Sound Leisure MiniPRO250 User manual

MiniPRO250
User Manual

MiniPRO250
Thank you for purchasing the Sound Leisure MiniPRO250 Professional
Audio Amplifier solution, Designed for use with Sound Leisure MiniPRO Flat
Panel LoudSpeakers.
Features
Music and Microphone input
Independent 3 band EQ for Music and Microphone
Lockable EQ for Music and Microphone
Mono/Stereo operation
Clipping detect LED
Self-Resetting Protection Features
Specification
2 x 65W rms Speaker outputs (For use with SL MiniPRO)
1 x 125W rms Subwoofer output (For use with SL
MiniPRO Sub)
20KΩ Music input impedance (1Vp-p Nominal Input)
Low Impedance Electronically Balanced or Single Ended
Microphone input
+/- 15 dB Bass Control Range
+/- 7 dB Middle Control Range
+/- 15 dB Treble Control Range
230V / 110V Operation (factory set)
Over/Under Voltage, Over Current, Over Temperature
Self-Resetting Protection Features
Light Weight 1.65Kg
2

3
Contents
Features & Specifications Pg 2
Amplifier Layout Pg 4 - 5
LED Information Pg 5
Setup Examples Pg 6
DIP Switch Settings Pg 7
Troubleshooting Pg 8
Warranty Information Pg 9
Blank Pages Notes & Settings Pg 10 - 11

Amplifier Layout.
Mic Input
Combi-Jack
- XLR
Stereo Input
Audio Jack
Phono Input
Left / Right
min min
min min min
POWER FAULT CLIP
ON
OFF
Channel 2/
Subwoofer
output
2 x 65w speaker outputs
1 x 125w subwoofer output : Only compatable
with soundleisure miniPRO 250 sub.
Sound Leisure
Sandleas Way, Leeds, UK
T: 0845 230 1775
www.soundleisure.com
serial number
ON
Speaker Output Connector
Music Amp Volume
Mic Volume
LED Indicators
Power (Blue)
Fault (Red)
Clip LED (Amber)
EQ Settings Bass / Mid / Treble
Dip Switches
Sw1 = Stereo on/off
Sw2 = EQ on / disabled (flat)
Sw3 = Music EQ Lock on/off
Sw4 = Mic EQ Lock on/off
Inputs/Outputs See below
Mic Input
Combi - Jack
-XLR1
Stereo Input
Audio Jack3
Phono Input
Left/Right2
Channel 2
Output to
Secondary
MiniPRO or SUB4
Mains Power
input5
Power ON/OFF
Switch
1XLR/Jack Combination Socket
Shield /1 = ND
Ring / 3 = COLD
Tip /2 = HOT
22 x RCA Phono Connectors
3 Stereo 6.35mm
Jack Socket
Tip = left Channel
Ring = Right Channel
Shield = ND
44 pole speakon socket
1+ = Channel 2 Hot
1- = Channel 2 Cold
2 + = Channel 1 Hot
2 - = Channel 1 Cold
5IEC 3 Pin Socket.
TThhiiss eeqquuiippmmeenntt
mmuusstt bbee
ggrroouunnddeedd..

Mic Input
Combi-Jack
- XLR
Stereo Input
Audio Jack
Phono Input
Left / Right
min min
min min min
POWER FAULT CLIP
ON
OFF
Channel 2/
Subwoofer
output
2 x 65w speaker outputs
1 x 125w subwoofer output : Only compatable
with soundleisure miniPRO 250 sub.
Sound Leisure
Sandleas Way, Leeds, UK
T: 0845 230 1775
www.soundleisure.com
serial number
ON
LED Indicators
The LED indicators on the MiniPRO 250 are as follows.
Blue = Indicates that the MiniPRO 250 is powered up and ready for use.
Red = Indicates there is a fault with the MiniPRO 250. See the
Troubleshooting guide for possible solutions.
Amber = Clip LED Indicates that the MiniPRO 250 output is clipping, this will
degrade the audio output and cause distrortion. Reduce the
relevant volume control until the LED ceases to flash.
5

FAULT SOLUTION
No Audio 1. Check the Power (Blue LED) is on.
2. Check if Fault (Red LED) is on. (see below)
3. Check all wiring connections.
4. Check Volume Levels.
No EQ Control Ensure SW2, SW3 and SW4 are all set at the OFF
position.
Fault LED Lit 1. Disconnect all wire connections.
2. Connect Power. If Fault LED (Red) remains on
contact Sound Leisure.
3. If Fault LED (Red) remains OFF reconnect the
system in turn, checking the Fault LED after
each connection. If the Fault is found remove
and replace faulty parts.
No Power (Blue)
LED
Check the power connection and ensure switch is
turned on.
Contact SL - No user serviceable parts inside.
Clip LED (AMBER)
Lit
Clip LED Indicates that the MiniPRO 250 output is
clipping, this will degrade the audio output and
cause distrortion. Reduce the relevant volume
control until the LED ceases to flash.
Trouble Shooting
Should a fault occur please refer to the following table for a list of possible
solutions. All the problems should be followed through methodically in order
to find the relevant solution. If the RED fault light should display the MiniPRO
250 will shut down and the LED will remain lit. In this instance you should call
Sound Leisure on: [phone]
8

Set up Examples.
The MiniPRO250 can be set up in 3 different ways.
1. As as a single speaker/amplifier unit by using the MiniPRO 250 on its
own. (SW1 set to ON/UP for mono operation)
2. As a stereo set up by using an additional MiniPro speaker (sold separately)
(SW1set to OFF/DOWN for Stereo Operation)
3. As a stereo set up (as above) with an added Sub Bass unit
(MiniPROSUB also available separately)
3. Stereo set up with MiniPROSub unit
1. MiniPRO 250 Speaker and Amp unit.
2. Second MiniPRO Speaker unit (sold separately)
3. MiniPROSUB unit (sold separately)
Connections
4. Mic input (balanced XLR or single ended)
5. Stereo Phono inputs for connection to CD,iPod,External Mixer
6. Mains Power supply - Either 230v or 110v Factory set
7. Output to MiniPROSub
8. Output from MiniProSub to secondary MiniPro
9. Input connection from MiniProSub
1
2
3
45 6
7 8
9
2. Stereo set up with additional MiniPRO
Setup as above with exception that connection 7 should be
connected directly to the input on the secondary MiniPRO
speaker unit.
1. Single unit set up
6

DIP Switch Settings
SW1 : ON = Mono
SW1 : OFF = Stereo
SW1 allows the MiniPRO 250 to work in stereo or mono. If you are running your
MiniPro 250 as a single unit setup (as on page 3) You must set this Dip Switch to
Mono (ON/UP position) failing to do so will result in you only hearing part of your
audio track as there is no additional speaker in which to produce the stereo sound.
When using the MiniPRO 250 with an additional MiniPRO speaker or speaker/sub
setup you can select the Stereo set up (DIP switch to the OFF/DOWN position) This
will produce a true (left and right) stereo sound.
SW2 : ON = EQ Bypassed
SW2 : OFF = EQ Enabled
SW2 (ON/UP) bypasses all eq setting made by the MiniPRO 250 and returns the
EQ to a “FLAT” sound.
SW3 : ON = Music EQ Locked ON
SW3 : OFF = Music EQ Locked OFF
SW3 allows any eq settings made to effect the sound of the MUSIC (by adjusting the
bass, mid and treble knobs) to be locked. By switching SW3 to the ON/UP position
locks the eq set. No further settings to the music EQ will be able to be made until
SW3 is set to OFF/DOWN position.
SW4 : ON = Mic EQ Locked ON
SW4 : OFF = Mic EQ Locked OFF
SW4 Allows locking of any EQ set to the Mic
sound. Setting SW4 to OFF/DOWN allows settings to be made by the bass, mid
and treble knobs. Switching the SW4 switch to ON/UP locks the settings made.
ADJUSTIN TH E OVERALL EQ OF THE MiniPRO250
To set the OVERALL EQ of both music and mic as a whole both SW3 and SW4
should be set to the OFF/DOWN position and SW2 should be set to the
OFF/DOWN position. Any adjustment to the bass, mid and treble knobs will effect
the sound of the MiniPRO 250 as a whole. Please note that any settings made
individually to the mic/music channels will be lost.
ON ON
ON
ON
ON
mono
eq
bypassed
music EQ
locked
ON
ON music EQ
Unlocked
OFF
ON mic EQ
locked
ON
ON mic EQ
Unlocked
OFF
eq
enabled
stereo
ON ON
ON
ON
ON
mono
eq
bypassed
music EQ
locked
ON
ON music EQ
Unlocked
OFF
ON mic EQ
locked
ON
ON mic EQ
Unlocked
OFF
eq
enabled
stereo
ON ON
ON
ON
ON
mono
eq
bypassed
music EQ
locked
ON
ON music EQ
Unlocked
OFF
ON mic EQ
locked
ON
ON mic EQ
Unlocked
OFF
eq
enabled
stereo
ON ON
ON
ON
ON
mono
eq
bypassed
music EQ
locked
ON
ON music EQ
Unlocked
OFF
ON mic EQ
locked
ON
ON mic EQ
Unlocked
OFF
eq
enabled
stereo
3. Stereo set up with MiniPROSub unit
1. MiniPRO 250 Speaker and Amp unit.
2. Second MiniPRO Speaker unit (sold separately)
3. MiniPROSUB unit (sold separately)
Connections
4. Mic input (balanced XLR or single ended)
5. Stereo Phono inputs for connection to CD,iPod,External Mixer
6. Mains Power supply - Either 230v or 110v Factory set
7. Output to MiniPROSub
8. Output from MiniProSub to secondary MiniPro
9. Input connection from MiniProSub

NNOOTTEESS && UUSSEERR SSEETTTTIINNSS
10

11

WWAARRRRAANNTTYY
SLR Products are warranted against defects in materials and workmanship.
This warranty applies for one year from the date of delivery. We will repair
or replace products that prove to be defective during the warranty period
provided they are returned to SLR,
uunn--ttaammppeerreedd.
This warranty is in lieu of all other warranties, expressed or implied,
including the implied warranty of fitness for a particular purpose to the
original purchaser or to any other person. SLR shall not be liable for
consequential damages of any kind.
If the product is to be returned to SLR for repair under warranty, it is
essential that the type and serial number be quoted, together with full
details of any fault.
No service work should be undertaken by the customer while the unit is
under warranty except with the written authorisation of SLR.
If the product is to be returned to SLR for repair under warranty, it is
essential that it is suitably packed and that carriage is insured and prepaid,
SLR cannot accept responsibility for damage sustained during transit.
TThhiiss WWaarrrraannttyy MMaayy BBee NNuullll AAnndd VVooiidd SShhoouulldd TThhee CCuussttoommeerr FFaaiill TToo MMeeeett
OOuurr TTeerrmmss OOff PPaayymmeenntt
IIff yyoouu hhaavvee aannyy qquueessttiioonnss aabboouutt tthhiiss pprroodduucctt yyoouu ccaann ccoonnttaacctt uuss::
SSoouunndd LLeeiissuurree LLiimmiitteedd
SSaannddlleeaass WWaayy
LLeeeeddss
LLSS1155 88AARR
TT:: 00884455 223300 11777755
FF:: 00884455 223300 11777766
EE:: eennqquuiirriieess@@ssoouunnddlleeiissuurree..ccoomm
wwwwww..ssoouunnddlleeiissuurree..ccoomm
9
