SOUNDMASTER highline BT3000 User manual

BT3000
DEUTSCH NEDERLANDS
ENGLISH ESPAÑOL
FRANÇAIS PORTUGUÊS

BT3000/Englishinstructionmanual
EN- 1


PACKAGECONTENTS…………………………………………………………..2
FEATURES……………………………………………………………………………2
SAFETYPRECAUTION…………………………………………………………..3
CONTROLS…………………………………………………………………………..4
REMOTECONTROLBATTERY………………………………………………..5
GENERALOPERATION………………………………………………………….6
TROUBLESHOOTING……………………………………………………….……8
SPECIFICATION…………………………………………………………………….8
TRADEMARK………………………………………………………………………..8
RECYCLING…………………………………………………………………………..8





Congratulationonyourpurchase.Forabetteruseofyour
newdevice,werecommendyoutoreadcarefullythis
usermanualandkeepitforrecord.
Tableofcontents
Congratulation

BT3000/Englishinstructionmanual
EN- 2

- MainUnit
- RemotecontrolfunctionwithbatterytypeCR2025
(included)
- Detachablepowercord
- 3.5mmAUXINcablex1
- InstructionManualx1
- QuickStartGuidex1
- 3.5mmauxinjacktoconnectyourMP3player
- Bluetoothenabledtowirelesslyplayyourmusic
- Fullfunctionremotecontrol
Packagecontents
Features

BT3000/Englishinstructionmanual
EN- 3

1. WaterandMoisture–Theunitshouldnotbeusednearwater.For
example:nearabathtub,washbowl,kitchensink,laundrytub,
swimmingpoolorinawetbasement.
2. Ventilation–Theunitshouldbesituatedsothatitslocationor
positiondoesnotinterferewithitsproperventilation.Forexample,it
shouldnotbesituatedonabed,sofa,rugorsimilarsurfacethatmay
blockventilationopenings.Also,itshouldnotbeplacedinabuilt‐in
installation,suchasabookcaseorcabinet,whichmayimpedetheflow
ofairthroughtheventilationopenings.
3. Heat–Theunitshouldbesituatedawayfromheatsourcessuchas
radiators,heatregisters,stovesorotherappliances(including
amplifiers)thatproduceheat.
4. PowerSources–Theunitshouldbeconnectedtoapowersupplyonly
ofthetypedescribedintheoperatinginstructionsorasmarkedonthe
appliance.
5. PowerCableProtection–Powersupplycablesshouldberoutedso
thattheyarenotlikelytobewalkedonorpinchedbyitemsplaced
uponoragainstthem.Itisalwaysbesttohaveaclearareafromwhere
thecableexitstheunittowhereitispluggedintoanACsocket.
6. Cleaning–Theunitshouldbecleanedonlyasrecommended.Seethe
Maintenancesectionofthismanualforcleaninginstructions.
7. ObjectsandLiquidEntry–Careshouldbetakensothatobjectsdonot
fallandliquidsarenotspilledintoanyopeningsorventslocatedon
theproduct.
8. Attachments–Donotuseattachmentsnotrecommendedbythe
productmanufacturer.
9. LightningandPowerSurgeProtection–Unplugtheunitfromthewall
socketanddisconnecttheantennaorcablesystemduringalightning
stormorwhenitisleftunattendedandunusedforlongperiodsof
Safetyprecaution

BT3000/Englishinstructionmanual
EN- 4
time.Thiswillpreventdamagetotheproductduetolightningand
power‐linesurges.
10.Overloading–Donotoverloadwallsockets,extensioncords,or
integralconveniencereceptaclesasthiscanresultinariskoffireor
electricshock.
11.DamageRequiringService–Theunitshouldbeservicedbyqualified
servicepersonnelwhen
A.thepowersupplycableorplughasbeendamaged.
B.objectshavefallenintoorliquidhasbeenspilledintotheenclosure.
C.theunithasbeenexposedtorain.
D.theunithasbeendroppedortheenclosuredamaged.
E.theunitexhibitsamarkedchangeinperformanceordoesnotoperate
normally.
12.PeriodsofNoneUse–Iftheunitistobeleftunusedforanextended
periodoftime,suchasamonthorlonger,thepowercableshouldbe
unpluggedfromtheunittopreventdamageorcorrosion.
13.Servicing–Theusershouldnotattempttoservicetheunitbeyond
thosemethodsdescribedintheuser’soperatinginstructions.Service
methodsnotcoveredintheoperatinginstructionsshouldbereferred
toqualifiedservicepersonnel.
14.WARNING: To reduce the risk of fire or electric shock, do not expose this
apparatus to rain or moisture. The apparatus shall not be exposed to
dripping or splashing and that no objects filled with liquids, such as
vases, shall not be placed on apparatus.
15.WARNING: The mains plug is used as disconnect device, the disconnect
device shall remain readily operable.
16.When not in use and during movement, please take care of the power
corset, e.g. tie up the power cordset with cable tie or something like that.
It shall be free from sharp edges and the like that can cause abrasion of
the power corset. When put into use again, please make sure the power
cordset being not damaged. If any damages found, please look for the
service person to replace the power corset specified by the manufacturer
or have the same characteristics as the original one.
17. Correct Disposal of this product. This marking indicates that this
product should not be disposed with other household wastes throughout
the EU. To prevent possible harm to the environment or human health

BT3000/Englishinstructionmanual
EN- 5
from uncontrolled waste disposal, recycle it responsibly to promote the
sustainable reuse of material resources. To return your used device,
please use the return and collection systems or contact the retailer
where the product was purchased. They can take this product for
environmental safe recycling.

WARNINGS
Batteriesaretobeinsertedwiththecorrectpolarity.
Neverusebatteriesthatshowsignsofelectrolyte
leaksorcracking.
Neverdisposeofusedbatteriesinanopenfire,riskof
explosion.
Keepbatteriesoutofreachofchildren.
Nevershortcircuitbatteryterminals.
Exhaustedbatteriesaretoberemovedfromthe
product.
Removebatteriesfromtheappliancebeforedisposing
ofitattheendofitsservicelife,orduringlong
periodsofnon‐use.
Donottrytoopenthebatteries.
Batteries(batterypackorbatteriesinstalled)shallnot
beexposedtoexcessiveheatsuchassunshine,fireor
thelike.
Ensurethebatterycompartmentpanelissecure.
Dangerofexplosionifbatteryisincorrectlyreplaced.
Replaceonlywiththesameorequivalenttype.
IMPORTANT
Whenreplacingusedbatteries,pleasecomplywith
applicableregulationrelatingtotheirdisposal.
Pleasereturnthemtoasuitablecollectionfacilityfor
environmentallyfriendlydisposal.
Donotchargenon‐rechargeablebatteries.

BT3000/Englishinstructionmanual
EN- 6




Powersupply:AC100‐240V,50/ 60Hz
Batteryforremotecontrol:3V (CR2025)
Powerconsumption:140W
Outputpower:Appr.250Wmax.
Standbymodeconsumption:0.45W
Bluetootheffectivedistance:10metersopenair
AUXinjack:3.5mm
Bluetoothversion :V2.1+EDR


TOPPANEL
TechnicalSpecification
InstallationandMaintenance

BT3000/Englishinstructionmanual
EN- 7
FRONTPANEL

REARPANEL

BT3000/Englishinstructionmanual
EN- 8
REMOTECONTROL
1. Power/Pairing/Function
2. Volume–
3. Volume+
4. AUX(Green)/Bluetooth(Blue)
/Standby(Red)indicator
5. Remotesensor
6. AUXjack
7. ACsocket
8. Poweron/off
9. Bluetoothswitch
10.Mute
11.Previous
12.Bassup
13.Bassdown
14.Pairing
15.AUXswitch
16.Play/Pause
17.Next
18.Volumeup
19.Volumedown

BT3000/Englishinstructionmanual
EN- 9
1. Slideandholdthebatteryreleasetabinthedirection
ofthearrow.
2. Pulloutthebatteryholderandremovetheold
battery.
3. Replacewithanewbattery(CR2025).
4. Insertthebatteryholderbackintotheremotecontrol.
Poweringupyourunit

TopowertheplayerON:
1. PlugACcordintoACjack,andplugintoaliveACwall
outlet.
2. PressthePower/Pairing/Functionbuttononthetop
panelorthePowerbuttonontheremotecontrol
toswitchtheplayertoONmode.
3. PressandholdthePower/Pairing/Functionbuttonon
thetoppanelfor1to5secondsorpressthe
Powerbuttonontheremotecontroltoswitchthe
playertoStandbymode.
Remotecontrolbattery

BT3000/Englishinstructionmanual
EN- 10
Note:Tosavepower,theplayerwillswitchtoeconomic
standbymodewhenthespeakerisidlefor15minutes.

UsingBluetoothFunction:ParingYourDevice
Beforeyourstart
YourBluetoothdevice(cellphone,MP3player,computer,
etc.)mustsupporttheA2DPBluetoothprofile(Commonly
knownasstereoaudioprofile)toworkwiththeplayer.
ManyofthelatestmobilephonesandPCswithbuilt‐in
Bluetoothfunctionalitywillsupportthisprofile.For
accurateinformationaboutyourproduct,pleasereferto
yourBluetoothdevice’susermanualfordetailsonthe
Bluetoothprofilesitsupportsandonhowtosetthe
device’sBluetoothpairing/searching/setupmode.

PairingyourBluetoothdevicewiththeplayer
1. PressandholdthePower/Pairing/Functionbuttonon
thetoppanelfor5secondsorthePairingbuttonon
theremotecontrolfor2secondsatONmodeuntil
bluelightflashesslowlytobeginpairingoperation.
LEDStatus:
Flashingquickly–Nodevicepaired
FlashingSlowly‐Devicepairing
PermanentlyON–Devicepaired
2. ActivateBluetoothonyourdeviceaccordingtothe
device’susermanualtolinktotheplayer.Typically,
Bluetoothcontrolsarefoundonthedevice’stoolsor
settingsmenu.TurnonBluetoothconnectivityand
makeyoudevice“discoverable”.
3. Searchthedevicename“BT3000”onyourBluetooth
devicelistedandselectitasyouraudiospeaker.

BT3000/Englishinstructionmanual
EN- 11
4. Oncepairedwithadevice,theBluelightwillstop
flashingandglowsteadily.Abeepsoundwillalso
indicatethattheconnectionisestablished.
5. Pairingremainsintactevenwhentheplayerorthe
Bluetoothdeviceispoweredofforistakenoutoflink
range.Theplayerwillautolinkwiththelastlinked
devicewhenthatdeviceisinrange.
Note:ConnectingtoaBluetoothdevicemaytakeupto5
minutes.Ifthepairingisunsuccessfullyrepairyour
Bluetoothdevicewiththeplayerandrepeattheabove
steps.

PairingyourotherBluetoothdevice
PreviouslyPairedDevices:
Torestartthecurrentconnectionfromplayerforselect
theotherBluetoothdevice,pressandholdthe
Power/Pairing/Functionbuttononthetoppanelfor5
secondsorthePairingbuttonontheremotecontrolfor2
secondsandrepeattheabovestepsforpairingyourother
Bluetooth.
PhoneCallsDuringBluetoothConnection:
1. Theaudioplayingwillbeinterruptedwhenthereisan
incomingcallorwhentheusermakesacall.
2. Theaudiowillcontinuetoplaywhereitstoppedonce
thecallisfinished.

PlayingBluetoothMusic
1. Onceyourdeviceandtheplayerarelinkedyoucan
starttoplayBluetoothmusicthroughtheplayer.



BT3000/Englishinstructionmanual
EN- 12

2. Turnontheplayerandpressthe
Power/Pairing/Functionbuttononthetoppanelor
theBluetoothbuttonontheremotecontroltoselect
theBluetoothmode,BluelightindicatesforBluetooth
mode.
3. Pressthebuttonontheremotecontroltoplay
yourBluetooth‐enabledevice.
(DependingontheBluetoothdeviceyouareusing,
youmayneedtomanuallygointomediaplayermode
onyourdevicetomakeitworkproperly)
4. Pressthebuttonontheremotecontroltoskipthe
nexttrack.
5. Pressthebuttonontheremotecontroltoskip
backtothebeginningofthetrackcurrentlyplay.Press
thebuttonagainimmediatelytoskiptheprevious
track.
6. Pressthebuttonontheremotecontrolagainto
pauseplay;Pressagaintoresumeit.
7. PresstheVolume+/‐buttononthetoppanelor
remotecontroltoadjustthesystemvolume.
Note:PleaseremembertoturnoffBluetoothdevice
manually.




1. ConnectasoundsourceswithaLineorheadphone
analogueoutputtoplaythroughyourplayerasbelow
hookupdiagramshown.

Lineinconnection

BT3000/Englishinstructionmanual
EN- 13

2. PressthePower/Pairing/Functionbuttononthetop
panelorpresstheAUXbuttonontheremotecontrol
toselecttheAUXmode.GreenlightindicatesAux
Modealso.
3. Setyourpersonalaudioplayer/computertoPLAY.
Headphonesocket3.5mmjackcable(included)


Note:
Duetothedifferentaudiosources,theinputlevelmay
varyatmaximumvolumeoutputlevel.Therefore,ifthe
unitrandomlystopsplayingthemusicorbecomes
distorted,movethevolumeleveltominimumandwait
forawhile.Theusercantrytomoveupthevolume
levelagainandtheunitwillplayatnormaloperation
again.
ziPhone/iPad/iPodmodels
zMP3players
zCDwalkmanplayers
zTapewalkmanplayers
zPersonalcomputersor
laptops

BT3000/Englishinstructionmanual
EN- 14


Thereisnopowertotheplayer
zEnsurethatthePowerSwitchofwallsocketis
physicallysettotheONposition.
zEnsurethattheACplugissecurelyconnectedtothe
playerandproperwalloutlet.
z
Troublepairingdevice/computerwiththeplayer
zMakesureyouhavethelatestfirmwareforyour
iPhone/iPad/iPod.
zMakesureyourdeviceisworkingproperly.Check
yourdevice’smanualfordetailsonBluetoothpairing
andlinking.
zMakesureyourdevicesupportstheA2DPandAVRCP
Bluetoothprofilesbeforelinking/pairing.Theplayer
defaultstothelastlinkeddevice,soanewdevicemay
needtobelinkedbypressandholdthe
Power/Paring/Functionbuttonforpairingother
device.




Troubleshooting

BT3000/Englishinstructionmanual
EN- 15

ThisproductbearstheselectivesortingsymbolforWaste
electricalandelectronicequipment(WEEE).Thismeansthat
thisproductmustbehandledpursuanttoEuropeandirective
2002/96/ECinordertoberecycledordismantledtominimize
itsimpactontheenvironment.
Userhasthechoicetogivehisproducttoacompetent
recyclingorganizationortotheretailerwhenhebuysanew
electricalorelectronicequipment.
Forfurtherinformation,pleasecontactyourlocalorregional
authorities.

Netweight:6300g


Hereby,WörleinGmbHdeclaresthatthisBluetoothdeviceisin
compliancewiththeessentialrequirementsandotherrelevant
provisionsofDirective1999/5/EC.
AcopyoftheDeclarationofConformitymaybeobtained
atthefollowinglocation:WörleinGmbH,Gewerbestrasse
12,D90556Cadolzburg,Germany
