SOUNDMASTER High line SCD 2700USB User manual

SCD 2700USB
DEUTSCH
ENGLISH
FRANÇAIS
NEDERLANDS
ESPAÑOL

This symbol indicates the presence of dangerous
voltage inside the enclosure, sufficient enough to
cause electric shock.
This symbol indicates the presence of important
operating and maintenance instructions for the
device.
Safety, Environmental and Setup Instructions
•Use the device in dry indoor environments only.
•Protect the device from humidity.
•Do not open the device. RISK OF ELECTRIC SHOCK! Refer opening and servicing to qualified personnel.
•Connect this device to a properly installed and earthed wall outlet only. Make sure the mains voltage corresponds with
the specifications on the rating plate.
•Make sure the mains cable stays dry during operation. Do not pinch or damage the mains cable in any way.
•A damaged mains cable or plug must immediately be replaced by an authorized service center.
•In case of lightning, immediately disconnect the device from the mains supply.
•Children should be supervised by parents when using the device.
•Clean the device with a dry cloth only.
Do NOT use CLEANING AGENTS or ABRASIVE CLOTHS!
•Do not expose the device to direct sunlight or other heat sources.
•Install the device at a location with sufficient ventilation in order to prevent heat accumulation.
•Do not cover the ventilation openings!
•Install the device at a safe and vibration-free location.
•Install the device as far away as possible from computers and microwave units; otherwise radio reception may be
disturbed.
•Do not open or repair the enclosure. It is not safe to do so and will void your warranty. Repairs only by authorized
service/ customer center.
•The device is equipped with a “Class 1 Laser”. Avoid exposure to the laser beam as this could cause eye injuries.
•Only use mercury and cadmium-free batteries.
•Used batteries are hazardous waste and NOT to be disposed of with the household waste!!! Return the batteries to your
dealer or to collection points in your community.
•Keep batteries away from children. Children might swallow batteries. Contact a physician immediately if a battery was
swallowed.
•Check your batteries regularly to avoid battery leakage.
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
PRODUCTO LASER CLASE 1
CAUTION - INVISIBLE LASER RADIATION WHEN OPENING
THE COVER OR PRESSING THE SAFETY INTERLOCK. AVOID
EXPOSURE TO THE LASER BEAM.
ENVIRONMENTAL PROTECTION
Do not dispose of this product with the normal household waste at the end
of its life cycle. Return it to a collection point for the recycling of electrical
and electronic devices. This is indicated by the symbol on the product,
user manual or packaging.
The materials are reusable according to their markings. By reusing, recycling or
other forms of utilization of old devices you make an important contribution to
the protection of our environment.
Please contact your local authorities for details about collection points.
WARNING
Risk of electric shock
Do not o
p
en!
Caution: To reduce the risk of electric shock, do not remove the cover (or back). There
are no user serviceable parts inside. Refer servicing to qualified service personnel.

ENGLISH
ENG 1
General controls
1. Function selector
2. Track skip
3. Volume control
4. Power indicator
5. Track skip
6. LCD display
7. USB/CARD button
8. Program
9. MMC/SD card jack
10. USB jack
11. Mode
12. Folder up
13. FM ST indicator
14. STOP
15. Tuning control
16. Play/Pause
17. Band switch
18. CD door
19. FM antenna
20. Phone jack
21. AUX IN jack
22. AC jack
Technical information
FM Frequency: 87,5 – 108 MHz
AM Frequency: 530 – 1600 KHz
Power supply: AC 230V ~ 50Hz
12V 8x UM-2 / C 1.5V
Power consumption: 15 Watts

ENGLISH
ENG 2
Radio operation
1) Slide the function selector to RADIO position
2) Slide the band selector to desired band FM, FM stereo or AM.
3) - Extend the FM antenna for better FM reception
- Rotate the unit for better AM reception
4) Rotate the tuning control to tune down or up the radio frequency. By FM stereo reception the
FM stereo indicator will light on.
CD/MP3 player operation
This unit is compatible with CD, CD-R/RW, CD/MP3 discs.
1) Slide the function selector to LINE-IN/MP3/CD position
2) Open the CD door
3) Place the CD on the spindle with the label side facing up
4) Close the CD door
Play and pause
1) In stop mode, press to begin CD playback
2) During CD playback, press to pause playback. Press again to resume.
Skip and search
1) Press to skip to the previous or next rack respectively
2) Press and hold to search quickly current track backward or forward respectively.
Stop playback
Press to stop playback
Play mode
Press PLAY-MODE to select among REPEAT mode (repeat current track / repeat folder (MP3
disc only) / repeat all / random (CD only) / repeat off). Selection made is indicated by icons on
display.
Folder function (MP3 mode)
By pressing button FOLDER UP (12) you skip to next folder/album
Program
1) In stop mode, press PROG to enter program setting mode. Program icon flashed.
2) Press to select the desired track.
3) Press PROG again to confirm your selection
4) Repeat steps 2 to 3 until desired tracks are saved
5) Press in program mode to start program playback (PROG icon lights on the display)
6) Press to return to stop mode.
Clearing program list:
- Press while the program playback is stopped
- Open the CD door
USB/CARD operation
Slip the function button to USB/CARD band
1) Insert the MMC/SD card in slit.
2) Insert the USB in slot
3) Functions like PLAY/PAUSE, skip are the same as CD operate
LINE-IN
1) Connect the external player to the AUX jack with an audiocable (not provided)
2) Adjust the external player to mid-range volume and adjust the master volume by rotating
volume control on the unit.
Headphone connection
You can connect a headphone with 3.5mm plug to headphone jack PHONE (20).
Speakers will automatic switched off.
Copyrights by Woerlein GmbH, D-90556 Cadolzburg, Germany
Technical changes without any further announcement
