Sony TRINITRON KV2080R User manual

(CABLE COMPATIBLE TV) .
OPERATING INSTRUCTIONS
Weicome to the advanced world of Sony TV. For the best
results and the utmost satisfaction from your new set,
please read this manual thoroughly and retain it for
~future reference.
OWNER’S RECORD
The model and serial numbers are located at the rear.
Record these numbers in the spaces provided below.
Refer to them whenever you call upon your Sony dealer
regarding this product.
| Model No. Kv20 (2 serial No.
TRINITRON. COLOR TV
©1986 by Sony Corporation

CONTENTS
Wa tninGiccieencedte ave ee eect ee Benes a ounces 2
PreGautions =.228c een ect etslicin de eetecasensteeiies 3
PE atutes: -xicnteceten ss Be tscetcl IN ee oth iain seasieterresnabottnees 3
Location Of CONTIONS ........ eee ececceesssceeeeesessssesessesscseeeeeseas 4
SOU=U Ps pccsties. eed. ccctteehed ok eneh vtneticidble atone Sti nctesteeen be: 5
Remote COMMANGE?L ..........cccccccsccecsesssssceseessecessserssensees 5
INdOOr ANTENNA ...... eee ccc cseecceessseecceesesseeseseessecssseeeeees 5
OPO AtiON es: -ncee5 eosin ee eece eet ek eS EE ewan eee alee 6
Viewing TV Programs............esceseeceseeeseeeeeeeeeseceeceeeeeeeaee 6
Listening to MTS (Multichannel TV Sound)
DIOAACASIS 5 isos. seccsesecesieccees sists ieea eeasdiceeseins hciehniveeeiels
Picture adjustMents ....00.......c ccc ccccececesssseeeceeesenseeeeeceee
Presetting Channels..........ccccceeeescseececeececeeseneeeesereeesenees
Adding Channels .........eceeeceeeccceeseessenseceseneneesseeeeneeeees
Erasing channels ..0..........cescessceeseeseeeseeeceneneceeeseeeeseees
MIMO BIOCK. sisi sontechs oocda detain hase icin tet teins. te cliisy
How to set the internal clock
How to set the program start Timer.................. ay 12
How to set the channel BIOCK ..0000...... ccc cceeceeseeeeees 13
Applications with other optional equipment ................. 14
Enjoying FM simulcasted programs...............0ccccee 14
Enjoying VCR playback... ccccccsssecesseesesstseeeseees 14
Antennalcable COnne ction ...........ccccececccceessesceceeeessaseneeees 15
SPEC fications ssc cisiksicsiheevesdsncreoateerlees back cover
TroUuDIOSNOOTING. .........ceeeecsecceeseeneeceneeeeseeeeeesnees back cover
RAGS
To prevent fire or shock hazard, do not ex-
pose the unit to rain or moisture.
oy Venlo)
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol is intended to alert the
user to the presence of uninsulated
“dangerous voltage” within the prod-
uct’s enclosure that may be of suffi-
cient magnitude to constitute a risk of
electric shock to persons.
This symbol! is intended to alert the
user to the presence of important
operating and maintenance (servicing)
instructions in the literature accompa-
nying the appliance.
CAUTION
TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS
POLARIZED AC PLUG WITH AN EXTENSION CORD,
RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES
CAN BE FULLY INSERTED TO PREVENT BLADE
EXPOSURE.

PRECAUTIONS
[sate
* Operate the set only on 120 V AC.
¢ One blade of the plug is wider than the other for the
purpose of safety and will fit into the power outlet only
one way. If you are unable to insert the plug fully into
the outlet, contact your dealer.
¢ Should any liquid or solid object fall into the cabinet,
unplug the set and have it checked by qualified person-
nel before operating it any further.
¢ Unplug the set from the wall outlet if it is not going to
be used for several days or more. To disconnect the cord,
pull it out by the plug. Never puil the cord itself.
—
Installation
* To prevent internal heat build-up, do not block the ven-
tilation openings.
* Do not install the set in a hot or humid place or in a
place subject to excessive dust or mechanical vibration.
Cleaning |
Clean the set with a slightly damp soft cloth. Use a mild
household detergent. Never use strong solvents such as
thinner or benzine as they might damage the finish of the
cabinet.
Repacking
Retain the original carton and packing materials for safe
transport of this set in the future.
Use of this television receiver for other than private view-
ing of programs broadcast on UHF or VHF or transmitted
by cable companies for the use of the genera! public may
require authorization from the broadcaster/cable company
and/or program owner.
a ETT NEES SETA A ENO CE ELIE TD
FEATURES
eee .8@
New Microblack™ Trinitron picture tube for high
resolution, high contrast picture.
Multi-band VHF/UHFICATV tuner receives up to 125 cable
channels for a total of 181 possible off-air and cable
channels.
Built-in MTS (Multichannel TV Sound) decoder enables
reception of stereo programs and SAP (Second Audio
Program) broadcasts*
Timer/Block features automatic program starting and
channel blocking.
External-audio selector enables you to receive FM
simulcasted programs with the addition of optional
equipment.
Built-in video and R/L audio input and output jacks pro-
vide direct hook-up to VCRs and other optional
equipment.
Converter (decoder) for pay cable TV can be easily con-
nected using TO CONVERTER and AUX terminals.
MONITOR OUTITV OUT selector allows for taping of
either the picture being viewed on the TV or the TV
signals.
ANT/AUX button on the remote commander permits one-
touch selection of pay cable TV when a convertor is
connected.
Jump button makes it possible to switch quickly be-
tween two channels and monitor two different programs
alternately.
Sleep timer automatically turns off the TV after one hour.
Remote Commander for convenient operation.
On-screen display
Dynamic Color™ system for superior color reproduction
with natural facial color tones and dazzling whites.
Dynamic Picture™ system, which adjusts picture con-
trast automatically to produce more detail in both bright
and dark areas of every scene.
Colorpure Filter™, which produces fine picture detail
without color spill or color noise.
Depends on the availability of off-air stereo broadcasts.

LOCATION OF CONTROLS
For further details, refer to the page numbers next to each
item.
Front
On-screen display indicates
¢ Channel numbers
e “MUTING” or “SLEEP” indi-
cations
e “VIDEO” mode
e “MAIN,” “SAP” or “BOTH”
modes
e “EXT-A” mode
« “AUX” mode
« TIMER/BLOCK settings
Bar display
Indicates picture or
sound level setting.
Press to open the panel.
POWER switch @
STEREO indicator @
TIMER indicator @
VIDEO indicator @
SLEEP indicator @
Remote control
detector @
CHANNEL +
EXT ON OFF
VIDEO AUDIC (WONG. cars SHARPHESS ERIGHT COLUM HU:
MYR o
Rear
VIDEO INPUT jack @ —
VIDEO L_____§
MONITOR OUT
VIDEO
AUDIO INPUT R/L jacks @
AUX terminal @
BRIGHT (brightness) control @
SHARPNESS
control
@
COLOR
control
@
MTS (Multichannel TV Sound) button @ HUE control @
AUTO
STEREO
selector
@
buttons
@
VIDEO EXT-AUDIO selector @ ERDSE boon:
ADD button ©
CHANNEL scan buttons @
VOLUME buttons @
TV/VIDEO button @ @
TIMER/BLOCK button @
CABLE selector @ @
VIDEO OUTPUT jack @
MONITOR OUT/TV OUT selector @
AUDIO OUTPUT RIL jacks @
——— TO CONVERTER terminal ®
VHF/UHF antenna terminal ®

SET-UP
REMOTE COMMANDER
1 Turn the Remote Commander face down, press the tab
and lift the cover.
2 Place batteries in the Commander with the polarities in
the correct directions, as illustrated inside the case.
3 Replace the cover.
Notes
e Use 2 size AA batteries (IEC designation Ré6).
¢ In normal operation, batteries will last up to half a year.
If the set does not operate properly, the batteries might
be exhausted. Replace all with new ones.
¢ To avoid damage from possible battery leakage, remove
the batteries for extended unused periods.
«Be sure that there are no obstructions between the Com-
mander and the TV.
¢ Operable range is limited.
Remote
control
detector
INDOOR ANTENNA
If your local broadcast signals are strong, attach the sup-
plied indoor antenna.
Rear of TV
Fasten with a
screwdriver.
Adjust the length, direction and angle of both elements
symmetrically until the picture is clearest.
If the supplied antenna connector has a slot as illus-
trated below:
fy,
Antenna ora
Connector 6) | Shaul he
D vertical.
I ( 300 2 )
UHF/VHF
To turn the slot, use a
coin or a similar object.

OPERATION
VIEWING TV PROGRAMS
This TV set is capable of receiving normal VHF and UHF
broadcasts plus cable TV channels. (See ‘“‘Cable TV chan-
nel chart” below.)
Usually the Remote Commander is all that is needed to
operate the TV set in everyday use.
ENTER button
SLEEP button
MUTING button
DISPLAY button
JUMP button
Channel number buttons
Buttons which are not
duplicated on the TV.
Cable TV channel chart*
Cable TV systems use letters or numbers to designate
channels. To tune in a channel, refer to this chart.
Number ‘on this Vv a
+ a tars
, Corresponding CATV channel
18
E
31
R
95
AS
Check with your local cable TV company for more com-
19
F
32
20
G
33
Ti
97
A3
21
22
35
v
"99
Ad
Bee XB
Ag AT AG
23° 24 «2256
K LM
364«37:2=«ttia wd”
Wo Wat W42 W43
“400 «101 «102
W+59 W+60 W+61 0...
14 15 16 7
A B Cc Dd
27 2880
N Oo PF Q
. 93 9d
.. W+57 W458
123. 124 126 |
W+82 W+83 W+84-
plete information on the available channels.
* The designation of the cable TV channels conforms
to the EIA/NCTA recommended standards.
Remote Commander RM-735
POWER button
Buttons used for setting
TIMER/BLOCK.
See page 10.
ANT/AUX button
This button is not duplicated on the TV.
TVNVIDEO button
MTS (Multichannel TV Sound) button
CH (channel) scan buttons
VOL (volume) buttons
PICTURE buttons

Preparation
Make sure the following are properly set.
¢ On-screen “EXT-A” indication should be off.
If not, set the EXT-AUDIO/VIDEO selector to VIDEO.
¢ On-screen “VIDEO” indication and the VIDEO in-
dicator should be off.
If not, press the TV/VIDEO button so that they
disappear.
e AUTO STEREO ON/OFF selector
Set to ON.
¢ CABLE ON/OFF selector
For cable TV channels, set to ON.
For VHF and UHF channels, set to OFF.
On-screen ‘‘AUX” indicator
(Press ANT/AUX button to change as necessary.)
For VHF, UHF and regular cable TV channels:
The indicator should be off.
For pay cable TV channels:
The indicator should be displayed.
1 Press POWER to turn on the TV.
The channel number wil! be displayed on the screen for
several seconds.
2 Select channels in one of the following two ways.
¢ Press the numeral(s) of the channel and then press
ENTER.
Ex. To select channel 6, press 6 and then ENTER.
To select channel! 125, press 1, 2, 5 and then
ENTER. ;
If you have pressed the wrong numeral. wait for a few
seconds until the channel number display has disap-
peared. Then press again.
¢ Press CH + for higher-numbered channels and —
for lower-numbered channels. The channels wil! ap-
pear in numerical sequence.
The channel number display will disappear after several
seconds. ;
To keep the display on the screen, press DISPLAY.
3 Adjust the volume and picture to your preference.
Press VOL+to increase volume, — to decrease it.
Press PICTURE +to increase picture contrast, - to
decrease it.
To switch quickly between 2 channels, press JUMP.
Each time JUMP is pressed, the channel which appeared
on the screen directly before is recalled. This button
enables you to keep track of two programs alternately.
To mute the sound, press MUTING. The “MUTING" indica-
tion will appear on the screen. To restore the sound, press
MUTING again or VOL+/-.
To turn off the set, press POWER again.
To have the TV turn off automatically after 1 hour, press
SLEEP. The “SLEEP” indication will appear on the screen
for a few seconds and the SLEEP indicator on the TV will
remain lit until the TV is turned off. To cancel the SLEEP
timer, press SLEEP again so that the SLEEP indicator goes
out, or turn off the TV.
LISTENING TO MULTICHANNEL TV SOUND
(MTS) BROADCASTS
To receive a stereo program
Normally set the AUTO STEREO selector to ON. In this
position the STEREO indicator on the TV will light whenever
a stereo broadcast is received.
To listen to the stereo sound, select the MAIN mode with
the MTS button so that the “MAIN” indication is displayed.
The stereo sound will be heard from the built-in left and
right speakers.
Every push on the MTS button changes the indication as
follows:
MAIN = SAP ———» BOTH
et
Select the appropriate mode according to various possi-
ble incoming broadcast signals.
When there is a SAP (Second Audio Program) broadcast
Select the SAP mode so that the “SAP” indication is
displayed, and only the SAP sound will be heard from both
speakers.
To listen to both MAIN and SAP broadcasts
Select the BOTH mode so that the “BOTH” indication is
displayed. The MAIN and SAP sounds will come out from
the left and right speakers respectively.
The MAIN sound becomes monaural (mixed) even when
there is a stereo broadcast, because the sound comes on-
ly from the left speaker.
Notes
¢ There may be cases of stereo broadcasts where ex-
cessive “noise” will be heard due to a weak incoming
signal. By setting the AUTO STEREO selector to OFF
and returning to monaural mode, the noise should be
eliminated.
¢ When the SAP or BOTH mode is selected and there is
no SAP broadcast, no sound is heard from the speakers
(in SAP mode) or the sound is heard only from the left
speaker (in BOTH mode).
¢ The SAP broadcast will always be transmitted with the
MAIN broadcast.

PICTURE ADJUSTMENTS
Satisfactory results will usually be obtained with the con-
trols set at the factory-preset levels. If any adjustments are
necessary, adjust the required controls as follows.
The controls are located behind the front panel.
Adjusting the picture
HUE
skin tones >
become purplish
COLOR
_for less color ra)
intensity
BRIGHT
for less ‘~e
brightness
SHARPNESS
for less roy
sharpness
skin tones
become greenish
for more color
intensity
for more
brightness
for more
sharpness

PRESETTING CHANNELS
ERASE button
ADD button
CABLE selector
CHANNEL scan buttons
Receivable channels of your set are:
VHF: 2-13
UHF: 14-69
Cable TV: 1-125
By adding and erasing channels, you can preset your TV
so that only the desired channels appear, in numerical se-
quence, when CH (CHANNEL)+/-— are pressed.
-— Preparation
1 Turn on the TV.
2 On-screen “EXT-A” indication should be off.
If not, set the EXT-AUDIO/VIDEO selector to VIDEO.
On-screen “VIDEO” indication and the VIDEO in-
dicator should be off.
If not, press the TV/VIDEO button so that they
disappear.
3 Set the CABLE ON/OFF selector according to the
channei to be added or erased.
For cable TV channels, set to ON.
For VHF and UHF channels, set to OFF.
4 Press ANT/AUX button as necessary.
* Qn-screen “AUX” indicator
For VHF. UHF and regular cable TV channels:
The indicator should be off.
For pay cable TV channels:
The indicator should be displayed.
Channel number
buttons
TV/VIDEO button
ENTER button
ADDING CHANNELS
1 Select the channel to be added by pressing the chan-
nel number buttons and ENTER button.
2 Press ADD.
A “+” indication will appear on the screen on the
left of the channel number, indicating that the chan-
nel has been added.
Repeat steps 1 and 2 for other channels to be added.
ERASING CHANNELS
1 Select the channel to be erased.
2 Press ERASE.
A “—” indication will appear on the screen on the
left of the channel number, indicating that the chan-
ne! has been erased.
Repeat steps 1 and 2 for other channels to be erased.
To add erased channels again, follow the steps for adding
channels.
Note
If you erase a VHF or UHF channel, the cable TV channel
with the same number will also be erased, and vice versa.

TIMER/BLOCK
Internal clock
Once the internal clock is set, the current time will appear
on the screen. It is necessary to set the clock correctly to
activate the program start TIMER and channel BLOCK.
Program start TIMER
Makes a program of your choice appear on the screen
automatically.
Channel BLOCK
Blocks a channel from appearing on the screen for 12
hours. Use channel BLOCK to prevent children from
watching undesirable programs.
The buttons used for setting the internal clock, program
_. start TIMER and channel BLOCK are located on the
Remote Commander.
Remote Commander
TIMER OFF/REPEAT button
Used to deactivate or
reactivate the program
start TIMER.
CLEAR button
Used to erase the time and
channel number from the
set's memory.
Notes
« All settings will be erased from the set’s memory if the
set is unplugged, or if a power failure occurs.
¢ The TIMER and BLOCK will operate only if the clock is
. set correctly.
¢ if the TIMER and BLOCK are set for overlapping times
on the same channel. the blocked channel will appear
on the screen at the time set on the TIMER.
10
TIMER/BLOCK button
Used to change the “pages.”
See next page.
This button and the TIMER/
BLOCK button on the TV are
operated in the same way.
AMIPM button
Each time this button is
pressed, the on-screen
“AM” and “PM” indications
will appear alternately.

‘To set the internal clock, program start TIMER and chan-
_ nel BLOCK, you must summon the corresponding “pages”:
“clock page,” “TIMER page” and “BLOCK page.”
To change the “pages,” press the TIMER/BLOCK button
as illustrated below.
The illustration shows how to change the “pages” after
the clock has been set.
[T/B} stands for “Press the TIMER/BLOCK button.”
seo
T/B
|
8:00am | 9:00
“normal
page”
“clock
page”
“clock
page”
tie “AM"?/“PM”
9 seconds —— | indication
| disappears
before “AM’/“PM”
T/B
ue indication disappears
8:00am
“BLOCK
page”
“TIMER
page”
(indications
in
red)
11

HOW TO SET THE INTERNAL CLOCK
Ex. To set the clock to 8:05 PM, follow the steps below.
1 Press TIMER/BLOCK once to change from “normal
page” to “clock page.”
“clock page”
ek eiam
“2 Press 0, 8, 0,5, AM/PM (0 necessary).
3 If you have made a mistake, press CLEAR and return
to step 2.
lf you have performed the operation correctly, press
ENTER.
The numbers will “wink” to indicate that the clock has
been set.
(The 0 in front will disappear.)
8:05pm
The
“AM’/“PM”
indication
will
disappear
after
2
seconds.
To
summon
“TIMER
page,”
press
TIMER/BLOCK
before
the
“AM’/“PM” indication disappears.
To
return
to
‘normal
page,”
press
TIMER/BLOCK
after
the
“AM”’/“PM” indication has disappeared.
To
reset
the
clock,
summon
“clock
page”
and
press
CLEAR
before
the
“AM’/‘PM”
indication
disappears.
Then
follow
the
steps
above
from
step
2.
Note
12:00 AM stands for midnight.
12:00 PM stands for noon.
12
HOW TO SET THE PROGRAM START TIMER
Make sure that the clock has been set correctly before set-
ting the program start TIMER.
Ex. To set the TIMER for a program which begins at 10:30
PM on channel 12, follow the steps below.
1 Press TIMER/BLOCK once to change from “normal page”
to “clock page.”
“clock page”
2 Press TIMER/BLOCK before the “AM”/“PM” indication
disappears and summon “TIMER page.”
“TIMER page”
3 Press 1, 0, 3, 0, AM/PM, ENTER.
Numbers will “wink” to indicate that the time has been
set.
10:30pm
=CH.
8:0Sem
4 Press 1, 2, ENTER (0 not necessary).
Numbers will “wink” to indicate that the channel has
been set.
10: 30em
See
The TIMER indicator will light up to indicate that the
TIMER has been set.
If you have made a mistake, press CLEAR and return to
step 3.

At the preset time, the selected channel will appear on the
screen and the TIMER indicator will go out. The TIMER will
operate whether you are watching a TV program or a VCR
playback, or even if you have turned off the TV.
\f no button* is pressed within 2 hours after the preset time,
an “OFF” indication will appear on the screen for 1 minute.
If a button” is still not touched during the 1 minute, the TV
will turn off automatically as a safety precaution.
* AUTO STEREO selector and HUE, COLOR, BRIGHT and
SHARPNESS controls excepted.
The TIMER operates only once, but the time and the chan-
fel will remain in the set’s memory.
If, at a future date, you want to see the same channel at
the same time, press TIMER OFF/REPEAT. The TIMER in-
dicator will light up to indicate that the TIMER has been
reactivated.
lf you want to deactivate the TIMER, press TIMER
OFF/REPEAT again so that the TIMER indicator goes out.
It is not necessary to summon “TIMER page” to use the
TIMER OFF/REPEAT button. Furthermore, this button is ef-
fective even if the TV has been turned off.
To clear the TIMER setting, summon “TIMER page” and
press CLEAR.
To reset, clear the setting and follow the steps on the
previous page from step 3.
HOW TO SET THE CHANNEL BLOCK
Make sure that the clock has been set correctly before set-
ting the channel BLOCK.
Ex. To set the BLOCK for a program which begins at 9:30
AM on channel 8, follow the steps below.
1 Press TIMER/BLOCK three times to change from “nor-
mai page” to “BLOCK page.”
“BLOCK page”
(indications in red)
8:05pm
2 Press 0, 9, 3, 0, ENTER (0 necessary).
Numbers will “wink” to indicate that the time has been
set.
Press 8, ENTER (0 not necessary).
Number will “wink” to indicate that the channel has
been set.
Press the ANT/AUX button to check which channel you
have selected. To select a pay cable TV channel, press
the ANT/AUX button until on-screen “AUX” indicator ap-
pears for a few seconds.
The BLOCK has now been set.
If you have made a mistake, press CLEAR and return
to step 2.
At the preset time, the picture of the selected channel will
be blocked from view and the sound will be muted.
A red “BLOCKED” indication will appear on the screen
while the channel is blocked.
Normal reception will be resumed after 12 hours.
To return to normal reception while the channel is block-
ed, recall “BLOCK page” and press CLEAR.
The BLOCK setting blocks a specified channel for the same
12-hour period everyday.
To clear the BLOCK setting, summon “BLOCK page” and
press CLEAR.
To reset, clear the setting and follow the steps above from
step 2.
13

fo ot oat niet rhe
_ APPLICATIONS WITH OTHER
OPTIONAL EQUIPMENT
ENJOYING
FM
SIMULCASTED
PROGRAMS
By connecting an FM stereo tuner to the AUDIO INPUT
jacks in addition to the usual CATV cable connection, you
can enjoy certain cable TV programs with stereo sound,
such as MTV (music television), whose stereo audio signals
are sent over the cable on certain FM frequencies. The in-
coming cable signal is split by an optional signal splitter
and fed to both the TV tuner (for picture) and an FM tuner
(for sound).
CATV 75-ohm
coaxial cable
<<-2 Signal flow
Set to
MONITOR
Signa! splitter
to VHF/
UHF
antenna
input
cn
to line output
Amplifier
Afto line
iS SVEST SES TSM, \\finput
AUX TO CONVERTER
RK-74A (optional)
to AUDIO INPUT
(~~ Preparation
1 Turn on the TV.
2 Set the EXT-AUDIO/VIDEO selector to EXT-AUDIO.
3 Press the TV/VIDEO button so that the “EXT-A” in-
dication appears on the screen for a few seconds.
4 Set the CABLE ON/OFF selector to ON.
Depending on the channe! to be viewed. the on-
screen “AUX” indicator shiouis be as follows:
(Press ANT/AUX button to change as necessary.) !
For regular cable TV channels:
The indicator should be off.
For pay cable TV channels:
The indicator should be displayed
5 Operate the TV the same as in usual TV viewing.
Note
If the EXT-AUDIO/VIDEO selector is set to EXT-AUDIO and
no sound source is connected to the AUDIO INPUT jacks,
no sound is heard.
14
ENJOYING VCR PLAYBACK
You can achieve better picture and sound quality by con-
necting a VCR to your TV using the direct audio R/L and
video jacks rather than using an RF connection to the
antenna terminal. With this connection, you don’t have to
select channel 3 or 4 to view VCR playback.
| ONO (=>
AUDIO AUDIO
ir (<p |
oF)
srt VIDEO OUTPUT}
AUX 10 CONVERTEH
Cae
to VIDEO INPUT
to AUDIO INPUT
VMC-2P3 (optional)
Preparation
1 Turn on the TV.
2 Set the EXT-AUDIO/VIDEO selector to VIDEO.
3 Press the TV/VIDEO button so that the “VIDEO”
indication appears on the screen and the VIDEO
indicator lights up.
For operation, refer to the instruction manual furnished with
the VCR.
You can select the desired TV channel even while viewing
a VCR playback or listening to the sound fed in through
the AUDIO INPUT jacks.
When the VCR is only equipped with one monaural audio
output jack
Connect the audio output of the VCR to the AUDIO [INPUT
L. (mono) jack. The monaurai sound will be heard through
both speakers. !f it is connected to the AUDIO INPUT R
jack. the sound will only be heard from tne right speaker.
Notes
¢ If you have connected a VCR to your TV using only an
RF connection, and cannot obtain a clear picture and/or
sound, the following procedures may solve the problem.
1 Make sure that the TV/VTR (program select) button
on the VCR is set to TV.
2 Re-select the desired channel with the buttons on the
TV or TV Remote Commander.
* Keep the VCR away from the TV. if the picture or sound
is affected.

ANTENNAICABLE CONNECTION
If you cannot obtain satisfactory reception with an indoor
antenna, using an outdoor antenna may be necessary.
Cable TV reception is only possible by connecting a cable
supplied by your local cable operator.
1 Remove the indoor antenna from the antenna terminal
of the TV.
2 Prepare the antenna or cable end using the appropriate
connector, and connect the antenna or cable to the
antenna terminal of the TV. (See A or B below.)
A | Combination VHF/UHF antenna*, VHF antenna, UHF
antenna or CATV cable
Select the proper connector according to the cable type.
When the cable is a 75-ohm When the cable is a 300-
coaxial
type
(round)
ohm
ribbon
type
lead-in
(flat)
a Pts
©
<<
Use an optional F-type Attach the antenna connec-
connector. tor.
Rear of TV
VHF/UHF
Antenna connector}
«Most combination antennas are equipped with a signal
splitter. Take off the splitter and attach the proper
connector.
B [ When both VHF and UHF antennas are connected |
Prepare the VHF antenna end using the appropriate con-
nector as illustrated in A.
Attach an optional EAC-66 U/V mixer to the TV antenna ter-
minal, and connect the cables to the U/V mixer.
UHF
Rear of TV VHF/UHF
0
When the cable is connected to the TV with the U/V mix-
er, snow and noise may appear in the pictures of the cable
TV channels over 37 (W +1).
Note to CATV system installer in the U.S.A.:
This reminder is provided to call the CATV system in-
staller’s attention to Article 820-22 of the NEC that provides
guidelines for proper grounding and, in particular, specifies
that the cable ground shall be connected to the grounding
system of the building, as close to the point of cable en-
try as practical.
Cc [ Cable with a special converter (decoder)
Pay cable TV systems use scrambled or encoded signals
and require special converters (decoders)* in addition to
the normal cable connection. Connect the converter
(decoder) with a 75-ohm coaxial cable (optional).
AUX
Output
Special
converter
Pay TV
Cable (decoder)
~The special converter (decoder) will be supplied by the
cable company.
lf the supplied antenna connector has a slot as illus-
trated below:
The antenna connector can be used also as a U/V mixer.
When connecting both 75-ohm VHF and 300-ohm UHF
antennas, or 300-ohm UHF antenna only;
LT
Antenna |
Connector — Should be Horizontal.
ome Q UH )
75 Q VHF
To turn the slot, use a coin or a similar object.
15

SPECIFICATIONS
Television system
Channel coverage
Picture tube
Input
Output
American TV standards
VHF: 2-13
UHF: 14-69
Cable TV: 1-125
Microblack Trinitron tube
20-inch picture measured
diagonally
21-inch picture tube measured
diagonally
Audio R/L
phono jack, 408 mVrms (100%
modulation), more than 47 k ohms
Video
phono jack, 1 Vp-p, 75 ohms,
unbalanced, sync negative
Audio R/L
phono jack, 408 mVrms (100%
modulation), more than 47 k ohms
Video
phono jack, 1 Vp-p, 75 ohms, un-
balanced sync negative
Power requirements 120 V AC, 60 Hz
Power consumption 130 W (max.)
6 W (in standby condition)
Accessories supplied
Remote Commander RM-735
with 2 size AA batteries
Telescopic dipole antenna
Antenna connector
Optional accessories
Connecting cord RK-74A
VMC-2P3
Design and specifications are subject to change
without notice.
Sony Corporation
Printed in Japan
TROUBLESHOOTING
Disturbances in picture and sound can often be eliminated
by checking the symptoms and foilowing the suggestions
listed below.
SYMPTOM CHECK AND ADJUST
GENERAL
Poor or no picture
(screen not lit),
good sound
Good picture,
no sound
No picture (screen
not lit), no sound
No color
¢ Adjust PICTURE.
e Adjust BRIGHT.
¢ Check antenna/cable
connections.
¢ Press VOLUME +.
« Release MUTING on
the Remote
Commander.
e Check the EXT-
AUDIO/VIDEO selec-
tor setting.
¢ Check that the MTS
button is set
correctly.
e Is POWER switched
on?
Power in outlet?
e Check that the TV/
VIDEO button is set
correctly.
Is it a color program?
Snow and noise
only
bleZadeaitie wy Dotted
| ot _ lines
| sas :
SS Lor
} a > stripes
¢ Is it an active or the
correct channel?
¢ Check the CABLE
switch setting.
¢ Check antenna
connections.
This is often caused by
local interference.
(Ex. cars, neon signs,
hairdryers etc.) Adjust
antenna for minimum
interference.
— Double | often cause this
#i if @ images | problem.
= or A highly directional
i ghosts | outdoor antenna or
-—a- SS CATV
cable may improve the
i picture.
Reflections from
nearby
mountains or buildings
Try another channel. It could be station trouble.
TIMER/BLOCK
Program start
TIMER
and/or channel
BLOCK
does not operate
properly.
e Is the clock set
correctly?
e Is the setting
correct?
¢ Have you unplugged
the
set?
Has a power failure
occurred?
If so, the settings
will
have been erased.
If the problem still cannot be solved, contact your
nearest service facility.
4-482-191-23 (2)
