Selecting the Conversion Mode of
the Effective Scanning Line Number
(when HKDV-502 is installed)
When the optional HKDV-502 HD Line Converter
Board is installed in the HDW-500, to select the
conversion mode, follow the procedure below.
1Press the MAINTENANCE switch using the tip of
a small pointed object.
2Press the [F8](MAINTE EXEC) button while
holding down the SFT button.
3Press the [F9](OTHERS CHECK) button.
4Press the [F9](SYSTEM MENU) button.
5Press the [F1](ACTIVE LINE) button to select the
conversion mode.
Pressing the button cycles the settings from 1035,
1080, off. off is used to activate the function to
improve the vertical resolution during slow-motion
playback.
1035: Convert the effective scanning line number
from 1080 to 1035.
1080: Convert the effective scanning line number
from 1035 to 1080.
6Press the [F9](EXEC).
A message asking you to confirm the operation
appears in the display.
To cancel the excusion
Press the [F8](CANCEL) button.
7Press the [F9](EXEC).
The HDW-500 is restarted automatically.
8Press the SET UP button.
The VTR SETUP menu appears in the display.
