Sony ICD-SX733 User manual

Feature packed the ICD-SX733 delivers. Combining exibility and capability
with convenience for musicians, business people and students the
ICDSX733 oers: a 3-element stereo microphone, LPCM and MP3 Record
modes, Memory Card Slot, Manual/Automatic Level Control, Intelligent
Noise Cut circuitry, the ICD-SX733 oers powerful recording capability in the
palm of your hand.
Premium Recording
Introducing the ideal digital voice recorder for business and music recording, delivering
Sony’slegendary ease of use with superior recording and audio playback capability.
Built-in 4 GB ash memory1
4 GB of available internal ash memory provides ample space for recording life’s important
moments-up to 159 hours in fact.1
3 Element Microphone
Capture every nuance, distant or low volume, with greater clarity via a 3-element microphone
array featuring adjustable sensitivity and zoom functionality.
Dual AD Convertors
Dual analog to digital converters work in tandem to deliver wider dynamic range with minimized
distortion. The result is smoother/fuller sounding recordings that capture everything from the
quietest whisper to the loudest noise in the room and all things in between.
Memory Card Expansion Slot
A built-in Memory Card Expansion Slot (microSD/M2) allows for additional recording time via
removable ash memory. It can also be used to transfer recordings to a computer. Thanks to the
cross-memory recording feature, the recorder can automatically extend a recording from the
built-in ash memory to the micro SD card without interruption.
Pre-Record Mode
Pre-Record mode, when activated, buers sound for ve seconds prior to the moment when the
Record key is depressed so you never miss a word or note.
Playback convenience-Key Control
With Key Control, playback speed can be adjusted from 0.25 times to 3.00 times in natural tones
by
means of a digital processing function. You can even adjust playback in semitones higher or
lower, each in 6 steps.
Playback convenience-Voice Up
When activated, the Voice Up function amplies low volume sounds so that distant voices and
other sounds can be heard.
USB-Direct PC and Mac® compatibility2
A convenient retractable USB terminal enables direct connectivity and charging with both
Windows® and Macintosh® computers.2
Lithium-Ion battery
A built-in rechargeable battery delivers up to 19 hours of recording time so you will never miss a
beat.3
Specications
Audio
ICD-SX733 Digital Flash Voice Recorder

Format(s)
Supported
Recording -
MP3 les:
Bit Rate: 48 kbps - 320 kbps, VBR
Sampling Frequencies: 16/22.05/24/32/44.1/48 kHz
File Extension: .mp3
PCM les:
Bit Rate: 16 bit
Sampling Frequencies: 44.1 kHz
File Extension: .wav
Playback -
MP3/AAC/WMA/WAV
Frequency Range
LPCM 44/16: 40 - 20,000 Hz
MP3 320k: 40 - 20,000 Hz
MP3 192k: 40 - 18,000 Hz
MP3 128k: 40 - 16,000 Hz
MP3 48k (Mono): 40 - 14,000 Hz
Microphone Built-in, 3-Element S-Mic microphone
Recording System Digital Stereo, Monaural Recording
Audio Features
Microphone
Sensitivity Feature Yes (Auto & Manual SENS Settings with Limiter functionality)
Recording
Features 5 Modes: Linear PCM / MP3 320kbps / MP3 192kbps / MP3 128kbps / MP3 48kbps (Mono)
Convenience
Message Folder(s)
5 Pre-Programmed at factory (400 Maximum)
199 Maximum les per folder
4074 Maximum les
Convenience Features
Erase/Protect Yes
Message Folder(s) Yes (400 Folders maximum)
On-Screen Clock Yes, with Calendar
Remote Control No
Safety Lock Yes (Hold Function)
Search Features Cue/Review, Easy Search, Calendar Search, Track Mark
Voice E-Mail
Function Yes
General
Recording and
Playback Times
Linear PCM (44 kHz/16 bit): 5 hrs 20 min; Max 19 hrs
battery
MP3 (192 kbps): 39 hrs 45 min; Max 17 hrs battery life
MP3 (48 kbps MONO): Max 159 hrs; Max 19 hrs
Recording Media Built-In Flash Memory 4GB³ and Memory Card
Expansion Slot (microSD/M2)
Type of Use Ultra Portable Voice Recorder
Hardware
Display Full Function backlit (LED) LCD Display with recording
operation indicator
Inputs and Outputs
Headphone
Output(s) 1 (Minijack, Stereo)
Microphone Input 1 (Minijack, Stereo)
USB Port(s) 1 (Type-A jack), High-Speed USB Compatible
Memory
Memory Size 4 GB = 4,294,967,296 bytes
Available: 3.2 GB (3,435,973,837 bytes)
Power

1. 1 GB equals 1073741824 bytes, a portion of which is used for data management
functions. Actual storage capacity may vary based on product settings, usage patterns,
operating environment and battery condition.
2. 64 Bit Windows Vista® compatible with optional DVE 3.2. (Need to revise)
3. Actual battery life will vary based on network, product settings, usage patterns, battery,
and environmental conditions.
© 2013 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without
written permission is prohibited. Sony is a trademark of Sony. Windows® is a registered
trademark of Microso Corporation in the United States and/or other countries.
Macintosh® and Mac® are registered trademarks of Apple, Inc. Dragon Naturally
Speaking® is a registered trademark of Nuance Communications, Inc. All other trademarks
are trademarks of their respective owners. Features and specications are subject to
change without notice. Non-metric weights and measures are approximate and may vary.
/Updated: April 3, 2013
Battery Life
(Approx) Up to 19 hours
Battery Type Rechargeable Lithium
Output Power 150 mW
Soware
Operating System
Compatibility
Windows® 8 Windows® 7 SP1 or higher, Windows Vista®
SP 2 or higher, Windows XP SP3 or higher
Mac OS X (v10.3.9-v10.8), pre-installed
Supplied Soware Application Soware, Sound Organizer (On unit) compatible with: Windows® 8, Windows 7, Windows
Vista® SP 2 or higher, Windows XP SP3 or higher
Speaker
Speaker
Dimensions Approx. 0.4 x 0.2 in. (10 x 6 mm) diameter
Weights and Measurements
Dimensions
(Approx.) Approx. 1.6 × 4.3 × 0.6 in. (39.5 x 110.8 x 14.6 mm) not including projecting parts and controls
Weight (Approx.) Approx. 2 5/8 oz. (82 g)
Accessories
Supplied
Accessories
IC Recorder (1)
Application Soware, Sound Organizer (On unit) (1)
USB connection support cable (1)
Stereo headphones (1)
Carrying Case (1)
Stand (1)
Quick Start Guide (1)
Optional Accessories
Optional
Accessories
Memory Stick Micro™ (M2™): MS-A16GU2, MS-A8GU2,
MS-A4GU2, MS-A2GU2
microSD/microSDH: SR-8A4, SR-4A4, SR-2A1
