SoundLogic XT HT-1315/TPS-6/1754 User manual

1
TWS Wireless Speaker
Item NO: HT-1315/TPS-6/1754
INSTRUCTION MANUAL
PLEASE READ ALL INSTRUCTIONS CAREFULLY
AND RETAIN FOR FUTURE USE

2
Getting Started
Remove the speaker from the box.
Please retain all packaging until you have checked and counted all the parts and the contents
against the parts list.
Package Contents
Twins - Pair of Portable Ture Wireless Speaker
USB rechargeable cable x 2
Auxiliary cable x 2
Instruction Manual
Key Features
Twins - Pair of Portable Ture Wireless Speaker
Wirelessly connect both speakers for true right & left stereo play back
Stream music wirelessly and enjoy music from both left & right speakers
Words independently or together as paired true wireless speaker
Delivers rich sound with bass
Bluetooth transmission range up to 33 feet
Supports hands-free calls
SAFETY INSTRUCTIONS
Keep the speaker away from heat sources, direct sunlight, humidity, water and any other liquids.
Do not operate the speaker if it has been exposed to water, moisture or any other liquids to
prevent against electric shock, explosion and/or injury to yourself and damage to the speaker.
Do not use the speaker if it has been dropped or damaged in any way.
Repairs to electrical equipment should only be performed by a qualified electrician. Improper
repairs may place the user at serious risk.
Do not use the speaker with wet hands.
Do not put objects into any of the openings.
Keep the speaker free from dust, lint etc.
Do not use this speaker for anything other than its intended use.
Keep the speaker out of reach of children.
This appliance is not a toy.
Batteries (battery pack or batteries installed) shall not be exposed to excessive heat place, such
as sunshine, fire or the like.

3
Description of Parts
1
Auxiliary Port
2
USB (Flash Drive) Slot
3
Micro SD (TF) Card Slot
4
Charging Port
5
LED Indicator
6
Mode Button
7
Previous Track/Volume Decrease Button
8
Built-in Mic (inside)
9
Play/Pause/Phone Button
10
Next Track/Volume Increase Button
11
ON/OFF Switch
Note: Flash Drive & Micro SD Card NOT included.
INSTRUCTIONS FOR USE
Charging the speaker
The speaker has built-in rechargeable battery. When the battery is drained out, speaker would turn OFF
automatically. Please recharge the battery every time it drains out.
Plug the Micro USB end of the included USB rechargeable cable into the charging port. Plug the other
end into a USB port on your computer or other devices made for USB charging. Red LED Light illuminates
indicating that the device is being charged.
It takes 3-5 hours to fully charge the speaker. Once the speaker is fully charged, LED Light would turn
OFF.

4
Turning ON/OFF the Speaker –
Before Turning ON the speaker, please ensure that it is fully charged.
Slide the ON/OFF Switch to ON or OFF position to turn on or off the unit.
TWS pairing use –
TWS stands for True Wireless Stereo. This feature enables 2 separate speakers to
play music from one source at the same time, without any wires connecting both
speakers.
1. Make sure both the speakers are turned on and not paired with any Bluetooth device. An
indication tone would be heard from each speaker and the LED flashes blue rapidly. After few
seconds, another indication tone would be heard if they pair together automatically. The LED
light indicator on one speaker will flash blue rapidly, and the LED light indicator on the other
speaker will stay on.
2. Activate the Bluetooth function on your source device (Mobile Phone, Tablet etc). Please refer
to manufacturer’s instructions for instructions on enabling Bluetooth on your device.
3. Search for available Bluetooth devices and you would find “SL TWINS” –Pair it with this device.
4. If required, enter the password “0000” to pair with the device.
5. Once paired successfully, another indication tone would be heard and the LED light indicator on
both units will stay blue.
6. You can now stream wireless music on your speakers through your source device.
Note: TWS stands for True Wireless.
Answer Phone Calls through Bluetooth Speaker
Please ensure that your mobile device is paired with the Bluetooth Speaker to use the below functions.
Function
Operation
Button
Answer Incoming
Call
Incoming Call
Press the Phone button once to answer an incoming call.
Reject incoming call
Incoming Call
Press and hold the Phone button for 2 seconds
End Call
Incoming Call
After your phone conversation, short press the Phone button
Increase Volume
During a call
Press and hold the Volume increase button to increase the
volume
Decrease Volume
During a call
Press and hold the Volume decrease button to decrease the
volume
Redial last number
Standby mode
and connected
to a device
Short press the Phone button twice
Listening to Music Wirelessly
Please ensure that your mobile device (iPhone, Tablet or Other Smart Phone) is paired with the
Bluetooth Speaker to stream music wirelessly. Once it is paired, play music from your device.
Function
Operation
Button

5
Increase Volume
Playing music
Press and hold the Volume increase button of one speaker to
increase the volume
Decrease Volume
Playing music
Press and hold the Volume decrease button of one speaker to
decrease the volume
Pause
Playing music
Short press the Play/Pause button of one speaker will pause the
music
Play
Pausing
Short press the Play/Pause button of one speaker will resume
the music
Previous track
Playing music
Short press the Previous track button of one speaker will return
you to the previous track
Next track
Playing music
Short press the Next track button of one speaker will take you to
the next track
(Note: An indication tone will alert you when the volume is adjusted to the maximum level. In Aux
mode, besides the volume increase/decrease, you will need to control through your source device.)
Stream music from Micro SD (TF) Card or USB Flash Drive –
Turn ON any one speaker.
Insert the Micro SD (TF) Card or USB Drive preloaded with songs, into the Micro SD (TF) Card
Slot or USB Card Slot of the speaker respectively. An indication tone would be heard and
speaker would automatically start playing songs from the Micro SD (TF) Card or USB Drive.
To Skip Track Forward –Short press the Next track button.
To Skip Track Backwards –Short press the Previous track button.
To Pause the Track –Short press the Play/Pause button.
To Play the Track –Short press the Play/Pause button.
Long press Volume increase button to increase the volume or Volume decrease button to
decrease the volume.
Note: Flash Drive & Micro SD Card NOT included.
Listening to FM radio
Turn ON any one speaker.
Insert the USB cable (included) into the charging port. Leave the other end of the cord open. The
USB cable serves as FM Antenna while in FM Radio mode.
Press the Mode button each time until it reaches FM radio mode, with sound coming from a FM
radio station.
To AUTO-SCAN the stations, press and hold the Play/Pause button for 2 seconds.
It will take few minutes to search all the stations. Once all the stations are scanned, they get
registered in memory, automatically.
Press Next track or Previous track button to skip selected stations.
Long press Volume increase button to increase the volume or Volume decrease button to
decrease the volume.
Play music through “Auxiliary” mode
Turn ON any one speaker.

6
Insert one end of the Auxiliary cable (included) into the Auxiliary port, and an indication tone
would be heard. Insert the other end to the audio device (such as phone / MP3 Player /
computer / tablet / …..etc.).
Select your favourite song at the source device to play.
Long press Volume increase button to increase the volume or Volume decrease button to
decrease the volume.
Note: Play, Pause, Skip Forward, Skip Backward etc can only be controlled through the source devices,
while playing music in Auxiliary mode.
Tips!!
1. Short press the “Mode button” to switch different functions of the speaker between – Bluetooth
/ FM radio / Micro SD (TF)-USB / AUX-In.
2. When the speaker is not in use, turn it OFF in order to save the battery power.
Specifications –
Bluetooth version: 5.0
Unit size: Dia. 3.1”x3.8” H
Unit weight (each speaker): ~8 oz
Power input: DC 5V
Charging time: 3-5 hours
Play time: 3-4 hours (maximum volume)
Bluetooth range: 33 feet
FM frequency range: 87.5-108MHz
Built-In Rechargeable Battery (each speaker): 3.7V 1200mAh
Micro SD (TF) Card/USB Drive: Support up to 32GB
(Note: Battery life & charging time may vary based on usage, types of devices connected & wireless
distance.)
Troubleshooting
Problem
Possible Cause
Solution
Low sound level
Source (Tablet, Mobile Phone, Laptop,
etc.) volume too low.
Battery dead
Adjust source volume.
Charge Battery.
Sound distorted
Battery nearly dead
Charge Battery.
No sound at all.
Source (Tablet, Mobile Phone,
Laptop.) turned off.
Speaker turned off.
Volume turned down source.
Media paused on source.
Turn the source on.
Turn the speaker on.
Adjust volume source.
Play media from source.
Care and maintenance
Read the following recommendations before using the Bluetooth Speaker. Following these you will be
able to enjoy the product for many years.
Do not expose the unit to liquid, moisture or humidity to avoid the product’s internal circuit being

7
affected.
Don’t use abrasive cleaning solvents to clean the unit.
Do not expose the unit to extremely high or low temperature as this will shorten the life of
electronic devices, destroy the battery or distort certain plastic parts.
Don’t dispose of the unit in fire as it will result in an explosion.
Don’t expose the unit to contact with sharp objects as this will cause scratches and damage.
Don’t let the unit fall down onto the floor. The internal circuit might get damaged.
Don’t attempt to disassemble the unit as it may get damaged if you are not professional.
FCC Instructions
Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the product.
NOTE: This product has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This product generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If the product does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the product and receiver.
-Connect the product into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Limited Warranty
This manufacturer's product warranty extends to the original consumer purchaser ofthe product. Neitherthe
retailer nor any othercompany involved inthe saleorpromotionof this product is a co-warrantor of this
manufacturerwarranty.
WARRANTY DURATION: All materials and workmanship are warranted to the original consumer purchaser
for a period of ninety (90) days from the original purchase date.
WARRANTY COVERAGE: Thisproduct iswarrantedagainst defectivematerialsor workmanship. This warranty
is void if the product has been damaged by accident, in shipment, unreasonable use, misuse, neglect,
improper service, commercial use, repairs by unauthorized personnel or other causes not arising out of
defects in materials or workmanship. This warranty is effective only if the product is purchased and
operated in USA and does not extend to any unitswhich havebeen used in violationofwritten instructions

8
furnished by manufacturer or to units which have been altered or modified or, to damaged products or parts
thereof which have had the serial number removed, altered, defaced or rendered illegible.
WARRANTY DISCLAIMERS: Thiswarrantyisinlieuofallwarrantiesexpressedorimpliedand no representative or
personis authorized to assume for manufacturerany other liability in connection with the sale of our products.
There shall be no claimsfor defects or failure underany theory oftort,contractor commercial law including but
not limited to, negligence, gross negligence, strict liability, breach of warranty and breach of contract. Under no
circumstances will Manufacturer’s / Distributor’s maximum liability exceed the retail value of the product.
WARRANTY PERFORMANCE: Duringtheabove90-daywarrantyperiod,aproduct with a defect will be either
repaired or replaced with a reconditioned comparable model (at manufacturer's option). The repaired or
replacement product will be in warranty for the balance of the 90-day warranty period andan additional
one-month period. No charge will be applicable for such repair or replacement.
SERVICE AND REPAIR: If service is required forthisproduct, youshouldfirst contactMidwest Trading Group
Customer Service at [e-mail] or by calling 1 [phone], Monday to Friday 10am to 6pm
EST.
NOTE: Manufacturer cannot assume responsibility for loss or damage during incoming shipment. As a
precautionary measure, carefully package the product for shipment, and insure it with the carrier. Be sure to
enclose the following details with the product: your full name, return address and daytime phone number, a
note describing the problem you experienced, a copy of your sales receipt or other proof of purchase to
determine warranty status. C.O.D. shipments cannot be accepted.
