SERVICE MANUAL AE-5 CHASSIS
MODEL COMMANDER DEST CHASSISNO.
KV-29FQ65B RM-893 French SCC-Q13G-A
KV-29FQ65E RM-893 ESP SCC-Q14G-A
MODEL COMMANDER DEST CHASSISNO.
KV-29FQ65K RM-893 OIRT SCC-Q16K-A

2
TABLE OF CONTENTS
Section Title Page Section Title Page
Specifications .................... 3
Connectors .................... 4
Self Diagnostic Software .................... 5
1. GENERALUsing the TV menu system .................... 8
Tuning your TV .................... 9
Finding yourVideo Channel .................... 9
NexTView .................... 11
Teletext .................... 13
Specifications .................... 14
Troubleshooting .................... 14
2. DISASSEMBLY
2-1. Rear Cover Removal .................... 15
2-2. Speaker Connector .................... 15
2-3. Chassis Removal .................... 15
2-4. Service Position .................... 16
2-5. D1 Board Removal .................... 16
2-6. J Board Removal .................... 16
2-7. B2 Board Removal .................... 16
2-8. Front Control Removal .................... 17
2-9. F3 and H6 Board Removal .................... 17
2-10. H5 Board Removal .................... 17
2-11. Service Connector .................... 17
2-12. PictureTube Removal .................... 18
BottomPlates .................... 19
3. SET-UPADJUSTMENTS
3-1. BeamLanding .................... 20
3-2. Convergence .................... 21
3-3. FocusAdjustment .................... 23
3-4. Screen [G2], White Balance .................... 23
4. CIRCUIT ADJUSTMENTS
4-1. ElectricalAdjustments .................... 24
4-2. VolumeElectricalAdjustments.................... 28
4-3. Test Mode 2 .................... 29
5. DIAGRAMS
5-1. Block Diagram (1) .................... 31
Block Diagram (2) .................... 35
Block Diagram (3) .................... 39
Block Diagram (4) .................... 43
5-2. CircuitBoard Location .................... 46
5-3. Schematic Diagrams and
Printed Wiring Boards .................... 46
* H5 Board .................... 47
* F3 Board .................... 48
* F1 Board .................... 48
* H6 Board .................... 48
* E Board .................... 49
* M1 Board .................... 53
* D1 Board .................... 56
* D Board .................... 63
* ABoard .................... 66
* J Board .................... 75
* C Board .................... 81
* VM Board .................... 83
* B2 Board .................... 85
5-4. Semiconductors .................... 89
5-5. IC Blocks .................... 88
6. EXPLODED VIEWS
6-1. Chassis .................... 92
6-2. PictureTube .................... 93
7. ELECTRICALPARTS LIST .................... 95
CAUTION
SHORT CIRCUIT THE ANODE OF THE PICTURE TUBE AND THE
ANODE CAP TO THE METALCHASSIS, CRT SHIELD, OR THE
CARBON PAINTED ON THE CRT,AFTER REMOVALOF THE
ANODE CAP.
WARNING !!
AN ISOLATION TRANSFORMER SHOULD BE USED DURING ANY
SERVICE WORK TOAVOID POSSIBLE SHOCK HAZARD DUE TO
LIVE CHASSIS, THE CHASSIS OF THIS RECEIVER IS DIRECTLY
CONNECTED TOTHE POWER LINE.
SAFETY-RELATED COMPONENT WARNING !!
COMPONENTS IDENTIFIED BY SHADING AND MARKED £ ON
THE SCHEMATIC DIAGRAMS, EXPLODED VIEWS AND IN THE
PARTS LIST ARE CRITICAL FOR SAFE OPERATION. REPLACE
THESE COMPONENTS WITH SONY PARTS WHOSE PART
NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN
SUPPLEMENTS PUBLISHED BY SONY.
ATTENTION
APRES AVOIR DECONNECTE LE CAPDE’LANODE,
COURT-CIRCUITER L’ANODE DU TUBE CATHODIQUE ET CELUI
DE L’ANODE DU CAPAU CHASSIS METALLIQUE DE L’APPAREIL,
OU AU COUCHE DE CARBONE PEINTE SUR LE TUBE
CATHODIQUE OU AU BLINDAGE DU TUBE CATHODIQUE.
ATTENTION !!
AFIN D’EVITER TOUTRISQUE D’ELECTROCUTION PROVENANT
D’UN CHÁSSIS SOUS TENTION, UN TRANSFORMATEUR
D’ISOLEMENTDOITETRE UTILISÈ LORS DE TOUTDÈPANNAGE
LE CHÁSSIS DE CE RÈCEPTEUR EST DIRECTMENT RACCORDÈ
Á L’ALIMENTATION SECTEUR.
ATTENTION AUX COMPOSANTS RELATIFS Á
LA SECURITÈ!!
LES COMPOSANTS IDENTIFIÈS PAR UNE TRAME ET PAR UNE
MARQUE £ SUR LES SCHÈMAS DE PRINCIPE, LES VUES
EXPLOSÈES ET LES LISTES DE PIECES SONT D’UNE IMPOR-
TANCE CRITIQUE POUR LA SÈCURITÈ DU FONCTIONNEMENT,
NE LES REMPLACER QUE PAR DES COMPSANTS SONY DONT LE
NUMÈRO DE PIÈCE EST INDIQUÈ DANS LE PRÈSENT MANUEL
OU DANS DES SUPPLÈMENTS PUBLIÈS PAR SONY.

3
ebuTerutciP
ediWnortinirTDF )sehcni92(mc27xorppA derusaemerutcipmc86xorppA( )yllanogaid noitcelfedeerged401
tuptuodnuoS
refoowbuS
rekaepstfeLdnathgiR )rewoPcisuM(W02x2 )SMR(W01x2
)SMR(W51x1)rewoPcisuM(W03x1
]RAER[slanimreTtuptuO/tupnI stnemeriuqeRrewoPV042-022
rotcennocoruEnip-12:1 )dradnatsCELENEC(
.slangisoediVdnaoiduArofstupnI .BGRrofstupnI oiduAdnaoediVVTfostuptuO .slangis
snoisnemiDmm075x536x567xorppA
rotcennocoruEnip-12:2
.slangisoediVdnaoiduArofstupnI .oediVSrofstupnI .slangisoiduAdnaoediVVTfostuptuO )elbatceles(
thgieWgk95xorppA
rotcennocoruEnip-12:3
.slangisoediVdnaoiduArofstupnI .oediVSrofstupnI slangisoiduAdnaoediVrofstuptuO )tuorotinom(
seirosseccAdeilppuS )1(rednammoCetomeR398-MR )2(yrettab6RdetangisedCEI
skcaJonohPoiduArofelbairavsrotcennoCtuptuO slangiS serutaeFrehtO esioN,retliFbmoClatigiD,weiVTxeN CRD,erutciPzH001CRD,noitcudeR resilauqEcihparG,erutciPzH05
]TNORF[slanimreTtuptuO/tupnI metsyslortnocetomeRlortnocderarfnI
kcajenohpdaeHkcajinimoerets stnemeriuqerrewoP cdV3 noitangisedCEIseirettab2 )AAezis(6R
stupnioiduAskcajonohp snoisnemiD)d/h/w(mm32x55x012xorppA
stupnioediVskcajonohp thgieW)yrettabgnidulcniton(g011xorppA
tupnioediVSNIDnip4
.ecitontuohtiwegnahcottcejbuserasnoitacificepsdnangiseD
LEDOMMETI metsySnoisiveleT metsySoeretS egarevoClennahC metsySroloC
hcnerFI,L,K/D,H/G/B MACIN/NAMREG oeretS 96E-12E:FHU21E-2E:FHVH/G/B 50S-10S,96R-12R,21R-10R:KD
MACES,LAP 85.3CSTN,34.4CSTN )NIOEDIV(
hsinapSK/D,H/G/B MACIN/NAMREG oeretS 96E-12E:FHU21E-2E:FHVH/G/B 50S-10S,96R-12R,21R-10R:KD
MACES,LAP 85.3CSTN,34.4CSTN )NIOEDIV(
TRIOK/D,H/G/BoeretSNAMREG 96E-12E:FHU21E-2E:FHVH/G/B 50S-10S,96R-12R,21R-10R:KD
MACES,LAP 85.3CSTN,34.4CSTN )NIOEDIV(
ledoM B56QF92-VK E56QF92-VK K56QF92-VK
noitpmusnoCrewoPW851W851W851
emaNledoM
metI B56QF92-VK E56QF92-VK K56QF92-VK
bmoClaPNONONO
PIPFFOFFOFFO
ytiroirPBGRNONONO
xoBrefooWNONONO
1tracSNONONO
2tracSNONONO
)3(nitnorFNONONO
4tracSNONONO
rotcejorPFFOFFOFFO
edom9:61niBKANONONO
G/BmroNNONONO
ImroNFFOFFOFFO
K/DmroNNONONO
SUAmroNFFOFFOFFO
LmroNFFOFFOFFO
TASmroNFFOFFOFFO
MmroNFFOFFOFFO
txeteleTNONONO
oeretSmaciNFFONOFFO

4
21 pin connector
Connected Not Connected (open) * at 20Hz - 20kHz
Pin No 1 2 4 Signal Signal level
1Audio output B
(right) Standard level : 0.5V rms Output impedence : Less than 1kohm*
2Audio output B (right) Standard level : 0.5V rms Output impedence : More than 10kohm*
3Audio output A (left) Standard level : 0.5V rms Output impedence : Less than 1kohm*
4Ground (audio)
5Ground (blue)
6Audio input A
(left) Standard level : 0.5V rms Output impedence : More than 10kohm*
7Blue input 0.7 +/- 3dB, 75 ohms positive
8Function select
(AV control)
High state (9.5-12V) : Part mode
Low state (0-2V) : TV mode
Input impedence : More than 10K ohms
Input capacitance : Less than 2nF
9Ground (green)
10 Open
11 Green Green signal : 0.7 +/- 3dB, 75 ohms,
positive
12 Open
13 Ground (red)
14 Ground (blanking)
15
_ _ Red input 0.7 +/- 3dB, 75 ohms, positive
_ (S signal Chroma
input) 0.3 +/- 3dB, 75 ohms, positive
16 Blanking input
(Ys signal) High state (1-3V) Low state (0-0.4V) Input impedence : 75 ohms
17 Ground (video
output)
18 Ground (video
input)
19 Video output 1V +/- 3dB, 75ohms, positive sync 0.3V
(-3+10dB)
20
_ _ Video input 1V +/- 3dB, 75ohms, positive sync 0.3V
(-3+10dB)
_ Video input
Y (S signal) 1V +/- 3dB, 75ohms, positive sync 0.3V (-3+10dB)
21 Common ground
(plug, shield)
19
17
15
13
11
9
7
5
3
1
20
18
16
14
12
10
8
6
4
2
21
Rear Connection Panel
noitarugifnocniptekcosoediVS
oNniP langiS leveLlangiS
1dnuorG-
2dnuorG-
3tupni)langisS(Y Bd01+3-V3.0.cnySevitisop,mho57Bd3-/+V1
4tupni)langisS(C.cnySevitisop,mho57Bd3-/+V3.0
S-Video
socket

5
AE-5 SELF DIAGNOSTIC SOFTWARE
The identification of errors within theAE-5 chassis is triggered in one of two ways :- 1: Busy or 2: Device failure to respond to IIC. In the event of
one of these situations arising the software will first try to release the bus if busy (Failure to do so will report with a continuous flashing LED) and
then communicate with each device in turn to establish if a device is faulty. If a device is found to be faulty the relevant device number will be
displayed through the LED (Series of flashes which must be counted) See table 1., non fatal errors are reported using this method.
Flash Timing Example : e.g. error number 3
StBy LED
ON ON ON
OFF OFF
metIcitsongaiD noitpircseD ybdnatSsemitfooN sehsalFDEL esuacelbaborP noitacoL smotpmySdetceteD
nonruttonseodrewoPthgiltonseoD .nideggulptonsidrocrewoP .tiucricneposiesuF
noemoctonseodrewoP VTehtotdeilppussirewopoN ytluafsiylppusrewopCA
)PCO(tnerrucrevOB+semit2 )draoBD(.detrohssi)4086/3086Q(TUO.H )draoBD(.detrohssi)6086Q(TEFytiraeniL )draoBD(.detrohssiCIrewoP4066CI
noemoctonseodrewoP
detrohssahenilrewopnodaoL
deppotsnoitcelfeDlacitreVsemit4 )draoBD(nepo5386RdeilppustonsiV51+ )draoBD(nepo4386RdeilppustonsiV51- )draoBD(detrohssi0076CI
deppotssaheslupnoitcelfedlacitreV
detrohssahenilrewoP
egasseMrorrE DEL edoC
rorreoN00
devreseR10
)noitcetorPtnerruCrevO(PCO20
)noitcetorPegatloVrevO(PVO30
noitcetorPlacitreV40
16TTelbane,s'03retfastratskcehc(BKAelbatsnU )26TTelbasid 50
noitcetorPlatnoziroH60
noitcetorPrekaepS70
rorre0subC2I80
redoceD-txeT-eleTB-M90
MVN,23C42TSB-M01
redoceDruoloCniaM,0239ADTB-J11
xoBerutaeFB-2B/1B21
retrevnoC-A/DB-1B31
dnekcaBB-E41
rossecorPdnuoS,D0143PSMB-J51
ediWotuA,7502DXCB-J61
MARlanretxE71

6
Device acknowledge is used to check IIC errors. Device acknowledge is checked by sending an IIC start sequence during CRT power on. Each
device is checked three times, if there is no acknowledge after each attempt, it will be regarded as an error.
There are three steps to check for errors.
1. IIC line 0
If all devices except the NVM have errors, IIC line 0 error is displayed.
2. Board check
If all devices mounted on one board have errors, board error is displayed.
3. Each device check
If IIC line error and board error are not detected then the device with the error is displayed.
The detected errors can be displayed as follows :
1. Error Monitor Menu.
2. Error Reader.
Error Detection Monitor
1. Error Monitor Menu
Operating Time : 000075 h 15 min
Stored Errors :
ERROR MONITOR
1. D1 - B CXA1875 or MB88141
2. No Error Occured
3. No Error Occured
4. No Error Occured
5. No Error Occured
Current Error :
Start Error Sequence
1. IGNORE ERRORS OFF ON OFF
Last menu Enter Item

7
2. Error Reader Display
The error reader display is connected to the service connector to read actual error codes. The part number for the error reader display is
S-188-900-10. Once an error has been detected it will then be displayed on the two digit error reader. The errors displayed refer to the following
table.
edoCrorrE egasseMrorrE
h000derruccororreoN
h1000CII,rorresuB
h2001CII,rorresuB
h001 draoB-A
h101rednapxEtroP,5781AXCB-A
h201renuTniaM,6231UTB-A
h301renuTbuS,0531UTB-A
h002 draoB-1B
h102,0829ADS.B-1BxoBerutaeF,456C38PB-1B
rotrevnoCA/D
h202B-1B 0829ADS.B-1BxoBerutaeF,456C38P rotrevnoCA/D,
h003 draoB-2B
h103CISEB,7794AAS.B-2B
h203yromeMdleiF,X594AAS.B-2B
h004 draoB-3B
h104X-DIM.B-3B
h204amaronaP.B-3B
h304CRD.B-3B
h404retsooBerutciP.B-KB
h005 draoB-1D
h105rotrevnoCcimanyD,0708AXCB-1D
h205rednapxEtroP,5781AXCB-1D
h006 draoB-E
h106dnekcaB,0012DXCB-E
h007 draoB-J
h107ediWotuA,7502DXCB-J
h207PIP,8829ADSB-J
h307redoceDruoloCbuSB-J
h407redoceDruoloCniaMB-J
h507dnuoS-buS,5781AXCB-J
h607reifilpmA-PH,9037ADTB-J
h707hctiwSoiduA,TD2246AETB-J
h807rossecorPdnuoS,D0143PSMB-J
h907PSDdnuoS,F7339CTB-J
hA07hctiwSVA,96X12AXCB-J
h008 draoB-M
h108MVN,23C42TSB-M

8
The operating instructions mentioned here are partial abstracts from the ‘Operating Instruction Manual’. The page numbers of the ‘Operating Instruction Manual’ remain as in the manual.
SECTION 1 GENERAL
12 Operation The TV consists of a menu system which is based on a series of user friendly on-screen displays and menus. These displays will help you get the most from your TV, helping you to change picture and sound settings, to alter the size of the TV picture and to rearrange the TV channels etc. Adjusting the picture and sound The picture and sound are preset at the factory. You can however adjust them to suit your own taste.
Using the TV menu system
Picture Adjustment
Picture Mode Contrast Brightness Colour Sharpness Reset AI Noise Reduction Colour Tone
Personal
On On
Normal
Picture Mode
Live
Personal
Movie
AI
On Off
Noise Reduction
On Off
Contrast
Select: Enter:
Colour Tone
Warm
Normal
Cool
1. Press the MENU button on the remote control to display the menu on the TV screen. 2. Press the v or Vbuttons to select for picture settings or for sound settings then press
Bto enter either the ‘Picture Adjustment’ menu or the ‘Audio Adjustment’ menu.
3. Press the v or Vbuttons to select the item on the screen you wish to adjust then press Bto
confirm. For a description of the menu items and their effects, see the table below.
4. Press the v, V, Bor bbuttons to adjust your selected item.
5. As soon as you have adjusted the item, press the OK button to store the new setting. 6. Repeat steps 3-5 if you wish to adjust any of the other items. 7. Press the MENU button to remove the menu from the TV screen.
Picture Control Item Effect/Operation Picture Mode VLive (for live broadcasts)
Personal (for individual settings)
vMovie (for movie broadcasts)
Contrast Less bB More Brightness* Darker bB Brighter Colour* Less bB More Hue** Reddish bB Greenish
Sharpness* Softer bB Sharper *Only available if ‘Personal’ is selected in ‘Picture Mode’ **Only available for NTSC colour signal (eg. US video tapes) Reset Resets picture to the factory preset levels AI VOn: Automatic optimization of contrast level (Artificial Intelligence) according to the TV signal.
vOff: Normal.
Noise Reduction VOn: Reduces picture noise in case of a weak
broadcasting signal.
vOff: No noise reduction.
Colour Tone VWarm: Gives a warm tint to the picture.
Normal: Normal.
vCool: Gives a cool tint to the picture.
13
Using the TV menu system:
Audio Adjustment
Equaliser Mode Equaliser Adjustment Balance Loudness Space Auto Vol. Control Dual Sound Volume Dual Sound
Stereo
Off Off
Stereo
Select Mode :
Off
Confirm: OK
Personal
Vocal
Jazz
Rock
0
NICAM
NICAM
Equaliser Adjustment
Sel: Adjust: Confirm:OK
(Personal)
+
0 –
120 150 1,5K 5 K 10 K
Auto Vol. Control
Off On
Dual Sound
Mono
Stereo
Volume
Dual Sound
B A
Space
Off On
Loudness
Off On
NICAM
NICAM
Balance 0
Sound Control Item Effect/Operation Equaliser Mode VPersonal
Vocal Jazz Rock Pop
vFlat (fixed setting, cannot be adjusted)
Equaliser adjustment You can adjust the mode selected in Equaliser mode by
cutting and boosting the 5 selected frequency bands. Press bor Bto select the frequency band then Vor vto adjust the frequency. Finally, press the OK button to store the new adjustment.
If you want to store the new setting, you need to set the Equaliser mode to ‘Personal’. Personal mode permanently stores the setting, all other modes (Vocal, Jazz, Rock, Pop) store only until the next mode change.
Balance bMore left
BMore right
Loudness VOff: Normal
vOn: For music broadcasts
Space VOff: Normal
vOn: Special acoustic effect
Auto Vol. Control VOff: Volume level changes according to the broadcast
signal.
vOn: Volume level of the channels will stay the same
independent of the broadcast signal (eg in the case of advertisements).
Dual Sound For a bilingual broadcast:
VA for channel 1 vB for channel 2 For a stereo broadcast: VMono vStereo
When NICAM stereo is beingbroadcast, the indication NICAM appears briefly on the screen.
Headphones i Volume Adjusts headphone volume.
Can also adjust the volume level of additional equipment connected to the RCA sockets on the rear of the TV.
i Dual Sound For a bilingual broadcast:
VA for channel 1 vB for channel 2

9
14
Using the TV menu system: Using the Features menu
1. Press the MENU button on the remote control to display the menu on the TV screen. 2. Press the v or Vbuttons to select for the ‘Features’ menu then press Bto enter the ‘Features’
menu.
3. Press the v or Vbuttons to select the desired menu item then press Bto confirm. For a description
of the menu items and their effects, see the table below.
4. Press the v, V, Bor bbuttons to select the desired setting.
5. Press the OK button to confirm your choice of setting. 6. Repeat steps 3-5 if you wish to select any of the other items. 7. Press the MENU button to remove the menu from the TV screen. Item Effect/Operation Sleep Timer You can select a time after which the TV switches itself into
standby mode. VOff v90 min
Parental Lock VOff: No parental lock.
vOn: This feature disables the TV buttons when the set isin standby mode.
It is only possible to switch the set back on by pressing a button on the remote control.
AV2 Output VTV audio/video signal from the aerial
AV1 audio/video signal from scart 1 AV2 audio/video signal from scart 2 AV3 audio/video signal from scart 3
vAV4 audio/video signal from connectors on front of the TV
Features
Select: Enter:
Sleep Timer Parental Lock AV 2 Output
Off Off
TV
10 min
Sleep Timer
Parental Look
Off On
AV 2 Output
TV
AV 1
AV 2 AV 3 AV 4
Changing the screen size This feature allows you to change the size of the TV picture.
Press the button on the remote control repeatedly or use the v or Vbuttons to select one of the
following formats then press the OK button to confirm your selection: 4:3 conventional 4:3 picture size, full picture information. 16:9 for 16:9 broadcasts.
4:3
16:9
5
Installation Before you tune your TV, you will be asked to set your language and country.
6. Tuning your TV
::
::
Language/Country
Select Language: Confirm:
Language Country
Čeština
Dansk
Deutsch
English
Español
Français
Italiano
Language/Country
Select Country: Confirm:
Language Country
France
Germany
Great Britain
Greece
Hungary
Ireland
Italy
English
1. The Language/Country menu appears on the TV screen with the
word ‘English’ highlighted.
2. Press the v or V buttons on the remote control to select your
chosen language then press the OK button to confirm. The country menu appears on screen with the word ‘OFF’ highlighted. Select ‘OFF’ if you do not want your channels stored in a given channel sequence starting from programme position 1.
3. Press v or V to select the country in which you wish to operate
the TV then press the OK button to confirm your choice.
4. The ‘autotune’ menu appears on the TV screen in your selected
language. Press the OK button to confirm.
5. Ensure the aerial is connected as instructed, then press the OK
button to confirm. The TV starts to automatically search and store all available channels for you. This may take a few minutes - please be patient and do not press any buttons.
6. Once the TV has tuned all available channels the ‘Programme
Sorting’ menu appears on the TV screen enabling you to change the order of the channels on your TV. If you wish to change the channel order, press the v or V buttons to select the channel you want to move, then press B. Press the v or V buttons to select the
new programme number position for your selected channel then press the OK button to confirm. The selected channel now moves to its new programme position and the other channels move accordingly. Repeat this procedure if you wish to sort the order of other channels on your TV.
7. Press the MENU button to remove the menu from the TV screen. 8. Press the PROGR+/- or the numbered buttons to view the TV
channels.
Note: If you would like to stop the autotune process at any stage,
press the OK button.
If you have connected a VCR to your TV, you now need to find your video channel. 1. Press the PROGR+/- buttons on the TV remote control until your video picture appears on the TV screen. Note: If you wish to move your video channel to a different programme position, refer to the ‘Re-arranging the TV channels’
section of this instruction manual.
7. Finding your video channel
Programme Sorting
Select Prog: Confirm:
PROG CH LABEL
Programme Sorting
Select Position: Move: OK
C03 TV 5
PROG CH LABEL
1 2 3 4 5 6 7 8 9 10 11
C03 C05 C07 C08 C09 C11 C12 C13 C14 C15 C16
TV 5 PRO 7 EU-SP SWF RTL SAT MDR DDI DSF RTL 2 KAB 1
C03 C05 C07 C08 C09 C11 C12 C13 C14 C15 C16
TV 5 PRO 7 EU-SP SWF RTL SAT MDR DDI DSF RTL 2 KAB 1
1 2 3 4 5 6 7 8 9 10 11
123
6
5
4
7 8 9
0

10
15
Using the TV menu system: Re-arranging the TV channels
After tuning the TV, you can use this feature to change the order of the channels on the TV.
1. Press the MENU button on the remote control to display the menu on the TV screen. 2. Press the V button to select the symbol on the menu screen then press Bto enter the ‘Set Up’
menu.
3. Press the V button to select ‘Programme Sorting’ then press Bto enter the ‘Programme Sorting’
menu.
4. Press the v or V buttons to select the channel you want to move then press Bto confirm.
5. Press the v or Vbuttons to select the new programme position (eg PROG 4) for your selected
channel then press the OK button to confirm. The selected channel now moves to its new programme position and the other channels move accordingly.
6. Repeat steps 4 and 5 if you wish to sort the other channels. 7. Press the MENU button to remove the menu from the TV screen.
Programme Sorting
Select Prog: Confirm:
Set Up
Auto Tuning Programme Sorting AV Preset Manual Set Up
Select: Enter:
PROG CH LABEL
Programme Sorting
Select Position:
Move: OK
C03 TV 5
PROG CH LABEL
1 2 3 4 5 6 7 8 9 10 11
C03 C05 C07 C08 C09 C11 C12 C13 C14 C15 C16
TV 5 PRO 7 EU-SP SWF RTL SAT MDR DDI DSF RTL 2 KAB 1
C03 C05 C07 C08 C09 C11 C12 C13 C14 C15 C16
TV 5 PRO 7 EU-SP SWF RTL SAT MDR DDI DSF RTL 2 KAB 1
1 2 3 4 5 6 7 8 9 10 11
Manually tuning the TV
You have already tuned the TV automatically using the instructions at the start of this manual. You can however carry out this operation manually, adding channels to the TV, one at a time.
1. Press the MENU button on the remote control to display the menu on the TV screen. 2. Press the V button to select the symbol on the menu screen then press Bto enter the ‘Set Up’
menu.
3. Press the V button to select ‘Manual Set Up’ on the menu screen then press Bto enter the ‘Manual
Set Up’ menu.
4. Press the V button to select ‘Manual Programme Preset’ on the menu screen then press Bto enter
the ‘Manual Programme Preset’ menu.
5. Press the v or V buttons to select a programme number for your channel (eg PROGR 1 for BBC1)
then press Bto highlight the ‘SKIP’ column.
6. Press v to select ‘OFF’ then press Bto highlight the ‘SYS’ column.
7. Press the v or V buttons to select the TV broadcast system or ‘EXT’ for a video input source
(AV1, AV2, ...) then press Bto confirm.
8. Press the v or V buttons to select ‘C’ for terrestrial channels, ‘S’ for cable channels, or ‘F’ for
direct frequency inputs then press Bto confirm.
9. Select the first number digit of ‘CH’ (channel) then the second number digit of ‘CH’ with the
number buttons on the remote control or Press the V button to search for the next available
channel.
10.If you do not wish to store this channel on the programme number you selected, press the V button
to continue searching for the desired channel.
11.If this is the channel you wish to store, press the OK button. 12.Repeat steps 5-11 if you wish to store more channels then press the MENU button to remove the
menu from the TV screen.
PROG SYS
Off SKIP LABEL
1B/G
Manual Set Up
Select: Enter:
Language/Country Manual Programme Preset Further Programme Preset RGB Set Up Picture Rotation Personal ID
Manual Programme Preset
Select: Enter:
PROG CHSYSSKIP LABEL
TV5 TV
Off Off Off Off Off Off Off Off Off Off Off
1 2 3 4 5 6 7 8 9 10 11
PROG CHSYS
Off SKIP LABEL
1B/G
D/K
IRL
EXT
CH
C
S
F
PROG SYS
Off SKIP LABEL
1B/G
CH
03 SEARCH
PROG CHSYS
Off SKIP LABEL
0EXT AV1
C09 C10
B/G B/G B/G B/G B/G B/G B/G B/G B/G B/G B/G
C21 C33
CXX CXX
CXX CXX
CXX CXX CXX
AV1 AV2 AV3 AV4
O
- - - - - - -
Set Up
Auto Tuning Programme Sorting AV Preset Manual Set Up
Select: Enter:
16 Using the TV menu system: Naming a channel
Names for channels are usually taken automatically from Teletext if available. You can however name a channel oran input video source using up to five characters (letters or numbers).
Skipping programme positions
This function enables you to skip unused programme positions when selecting them with the PROGR+/- buttons. However, by using the number buttons you can still select the skipped programme position.
1. Press the MENU button on the remote control to display the menu on the TV screen. 2. Press the V button to select the symbol on the menu screen then press Bto enter the ‘Set
Up’ menu.
3. Press the V button to select ‘Manual Set Up’ then press Bto enter the ‘Manual Set Up’
menu.
4. Press the V button to select ‘Manual Programme Preset’ then press Bto enter the ‘Manual
Programme Preset’ menu.
5. Press the v or V buttons to select the channel you wish to name.
6. Press the Bbutton repeatedly until the first element of the ‘LABEL’ column is highlighted. 7. Press the v or V buttons to select a letter or number (select ‘-’ for a blank) then press Bto
confirm. Select the other four characters in the same way.
8. After selecting all the characters, press the OK button. 9. Repeat steps 5 to 8 if you wish to label other channels. 10.Press the MENU button to remove the menu from the TV screen.
1. Press the MENU button on the remote control to display the menu on the TV screen. 2. Press the V button to select the symbol on the menu screen then press Bto enter the
‘Set Up’ menu.
3. Press the V button to select ‘Manual Set Up’ then press Bto enter the ‘Manual Set Up’
menu.
4. Press the V button to select ‘Manual Programme Preset’ then press Bto enter the ‘Manual
Programme Preset’ menu.
5. Press the v or V buttons to select the programme position then press Bto highlight the
‘SKIP’ column.
6. Press the v or V buttons to select ‘Off’ or ‘On’ (if you wish to skip this programme
position) then press the OK button to store.
7. Repeat steps 5 and 6 if you wish to skip or unskip further programme positions. 8. Press the MENU button to remove the menu from the TV screen.
Manual Programme Preset
Select: Enter:
PROG CHSYSSKIP LABEL
PROG CHSYSSKIP LABEL
53 I F189 - - -Off
On
C09 C10 BBC1
BBC
I I
Off Off Off Off Off Off Off Off Off Off Off
51 52 53 54 55 56 57 58 59 60 61
Manual Programme Preset
Select: Enter:
PROG CHSYSSKIP LABEL
C09 C10 ARD
BBC
B/G B/G
Off Off Off Off Off Off Off Off Off Off Off
1 2 3 4 5 6 7 8 9 10 11
PROG CHSYS
Off SKIP LABEL
6 I C07 TE
Manual Set Up
Select: Enter:
Language/Country Manual Programme Preset Further Programme Preset RGB Set Up Picture Rotation Personal ID Demo
O
- - - - - - -
Manual Set Up
Select: Enter:
Language/Country Manual Programme Preset Further Programme Preset RGB Set Up Picture Rotation Personal ID O
- - - - - - -
Manual Set Up
Select: Enter:
Language/Country Manual Programme Preset Further Programme Preset RGB Set Up Picture Rotation Personal ID O
- - - - - - -

11
8 Operation
NexTView is an electronic programme guide with up to 1 week* of programme information on those channels included in the selected provider.
*If the data exceeds the memory of NexTView, you will get information on less than 7 days.
When looking for information you can search by theme (sports, art etc.), date or time (e.g. broadcasts between 8 and 9
p.m.). When you’ve founda programme you can go directly to this programme, use the timer to remind you of it or preset your VCR with Smartlink.
The NexTView provider is responsible for the contents of the guide. The TV set is responsible for the presentation, that is the menu structure and the navigation, if there is none from the provider. If there is a navigation from the provider the basic operation with the joystick is the same as described in the Sony navigation. At first you need to select a channel providing a NexTView service. In this case the indication “NexTView” is displayed as soon as all data is available. When you later change the channel you can still select this NexTView service.
NexTView*
Index
full list of selection personal selection news broadcasts movies sports entertainment children return to last menu
* depending on availability of service
Operation using the Sony navigation 1. Press to switch NexTView on and off. 2. Use the joystick buttons as follows
(a) while in the columns date, time or icon (themes), the programme list changes according to the selection. (b) while in the programme list, confirming a running broadcast brings you directly to the TV programme or confirming
a future programme brings you to the long info menu.
• moving up or downwards within a column: Use vor V. • going to the left columns time and date: Use b. • going to the right column icons: Use B. • Confirming a selection: Press OK.
7
Tue
07 Tue 12:38
8
Wed
10
Fri
11
Sat
12
Sun
13
Mon
9
Thu 12
SWISS
Star Wars Super RTL
Fantasy film, USA, 1996 Werner - Beinhart Pro 7 Flui grüsst den Rest der Welt Kabel 1 Once upon a time in the West Euronews International News RTL Plus
10:35 - 12:45 10:20 - 12:00 10:45 - 10:50 11:00 - 11:20 11:45 - 12:50
TXT TPS / RINGIER
Tue 07. 04 .98
9
Individual Setting
When you select there will be no personal pre-selection. lets you make your own individualselection of themes, limiting the search to the marked ones.
1. Select using v or V. Push Bto enter.
The menu Individual Settings is displayed.
2. Select the item you wish to mark using v or V. Confirm by pressing OK.
Repeat step 2 for all the items you wish to have in your list.
3. When finished with the list, select using Band press OK.
Using the ‘Long Info’ menu 1. Select a future programme in the column programme list using v or V. Press OK.
The long info menu is displayed.
You may wish to record the selected programme with your VCR. (only with Smartlink VCRs) 2. Select using band press OK.
This information is transferred to the VCR connected to your set.
Setting up your VCR 3. Select VPS/PDC by pushing brepeatedly. 4. Select Speed using V. 5. Select VCR Setup using V.
6. Select using B. Press OK.
You are back in the last menu.
07 Tue 12:38
Address Mapping The position of the addresses in the OSDA is shown in the following diagram. The position values of the DPW are set to '0'. If other values are set, the complete combination will be scrolled. Example: if the DPWC is set to '63', the char-
Speed Timer Prog VPS/PDC SP
VCR1
On
This channel has been set for a timer
First nextTView/EPG-Providers in Europe
SWISS TXT TPS / RINGIER nexTView
Tue 07. 04 .98
With this setting on, you have the guaranteed recording of the whole broadcast should there be a change in the TV programme. This only works if the selected channel broadcasts a VPS/PDC signal.
• Select On or Off using OK.
Select between standardplay (SP) or longplay (LP) mode.With longplay you can record twice as much on a videotape. The picture quality, however, may suffer.
• Select SP or LP using OK.
Operation
NexTView*
Select which of the connected Smartlink VCRs you wish to programme.
• Select VCR 1 or 2 using OK.
Speed
VPS/PDC
VCR1
On
SP
VCR Setup

12
17
Using the TV menu system: Using the Further Programme Preset feature
With this feature you can a) individually adjust the volume level of each channel, b) manually fine-tune the TV to obtain
a better picture reception if the picture is distorted or c) preset the AV output for the programme positions of channels
with scrambled signals (eg from a pay TV decoder). In this way a connected VCR records the unscrambled signal.
Manual Set Up
Select: Enter:
Language/Country Manual Programme Preset Further Programme Preset RGB Set Up Picture Rotation Personal ID O
- - - - - - -
Further Programme Preset
Select: Enter:
PROG AFTVOL DECODER
On On On On On On On On On On On
Off Off Off Off Off Off Off Off Off Off Off
0 0 0 0 0 0 0 0 0 0 0
1 2 3 4 5 6 7 8 9 10 11
PROG AFTVOL DECODER
10
PROG AFTVOL DECODER
1-5
PROG AFTVOL DECODER
1-5 On
On
Off
AV1 AV2
1. Press the MENU button on the remote control to display the menu on the TV screen. 2. Press the V button to select the symbol on the menu screen then press Bto enter the ‘Set
Up’ menu
3. Press the V button to select ‘Manual Set Up’ then press Bto enter the ‘Manual Set Up’ menu.
4. Press the V button to select ‘Further Programme Preset’ then press Bto enter the ‘Further
Programme Preset’ menu.
5. Press the v or V buttons to select the relevant programme number then press the Bbutton
repeatedly to select a)VOL b) AFT or c) DECODER. The selected item changes colour.
6. a)VOL - Volume Offset
Press the v or V buttons to adjust the volume level (range -7 to +7) of the channel. Store by pressing the OK button. Repeat steps 5 and 6a if you wish to adjust the volume level of the other channels. b) AFT - Automatic Fine Tuning Press the v or V buttons to fine tune the channel frequency over a range of -15 to +15. Press
the OK button to confirm. Repeat steps 5 and 6c if you wish to fine tune other channels. c)DECODER Press the v or V buttons to select AV1 or AV2 for the programme position then press the OK
button to confirm. You can now attach a decoder to the AV1 or the AV2 socket on the back of the TV and the picture from that decoder will appear on this programme number. Repeat steps 5 and 6d to preset the AV output for other programme positions.
7. Press the MENU button to remove the menu from the TV screen.
18 Using the TV menu system: Adjusting the picture geometry for an RGB source
When connecting an RGB source such as a Sony Playstation you may need to readjust the geometry of the picture.
RGB Set Up
Adjust Size: Confirm: OK
H Centre O H Size O
RGB Set Up
Adjust Position: Confirm: OK
H Centre O H Size O
1. Press the button on the remote control to select the connected RGB source . 2. Press the MENU button to display the menu on the TV screen. 3. Press the V button to select the symbol on the menu screen then press Bto enter the ‘Set
Up’ menu.
4. Press the V button to select ‘Manual Set Up’ on the menu screen then press Bto enter the
‘Manual Set Up’ menu.
5. Press the V button to select ‘RGB Set Up’ on the menu screen then press Bto enter the
‘RGB Set Up’ sub menu.
6. Press B to select H Centre then press v or Vto adjust the centre of the picture over a range
of -10 to +10. Store the new range by pressing the OK button.
7. Press B to select H Size then press v or Vto adjust the horizontal coordinates over a range
of -10 to +10. Store the new range by pressing the OK button.
8. Press the MENU button to remove the menu from the TV screen.
1
Adjusting the picture rotation
Because of the earth’s magnetism the picture might slant. In this case you can readjust the picture.
1. Press the MENU button on the remote control to display the menu on the TV screen. 2. Press the V button to select the symbol on the menu screen then press Bto enter the
‘Set Up’ menu.
3. Press the V button to select ‘Manual Set Up’ then press Bto enter the ‘Manual Set Up’
menu.
4. Press the V button to select ‘Picture Rotation’ then press Bto enter the ‘Picture Rotation’
sub menu.
5. Press the v or V buttons to rotate the picture over a range of -5 to +5 then press the OK
button to store.
6. Press the MENU button to remove the menu from the TV screen.
Manual Set Up
Rotate: Confirm: OK
Language/Country Manual Programme Preset Further Programme Preset RGB Set Up Picture Rotation Personal ID O
- - - - - - - - - -
Set Up
Auto Tuning Programme Sorting AV Preset Manual Set Up
Select: Enter:

13
10 Operation
Most TV channels broadcast information via Teletext. The index page of the teletext service (usually page 100) gives you information on how to use the service. Please use a TV channel with a strong signal, otherwise there may be Teletext errors.
Teletext
Switching Teletext on and off 1. Select the TV channel which carries the teletext service you want to view. 2. Press the button once to get Teletext only. 3. Press twice for Mix mode. 4. Press a third time to switch off Teletext. Selecting a Teletext page Input three digits for the page number using the numbered buttons on the remote control. If you make a mistake, type in any three digits then re-enter the correct page number. Using Other Teletext Functions Selecting the next or preceding page Press the or buttons on the remote control to select the previous or next page. Selecting a sub page A teletext page may consist of several sub pages. In this case an information line is displayed, showing the numberof subpages. It may take afew secondsfor the information line to appear. Select the sub page by pressing v or V. To freeze a Teletext page Press the button to freeze the page. Press again to cancel the freeze. Revealing the index page Press the button to reveal the index page (normally page 100). Using colour buttons to access pages (Fastext) (only available if the TV station broadcasts Fastext signals) When the colour coded menu appears at the bottom of a page, press a coloured button on the remote control (green, red, yellow or blue) to access the corresponding page. Using the feature ‘Page Catching’ 1. Press the numbered buttons on the remote control to select a teletext page which has
several page numbers on it (eg the index page).
2. Press the OK button. 3. Press v or Vto select the desired page number then press the OK button. The requested
page is displayed after some seconds.
Index
TELETEXT
Programme News Sport Weather
25 153 101 98
Index
TELETEXT
Programme News Sport Weather
25 153 101 98
m m m
216-02
01 03 04 05 06 07 0802
11
Operation
Teletext
Using the Teletext menu 1. With Teletext switched on, press the MENU button on the remote control to display the
menu on the TV screen.
2. Press v or Vto select your chosen item on the screen then press Bto display the relevant
sub menu.
3. To remove the Teletext menu from the screen, press the MENU button. Top/Bottom/Full The Top/Bottom/Full sub menu allows you to enlarge different sections of the Teletext page. Press vto enlarge the upper half of the screen, Press Vto enlarge the lower half. Press the OK button to restore the page to normal size. Press bto return to the Teletext menu screen. Text Clear Text Clear is a function thatdisplays a TV channel while a Teletext page is being searched for. Reveal Some Teletext pages contain hidden information (eg for a quiz), which can be revealed. Time Page* *depending on availability of service. Time Page allows a time-coded Teletext page (such as an alarm page), to be displayed at a set time.
Top: Bottom: Full: OK
Teletext
Top / Bottom / Full Text Clear Reveal Time Page Page Overview
Select: Enter Menu:
1. Press the button on the remote control twice to select full screen text. 2. Press the MENU button to display the ‘Teletext’ menu. 3. Press v or Vto highlight ‘Text Clear’ and press Bto select.
4. The current TV channel is displayed. Once the text page has been found a blue
symbol will appear in the top left hand corner of the screen.
5. Press the button on the remote control to view the page.
1. In text mode press the MENU button on the remote control to access the ‘Teletext’ menu. 2. Press v or Vto highlight ‘Reveal’ and press Bto select. The hidden information is
displayed on the screen.
1. In Text mode press the MENU button on the remote control to access the ‘Teletext’
menu.
2. Press v or Vto highlight ‘Time Page’ and press Bto select. The ‘Time Page’ sub menu
is displayed.
3. Enter the desired page number using the numbered buttons on the remote control. 4. Enter the desired time using the remote control. 5. Press OK to confirm the settings. The TV will exit Teletext mode and the time will be
displayed in the top left hand corner of the screen. At the requested time the desired page is displayed.
Time Page
PAGE TIME
Select Page: 0-9 Next:
- - : - -– – –
Page Overview* *only available if TOP-Text is transmitted by the TV station. In this menu the TOP-Text pages are divided into two columns, the first column showing ‘blocks’ of pages and the second showing ‘groups’ of pages. 1. Press b or B to select the first or second column.
2. Press v or Vto select the relevant ‘group’ or ‘block’ of pages.
3. Press the OK button to display the chosen pages.

14
22 Additional Information
Specifications
TV system B/G/H, D/K Colour system PAL, SECAM NTSC 3.58, 4.43 (only Video In) Channel coverage See the ‘Channel Display Table’ below. Picture tube FD Trinitron, Approx. 72cm (29 inches) Rear Terminals
/ 21-pin Euro connector (CENELEC standard) including audio/
video input, RGB input, TV audio/video output.
/ 21-pin Euro connector (CENELEC standard) including audio/
video input, S-video input, Selectable audio/video output.
/ 21-pin Euro connector (CENELEC standard) including audio/
video input, S-video input, Monitor audio/video output.
L/G/S/I
RCA connectors, variable output for audio signals.
R/D/D/D
RF In
Front Terminals
Video input -phono jacks Audio inputs - phono jacks S video input - 4 pin DIN Headphones jack - minijack stereo
1
1
2
s
2
3
s
3
4
4
s
4
Sound output Left/Right: 2x20W (Music Power)
2x10W (RMS)
Sub woofer: 30W (Music Power)
15W (RMS)
Power consumption 158W Dimensions (wxhxd) Approx. 765x635x570mm Weight Approx. 59kg Accessories supplied RM-893 remote control (1) IEC designated size AA batteries (2) Optional accessory TV Stand: SU-29FQ1 Other features Flat display Trinitron tube, noise reduction, graphic equaliser, 2000 page TEXT memory, personal ID, sleep timer, NexTView. Design and specifications are subject to change without notice.
Channel Display Table
Receivable Channels Channel Displays
B/G/H E2..12, 21..69 C02..C12, C21..69 KABEL-TV (1) S1..S41 S01..S41 KABEL-TV (2) S01..S05 S42..S46
M1..M10 S01..S10 U1..U10 S11.S20
ITALIEN A, B..H, H1, H2 C13, C14..C20, C11, C12 D/K R01..R12, R21..R69 C01..C12, C21..C69
S01..S05 S42..S46
23
Additional Information Here are some simple solutions to problems which may affect the picture and sound. • If you continue to have these problems, have your TV serviced by qualified personnel. • NEVER open the casing yourself.
Troubleshooting
Problem Suggested remedy No picture (screen is dark), no sound. • Plug the TV in.
• Press the button on the front of the TV. • If the indicator is on press the button or a numbered
button on the remote control.
• Check the aerial connection. • Turn the TV off for 3 or 4 seconds and then turn it on again
using the button on the front of the TV.
Poor or no picture (screen is dark), but good sound. • Using the MENU system, select the Picture Adjustment
display. Adjust the brightness, picture and colour balance levels.
• From the Picture Adjustment display select RESET to return
to the factory settings.
Good picture, no sound. • Press the button on the remote control.
• If is displayed on the screen, press the button on the
remote control.
No colour on colour programmes. • Using the MENU system, select the Picture Adjustment
display and adjust the colour setting.
• From the Picture Adjustment display select RESET to return
to the factory settings.
Distorted picture when changing programmes or selecting Teletext. • Turn off any equipment connected to the scart connectors on
the rear of the TV.
Remote control does not function. • Replace the batteries. The standby indicator on the TV flashes.
• Contact your nearest Sony service centre.
Interference on picture from external equipment. • Reduce sharpness level.
/

15
Remove the rear cover fixing screws indicated. Take care
when removing the rear cover not to damage the speaker
cables [Disconnect the speaker connector] as speakers are
fitted inside the rear cover.
SECTION 2 DISASSEMBLY
2-1. Rear Cover Removal
To remove lift the main bracket rear slightly and slide the
chassis away from the beznet. Ensure that the interconnecting
leads are released from their purse locks to prevent damage
being caused.
2-2. Speaker Connector Disconnection
When refitting the chassis ensure that the main
bracket is located in the beznet guide slots before
sliding the chassis forwards. Refit the
interconnecting leads in their respective purse locks.
Before completely removing the rear cover disconnect the
speaker connector which is located on the inside.
2-3. Chassis Removal and Refitting
=>
=>
=> =>
=>
<=
<=
<=
<=
<=
<=

16
2-4. Service Position 2-5. D1 Board Removal
2-6. J Board Removal
To remove the D1 Board release the clip circled and gently
remove the board in a vertical direction.
Position the PWB as indicated to access the solder side.
To gain access to the D Board follow the instructions on page
19. [Removal and Replacement of the main bracket bottom
plates ].
Release the two metal bracket support clips located on either
side of the chassis. Tilt the bracket very slightly away from the
shield case indicated. Release the J board board socket
retainingclip and carefully liftthe complete assembly
vertically.
2-7. B2 Board Removal
Loosen the purse lock and release the cables indicated.Access to the
B2 Board is possible after removal of the shield case. Remove the
case and release the board socket clip as indicated in the D1 board
removal. Remove the board in a vertical direction.
Clip
Shield
case
Note :
Removal of the B2, E, and M1 printed circuit boards follows the
same procedure of releasing the securing clips as indicated
in the fig for D1 board removal.
Take care not to apply to great a pressure to the clips as this may
causedamage.
Cables
Shield
case

17
2-8. Front Control Module Removal 2-9. F3 and H6 Board Removal
To remove the F3 and H6 Boards release the clips circled and
ease the boards gently away from the main support bracket.
Clips
2-10. H5 Board Removal
To remove the H5 Board, first remove the control door from
bracket by releasing the clips circled and pushing them
through the main support bracket.
Clips
Removal of H5 Board follows the same procedure as removal
of the F3 and H6 Boards.
Remove the two screws fixing the user control module to the
front underside of the set. The control module drops down to
allow access to the boards.
Screws
2-11. Service Connector for H5 Board
If there is a requirement to use the front video and audio
sockets when the chassis is placed in its service position, it
would be necessary to use an extender board and extension
cable as indicated below.
The Extender board and extension cable are available as a
service part by ordering the part number as indicated.
From H5 Board
To CN 1703 on
A Board
Extender board assembly A-1647-037-A

18
Anode button
a
* REMOVING PROCEDURES.
Turn up one side of the rubber cap in
the direction indicated by the arrow a
12 Using a thumb pull up the rubber cap
firmly in the direction indicated by the
arrow b
3 When one side of the rubber cap is
separated from the anode button, the
anode-cap can be removed by turning
up the rubber cap and pulling it up in
the direction of the arrow c
bb
c
How to handle the Anode-Cap
1. To prevent damaging the surface of the anode-cap do not use
sharp materials.
2. Do not apply too great a pressure on the rubber, as this may cause
damage to the anode connector.
3. A metal fitting called a shatter hook terminal is fitted inside the
rubber cap.
4. Do not turn the rubber foot over excessively, this may cause damage
if the shatter hook sticks out.
Removal of the Anode-Cap
2-12. Picture Tube Removal
WARNING:
BEFORE REMOVING
THE ANODE CAP
High voltage remains in the CRT even
after the power is disconnected. To
avoid electric shock, discharge CRT
before attempting to remove the anode
cap. Short between anode and CRT
coated earth ground strap.
Coated Earth
Ground Strap
1. Discharge the anode of the CRT and remove the anode cap.
2. Unplug all interconnecting leads from the Deflection yoke, neck
assy, degaussing coils and CRT grounding strap.
3. Remove the C Board from the CRT.
4. Remove the chassis assembly.
5. Loosen the Neck assembly fixing screw and remove.
6. Loosen the Deflection yoke fixing screw and remove.
7. Place the set with the CRT face down on a cushion and remove
the Degaussing Coil holders.
8. Remove the Degaussing Coils.
9. Remove the CRT grounding strap and spring tentioners.
10. Unscrew the four CRT fixing screws [ located on each CRT
corner ] and remove the CRT.
[Take care not to handle the CRT by the neck.]
1
3
4
6
8
10 5
9
2
7

19
REMOVALANDREPLACEMENTOF THE MAIN-BRACKET
BOTTOMPLATES.
(1) REMOVING THE PLATES
In the event of servicing being required to the solder side of the D Board printed wiring board, the bottom plates fitted to the main chassis bracket require to be removed. This is performed by cutting the gates with a sharp wire cutter at the locations indicated by the arrows. Note : There are 3 plates fitted to the main bracket and secured by3 gates.
Only remove the necessary plate to gain access to the printed wiring board.
(2) REFITTING THE PLATES
Because the plates differ in size it is important that the correct plates are refitted in their original location. Please note that the plates need to be rotated 180 degrees from their cut position to allow the tabs to be fitted into their catch positions.
For safety reasons, on no account should the plates be removed and not refitted after servicing.
£
Tab
Catch

20
•When complete readjustment is necessary or a new picture tube is
installed, carry out the following adjustments.
•Unless there are specific instructions to the contrary, carry out
these adjustments with the rated power supply.
•Unless there are specific instructions to the contrary, set the
controls and switches to the following settings :
Contrast .................................. normal
Brightness .................................. normal
Preparation:
1. In order to reduce the influence of geomagnetism on the set’s
picture tube, face it in an easterly or westerly direction.
2. Switch on the TV set’s power and degauss with a degausser.
(1) Adjustment of Correction Magnet for Y-Splitting Axis.
1. Input a crosshatch signal from the pattern generator.
2. Set the Picture control to minimum and confirm that the
Brightness control is set to normal.
3. Position the neck assembly as indicated in Fig.3-2.
4. Loosen the deflection yoke fixing screw.
5. Move the deflection yoke as far forward as is possible.
6. Adjust the upper and lower pin symmetrically by opening or
closing theY-splitting axis correction magnets located on the neck
assembly. [See Fig 3-3]
7. Return the deflection yoke to its original position and re-tighten its
fixing screw.
Carry out the adjustments in the following order :
3-1. BeamLanding.
3-2. Convergence.
3-3. Focus.
3-4. WhiteBalance.
Note : Test equipment required.
1. Colorbar/pattern generator.
2. Degausser.
3. Oscilloscope.
4. Digital multimeter.
Fig.3-1
(2) Landing
Note : Before carrying out the following adjustments adjust the
magnets as indicated below [See Fig.3-4].
1. Input a crosshatch signal from the signal generator.
2. Rough-adjust the focus and horizontal convergence.
3. Switch from the crosshatch pattern to an all-red pattern.
4. Move the deflection yoke backwards and adjust with the purity
magnet so that the red is at the centre and it aligns
symmetrically [See Fig.3-5].
5. Move the deflection yoke forward to the point where the entire
screen just becomes red [Mark its position].
6. Move the deflection yoke further forward until the screen just
changes colour at the edges. [Mark its position]
7. Position the deflection yoke between the two marks indicated
above.
8. Input a crosshatch pattern from the pattern generator and rotate the
deflection yoke so that the horizontal lines are parallel with the top
and bottom of the screen.
9. When the position of the deflection yoke has been determined,
fasten it with its fixing screw.
10. Switch the pattern generator to green then blue and confirm the
purity.
11. If the beam does not land correctly in all the corners of the screen,
use disk magnets to correct it. [Confirm the corner landing for
green and blue]
SECTION 3 SET-UP ADJUSTMENTS
3-1. Beam Landing
Caution :
High voltages are present on the Deflection yoke terminals - take care
when handling the Deflection yoke whilst carrying out adjustments.
Y-splitting axis correction magnet
Fig.3-3
Fig.3-2
Neck assy
Align the edge
of the neck assy with
the edge of the G2 grid
on the G3 side.
G2
G1
G3
+
