Sony ICD-UX533 User manual

Featuring enhanced MP3 and Linear PCM recording features with 4 GB1
internal memory, the UX533 recorder is perfect for capturing music and
meeting notes. An expandable microSD memory card slot is perfect for
additional capacity. While the direct connect USB makes for easy le
transfer in addition to charging the rechargeable battery .
All around recording
Introducing the ideal digital voice recorder for business, school, and/or music recording,
delivering Sony’s legendary ease of use with superior recording and audio playback capability.
Built-in 4 GB ash memory1
4 GB of available internal ash memory provides ample space for recording life’s important
moments-up to 1,073 hours in fact.1
Stereo S- Microphone
Capture every nuance, distant or low volume, with great clarity via a
2-element stereo microphone array.
Memory Card Expansion Slot
A built-in Memory Card Expansion Slot (microSD/M2) allows for additional recording time via
removable ash memory. It can also be used to transfer recordings to a computer.
Automatic/Manual Record level
The recorder can be congured to automatically adjust recording levels for optimum results, or
when necessary allow for manual control. In manual mode, a Limiter Function prevents recording
distortion from loud sounds.
Sync-Record Mode
Quickly and easily record from various audio devices with Sync-Record. When activated, press
Play on the audio source and the recorder, sensing a signal will begin recording.
MP3 Playback with Graphic Equalizer4
More than just a digital voice recorder, the UX533 supports MP3/WMA/AAC playback with a ve-
band EQ.4
Calendar Search
Easily search for recordings by date. When in use, a calendar displays, indicating the dates when
recordings were made.
Bright White LCD Backlight
Enjoyed enhanced visibility day or night thanks to a bright white LCD backlight.
USB-Direct PC and Mac® compatibility
Transfer les quickly without searching for a USB connection cable. With direct connect, simply
connect the recorder to a PC or Mac® USB input.2
AAA Battery
The supplied, rechargeable NiMH AAA battery delivers up to 30 hours of recording time so you
will never miss a beat.3
Specications
Audio
ICD-UX533

Format(s)
Supported
Recording -
MP3 les:
Bit Rate: 8 kbps - 192 kbps, VBR
Sampling Frequencies: 16/22.05/24/32/44.1/48 kHz
File Extension: .mp3
PCM les:
Bit Rate: 16 bit
Sampling Frequencies: 44.1 kHz
File Extension: .wav
Playback -
MP3/AAC/WMA/WAV
Frequency Range
LPCM 44/16: 50 - 20,000 Hz
MP3 192k: 50 - 18,000 Hz
MP3 128k: 50 - 16,000 Hz
MP3 48k (Mono): 50 - 14,000 Hz
MP3 8k (Mono): 60 - 3,400 Hz
Microphone Built-in, Stereo S-Mic Microphone
Recording System Digital Stereo, Monaural Recording
Audio Features
Microphone
Sensitivity Feature Yes (Hi/Med/Lo)
Recording
Features 6 Modes: Linear PCM / MP3 320kbps / MP3 192kbps / MP3 128kbps / MP3 48kbps (Mono) / MP3 8kbps (Mono)
Convenience
Message Folder(s)
5 Pre-Programmed at factory (400 Maximum)
199 Maximum les per folder
4074 Maximum les
Convenience Features
Erase/Protect Yes
Message Folder(s) Yes (400 Folders maximum)
On-Screen Clock Yes
Safety Lock Yes (Hold Function)
Search Features Cue/Review, Easy Search, Track Mark
Voice E-Mail
Function Yes
General
Recording and
Playback Times
Linear PCM (16 bit): 6 hrs; Max 22 hrs battery
MP3 (192 kbps): 44 hrs 40 min; Max 24 hrs battery life
MP3 (128 kbps): 67 hrs 5 min; Max 24 hrs battery life
MP3 (48 kbps MONO): Max 178 hrs; Max 25 hrs
MP3 (8 kbps MONO): Max 1073 hrs; Max 30 hrs
Recording Media Built-In Flash Memory 4GB³ and Memory Card
Expansion Slot (microSD)
Type of Use Ultra Portable Voice Recorder
Hardware
Display Full Function backlit LCD Display with recording
operation indicator
Inputs and Outputs
Headphone
Output(s) 1 (Minijack, Stereo)
Microphone Input 1 (Minijack, Stereo)
USB Port(s) 1 (Type-A jack), High-Speed USB Compatible
Memory
Memory Size 4 GB = 4,294,967,296 bytes
Available: 3.6 GB (3,865,470,566 bytes)
Power

1. 1 GB equals 1073741824 bytes, a portion of which is used for data management
functions. Actual storage capacity may vary based on product settings, usage patterns,
operating environment and battery condition.
2. 64 Bit Windows Vista® compatible with optional DVE 3.2. (Need to update)
3. Actual battery life will vary based on network, product settings, usage patterns, battery,
and environmental conditions.
4. Not all WMA, WAV and MP3 les may play back due to le variations. Playback depends
on recording conditions.
© 2013 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without
written permission is prohibited. Sony and the Sony make.believe logo are trademarks
of Sony. Windows® is a registered trademark of Microso Corporation in the United
States and/or other countries. Mac® is a registered trademark of Apple, Inc. All other
trademarks are trademarks of their respective owners. Features and specications are
subject to change without notice. Non-metric weights and measures are approximate and
may vary. /Updated: April 3, 2013
Battery Life
(Approx) Up to 30 hours
Battery Type Rechargeable MiMH "AAA" x 1 (supplied)
Output Power 90 mW
Power
Requirements
One LR03 (size AAA) alkaline battery: 1.5 V DC
One NH-AAA rechargeable battery: 1.2 V DC
Soware
Operating System
Compatibility
Windows® 8 Windows® 7 SP1 or higher, Windows Vista®
SP 2 or higher, Windows XP SP3 or higher
Mac OS X (v10.3.9-v10.8), pre-installed
Supplied Soware Application Soware, Sound Organizer (On unit) compatible with: Windows® 8, Windows 7, Windows
Vista® SP 2 or higher, Windows XP SP3 or higher
Speaker
Speaker
Dimensions Approx. 13/16 in. (20 mm) diameter
Weights and Measurements
Dimensions
(Approx.) Approx. 1.6 × 4.3 × 0.6 in. (36.6 x 102.0 x 13.9 mm) not including projecting parts and controls
Weight (Approx.) Approx. 2 5/8 oz. (58 g)
Accessories
Supplied
Accessories
IC Recorder (1)
Application Soware, Sound Organizer (On unit) (1)
USB connection support cable (1)
Stereo Headphones (1)
Carrying Case* (1)
Stand (1)
Quick Start Guide (1)
* The carrying case and the stand are provided
together as an accessory.
Optional Accessories
Optional
Accessories microSD/microSDH: SR-8A4, SR-4A4, SR-2A1
