MODEL COMMANDER DEST. CHASSIS NO.
CHASSIS
TRINITRON ® COLOR TV
SERVICE MANUAL BG-3R
MODEL COMMANDER DEST. CHASSIS NO.
KV-XA29M66 RM-953 Singapore SCC-U39A-A
123
456
78
0
-/--
9
FAVORITE
SOUND
MODE SURROUND
PIPPROGR
PIPPROGR
ENTER
PICMODE

http://cxema.ru
– 2 –
KV-XA29M66
RM-953
SPECIFICATIONS
Note
Power requirements 110-240 V AC, 50/60 Hz
Power consumption (W) Indicated on the rear of the TV
Television system B/G, I, D/K, M
Color system PAL, PAL 60, SECAM, NTSC4.43, NTSC3.58
Stereo/Bilingual system NICAM Stereo Bilingual B/G, I; A2 Stereo Bilingual (German) B/G
Television system English, Arabic, French
Channel coverage
B/G VHF: E2 to E12 / UHF: E21 to E69 / CATV: S01 to S03, S1 to S41
IUHF: B21 to B68 / CATV: S01 to S03, S1 to S41
D/K VHF: C1 to C12, R1 to R12 / UHF: C13 to C57, R21 to R60
CATV: S01 to S03, S1 to S41, Z1 to Z39
MVHF: A2 to A13 / UHF:A14 toA79 /
CATV: A-8 to A-2, A to W+4, W+6 to W+84
˘(Antenna) 75-ohm external terminal
Audio output (Speaker) 8W + 8W 10% distortion
Number of terminal
D(Video) Input: 3* Output: 1 Phono jacks; 1 VP-P, 75 ohms
≥(Audio) Input: 3* Output: 1 Phono jacks; 500 mVrms
(S Video) Input: 2 Y : 1 Vp-p, 75 ohms,
unbalanced, sync
negative
C : 0.286 Vp-p, 75 ohms
(Component Video) Input: 1 Phono jacks
Y : 1 Vp-p, 75 ohms,
sync negative
CB: 0.7 Vp-p, 75 ohms
CR: 0.7 Vp-p, 75 ohms
Audio : 500 mVrms
2(Headphones) Output: 1 minijack
Picture tube 29 inch
Tube size (cm) 72 Measured diagonally
Screen size (cm) 68 Measured diagonally
Dimension (w/h/d, mm) 722 x 576 x 516
Mass (kg) 50
Design and specifications are subject to change without notice.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY SHADING AND MARK !ON
THE SCHEMATIC DIAGRAMS, EXPLODEDVIEWS AND INTHE
PARTS LIST ARE CRITICALTO SAFE OPERATION. REPLACE
THESE COMPONENTS WITH SONY PARTS WHOSE PART
NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN
SUPPLEMENTS PUBLISHED BY SONY.
CAUTION
SHORT CIRCUIT THE ANODE OF THE PICTURE TUBE AND
THE ANODE CAPTOTHE METAL CHASSIS, CRT SHIELD, OR
CARBON PAINTED ON THE CRT, AFTER REMOVING THE
ANODE.

http://cxema.ru
– 3 –
KV-XA29M66
RM-953
TABLE OF CONTENTS
Section Title Page
SELF DIAGNOSIS FUNCTION................................ 4
1. GENERAL........................................................................ 7
2. DISASSEMBLY
2-1. Rear Cover Removal................................................ 27
2-2. Speaker Removal ..................................................... 27
2-3. Chassis Assy Removal ............................................. 27
2-4. F Bracket Removal .................................................. 27
2-5. Service Position ....................................................... 27
2-6. Replacement of Parts ............................................... 27
2-6-1 Replacement of Light Guide .............................................. 28
2-6-2 Replacement of Power Button ........................................... 28
2-7.
HV Cap Block, PWB Holder and J Board Removal .. 28
2-8. Terminal Bracket Removal ...................................... 28
2-9. D3 Board Removal .................................................. 28
2-10. P2 and V1 Boards Removal ..................................... 28
2-11. H Board Removal .................................................... 29
2-12. A and B Boards Removal ........................................ 29
2-13. Picture Tube Removal.............................................. 29
2-14. Removal of Anode Cap............................................ 30
3. ADVANCE OPERATION
3-1. "RESET" Function................................................... 31
4. SET-UP ADJUSTMENTS
4-1. Beam Landing .......................................................... 32
4-2. Convergence Adjustment ......................................... 33
4-3. Focus Adjustment .................................................... 35
4-4. G2 (Screen) and White Balance Adjustments......... 36
5. CIRCUIT ADJUSTMENTS
5-1. Adjustments with Commander ................................ 37
5-2. Adjustment Method ................................................. 37
5-3. Picture Quality Adjustments.................................... 42
5-4. Display position Adjustment ................................... 42
5-5. A Board Adjustment After IC003
(memory) Replacement ........................................... 42
5-6. A Board Adjustment After IC003 (Memoy)
Replacement............................................................. 43
5-7. Picture Distortion Adjustment ................................. 44
Section Title Page
6. DIAGRAMS
6-1. Block Diagram .......................................................... 45
6-2. Circuit Board Location ............................................. 47
6-3. Schematic Diagrams ................................................. 48
(1) Schematic Diagrams of F, J and VM Boards ..... 49
(2) Schematic Diagram of A Board .......................... 51
(3) Schematic Diagram of B Board.......................... 67
(4) Schematic Diagram of P2 Board ....................... 75
(5) Schematic Diagram of C6 Board....................... 77
(6) Schematic Diagram of H Board ......................... 79
(7) Schematic Diagram of V1 Board........................ 81
(8) Schematic Diagram of D3 Board ....................... 83
6-4. Voltage Measurements.............................................. 84
6-5. Waveforms ................................................................ 92
6-6. Printed Wiring Boards and Parts Location............... 93
6-7. Semiconductors....................................................... 101
7. EXPLODED VIEWS
7-1. Picture Tube ............................................................ 103
7-2. Chassis .................................................................... 104
8. ELECTRICAL PARTS LIST.................................... 105

http://cxema.ru
– 4 –
KV-XA29M66
RM-953
The units in this manual contain a self-diagnostic function. If an error occurs, the STANDBY/TIMER lamp will automatically
begin to flash.
The number of times the lamp flashes translates to a probable source of the problem.A definition of the STANDBY/TIMER
lamp flash indicators is listed in the instruction manual for the user’s knowledge and reference. If an error symptom cannot
be reproduced, the remote commander can be used to review the failure occurrence data stored in memory to reveal past
problems and how often these problems occur.
1. DIAGNOSTICTEST INDICATORS
When an errors occurs, the STANDBY/TIMER lamp will flash a set number of times to indicate the possible cause of the
problem. If there is more than one error, the lamp will identify the first of the problem areas.
Result for all of the following diagnostic items are displayed on screen. No error has occured if the screen displays a “0”.
Diagnostic
Item
Description
• Power does not
turn on
• +B overcurrent
(OCP) or
overvoltage
(OVP)
• Vertical deflection
stopped
• Horizontal
deflection
overdrive
• White balance
failure (no
PICTURE)
• Micro reset
Detected
Symptoms
• Power does not come on.
• No power is supplied to the
TV.
• AC power supply is faulty.
• Power does not come on.
• Load on power line is
shorted.
• Has entered standby state
after horizontal raster.
• Vertical deflection pulse is
stopped.
• Power line is shorted or
power supply is stopped.
• No raster is generated.
• CRT cathode current
detection reference pulse
output is small.
• Power is shut down shortly,
after this return back to
normal.
• Detect Micro latch up.
Note 1: If a + B overcurrent is detected, stoppage of the vertical deflection is detected simultaneously.
The symptom that is diagnosed first by the microcontroller is displayed on the screen.
Note 2: Refer to screen (G2) Adjustment in section 3-4 of this manual.
* R(Q703), G(Q702) or B(Q701) out is faulty (C6 board).
SELF DIAGNOSTIC FUNCTION
No. of times
STANDBY/TIMER
lamp flashes
Does not light
2 times
5 times
—
Self-diagnostic
display/Diagnostic
result
—
002:000 or
002:001~255
003:001~255
004:001~255
at the same time
005:000 or
005:001~225
101:00 or
101:001~225
Probable
Cause
Location
• Power cord is not plugged
in.
• Fuse is burned out F4601
(F)
• H.OUT Q511 is shorted. (A
board)
• Q701, Q702, Q703 is
shorted (C6 board)
• -13V is not supplied. (A
board)
• IC 503 faulty (A board)
• G2 is improperly adjusted.
(Note 2)
• CRT problem.
• R(Q703), G(Q702) or
B(Q701) out is faulty
(C6 board)
• IC301 is faulty. (A board)
• No connection A board to
C6 board.
• Discharge CRT (C6 Board)
• Static discharge
• External noise

http://cxema.ru
– 5 –
KV-XA29M66
RM-953
2. DISPLAY OF STANDBY/TIMER LIGHT FLASH COUNT
3. STOPPINGTHE STANDBY/TIMER FLASH
Turn off the power switch on the TV main unit or unplug the power cord from the outlet to stop the STANDBY/TIMER lamp
from flashing.
4. SELF-DIAGNOSTIC SCREEN DISPLAY
For errors with symptoms such as “power sometimes shuts off” or “screen sometimes goes out” that cannot be confirmed, it
is possible to bring up past occurances of failure for confirmation on the screen:
[To Bring Up ScreenTest]
In standby mode, press buttons on the remote commander sequentially in rapid succession as shown below:
[Screendisplay] /channel [5] /Sound volume [-] /Power ON
˘
Note that this differs from entering the service mode (mode volume [+]).
Self-Diagnosis screen display
STANDBY/SLEEP lamp
Lamp ON 0.3 sec. Lamp OFF 3 sec.
Lamp OFF 0.3 sec.
2 times
3 times
Diagnostic Item Flash Count*
+B overcurrent/overvoltage 2 times
Vertical deflection stopped
White balance failure 5 times
* One flash count is not used for self-diagnostic.
002 : 000
003 : 000
004 : 000
005 : 001
Numeral "0" means that no fault has been detected.
Numeral "1" means a fault has been detected.
101 : 000
SELF DIAGNOSTIC

http://cxema.ru
– 6 –
KV-XA29M66
RM-953
5. HANDLING OF SELF-DIAGNOSTIC SCREEN DISPLAY
Since the diagnostic results displayed on the screen are not automatically cleared, always check the self-diagnostic screen
during repairs.When you have completed the repairs, clear the result display to “0”.
Unless the result display is cleared to “0”, the self-diagnostic function will not be able to detect subsequent faults after
completion of the repairs.
[Clearing the result display]
To clear the result display to “0”, press buttons on the remote commander sequentially as shown below when the diagnostic
screen is being displayed.
Channel [8] /0
[Quitting Self-diagnostic screen]
To quit the entire self-diagnostic screen, turn off the power switch on the remote commander or the main unit.
6. SELF-DIAGNOSTIC CIRCUIT
[+BovercurrentªOCPº] Occurs when an overcurrent on the +B(135) line is detected by Q604. If Q604 go to ON
and the voltage to pin 18 of IC301 should go down when V.SYNC is more than seven
verticals in a period, the unit will automatically turn off.
[Verticaldeflectionstopped] Occurs when an absence of the vertical deflection pulse is detected by Q509 and IC001
shut down the power supply.
[Verticaldeflectionovercurrent] Occurs when an overcurrent on V drive line is detected by Q507. Power supply will be
shut down when detect this by IC001.
[ hitebalancefailure] If the RGB levels* do not balance or become low level within 5 seconds, this error will be
detected by IC301.TV will stay on, but there will be no picture.
* (Refers to the RGB levels of the AKB detection Ref pulse that detects IK.)
IC301
Y/CHROMA JUNGLE
FROM
CRT
[V] Q509/507
IC001
SYSTEM IC003 MEMORY
IK-IN
MP/
PROTECT O-LED
IO-8DAT B-DAT
IO-SDAT
521
18 51
46
SDA 35
FROM
[+B] Q604 C6
45

http://cxema.ru
– 7 –
KV-XA29M66
RM-953
SECTION 1
GENERAL
2
To prevent fire or shock hazard, do not expose the TV to rain or moisture.
Do not operate the TV if any liquid or solid object falls into it. Have it checked immediately by qualified personnel only.
Do not open the cabinet and the rear cover of the TV as high voltages and other hazards are present inside the TV. Refer servicing and disposal of the TV to qualified personnel.
Your TV is recommended for home use only. Do not use the TV in any vehicle or where it may be subject to excessive dust, heat, moisture or vibrations.
Do not block the ventilation openings of the TV. Do not install the TV in a confined space, such as a bookcase or built-in cabinet.
For children’s safety, do not leave children alone with the TV. Do not allow children to climb onto it.
Do not plug in too many appliances to the same power socket. Do not damage the power cord. Clean the TV with a dry and soft cloth. Do not use benzine, thinner, or any other chemicals to clean the TV. Do not scratch the picture tube.
For your own safety, do not touch any part of the TV, the power cord and the antenna cable during lightning storms.
Pull the power cord out by the plug. Do not pull the power cord itself. Disconnect the TV before moving it or if you are not going to use it for several days.
WARNING • Dangerously high voltages are present inside the TV. • TV operating voltage: 110 – 240 V AC. (For Malaysia only: 220 – 240 V AC).
3
Using Your New TV
GB
Do not install the TV in an unstable position. Use a proper TV stand. Do not place any objects on the TV.
WARNING (continued)
The operating instruction mentioned here are partial abstracts from the Operating Instruction Manual.The page numbers of the Operating Instruction Manual remain as in the manual.

http://cxema.ru
– 8 –
KV-XA29M66
RM-953
4
Using Your New TV
123
R L Y C
B
C
R
VIDEO
VIDEO IN
VIDEO OUT
AUDIO
R L
Getting Started
CAUTION • Do not connect the power cord until you have completed making all other
connections; otherwise a minimum leakage current might flow through the antenna and other terminals to ground.
• To avoid battery leakage and damage to the remote, remove the batteries
from the remote if you are not going to use it for several days. If any liquid that leaks from the batteries touches you, immediately wash it away with water.
Step 1
Connect the antenna If you wish to connect a VCR, see the Connecting a VCR diagram below.
Connecting a VCR To watch the video input, press t(see page 10).
IEC connector (not supplied)
To video and audio outputs
VCR
(yellow)
L (MONO) (white) R (red)
To S video output
Antenna cable (not supplied)
To t 1, 2 or 3 (video input)
Audio/Video cable (not supplied)
S video cable (not supplied)
: Signal flow
To
(S video input)
To antenna output
To 8 (antenna)
or
: Signal flow
Antenna cable (not supplied)
Antenna cable (not supplied)
Rear of TV
Rear of TV
Using Your New TV
5
Using Your New TV
Using Your New TV
PROGRMENU AUTO
PROGR
ENTER SELECT
L(MONO)
3
1
2
Notes • If you connect a monaural VCR, connect the yellow plug to (the
yellow jack) and the black plug to -L (MONO) (the white jack).
• If you connect a VCR to the 8(antenna) terminal, preset the signal
output from the VCR to the program number 0 on the TV.
• If both (S video input) and …1 (video input) at the rear of your TV
are input at the same time, the (S video input) is automatically
selected. To view t1 (video input), disconnect the S video cable.
• Do not connect video equipment to t3 (video input) at the front and
the rear of your TV at the same time; otherwise the picture will not be displayed properly on the screen.
• When no signal is input to the connected video equipment, the TV screen
becomes blue.
Step 2
Insert the atteries into the remote
Note • Do not use old batteries nor use different types of batteries together.
Step 3
Preset the channels automatically
Tips • If you want to stop the automatic channel presetting, press MENU. • If your TV has preset an unwanted channel or cannot preset a particular
channel, then preset your TV manually (see page 32).
Note (KV XA34M84 only) • During automatic channel presetting, your TV screen will indicate “B/G”,
“I”, “D/K” or “M” for the TV system (“TV SYS”).
Front of TV

http://cxema.ru
– 9 –
KV-XA29M66
RM-953
6
Using Your New TV
Connecting optional components
You can connect optional audio/video components, such as a VCR, multi disc player, DVD, camcorder, video game or stereo system. To watch the picture of the connected equipment, press t(see page 10). Connecting a camcorder/video game equipment using the t (video input) jacks
Notes • You can also connect video equipment to the t1, 2 or 3 (video input)
jacks at the rear of your TV.
• If both (S video input) and t3 (video input) at the front of your TV
are input at the same time, the (S video input) is automatically
selected. To view t3 (video input), disconnect the S video cable.
• Do not connect video equipment to the t3 (video input) jacks at the
front and the rear of your TV at the same time; otherwise the picture will not be displayed properly on the screen.
Connecting audio/video equipment using the T (monitor output) jacks
Note • If you select “DVD” on your TV screen, no signal will be output at the T
(monitor output) jacks (see page 10).
To S video output
Front of TV
Camcorder
Video game equipment
To video and audio outputs
(yellow)
L (MONO)
(white)
R (red)
Rear of TV
To antenna output
To video and audio inputs
or
Audio system
To audio inputs
VCR
: Signal flow
: Signal flow
To
(S video input)
To
t
3 (video input)
To T (monitor output)
or
Audio/Video cable (not supplied)
S video cable (not supplied)
Antenna cable (not supplied)
Audio/Video cable (not supplied)
PROGRMENU AUTO
PROGR
ENTER SELECT
L(MONO)
3
L (MONO) R
3
123
L(MONO)
R
R L Y C
B
C
R
7
Using Your New TV
Using Your New TV
Notes • Some DVD player terminals may be labeled differently: • Since the high quality pictures on a DVD disc contain a lot of information,
picture noise may appear. In this case, adjust the sharpness (“SHARP”) in the “ADJUST” menu of the “PICTURE MODE” menu (see page 25).
• Connect your DVD player directly to your TV. Connecting the DVD player
through other video equipment will cause unwanted picture noise.
Connecting a DVD player using the (component
video input) jacks
1 Connect R and L under (component video input) on your TV to the LINE OUT,
AUDIO R and L output connectors on your DVD player.
2 Using a component video cable, connect Y, C
B
, and C
R
under (component video
input) on your TV to the COMPONENT VIDEO OUT Y, C
B
, and C
R
output
connectors on your DVD player.
DVD player
To
L (white) R (red)
Audio cable (not supplied)
To component video output
Component video cable (not supplied)
To audio output
: Signal flow
To
(component video input)
Connect To (on the DVD player) Y (green) Y C
B
(blue) C
b
, B-Y or P
B
C
R
(red) C
r
, R-Y or P
R
VIDEO
R-AUDIO-L
LINE OUT
Y
COMPONENT VIDEO OUT
S VIDEO OUT
C
B
C
R
R L Y C
B
C
R
Rear of TV
Connecting a DVD player using the t (video input) jacks
VIDEO
R-AUDIO-L
LINE OUT
123
L(MONO) R
DVD player
Audio/Video cable (not supplied)
(yellow)
L (MONO) (white) R (red)
To t 1, 2, or 3 (video input)
: Signal flow
Rear of TV

http://cxema.ru
– 10 –
KV-XA29M66
RM-953
8
Using Your New TV
Securing the TV
To prevent the TV from falling, secure the TV using one of the following methods: A
With the supplied screws, attach the and to the TV stand and to the rear of the TV using the provided hole.
or
B
Put the cord or chain through the clamps to secure the TV against a wall or pillar.
Note • Use only the supplied screws. Use of other screws may damage the TV.
20 mm
AB
3.8 mm
or
9
Using Your New TV
Using Your New TV
Watching the TV
This section explains various functions and operations available while watching the TV. Most operations can be done using the remote.
1
Press
!
to turn on the TV.
When the TV is in the standby mode (the
1
indicator on the TV is lit red), press ?/1on the remote or PROGR +/– on the TV.
2
Press PROGR +/– or num er uttons to select the TV program. For double digit numbers, press
-
, then the number
(e.g., for 25, press
-
, then
2 and 5).
To select a TV program quickly
(1) Press and hold PROGR +/–. (2) Release PROGR +/– when the desired program number appears.
Note • When you select a TV program quickly, the picture may be disrupted.
This does not indicate a malfunction.
%
t
a
Number buttons
JUMP
2
+/–
PROGR +/–
MENU
V/b/v/B/ENTER
or
1
indicator
123 456
78
0
-/--
9
PROGRMENU AUTO
PROGR
ENTER SELECT
L(MONO)
3
PROGRMENU AUTO
PROGR
ENTER SELECT
123 456
78
0
-/--
9
FAVORITE
SOUND
MODE SURROUND
PIP PROGR
PIP PROGR
ENTER
PIC MODE
continued
?/1

http://cxema.ru
– 11 –
KV-XA29M66
RM-953
10
Using Your New TV
Watching the TV (continued)
To Turn off temporarily Turn off completely Adjust the volume Mute the sound
Watch the video input (VCR, camcorder, etc.) Jump back to the previous channel Display the on-screen information*
Press ?/1. The 1indicator on the TV lights up red. !on the TV. 2+/–. %. t
to select “VIDEO 1”, “VIDEO 2” , “VIDEO 3”or “DVD”. To
return to the TV program, press
a
(or
t
on the TV).
JUMP.
.
Additional tasks
ENTER
ENTER ENTER
ENTER ENTER
PICTURE++MO C
INTELL I GENT P IC :OFF
WIDE MODE :OFF
DE : DYNAMI
E
COLOR SYS :AUTO
SETUP
PROGRAM SETUP PIC ROTATION
NGL I SH
LANGUAGE :
* The picture, sound, and either the program number or video mode are
displayed. The on-screen display for the picture and sound information disappears after about 3 seconds.
Changing the menu language You can change the menu language as well as the on-screen language. For details on how to use the menu, see “Introducing the menu system” on page 21. 1
Press MENU.
2
Press V or v to select the
“SETUP” icon ( ),
then press ENTER.
3
Make sure “LANGUAGE” is selected, then press ENTER.
4
Press V or v to select the
desired language (e.g., “”), then press
ENTER. The selected menu language appears.
To return to the normal screen
Press MENU.
LANGUAGE :
COLOR SYS :
SETUP
PROGRAM SE PIC ROTATI ENGL I SH
11
Using Your New TV
Using Your New TV
Setting the Wake Up timer 1
Press until the desired
period of time appears. The Wake Up timer starts immediately after you have set it.
2
Select the TV program or video mode you want to display when you wake up.
3
Press 1 or set the Sleep timer if you want the TV to turn off automatically. The indicator lights up orange.
To cancel the Wake Up timer
Press until “WAKE UP TIMER: OFF” appears or turn off the TV’s
main power.
Note • If no buttons or controls are pressed for more than two hours after the TV
is turned on using the Wake Up timer, the TV automatically goes into the standby mode. To continue watching the TV, press any button or control on the TV or the remote.
Setting the Sleep timer
Press until the desired period of time appears. The Sleep timer starts immediately after you have set it.
To cancel the Sleep timer
Press until “SLEEP TIMER: OFF” appears or turn the TV off.
WAKE UP TIMER:10M
WAKE UP TIMER:OFF
After 10 minutes
No Wake Up Timer
WAKE UP TIMER:12H00M
After 12 hours
SLEEP TIMER:30M SLEEP TIMER:60M SLEEP TIMER:OFF SLEEP TIMER:90M
After 30 minutes
No Sleep Timer
After 60 minutes
After 90 minutes

http://cxema.ru
– 12 –
KV-XA29M66
RM-953
12
Advanced Operations
SOUND MODE
PIC MODE
Selecting the picture and sound modes
You can select picture and sound modes and adjust the setting to your preference in “PERSONAL” option.
Selecting the picture mode
Press PIC MODE repeatedly until you get the desired picture mode.
Select To “DYNAMIC” receive high contrast pictures. “STANDARD” receive normal contrast pictures. “SOFT” receive mild pictures.
“PERSONAL” receive the last adjusted picture setting from the “ADJUST”
option in the “PICTURE” menu (see page 24).
Selecting the sound mode
Press SOUND MODE repeatedly until you get the desired sound mode.
Select To “DYNAMIC” listen to dynamic and clear sound that emphasizes the low and
high tones.
“DRAMA” listen to sound that emphasizes voice and high tones.
“SOFT” receive soft sound. “PERSONAL ” receive the last adjusted sound setting from the “ADJUST”
option in the “SOUND” menu (see page 26).
Tip • You can also set the picture and sound modes using the menu (see
Changing the “PICTURE” setting on page 24 and Changing the “SOUND” setting on page 26).
PERSONAL SOFT
STANDARD
DYNAMIC
≥
DYNAMIC
≥
DRAMA
≥
SOFT
≥
PERSONAL
PIC MODE
Advanced Operations
13
Advanced Operations
1
Press FAVORITE.
2
Press the num er utton from 1 to 6 to select the desired channel.
Tip • To program your favorite channels, see Adjusting each channel settings
(PROGRAM SETUP) on page 30.
Viewing your favorite channels
You can display and select six of your favorite channels directly from your TV screen.
Number buttons FAVORITE
123 456
123 456
78
0
-/--
9
FAVORITE
SOUND
MODE SURROUND
PIP PROGR PIP PROGR
ENTER
PIC MODE
Advanced Operations
1

http://cxema.ru
– 13 –
KV-XA29M66
RM-953
14
Advanced Operations
Watching two programs at the same time
— PIP With the Picture-in-Picture (PIP) feature, you can display a sub screen within the main picture of different TV programs or video inputs.
Displaying a su screen
Press .
To return to the normal screen
Press (when displaying the sub screen).
// /
V (PIP PROGR +)/ v (PIP PROGR –)
123 456
78
0
-/--
9
FAVORITE
SOUND
MODE SURROUND
PIP PROGR
PIP PROGR
ENTER
PIC MODE
15
Advanced Operations
Additional PIP tasks To
change a TV program in the sub screen select a video input in the sub screen swap pictures between the main and sub screens
freeze the sub screen
Tips • You can also display the sub screen and exchange pictures between the
main and sub screens using the menu (see Changing the “PIP” setting on page 28).
• You can change the position of the sub screen (see Changing the “PIP”
setting on page 28).
Notes • When you display a video input on the sub screen at a faster/slower
speed, the picture may be disrupted depending on the VCR type.
• If you display different color systems on the sub screen, the size of the sub
screen may be different and the picture may be disrupted. This does not indicate a malfunction of the TV.
Press V(PIP PROGR +) or v(PIP PROGR –).
.
.
.
To unfreeze the screen, press the button again.

http://cxema.ru
– 14 –
KV-XA29M66
RM-953
16
Advanced Operations
Press SURROUND repeatedly until you receive the desired surround sound.
Select To “TruSurround” listen to the surround sound that spreads out to the rear of a room. “OFF” turn off the surround sound.
Tip • You can also select the surround option using the menu (see Changing the
“SOUND” setting on page 26).
The surround of your TV is categorized as TruSurround.
TM
is a trademark of SRS Labs, Inc. SRS and the SRS symbol are
registered trademarks of SRS Labs, Inc. in the United States and selected foreign countries. SRS and TruSurround are incorporated under license from SRS Labs, Inc. and are protected under United States Patent Nos. 4,748,669 and 4,841,572 with numerous additional issued and pending foreign patents.
Listening with surround sound
The surround feature enables you to enjoy the sound effects of a concert hall or movie theater.
0
/
FAVORITE
SOUND
MODE SURROUND
PIP PROGR
PIP PROGR
ENTER
SURROUND: OFF
SURROUND: TruSurround
SURROUND
17
Advanced Operations
Broadcasting On screen display (Selected sound) NICAM stereo
NICAM bilingual NICAM monaural
Enjoying stereo or ilingual programs
(KV–XA34M66/XA29M66 only) You can enjoy stereo sound or bilingual programs of NICAM and A2 stereo systems.
Press A/B repeatedly until you receive the sound you want. The on screen display changes to show the selected sound. The indicator on the TV lights
up red when receiving any stereo
or bilingual program.
When receiving a NICAM program
A/B
NICAM MONO
(Stereo sound) (Regular sound)
NICAM
MAIN MONO
(Main sound) (Regular sound)
NICAM
SUB
(Sub sound)
NICAM
MAIN MONO
(Main sound) (Regular sound)
NICAM
continued
indicator
PROGRMENU AUTO
PROGR
ENTER SELECT
L(MONO)
3
123 456
78
0
-/--
9
FAVORITE
SOUND
MODE SURROUND
PIP PROGR PIP PROGR
ENTER
PIC MODE

http://cxema.ru
– 15 –
KV-XA29M66
RM-953
18
Advanced Operations
MONO AUTO
Receiving area Hong Kong, Singapore, New Zealand, Malaysia, Thailand, etc. Australia, Malaysia, Thailand, etc.
When receiving an A2 program Receiving area for NICAM and A2 programs
Notes • If the signal is very weak, the sound becomes monaural automatically. • If the stereo sound is noisy when receiving a NICAM program, select
“MONO”. The sound becomes monaural, but the noise is reduced.
If the sound is distorted when receiving a monaural program through the 8 (antenna) terminal
Press A/B repeatedly until “MONO” appears on the screen. To cancel the monaural sound setting, press A/B again until “AUTO” appears on the screen.
Notes • The “MONO” or “AUTO” setting is memorized for each program
position.
• You cannot receive stereo broadcast signal when the TV is in the “MONO”
setting. Normally set the TV to “AUTO”.
STEREO
MONO
(Stereo sound)
(Regular sound)
MAIN SUB
(Main sound) (Sub sound)
Broadcasting On screen display (Selected sound) A2 stereo
A2 bilingual
System NICAM A2
Enjoying stereo or bilingual programs (continued)
19
Advanced Operations
Viewing Teletext (KV XA34M66/XA29M66 only) TV stations broadcast an information service called Teletext via some TV channels. Teletext allows you to receive various information, such as shares market or news.
Displaying Teletext
1
Select a TV channel that carries the Teletext roadcast you want to watch.
2
Press to display the
text. A Teletext page (normally the index page) is displayed. If there is no Teletext broadcast, “100” is displayed at the top left corner of the screen.
To turn off Teletext
Press
a
.
t
b
a
P166 SECTEXT 166 FR1 MAR 03:59:09 From Singapore To PARIS To OSAKA To ROMA To SYDNEY
Day Dep/Arr Flight Alrcraft
1.6 220/0588 SQ28 747
2 2130/1225 PA115 L15 3 2115/1330 SQ26 747 2.7 2130/0745 SQ24
747
4 2300/0915 AZ487 747 2.5 1000/1715 SQ6 747 4.6 0930/2015 CX522 L10 1 2210/0610 SQ21A 747 2 2100/0835 SQ21A 747
A/B
123 456
78
0
-/--
9
FAVORITE
SOUND
MODE SURROUND
PIP PROGR PIP PROGR
ENTER
PIC MODE
continued
(red, green, yellow, blue)

http://cxema.ru
– 16 –
KV-XA29M66
RM-953
20
Advanced Operations
Additional Teletext tasks
To display a Teletext page on the TV picture check the contents of a Teletext service
select a Teletext page hold (pause) a Teletext display
reveal concealed information (e.g., an answer to a quiz) enlarge the Teletext display wait for a Teletext page while watching a TV program
* You can also select a Teletext page that appears in the colored columns at
the bottom of the screen using the corresponding color-coded buttons on the remote.
Using FASTEXT
This feature allows you to quickly access a Teletext page that uses FASTEXT. When a FASTEXT program is broadcasted, the colored menus appear at the bottom of the screen. The colors of the menus correspond to the red, green, yellow, and blue color-coded buttons on the remote.
To access a FASTEXT menu
Press the color-coded button on the remote corresponding to the menu you want. The menu page appears on the screen after several seconds.
Do this Press .
Each time you press , the screen changes as
follows: Teletext tTeletext and TV tTV. Press
.
An overview of the Teletext contents and page numbers appear on the screen. Press the number buttons to enter the three-digit page number of the desired Teletext page.* If you make a mistake, reenter the correct page number. To access the next or previous page, press PROGR +/–. Press to display the symbol “ ” at the top left
corner of the screen. To resume normal Teletext operation, press
or .
Press .
To conceal the information, press the button again. Press .
Each time you press , the Teletext display
changes as follows: Enlarge upper half tEnlarge lower half tNormal size. 1 Enter the Teletext page number that you want to
refer to, then press .
2 When the page number is displayed, press to
show the text.
Vie ing Teletext (continued)
21
Adjusting Your Setup (MENU)
Introducing the menu system
The MENU button lets you open a menu and change the settings of your TV. Here’s an overview of the menu system.
Level 1 Level 2 Level 3/Function “PICTURE”
“PICTURE MODE” Select the “PICTURE” mode:
“DYNAMIC”t“STANDARD”t“SOFT”t “PERSONAL”t“ADJUST”
“ADJUST” Adjust the “PERSONAL” option:
“PICTURE” t“COLOR”t“BRIGHT”t “HUE”t“SHARP”
“WIDE MODE” Change the picture size. “INTELLIGENT PIC” Optimize picture quality.
“SOUND” “SOUND MODE” Select the “SOUND” mode:
“DYNAMIC”t“DRAMA” t“SOFT” t “PERSONAL“ t“ADJUST”
“ADJUST” Adjust the “PERSONAL” option:
“BASS” t“TREBLE”t“BALANCE”t“BBE”
*
“SURROUND” Select the “SURROUND” mode:
“TruSurround” t“OFF”
“INTELLIGENT VOL” Adjust volume automatically.
“PIP” “PIP POSITION” Change the position of the sub screen.
“PIP” Display a sub screen within the main picture. “SWAP” Exchange pictures between main screen and sub
screen.
“SETUP” “LANGUAGE” Change the menu language:
“ENGLISH” t“”(Chinese) t “ ”(Arabic) t
“” (Thai)
“PIC ROTATION” Rotate the picture. “PROGRAM SETUP” Adjust each channel settings. “COLOR SYS” Change the color system:
“AUTO” t“PAL” t“SECAM” t “NTSC3.58” t“NTSC4.43”
Return icon
“PICTURE” icon
“PIP” icon
“CH PRESET” icon
Name of the current menu Menu level 3
Menu level 2
Adjusting Your Setup (MENU)
Menu level 1
“SETUP” icon
Menu guide icon
LANGUAGE :
COLOR SYS :
SETUP
PROGRAM SE PIC ROTATI ENGL I SH
continued
Adjusting Your Setup (MENU)
“SOUND” icon

http://cxema.ru
– 17 –
KV-XA29M66
RM-953
22
Adjusting Your Setup (MENU)
Level 1 Level 2 Level 3/Function “CH PRESET” “AUTO PROGRAM” Preset channels automatically.
“MANUAL PROGRAM”
Preset channels manually.
“TV SYS” Change the TV system:
“B/G” t“I” t“D/K” t“M”
*
The BBE is manufactured by Sony Corporation under license from BBE Sound, Inc. It is covered by U.S. Patent No. 4,638,258 and No. 4,482,866. The word “BBE” and the BBE symbol are the trademarks of BBE Sound, Inc.
Introducing the menu system (continued)
23
Adjusting Your Setup (MENU)
How to use the menu You can use the buttons on the remote and on the TV as well to display the menu and adjust the settings.
1
Press MENU to display the menu.
2
Press V or v to select the
desired item.
3
Press ENTER to confirm your selection and go to the next menu level.
Other menu operations To Press Adjust the setting value V,b,vor B Move to the next/previous menu level bor B Cancel the menu MENU
Tips • If you want to exit from Menu Level 2 to Menu Level 1, press Vor vuntil
the return icon ( ) is highlighted, then press ENTER.
• Some of the menu items can be operated directly using the remote
buttons.
• The MENU, ENTER, and SELECT
/
buttons on the TV can also be used
for the operations above.
Notes • If more than 60 seconds elapse between entries, the menu screen
automatically disappears.
PROGRMENU AUTO
PROGR
ENTER SELECT
R
TV
CH PRESET
SYS:B /G
MANUAL PROGRAM
AM+++
OPROGAUT
V/b/v/B/ENTER
MENU
Front of TV
RAM
UHF
MANUALPROG
SENS : H IGH
TV SYS:B/G FINE:AUTO
14PR:
ENTER
ENTER
0
/
FAVORITE
PIP PROGR
PIP PROGR
ENTER
PICTURE++MO C
INTELL I GENT P IC :OFF
WIDE MODE :OFF
DE : DYNAMI

http://cxema.ru
– 18 –
KV-XA29M66
RM-953
24
Adjusting Your Setup (MENU)
INTELLIGEN PER
SONAL
WIDE SOFT
MODE
MODE
:STANDARD
ADJUST
C
DYNAMI
FAVORITE
PIP PROGR PIP PROGR
ENTER
MENU
Changing the “PICTURE” setting
The “PICTURE” menu allows you to change the picture settings. 1
Press MENU.
2
Make sure the “PICTURE” icon ( ) is selected,
then press ENTER.
3
Press V or v to select the
desired item (e.g., “PICTURE MODE” ), then press ENTER.
Select To “PICTURE MODE” choose either “DYNAMIC”, “STANDARD”, “SOFT”
“PERSONAL”*, or “ADJUST”.
“WIDE MODE” change the picture size when receiving wide-mode (16:9)
picture signal. Press Vor vto select “ON”, then press ENTER. To cancel, select “OFF”, then press ENTER.
“INTELLIGENT PIC” optimize picture quality.
Press Vor vto select “ON”, then press ENTER. To cancel, select “OFF”, then press ENTER.
* When the “PERSONAL” mode is selected, you can receive the last
adjusted picture settings from the “ADJUST” items (see page 25).
Note • For details on the options under “PICTURE MODE”, see page 12.
To return to the normal screen
Press MENU.
ENTER
ENTER ENTER
V/b/v/B/ENTER
PICTURE MO C
INTELLIGENT PIC:OFF
WI DE MODE :OFF
DE : DYNAMI
25
Adjusting Your Setup (MENU)
80
COLOR
Adjusting the “ADJUST” items under “PICTURE MODE”
1
Press V or v to select the desired item (e.g., “COLOR”), then press ENTER.
2
Adjust the value according to the following ta le, then press ENTER. For Press v/B to Press V/b to “PICTURE” decrease picture contrast increase picture contrast “COLOR” decrease color intensity increase color intensity “BRIGHT” darken the picture brighten the picture “HUE”* increase red picture tones increase green picture tones
“SHARP” soften the picture sharpen the picture
* You can adjust “HUE” for the NTSC color system only.
3
Repeat the a ove steps to adjust other items. The adjusted settings will be received when you select “PERSONAL”.
Tip • For details on the menu system and how to use the menu, refer to
Introducing the menu system on page 21.
ENTER ENTER

http://cxema.ru
– 19 –
KV-XA29M66
RM-953
26
Adjusting Your Setup (MENU)
FAVORITE
PIP PROGR PIP PROGR
ENTER
MENU
Changing the “SOUND” setting
The “SOUND” menu allows you to change the sound settings. 1
Press MENU.
2
Press V or v to select the
“SOUND” icon ( ),
then press ENTER.
3
Press V or v to select the
desired item (e.g., “SOUND MODE”),
then press ENTER. Select To “SOUND MODE” choose either “DYNAMIC”, “DRAMA”, “SOFT”,
“PERSONAL”*, or “ADJUST”.
“SURROUND” choose either “TruSurround” or “OFF”. “INTELLIGENT VOL” adjust the volume of all TV programs and video inputs
automatically. Press Vor vto select “ON”, then press ENTER. To cancel, select “OFF”, then press ENTER.
* When the “PERSONAL” mode is selected, you can received the last
adjusted sound settings from the “ADJUST” option (see page 27).
Tip • For details on the options under “SOUND MODE” and “SURROUND”,
see pages 12 and 16 respectively.
To return to the normal screen
Press MENU.
V/b/v/B/ENTER
ENTER ENTER
SOUND MODE +
SOUND
INTELLIGENT VOL:OFF
SURROUND :OFF
:DYNAMI C+
PER
SOUND
SONAL
INTELLIGENSOFT
S SURROUND : O
OUND MODEDRAMA
ADJUST
C
DYNAMI
ENTER ENTER
27
Adjusting Your Setup (MENU)
Adjusting the “ADJUST” items under “SOUND MODE”
1
Press V or v to select the desired item (e.g., ”BALANCE“), then press ENTER.
2
Adjust the value according to the following ta le, then press ENTER.
For Press v/B to Press V/b to “BASS” decrease the bass increase the bass “TREBLE” decrease the treble increase the treble “BALANCE” increase the left speaker’s volume
increase the right speaker’s volume
“BBE” select “HIGH” for higher enhancement of sound clarity;
select “LOW” for lower enhancement of sound clarity; select “OFF” to turn off the BBE sound
3
Repeat the a ove steps to adjust other items. The adjusted settings will be received when you select “PERSONAL”.
Tip • For details on the menu system and how to use the menu, refer to
Introducing the menu system on page 21.
BALANCE 00
ENTER ENTER

http://cxema.ru
– 20 –
KV-XA29M66
RM-953
28
Adjusting Your Setup (MENU)
PIP
SWAP PIP:OFF
POS I T ION :
78
0
-/--
9
FAVORITE
SOUND
MODE SURROUND
PIP PROGR
PIP PROGR
ENTER
MENU
Changing the “PIP” setting
The “PIP” menu allows you to display a sub screen, change the sub screen position and exchange pictures between the main and sub screens.
1
Press MENU.
2
Press V or v to select the
“PIP” icon ( ), then
press ENTER.
3
Press V or v to select the
desired item (e.g., “PIP”), then press ENTER.
V/b/v/B/ENTER
ENTER ENTER
ENTER ENTER
ON
OFF
+
PIP
SWAP PIP:
POSIT I ON :
Select To
“POSITION” change the position of the sub screen.
Press Vor vto select the desired position, then press ENTER.
“PIP” display a sub screen within the main picture.
Press Vor vto select “ON”, then press ENTER. To cancel, press or select “PIP : OFF”, then press ENTER.
If you preset a locked channel, that channel will be unlocked automatically.
“SWAP” exchange pictures between main screen and sub screen.
To return to the normal screen
Press MENU. Tip • For details on the menu system and how to use the menu, refer to
Introducing the menu system on page 21.
29
Adjusting Your Setup (MENU)
Changing the “SETUP” setting
The “SETUP” menu allows you to change the menu language, adjust the picture position, setup your program and select color system.
123 456
78
0
-/--
9
FAVORITE
PIP PROGR
PIP PROGR
ENTER
MENU Number buttons
V/b/v/B/ENTER
1
Press MENU.
2
Press V or v to select
“SETUP” icon ( ),
then press ENTER.
3
Press V or v to select
the desired item (e.g., “COLOR SYS”), then press ENTER.
Select To “LANGUAGE” change the menu language (see Changing the menu language
on page 10).
“PIC ROTATION” adjust the picture position when it is not aligned to the TV screen.
Press V, b, vor Bto adjust the picture position, then press ENTER.
“PROGRAM SETUP” adjust each channel settings. (see Adjusting each channel settings
(PROGRAM SETUP) on page 30).
“COLOR SYS” change the color system. Normally, set this to “AUTO”.
To return to the normal screen
Press MENU.
ENTER ENTER
ENTER ENTER
ENTER ENTER
continued
E
COLOR SYS :AUTO
SETUP
PROGRAM SETUP PIC ROTATION
NGL I SH
LANGUAGE :
LANGUAGE : E
COLOR SYS : NTS
SETUP
C3.58
PROGRAM SE SECAM PIC ROTATI PAL
AUTO
NTSC4.43
