Sony KV-9PT50 - 9" Trinitron Color Tv Guide

5 3/4"
+
-
+
-
2 1/8" 4 1/2"
6"
6 1/8"
10 3/8" 5 3/4"
7 1/2"
7 1/8"
10 1/4"
MOUNTING BRACKET
Sony Electronics Inc • Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX [phone]
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
MODEL:
DESCRIPTION:
DIMENSIONS
(WHD):
DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
POWER
REQUIREMENTS:
POWER
CONSUMPTION:
1/4 inch = 1 inch Scale 4:1
9'" Trinitron®
Monitor /Receiver
10 1/4" x 11 1/2" x 12 1/8"
12 Lbs 9 oz
120V
AC
53 Watts
SIDE
VIEW
FRONT
VIEW
10 1/2"
11 1/2"
NOTE: MOUNTING BRACKET ON KV9PT50 ONLY!
4"
MIN. TO THE WALL
12 1/8"
REMOTE SENSOR
KV-9PT50/60
NOTE:
WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION WE
RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL
MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
