Soojee ZJ-BG7001 User manual

SMART TOILET SEAT
PRODUCT INSTRUCTION

BRIEFINTRODUCTION
Intelligent toilet seat has the functions of hip cleaning ,lady cleaning ,reciprocating cleaning ,seat
heating ,warm air ,damping buffer ,seat sensor ,massage function ,nozzle cleaning ,nozzle position
adjustment , water temperature adjustment and so on . The product has a good physical therapy
for patients who suffer from hemorrhoids, anus inflammation etc.
CONSIDERATE REMIND
1.Please connect the water-inlet hose in advance. Then under the situation of completely open the
water-inlet horn valve, connect the supply power, otherwise the toilet seat will damage.
2.The sensor is installed inside the toilet seat .If no one use it, the system will quit the washing and
drying mode.
model can be used under the condition of both power 220V50Hz and 110V60Hz
“BG”model can be used under the condition of power 220V50Hz only
ZJ-BG7001 ZJ-BG8381 ZJ-BS8381 ZJ-BG8386 ZJ-BS8386 ZJ-BG8361 ZJ-BS8361 ZJ-BG831 ZJ-BS831
Rear Cleaning ●●●●●●●●●
Front Cleaning ●●●●●●●●●
Reciprocating Cleaning ●●●●●●●●●
Spiral Cleaning ●
Massage Cleaning ●●●●●●●●●
Seat Heating ●●●●●●●●●
Seat Temp Adjustment ●●●●●●●●●
Warm Air ●●●●●●●●●
Warm Air Adjustment ●●●●●●●●●
Self-cleaning Nozzle ●●●●●●●●●
Nozzle Position Adjustment ●●●●●●●●●
Water Temp Adjustment ●●●●●●●●●
Water Pressure Adjustment ●●●●●●●●●
Seat Sensor ●●●●●●●●●
Button Control ●●●●●●●●●
Energy Saving ●●●●●●●●●
Damping Buffer ●●●●●●●●●
Remote Controller ●
Constant Temp Cleaning ●●●●●
Auto Deodorization ●
Model
Function
ZJ-BG7022 ZJ-BG8022 ZJ-BS8022 ZJ-BG827 ZJ-BS827 ZJ-BG827D ZJ-BS827D ZJ-S901A
Rear Cleaning ●●●●●●●
Front Cleaning ●●●●●●●
Reciprocating Cleaning ●●●●●●●
Spiral Cleaning
Massage Cleaning ●●●●●●●
Seat Heating ●●●●●●●●
Seat Temp Adjustment ●●●●●●●
Warm Air ●●●●●●●
Warm Air Adjustment ●●●●●●●
Self-cleaning Nozzle ●●●●●●●
Nozzle Position Adjustment ●●●●●●●
Water Temp Adjustment ●●●●●●●
Water Pressure Adjustment ●●●●●●●
Seat Sensor ●●●●●●●
Button Control ●●●●●●●
Energy Saving ●●●●●●●
Damping Buffer ●●●●●●●
Remote Controller
Constant Temp Cleaning ● ● ● ●
Auto Deodorization
Model
Function
“BS”

DEMENSION
373
385
505
145
503
32
130-210
157
348
295
212
428
468
ZJ-BG7001
200
125-185
30-35
389
459
279
65 160
293
507
ZJ-BG8381/ZJ-BS8381
200
125-185
30-35
389 160
507
293
ZJ-BG8386/ZJ-BS8386

DEMENSION
200
125-185
30-35
389
459
279
160
293
507
ZJ-BG8361/ZJ-BS8361
460
389
507
165
125-185
30-55
296
199
45
ZJ-BG831/ZJ-BS831
142
506
296
199
125-185
30-55
450
379
45
ZJ-BG7022

DEMENSION
444
378
505
30-55
303
45
200
136 125-185
197
ZJ-BG8022/ZJ-BS8022
447
382
379
505
136
30-55
125-185
296
45
199
ZJ-BG827/ZJ-BS827
447
382
379
475
136
30-55
296
45
199
125-185
ZJ-BG827D/ZJ-BS827D

DEMENSION
308
30-158
212
65
501
470
370
ZJ-S901A

TECHNICAL PARAMETERS
Model
ZJ-BG7001
Voltage/Frequency
AC220V 50Hz
Rated Input Power
920W
Length of Supply cable
1.5m
Safety Device
Leakage Protector(Operating Current=10mA)
Applicable Water pressure
0.1~0.75MPa
Dimension
505*373*145mm
Input water temperature
>1℃<40℃
Cleaning device
Water flow capacity
0.6~1.1L/min
Water heating power
600w
Water temperature adjustment
Four levels (Normal temperature about 40℃)
Safety device
Water temperature sensor system :45℃to 50℃
Temperature protector ,Anti-Dry protector .
Seat warm device
Seat heating power
45w
Seat temperature adjustment
Four levels (Normal temperature about40 ℃)
Safety Device
Heating protection 77 ℃
Damping device
Both cover and seat have damping device
Warm Air Drying
Warm air Power
190w
Warm air temperature
Four levels (Normal temperature about60 ℃)
Safety Device
Double heating protection 95 ℃/150℃
Model
ZJ-BG8381/ZJ-BS8381
ZJ-BG8386/ZJ-BS8386
Voltage/Frequency
AC220V 50Hz /110V 60Hz
Rated Input Power
1320W(BG)/1050W(BS)
Length of Supply cable
1.5m
Safety Device
Leakage Protector(Operating Current=10mA)
Applicable Water pressure
0.1~0.75MPa
Dimension
507*369*160mm
Input water temperature
>1℃<40℃
Cleaning device
Water flow capacity
0.6~1.1L/min
Water heating power
600w
Water temperature adjustment
Four levels (Normal temperature about 40℃)
Safety device
Water temperature sensor system :45℃to 50℃
Temperature protector ,Anti-Dry protector .
Seat warm device
Seat heating power
45w
Seat temperature adjustment
Four levels (Normal temperature about40 ℃)
Safety Device
Heating protection 77 ℃
Damping device
Both cover and seat have damping device
Warm Air Drying
Warm air Power
190w
Warm air temperature
Four levels (Normal temperature about60 ℃)
Safety Device
Double heating protection 95 ℃/150℃

TECHNICAL PARAMETERS
Model
ZJ-BS8361/BG8361
ZJ-BS831/BG831
Voltage/Frequency
AC220V 50Hz /110V 60Hz
Rated Input Power
1320W(BG)/1050W(BS)
Length of Supply cable
1.5m
Safety Device
Leakage Protector(Operating Current=10mA)
Applicable Water pressure
0.1~0.75MPa
Dimension
507*389*160mm
Input water temperature
>1℃<40℃
Cleaning device
Water flow capacity
0.6~1.1L/min
Water heating power
600w
Water temperature adjustment
Four levels (Normal temperature about 40℃)
Safety device
Water temperature sensor system :45℃to 50℃
Temperature protector ,Anti-Dry protector .
Seat warm device
Seat heating power
45w
Seat temperature adjustment
Four levels (Normal temperature about40 ℃)
Safety Device
Heating protection 77 ℃
Damping device
Both cover and seat have damping device
Warm Air Drying
Warm air Power
190w
Warm air temperature
Four levels (Normal temperature about60 ℃)
Safety Device
Double heating protection 95 ℃/150℃
Model
ZJ-BG7022
Voltage/Frequency
AC220V 50Hz
Rated Input Power
1320W
Length of Supply cable
1.5m
Safety Device
Leakage Protector(Operating Current=10mA)
Applicable Water pressure
0.1~0.75MPa
Dimension
506*379*142mm
Input water temperature
>3℃<40℃
Cleaning device
Water flow capacity
0.6~1.1L/min
Water heating power
0-1600w
Water temperature adjustment
Four levels (Normal temperature about 40℃)
Safety device
Water temperature sensor system : 50℃
Temperature protector ,Anti-Dry protector .
Seat warm device
Seat heating power
45w
Seat temperature adjustment
Four levels (Normal temperature about40 ℃)
Safety Device
Heating protection 77 ℃
Damping device
Both cover and seat have damping device
Warm Air Drying
Warm air Power
190w
Warm air temperature
Four levels (Normal temperature about60 ℃)
Safety Device
Double heating protection 95 ℃/150℃

TECHNICAL PARAMETERS
Model
ZJ-BG827/ZJ-BS827
Voltage/Frequency AC220V 50Hz AC110V 60Hz
Rated Input Power 1320W (BG) 1050W (BS)
Length of Supply cable 1.5m
Safety Device Leakage Protector(Operating Current=10mA)
Applicable Water pressure 0.1~0.75MPa
Dimension 505*382*136mm
Input water temperature >3℃<40℃
Cleaning device
Water flow capacity 0.6~1.1L/min
Water heating power 0-1600w
Water temperature adjustment
Four levels (Normal temperature about 40
℃
)
Safety device
Water temperature sensor system : 50
℃
Temperature protector ,Anti-Dry protector .
Seat warm device
Seat heating power 45w
Seat temperature adjustment
Four levels (Normal temperature about40
℃
)
Safety Device
Heating protection 77
℃
Damping device Both cover and seat have damping device
Warm Air Drying
Warm air Power
190w
Warm air temperature
Four levels (Normal temperature about60
℃
)
Safety Device
Double heating protection 95
℃
/150
℃
Model ZJ-BG8022/ZJ-BS8022
Voltage/Frequency
AC220V 50Hz/AC110V 60Hz
Rated Input Power
1320W (BG) 1050W (BS)
Length of Supply cable
1.5m
Safety Device
Leakage Protector(Operating Current=10mA)
Applicable Water pressure
0.1~0.75MPa
Dimension
505*378*136mm
Input water temperature
>3
℃
<40
℃
Cleaning device
Water flow capacity
0.6~1.1L/min
Water heating power 0-1600w
Water temperature adjustment Four levels (Normal temperature about 40℃)
Safety device Water temperature sensor system : 50℃
Temperature protector ,Anti-Dry protector .
Seat warm device
Seat heating power 45w
Seat temperature adjustment Four levels (Normal temperature about40 ℃)
Safety Device Heating protection 77 ℃
Damping device Both cover and seat have damping device
Warm Air Drying
Warm air Power 190w
Warm air temperature Four levels (Normal temperature about60 ℃)
Safety Device Double heating protection 95 ℃/150℃

TECHNICAL PARAMETERS
Model
ZJ-S901A
Voltage/Frequency AC100-240V 50/60Hz
Rated Input Power
Length of Supply cable 1.5m
Safety Device
Applicable Water pressure
Dimension 501*370*65mm
Input water temperature
Cleaning device
Water flow capacity
Water heating power
Water temperature adjustment
Safety device
Seat warm device
Seat heating power 25w
Seat temperature adjustment
Safety Device
Damping device Both cover and seat have damping device
Warm Air Drying
Warm air Power
Warm air temperature
Safety Device
Model
Voltage/Frequency
AC220V 50Hz/AC110V 60Hz
Rated Input Power
1320W (BG) 1050W (BS)
Length of Supply cable
1.5m
Safety Device
Leakage Protector(Operating Current=10mA)
Applicable Water pressure
0.1~0.75MPa
Dimension
475*382*136mm
Input water temperature
>3
℃
<40
℃
Cleaning device
Water flow capacity
0.6~1.1L/min
Water heating power 0-1600w
Water temperature adjustment Four levels (Normal temperature about 40℃)
Safety device Water temperature sensor system : 50℃
Temperature protector ,Anti-Dry protector .
Seat warm device
Seat heating power 45w
Seat temperature adjustment Four levels (Normal temperature about40 ℃)
Safety Device Heating protection 77 ℃
Damping device Both cover and seat have damping device
Warm Air Drying
Warm air Power 190w
Warm air temperature Four levels (Normal temperature about60 ℃)
Safety Device Double heating protection 95 ℃/150℃
ZJ-BG827D/ZJ-BS827D
-
-
-
-
-
-
-
-
-
-
-
-
-

INSTALLATION METHOD
1 Take off the original toilet seat
1) Unscrew the nut.
2) Take off the original toilet seat and wipe the top surface of the bowl.
2 Fixation board installation
1) Before installation, please put the intelligent toilet seat on the bowl to adjust the degree
of adaptability, after that, please put the fixation board on the bowl .
2) Please put the fixation board on the installation hole of bowl, then inlay the adjustment
board and insert the bolt.
3) Screwing the bolt with screw driver to fix the fixation board.
3 Toilet seat fixation& water-inlet hose installation
1) Pushing the intelligent toilet seat into the fixation board which has already fixed. It shows
the toilet seat has already combined with the fixation board when it pulled by hand and
can not remove.
2) When the front of the intelligent toilet seat and the front of the bowl don't match perfectly.
It should take off the toilet seat from the fixation board to readjust.
3) Unscrewing the bolt, take off the adjustment board from the fixation board. Remove the
fixation board to adjust the distance forward or backward, then readjust and inlay the
adjustment board to fix.
4) As per the drawing, install the intelligent toilet seat, then connect the water-inlet hose
and open the horn valve of water supply.

4.Membrane filter installation : Please don’t put wrong or upside way which will cause no water phenomenon.
Note :
1.Conversion connector can be selected to use ,it depends on your own valve’s direction .
2.Change a new membrane filter and make sure it connects with the valve tightly ,then open the valve and check
to see if it is leaking .

USING METHOD
Before using
Please check the following details before using
1.Make sure your installation is correct
2.Make sure the valve has been opened
3.Make sure the plug has been connected
4.Make sure you have opened the leakage protection
5.Make sure you have put the battery in the remote controller and model
6.Make sure your skin touch with the seat sensor
How to using
1.Please Setting the following functions before using
Seat temperature :Press “seat temp”to adjust the temperature ,there are four levels :low 34℃,middle 37℃,high
40℃,normal temperature (interior temperature). when it starts to work, it will keep on“middle level ”
Water temperature :Press “water temp”,there are four levels :low 34℃(green Indicator light),middle
37℃(orange Indicator light),high 40℃(red Indicator light) ,normal level (without indicator light )
Water pressure :Press “water pressure ”on the basis of cleaning mode ,it can be set at four levels: low
lever ,middle level ,high level and quit level . when you start the model, it will keep middle level.
Energy saving: Press “energy saving”，the water and seat temperature will keep saving mode by “low
level”, When you turn off this function, the temperature can be set as your requirement in normal way .When
you finish using and leaving ,it will still keep “energy saving”mode.
2.Basic functions
Rear cleaning :Press “rear cleaning”, it starts to clean, press again ,it will stop. If you don’t press this
button ,it will work around 1mintues and 30seconds ,then stop automatically.
Front cleaning :Press “front cleaning”,it starts to clean, press again ,it will stop. If you don’t press this
button ,it will work around 1minutes and 30second ,then stop automatically. During cleaning ,if you want to
change the function between rear cleaning and front cleaning ,the rinsing rod will protrude or retract for self-
cleaning .
Reciprocating :Press “reciprocating ”for one time ,the water pressure can be changeable; press thesecond
time ,it will move forward and backward together with different water pressure ;press the third time ,it will quit
“Reciprocating cleaning ”and work in normal cleaning mode .
Warm air: There are four levels :low level ,high level ,normal level (natural wind )and quit level .when you press
“warm air ”,It will start to work in lower level ,meanwhile ,the water will flush the toilet bowl automatically; press
the second time ,it will work in high level; press the third time ,it will work in normal level (natural wind );press the
forth time ,it will stop working .if you don’t stop this function, it will work around 2minutes and 30seconds,then
stop automatically .
Nozzle position: Press cleaning to adjust the nozzle forward and backward be according to your requirement .
Both movement have five levels to adjust .

OTHER FUNCTIONS
Damping buffer :Both toilet cover and seat with damping device ,so it can be closed very quietly .
Automatic deodorization :When you sit ,the automatic deodorization will start working until you leave ,this
procedure will cost around 40 seconds .
Remote controller :All the functions like cleaning ,warm air ,automatic flushing would be working when your skin
touch with the seat sensor .Please avoid the remote to touch water .Please change new battery when the old one
exhausted.
E Function: Press “E key”,the model will automatically start to clean for 1mintues ,then change into warm air for
1minutes .
Massage :Press ”massage”one time ,the water will alternate cold with warm; press second time , the water will
alternate cold with warm ,meanwhile ,the model starts to clean forward and backward ;press third time ,only
with warm water cleaning and reciprocating cleaning ;press forth time ,quit this function .
WARNING
Make sure the power supply is accordance with products to avoid damage
Make sure the children use the products under the guidance of adults. When the old people ,children ,disable
man, patients use this models ,the temperature must in low lever to avoid any dangerous.
Make sure the water clean and don’t use the industrial or recycled water
Make sure using soft wet-clothing wipe the surface of the toilet seat and toilet bowl
Make sure the product is dry and far away fire source such as cigarette
Don’t try to dismantle, fix or change by yourself to avoid any damage
Don’t put the heavy things on the body or cover to avoid any damage
Don’t turn over the products to avoid any damage
NOTE: When long time non-use, please close the water-inlet horn valve, take off the plug. When it appears
malfunction, please don't take off the product by yourself, and call professional technician for repair.
MALFUNCTION AND SOLUTION
Phenomenon
Cause
Solution
Power failure
Socket without power or the plug loose
Check the power supply and plug
No water for cleaning
Water pressure is too lower
Check the supply water pressure
Interior filter block
Reassemble and clean the filter
Nozzle block
Clean the nozzle
No water for Ceramic
flushing
Water pressure is too lower or filter block
Check water pressure or clean the filter
Nozzle leakage
Electromagnetic valve impurity
Clean or change the electromagnetic valve
Without warm water
Without warm seat
The device under the mode of saving
energy
Adjust temperature as your requirement
Body loose
Screws loose
Tighten the screws
Remote-controller
failure
Low battery
Change new battery
Infrared receiving window is covered
with something
Clearing the cover
