCF file format must be
restored before playback is possible. Images
captured on all other digital still cameras and
camcorders will need to be formatted on a PC
to the DCF file format (with third party software
not supplied with the projector) before they can
be viewed.
Sony Electronics Inc.
1 Sony Drive
Park Ridge, NJ 07656
