KDL-V26XBR1
BRAVIA ™ XBR® FlatPanelTelevision
Key Features
ATSCIntegratedTunerwithCableCARD™Slot
16:9HDResolutionPanel-1366(H)x768(V)
WEGAEngine ™System
WCG-CCFL(WideColorGamut-CCFL)backlight
WEGAGATE ™-EasyOperationGuide
PCInput
HDMI™(HighDefinitionMultimediaInterface)Connector
Key Technologies
7th Generation Sony ® LCD Panel The Sony® BRAVIA ™ XBR ®series uses the world’s first 7th generation Sony
LCD panel for truly matchless image quality and performance. Specially crafted at the S - LCD plant, these panels
are produced from the world ’s biggest mother glass to efficiently create large, high quality panels. The 1 Mega
Pixel S - PVA high definition display (1366 x 768) that is used offers an astounding 178 degree viewing angle, very
fast response times (8 ms total rise and fall time) and a spectacular contrast ratio.
WCG -CCFL (Wide Color Gamut-Cold Cathode Fluorescent Light) Sony brings decades of television expertise
and experience to LCD with a revolutionary backlight - WCG - CCFL. New spectrum phosphors have been developed
exclusively by Sony to deliver a very wide color gamut that exceeds the color gamut of ordinary CCFL backlights
and produces true reds, vivid greens and vibrant blues. Images are reproduced with enhanced vibrancy and
intensity resulting in an even greater sense of realism.
WEGA Engine ™ Because of the special demands HDTV places on signal quality a new generation of Sony’s
exclusive WEGA Engine™advanced picture quality system has evolved. Two innovative digital imaging processes
have been added to improve overall picture quality. A High Contrast Image processor dynamically detects the
histogram of each frame and instantly applies the ideal contrast level for crisper images. And the Natural High
Density Picture image processor reduces noise elements by intelligently separating the noise from the video
signal for a purer more detailed picture. Enjoy a stunning display of realistic images, amazing detail and
sharpness, reduced noise and enhanced clarity with improved depth and contrast.
WEGA GATE ® User Guide Explore and navigate your Sony “ BRAVIA ”television effortlessly with the WEGA GATE
user guide. You can easily change your settings or access your favorite TV channels and external inputs. Simply
touch the WEGA GATE button on the remote control to activate the comprehensive graphic menu. Your eyes remain
on the screen instead of searching in the dark for tiny buttons on the remote control.

SonyElectronicsInc. • 16530ViaEsprilloDrive • SanDiego,CA92127 • 1-800-222-7669 • www.sony.com
LastUpdated:08/31/2006
KDL-V26XBR1
BRAVIA ™ XBR® FlatPanelTelevision
PleasevisittheDealerNetworkforcurrent
informationatwww.sony.com/dn
Features
General
Auto SAP: Yes
Closed Caption (CC): Yes
ID1 Detection: Yes
Video Label: Yes
Clean Wire Management: Yes
Video
Tuner: 8 VBS, ATSC, NTSC, Clear QAM
Video Processing: Yes (WEGA Engine ™HD
System)
Color Temperature: Cool, Neutral, Warm 1,
Warm 2
Color Correction: High, Low, Off
Noise Reduction: Yes
Black Corrector: High, Medium, Low, Off
Clear White: High, Low, Off
Color Space: Wide, Normal
Gamma Compensation: High, Medium, Low,
Off
Live Color: High, Medium, Low, Off
CineMotion®Reverse 3:2 Pulldown
Technology: Yes
Contrast Enhancer: High, Low, Off
Direct Digital II Circuitry: Yes
Screen Modes (4:3): Wide Zoom, Normal, Full,
Zoom, Off
Slide Show Mode: Slide Show transitions
Display Mode for PC Input: Video, Text
Comb Filter: 3D Digital Comb Filter
DRC®MultiFunction Circuitry: Yes (DRC MF V1)
DRC®Mode: Yes
DRC® Palette Presets: Yes
Game Mode: On/Off
Auto Adjustment (PC): Yes
Phase (PC Only): Yes
Pitch (PC Only): Yes
Light Sensor: Yes
Advanced Video Menu: Yes
Picture Modes: Vivid, Standard, Custom
Color System: ATSC, NTSC
Wide Mode: Yes
Display Technology: LCD (7th Generation LCD
Panel)
Audio
Tone Control(s): Treble, Bass
Sound Mode: Dynamic, Standard, Custom
MTS Stereo Decoder: Yes
A/V Synch: Off/1/2/3
Digital Amplifier: Yes (S-Master® Digital
Amplifier)
Audio Mute: Yes
Speaker On/Off: Yes
Simulated Surround: Yes
SRS ®TruSurround®XT Audio Effect:Yes
Convenience
Channel Caption: On, Off, Program
Channel Label: Yes
Channel Skip/Add: Yes
Channel Jump: Yes
Favorite Channel: Yes
Speed Surf ™ Channel Selection: Yes
WEGA GATE ™ Technology: Yes
Scrolling Channel Index® System: Yes
Program Guide Access: Yes
Auto Channel Programming: Yes
Menu Color: Yes
Multiple Language Display: English, Español,
Français
Parental Control (V-Chip): Yes
Mode Memory: Yes
Info Banner: Yes
Programmable Timer: 2 Event
Sleep Timer: 15, 30, 45, 60, 90, Off
Timer Events: Timer 1, Timer 2
Caption Vision: Basic, Digital CC, Advanced
Clock: Yes
Power Save Mode: Standard, Reduced, Picture
Off
Built -In AC Adaptor: Yes
Picture Freeze: Yes (with side-by-side viewing)
Specifications
General
Aspect Ratio: 16:9
Screen Size: 26"
Video
Native Resolution: 720p
Contrast Ratio: 2/23/1900 4:01:00 AM
Display Resolution: 1366 x 768
Overscan: Normal, -1, -2
Viewing Angle: Right/Left: 178 ° , Up/Down: 178 °
Display Response Time: 8ms
Vertical Center: Yes
Horizontal Center: Yes
Brightness: Typical 480 cd/m
Audio
Speaker Type: 2 Way, Oval Cone
Speakers (Total): 4
Tweeter Size: 1 4/7" (40mm)
Full Range Speaker Size: 40 x 100mm Oval
Audio Power Output: 26W Total (13W x 2)
Convenience
Stand Tilt Range: Forward 3 ° / Back 8 °
Stand Swivel Range: L/R: 30 °
Inputs and Outputs
Analog Audio Input(s): 6 (1 Front/5 Rear)
Audio Out (Variable/Fixed): 1 (Rear)
CableCARD ™ Slot: 1 (Rear)
Component Video (Y/Pb/Pr ) Input(s): 3 (1
Front/2 Rear) 480i, 480p, 720p, 1080i
Composite Video Input(s): 3 (1 Front/2 Rear)
RF Connection Input(s): 2 (Rear)
S -Video Input(s): 1 (Rear)
Headphone Output(s): 1 (Front)
PC Audio Input(s): 1 (Rear)
PC Video Input(s): 1 (Rear)
HDMI ™ Connection(s): 1 (Rear) with Audio
Input
Optical Audio Digital Output(s): 1 (Rear) Dolby®
Digital
1
2
Power
Internal Power Supply: Yes
Power Consumption (in Operation): 140W
Power Consumption (in Standby): Less than
0.15W
Power Requirements: AC 120-240V, 50/60Hz
Power Management: Yes
Regulation and Standard Compliance
Energy Star ®Compliant: Yes
VESA: Yes (200 x 100 hole pattern/ M4 thread
size/ 14mm hole depth)
Service and Warranty Information
Limited Warranty: 1 Year Parts / 1 Year Labor
Dimensions
Weight: 29lbs 16oz (13.6Kg)
Measurements: 26 9/16 x 18 8/13 x 4 1/16" (674.8
x 472.7 x 103mm)
Supplied Accessories
Remote Control (RM-YD002)
Battery (Type AA, x2)
AC Power Cord
Cable Clamper
Support Belt
Securing screws
Operating Instructions
Quick Setup Guide
Warranty Card
On-line Registration Card
Optional Accessories
Wall -Mount Bracket (SU-LW31)
UPC Code: 027242677258
