Soulution 701 User manual
Series 7
Monoamplifier 701
User manual
Monoamplifier 701
User manual
Page 1
Dear client
We are proud that you decided yourself for a soulution amplifier. You have acquired
an amplifier with outstanding sonic performance which you will enjoy for many
years.
We understand your eagerness to get started but even though please study this
manual step by step before you integrate the monoamplifier 701 in your High Fidel-
ity system. This manual contains also useful tips for the optimization of your overall
HiFi-system.
If there are any questions regarding the start-up or operation of your monoamplifier
701 please do not hesitate to contact your dealer.
Have fun!
Your soulution - team
soulution
nature of sound
Page 2
CE-Declaration of Conformity
Spemot AG declares that this product is in conformance with the following direc-
tives and standards:
Low Voltage Directive 2006/95/EG (EN/IEC 60065:2002)
Electromagnetic 2004/108/EG (EN 55013:2001, EN 55020:2002, EN 61000-3-
2:2006, EN 61000-3-3:1995)
FCC-Notice
Note: This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are de-
signed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harm-
ful interference to radio communications. However there is no guarantee that inter-
ference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encour-
aged to try to correct the interference by one or more of the following measures:
-adjust or relocate the receiving antenna
-increase the separation between the equipment and the receiver
-connect the equipment into an outlet on a circuit different from that to which
the receiver is connected
-consult the dealer or an experienced radio/TV technician for help
Disposal
According to the Directive 2002/96/EG of the European Parliament used
consumer-electro technical appliances have to be disposed separately
and have to be indicated with the following symbol.
In the case of disposal of this component please do so in conformity with legal and
environmental regulations.
Monoamplifier 701
User manual
Page 3
Table of content
1Quick start.......................................................................................... 3
2Technical Highlights............................................................................ 4
3Safety advice: ................................................................................. 5
4Scope of delivery................................................................................. 6
5Rear panel .......................................................................................... 6
6Front panel ......................................................................................... 8
7Protection functions ............................................................................ 9
8Trouble shooting ............................................................................... 10
9Warranty........................................................................................... 11
10 Service ............................................................................................. 11
11 Specification .................................................................................... 12
12 Dimensions....................................................................................... 13
1Quick start
Unpacking
Unpack the monoamplifier 701
Store the packing for future transportations.
Treat the high quality surface with care
Positioning
Position the monoamplifier 701 on a stable base
Do not put the 701 in a closed cabinet, at least two
sides must be open for unrestricted airflow
Cabling
Disconnect all components of your system from the mains
Connect the 701 with your preamplifier
Connect the701 with your speakers
Connect all components with the mains.
While manipulating with cables the monoamplifier 701
has to remain disconnected from the mains.
Settings
Define the brightness of the display, the start-input, start-mode,
as well as the operation-mode.
Switch-On
Switch-on your source components and the preamplifier
Turn down the preamplifier to low volume
Switch on the monoamplifier 701
Check the cabling before switching on the 701.
soulution
nature of sound
Page 4
2Technical Highlights
2.1 Philosophy
The ideal amplifier is perfectly load stable and 100% level and phase accurate. The
monoamplifier 701 is closest of all to this ideal. It is capable to output up to
1’200W of continuous power (into 4Ω) and more than 12,000W of transient power.
More than enough to breathe new sonic life into even the most demanding loud-
speakers.
2.2 Layout
To deliver these impressive power levels we have used bridged amplifiers. Optimized
mechanical construction ensures both amplifier circuits are perfectly balanced,
sharing identical thermal conditions and ideal grounding. When no music is playing
an intelligent control system automatically lowers the quiescent current. And when
loudspeakers dictate bi-amping, the 701 can be easily switched to this mode. We
think of it as tailor-made amplification.
2.3 Amplification
From the input the 701 first buffers the music signal. A high performance correc-
tion amplifier is then used to capture and correct any deviations in the signal, very
quickly and very precisely. Ultra wideband amplification using no feedback loops
follows, a less than 10 nanosecond transit time and level accuracy to within 0.1dB
ensuring signal purity. The whole is housed within a sealed module, maintaining a
common temperature across all stages to further guarantee precision. The output
stage comprises 14 power transistors per channel (28 per monoamplifier), all
mounted onto a massive copper rail which is temperature controlled for a constant
quiescent current. The 701‘s impressive low level signal handling is reflected in its
raw power delivery. Current levels of 60A and more are readily attainable.
2.4 Power supply
The supply of the amplifier section is based on modern switched mode power sup-
plies. Four modules with 600VA each optimized for audio application combined
with audiophile capacitors (>1’000’000 microFarad) provide enough power reserves
even for the most demanding music signals. Circuitry that does not process audio
signals should not be able to influence them. That’s why we use no less than 3 ded-
icated power supplies within each monoamplifier for the ancillary stages.
Monoamplifier 701
User manual
Page 5
3Safety advice:
User manual
Follow the safety advices
Keep this user manual.
Mains supply
Exclusively use 3 phase power cords with ground conductor.
Unplug the 701 from the mains in the following cases:
before you manipulate with cables
before cleaning
during thunder storms
before you leave for longer periods
Cabling
While manipulating with cables the 701 has to remain discon-
nected from the mains. Wrong cabling may cause damages to
your 701, amplifier and loudspeakers. Excessive volumes due to
inappropriate handling may cause hearing damages.
Transport
Use only with the cart, stand, tripod, bracket or table specified by
the manufacturer or sold with the apparatus. When a cart is used,
use caution when moving cart/apparatus combination to avoid in-
jury or tip over.
Packing
In order to omit condensation of water inside your monoamplifier
701, let it warm up within the packing.
Please keep the original packing for future transports.
Operation
Never run your monoamplifier 701
with opened housing
with closed cooling-slots
with high ambient temperatures (>40°C)
close to heat sources like radiators, etc.
with extremely high humidity for example in humid cellars
close to water (Sink, bathtub, or similar equipment)
Cleaning
Use a soft and dry towel. We suggest using a nonabrasive microfi-
ber towel. Please do not use any solvents or liquidities
Service
Service by a qualified person required if
the mains-cable or the mains connectors are damaged
foreign substances or liquidity have entered the 701
the 701 has seen rain
the 701 seems to malfunction
the 701 has fallen to the floor or the housing is damaged
soulution
nature of sound
Page 6
4Scope of delivery
-Monoamplifier 701
-Mains power cord
-User manual
5Rear panel
5.1 Mains (A)
The monoamplifier 701 does have no mains switch. As soon as connected with the
mains it will be in operation mode OFF (<0.5W)
5.2 Input (B)
Please use top grade audio cables. For longer connecting cables we suggest using
the balanced inputs. If there is no music signal (>10min) the idle current gets re-
duced automatically (C LOW = Consumption Low).
5.3 Output (C)
The music can be transmitted the next amplifier through the output connector (only
balanced connectors).
Monoamplifier 701
User manual
Page 7
5.4 Operation-Mode (D)
Defines the operation mode „Mono“ or „Dual“. The new setting gets activated after
the 701 has been unplugged from the mains.
5.5 Speaker (E)
Connect the speakers according to the chosen operation mode. Check the connect-
ors for tight fit. Check the cables for eventual damages. Short circuits provoked by
thin threads form loudspeaker cables may end in a fire.
5.6 LINK (F)
Connect the LINK-In of the 701 with the LINK-Out of your soulution preamplifier.
LINK-Out allows including further components in the LINK-network.
5.7 Settings (G)
The new setting gets activated after the 701 has been unplugged from the mains.
Start-Mode
OFF:
The 701 remains in operation mode OFF
ON:
The 701 switches ON automatically
LINK:
The LINK-System defines the operation mode
Start-Input
Start-Input defines the active input after switch on.
Brightness
Defines the brightness of the display (1=low / 2=medium / 3=high).
5.8 RS232 –Interface (H)
The monoamplifier 701 can be remote controlled through the RS232 interface. All
functions can be controlled and relevant information is provided to the control unit.
5.9 Type label (I)
The type label shows the serial number and the nominal power rating.
-220 - 240 V, 50-60Hz, 2’500W
-100 - 120 V, 50-60Hz, 2’500W
-220 V, 60Hz, 2’500W
soulution
nature of sound
Page 8
6Front panel
6.1 Power (J)
The power button defines the operating condition ON or OFF (red LEDs). In operat-
ing condition OFF the loudspeaker terminals are muted.
6.2 Mode (K)
The mode button (de)activates the LINK function. The monoamplifier 701 can al-
ways be switched on/off via the front panel.
6.3 Input (L)
The input button defines the active input. The inactive input gets muted.
6.4 Display (M)
The display shows all relevant information.
Monoamplifier 701
User manual
Page 9
7Protection functions
Comprehensive protection functions ensure safe operation and a long lifetime. The
monoamplifier 701 has the following protection functions:
Level limitation:
For to high levels at the input of the monoamplifier 701 the soft clip circuit is acti-
vated. The activated soft clip circuit will distort the output signal significantly, the
sonic performance is reduced. Please ensure that the input levels are within the
limit of 1.8 Vrms.
Overcurrent:
If the output current to the loudspeakers exceeds 80 A the monoamplifier 701 is
switched off automatically. This represents a maximal power rating of ca. 8’000 W
(100V @ 0.6)
Overtemperature:
The temperature of the power transistors is permanently monitored. If the maximal
operating temperature is exceeded despite of active cooling system the monoampli-
fier 701 is switched off automatically.
Fuse
The mains connection has a fuse which protects your monoamplifier 701 against
too high power consumption. Please replace with the same fuse type. The fuse is
located within the mains switch on the rear side of the monoamplifier 701.
Model 220 - 240 V, 50-60Hz 10A/T 250V micro fuse 5x20mm
Model 100 - 120 V, 50-60Hz 15A/T 250V micro fuse 5x20mm
Model 220 V, 60Hz 10A/T 250V micro fuse 5x20mm
soulution
nature of sound
Page 10
8Trouble shooting
Error
Measure
No display
Check the cabling to the mains supply. Eventually replace the
fuse of your monoamplifier 701.
No music
Check the cabling, whether the correct input (SYM/ASYM) is ac-
tivated, whether the preamplifier is switched on and if the right
source has been selected, whether the source component is
switched on and does output signal (Mute, Pause, etc.).
PS-A
FAIL
The switched-mode power supply A has failed.
Switch-off the 701 and try again after approx. 30sec.
PS-B
FAIL
The switched-mode power supply B has failed.
Switch-off the 701 and try again after approx. 30sec.
PS60
FAIL
The auxiliary 60V power supply has failed
AMP1
FAIL
The inner amplifier channel has a malfunction
AMP2
FAIL
The outer amplifier channel has a malfunction
DATA
-CON
The communication to the audio channels is broken
8.1 Actions after the appearance of an error
If you cannot identify the error please disconnect the mains supply (before you dis-
connect the monoamplifier 701 has to be in operating condition OFF) and contact
your soulution dealer.
Monoamplifier 701
User manual
Page 11
9Warranty
All soulution products are guaranteed against defects in material and workmanship
for five years from date of purchase. The warranty is not transferable.
The warranty is void if the monoamplifier 701 has been subject to misuse, or negli-
gence or has been modified, repaired or opened by a non-authorised person without
written authorisation of Spemot AG.
For the return transport to our premises please use exclusively the original packag-
ing. Transport damages are not subject to this guarantee, repairs will be charged.
We recommend effecting a transport insurance. If you do not possess the original
packaging no more please contact your soulution dealer.
Basic repairs may be completed by your soulution dealer. Please clarify whether he
is able to do the work before you send the monoamplifier 701 back to us.
10 Service
If your monoamplifier 701 needs service please contact your soulution dealer. For
further information see www.soulution-audio.com
soulution
nature of sound
Page 12
11 Specification
Dual
Mono
Power rating
Audio power rating @ 8
@ 4
@ 2
2 x 150 W
2 x 300 W
2 x 600 W
600 W
1’200 W
2’000 W
General data
Standby / OFF
Idle “High Consumption”
Idle “Low Consumption”
<0.5 W
ca. 250 W
ca. 150 W
<0.5 W
ca. 250 W
ca. 150 W
Input
Impedance XLR
cinch
Sensitivity
2.3 k
4.0 k
1.38 Vrms
2.3 k
4.0 k
1.38 Vrms
Output
Impedance
Output voltage max.
Output current max.
Impulse rating
0.001
35 Vrms
120 A
> 2x6’000 W
0.002
70 Vrms
120 A
>12’000 W
Performance
Voltage amplification
Frequency response
Slew rate
THD+N
Signal to noise ratio @ 1kHz
Damping factor @ 100Hz
+26 dB
DC-1 MHz
400 ns
<0.001 %
107 dB
> 10’000
+32 dB
DC-2 MHz
200 ns
<0.00015 %
101 dB
> 5’000
Weight
ca. 76 kg
Technical specifications are subject to change without prior notification.
Monoamplifier 701
User manual
Page 13
12 Dimensions
Spemot AG
Industriestrasse 70
CH-4657 Dulliken
www.soulution-audio.com
info@soulution-audio.com
part.no. 92178
Table of contents
Other Soulution Amplifier manuals
