Symmons Winslet Series Manual

Model Numbers Specification
Modifications
5103
Hand shower system powered by the Temptrol®Pressure
Balancing valve. Features adjustable stop screw to limit
handle turn, 1 mode hand shower and standard 2.5 gpm
(9.5 L/min) ow restrictor.
5105
Shower/hand shower system powered by the Temptrol®
Pressure Balancing valve. Features adjustable stop screw
to limit handle turn, separate two function diverter,
1 mode hand shower, 1 mode showerhead and standard
2.5 gpm (9.5 L/min) ow restrictors.
5106
Tub/shower/hand shower system powered by the
Temptrol®Pressure Balancing valve. Features adjustable
stop screw to limit handle turn, separate three function
diverter, non-diverter tub spout, 1 mode hand shower,
1 mode showerhead and standard 2.5 gpm (9.5 L/min)
ow restrictors.
All components made from metal and nonmetallic
materials plated in standard polished chrome nish.
Winslet®Series
Operation & Maintenance Manual
5103, 5105, 5106
5103
Winslet Hand/Shower System
Compliance
5105
Winslet Shower/Hand Shower System
Note: Append appropriate -sufx to model number.
-ASME A112.18.1/CSA B125.1
5106
Winslet Tub/Shower/Hand Shower System
-1.5
1.5 gpm (5.7 L/min) flow restrictor
-2.0
2.0 gpm (7.6 L/min) flow restrictor
-IPS
1/2" female IPS connections
CG
-H521-V
30" slide bar in place of wall cradle on hand
shower units (chrome and satin finishes only)
Warranty
Limited Lifetime - to the original end purchaser in
consumer/residential installations.
5 Years - for industrial/commercial installations.
Refer to symmons.com/warranty for complete warranty
information.
-REV
Reverse coring, hot on right, cold on left, for
back to back installations
-X
Integral service stops
-STN
Satin Nickel finish
-X-CHKS
Integral check stops - for use in installations
where a positive shut-off device is used down-
stream of mixing valve

2
Dimensions
Notes:
1) All dimensions measured from nominal rough-in (see O as reference).
2) Dimensions subject to change without notice.
Measurements
AØ 2-1/2", 64 mm
B 12", 305 mm
C 6", 152 mm
D
Male 1/2" NPT thread must
protrude 1/2" (13 mm)
from nished wall
E Ref. 77", 1956 mm
F 3-1/2", 89 mm
G Ø 5", 127 mm
H Ø 7-1/2", 191 mm
I 10", 254 mm
JØ 2-1/2", 64 mm
K
5106
Ref. 32", 813 mm
5103, 5105
Ref. 42", 1067 mm
L 12", 305 mm
M 2-7/8", 73 mm
N 3-1/8", 79 mm
ORough-in
2-3/8" ± 1/2", 60 mm ± 13 mm
P
Male 1/2" NPT thread must
protrude 1/2" (13 mm)
from nished wall
Q 7", 178 mm
AA
GG
H
H
K
K
L
L
E
E
B
B
D
D
F
F
I
I
M
M
O
O
Q
Q
P
P
FLOOR
FLOOR
N
N
CC
51065106
JJ

3
Parts Breakdown
Replacement Parts
Item Description Part Number
A Showerhead 4-166
B Shower Arm T-604
CShower Arm Flange T-605
D Handle Assembly T-611
E Dome Cover T-01197-PL
F
G
H
Diverter Escutcheon
Screws
Mounting Plate
T-607-NS-K001
I
J
K
Shower Escutcheon
Screws
Mounting Plate
T-609-NS-K001
L Tub Spout 512TS
M Hand Shower 462W
NWall Cradle Flange T-606
O Wall Cradle T-613
P
Q
In-line Vacuum
Breaker & 60” Hose EF-104
Notes:
1) Append -STN to part number for Satin Nickel
nish
2) Append -1.5 or -2.0 to showerhead or hand
shower for low ow.
D
A
BC
HOT
Water Supply
E
FG
G
H
IJ
J
K
L
E
M
D
COLD
Water Supply
P
N
O
Q
Tools Required for Installation
Adjustable
Wrench
Allen
Wrench (1/8")
Phillips Head
Screwdriver
Plumber Tape
Silicone
Notes:
1) Apply a bead of silicone around the perimeter of all shower trim
installed ush to the nished wall (less mounting plates and
brackets). Leave opening on bottom of escutcheons for weep hole.
2) Apply plumber tape to all threaded connections.

4
Installation
Note:
For valve body installation, please
see valve body installation guides.
1) Install mounting plate (H) to di-
verter valve (5105 diverter valve =
2DIV-BODY, 5106 diverter valve =
3DIV-BODY) and mounting plate (K)
to shower valve (4000-BODY).
Secure each with two screws (G,J).
2) Attach diverter escutcheon (F) to
mounting plate (H).
Note: Tabs should snap into place.
3) Attach shower escutcheon (I) to
mounting plate (K).
Note: Tabs should snap into place.
4) Install dome covers (E) to valves
by turning clockwise.
5) Install diverter handle (D) and
shower handle (D) to valves.
Secure handles by tightening set
screws.
Note: Handles should be facing the
6 o'clock position.
6) Install tub spout (L) to pipe tting.
Turn clockwise to secure.
1
H
G
J
K
1
2
2
F
H
1
E
E
1
2
1
1
D
D
2
1
2
L
K
I

5
7) Install wall cradle ange (N) to
pipe tting. Turn clockwise to
secure.
8) Attach wall cradle (O) to wall cra-
dle ange (N) turning clockwise to
tighten.
9) Attach shower arm (B) and
ange (C) to vertical shower pipe
turning clockwise to tighten.
10) Install showerhead (A) to
shower arm (B) turning clock-
wise to tighten.
11) Attach large end of hand shower
hose (Q) to hand shower (M).
Attach small end of hand shower
hose (Q) and gasket to in-line
vacuum breaker (P). Connect
in-line vacuum breaker (P) to
wall cradle (O). Turn clockwise to
tighten.
Installation
2
1
N
1
2
N
O
4
1
3
2
Q
M
O
P
Q
1
2
B
C
Operation (Temperature Control)
1) Turn shower handle counter-
clockwise approximately 1/4 turn
to put valve in cold position.
2) Turn shower handle counter-
clockwise approximately 1/2 turn
to put valve in warm position.
3) Turn shower handle counter-
clockwise approximately 3/4 turn
to put valve in hot position.
1
2
A
B

Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2018 Symmons Industries, Inc. ■symmons.com ■[email protected] ■ZV-3063 REV B ■ 080118
Operation (Diverter Control: 5105)
POSITION 1 POSITION 2
1) Cartridge is factory set to divert
to function 1.
2) Turn handle to position 2 to divert
to function 2.
3) Turn handle to position 3 to share
functions 1 and 2.
POSITION 3
Operation (Diverter Control: 5106)
1) Cartridge is factory set to divert
to function 1.
POSITION 2
2) Turn handle to position 2 to divert
to function 2.
POSITION 1 POSITION 3
POSITION 6
3) Turn handle to position 3 to divert
to function 3.
6) Turn handle to position 6 to share
functions 1 and 2.
5) Turn handle to position 5 to share
functions 1 and 3.
POSITION 4
4) Turn handle to position 4 to share
functions 2 and 3.
POSITION 5
Problem Cause Solution
Finish is spotting. Elements in water supply may cause
water staining on nish.
Clean nished trim area with a soft
cloth using mild soap and water or a
non-abrasive cleaner and then quickly
rinse with water.
Troubleshooting Chart
WARNING: This product can expose you to chemicals including lead, which is known to the state of California to
cause cancer, birth defects, or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
Note: Additional handle positions for same output are illustrated.
