Sovereign LM 32H User guide

18V CORDLESS LAWN MOWER
Article No. 555376
Model No. LM 32H
HHGL Limited, MK9 1BA; HHGL (ROI) Limited, D02 X576 July 21
ORIGINAL INSTRUCTION MANUAL
Please read these instructions fully before starting assembly.
www.coreservice.co.uk
Technical Support & Parts
01904 727509
Mon-Fri 9am-5pm Sat-Sun 11am-4pm

2
CONTENTS
General safety warnings 3
Intended use 12
Warning symbols 13
In the box 17
Assembling the lawn mower 18
Operating the lawn mower 25
Maintenance and storage 29
Troubleshooting 32
Technical data 34
Recycling and disposal 35
Getting help 35
Warranty 36

3
GENERAL SAFETY WARNINGS
Safety Warnings
WARNING! Read all safety warnings and
instructions.
Failure to follow the warnings and instructions
may result in electric shock, re and/or serious
injury.
WARNING! Read all safety warnings and
instructions designated by the symbol.
Save all warnings and instructions for
future reference.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Perform assembly operations as described in this
manual. Failure to observe this warning may lead
to serious injury, death, or damage to the lawn
mower.
• Children should be supervised to ensure that they
do not play with the product.
IMPORTANT
READ CAREFULLY BEFORE USE & KEEP FOR FUTURE
REFERENCE

4
GENERAL POWER TOOL SAFETY WARNINGS
Training
• Read the instructions carefully and make sure
you fully understand them. Make sure you are
familiar with the controls and the correct use of
the product.
• Never allow children or people unfamiliar with
these instructions to use the product. Local
regulations can restrict the age of the operator.
• Never operate the product while people,
especially children or pets, are nearby.
• Keep in mind that the operator or user is
responsible for any accidents or hazards
occurring to other people or their property.
Preparation
• While operating the product, always wear
substantial footwear and long trousers. Do not
operate this product when barefoot or wearing
open-toed sandals. Avoid wearing clothing that is
loose tting or has hanging cords or ties.
• Thoroughly inspect the area where the product
is to be used and remove all objects which
could be thrown by the product.
• Before using, always visually inspect to see
that the blade, blade bolt and the blade
assembly are not worn or damaged. Replace
worn or damaged components in sets to preserve
balance. Replace any damaged or unreadable
labels.

5
• Ensure the switch is in the ‘o’ position before
inserting the battery pack. Inserting the battery
pack into a machine that is switched on can result
in injury.
General Operation
• Use the tool only with specically designated
battery packs. Use of any other battery packs will
increase the risk of injury and re.
• Only operate the product in daylight or in good
articial light.
• Do not expose the tool and charger to rain or
wet conditions. If a tool or charger is exposed to
moisture it will increase the risk of electric shock.
• Avoid operating the product on wet grass.
• Always be sure of your footing on slopes.
• Walk, never run.
• Mow across the face of slopes, never up and
down.
• Exercise extreme caution when changing direction
on slopes.
• Do not mow excessively steep slopes.
• Use extreme caution when reversing or pulling the
product towards you.
• Stop the blades if the product has to be tilted for
transportation, when crossing surfaces other than
grass, and when transporting the product to and
from the area to be mowed.

6
• Never operate the product with defective guards
or shields or without safety devices in place, such
as deectors or grass collector.
• When switching on the motor, keep feet well away
from the blades.
• Do not tilt the product when switching on the
motor, except if the product has to be tilted for
starting. In this case, do not tilt it more than
absolutely necessary and lift only the part furthest
away from the operator.
• Do not start the product when standing in front of
the discharge opening.
• Do not put hands or feet near or under rotating
parts.
• Keep clear of the discharge opening at all times.
• Do not transport the product while the cutting
blade is running.
• Stop the product and remove the key/battery pack
from the machine and make sure that all moving
parts have come to a complete stop:
- Whenever you leave the product unattended.
- Before clearing blockages or unclogging the
chute.
- Before checking, cleaning or working on the
product.
- After striking a foreign object, be sure to inspect
the product for damage and make repairs before
restarting and operating the product.

7
• If the product starts to vibrate abnormally:
- Inspect for any damages.
- Replace or repair any damaged parts.
- Check for and tighten any loose parts.
Chargers
• This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use of
the appliance in a safe way and understand the
hazards involved.
• Children shall not play with the appliance.
Cleaning and user maintenance shall not be made
by children without supervision.
• If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualied persons in order to avoid a hazard.
• Recharge only with the charger specied by the
manufacturer. Do not use the original charger
on other li-ion batteries or on any other type of
battery, as this can increase the risk of re or
explosion.
• Check the battery charger, cable and plug
before each use. Do not use the battery charger
if damaged. Do not open the battery charger
yourself; the charger must be repaired by qualied
personnel using original spare parts.

8
• The charger is designed to use a standard
household 230-240 V~ 50/60HZ power source;
ensure that the plug matches the outlet.
• Never modify the plug in any way, this will reduce
the risk of electric shock.
• Do not abuse the cord of the charger. Never use
the cord for carrying, pulling or unplugging the
charger. Keep the cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
• Make sure the charger cord is situated so that
it will not be stepped on, tripped over or get
damaged.
• Keep the battery charger clean. Contamination
can increase the risk of electric shock.
• The charger is for indoor use only, do not expose
to rain. Protect the battery charger from rain and
moisture. If water accesses the battery charger
there is an increased risk of electric shock.
• The battery will heat up whilst charging. To reduce
the risk of re, do not operate the battery charger
on ammable surfaces, such as paper or textiles.
• The temperature range over which the battery
pack can be charged is typically between 5ºC-45ºC.
Attempts to charge outside of the prescribed
temperature range may automatically be blocked
by the protection circuitry of the battery pack.
Longest life and best performance can be
obtained if the battery pack is charged at room
temperature.

9
• Disconnect the charger from the power supply
when not in use. This will reduce the risk of
electric shock or damage to the charger.
• If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualied persons in order to avoid a hazard.
• Do not short out the contacts of the battery or
charger.
• Respect the polarity “+/-“ when charging.
• Do not open the unit and keep out of the reach of
children.
• Do not charge the batteries of other manufactures
or ill-suited models.
• Ensure that the connection between the battery
charger and battery is correctly positioned and is
not obstructed by foreign bodies.
• Keep battery charger’s slots are free of foreign
objects and protect against dirt and humidity.
Store in a dry and frost-free place.
• When charging batteries, ensure that the battery
charger is in a well-ventilated area and away from
inammable materials. Batteries can get hot
during charging. Do not overcharge any batteries.
Ensure that batteries and chargers are not left
unsupervised during charging.

10
Battery pack
• Fully charge the battery pack before rst use.
• Recharge the battery pack immediately when the
power output starts to slow.
DO NOT CONTINUE
TO USE THE PRODUCT WHEN THE BATTERY LEVEL IS
LOW.
• To prevent serious damage to the battery, charge
in temperatures above 5ºC or below 45ºC. Longest
life and best performance can be achieved when
the battery is charged at room temperature.
• If the battery temperature is above 45ºC it must be
allowed to cool before putting it into the charging
station.
• To reduce the risk of explosion, ensure the battery
pack is not left in the sun for extended periods of
time and that it is kept away from re.
• Do not carry individual battery packs in your
pockets or bag, as they could short circuit against
other metal items.
• Should a li-ion battery catch re, be sure to use
the correct re extinguisher to combat the re.
DO NOT THROW WATER ON A BURNING LI-ION
BATTERY.
• If the battery pack becomes too hot during
charging, disconnect and switch o immediately.
Contact the service centre directly.
• Do not attempt to open the battery yourself.

11
• When the battery pack is not in use keep it away
from other metal objects, such as paperclips,
coins, keys, nails, screws or other small metal
objects that can make a connection from one
terminal to another.
• Do not dismantle, open or shred cells or battery
pack.
Maintenance and storage
• Keep all nuts, bolts and screws tight to be sure the
product is in a safe working condition.
• Check the grass collector frequently for wear or
deterioration.
• Be careful when adjusting the product to prevent
trapping ngers between moving blades or other
xed parts of the product.
• Always allow the product to cool down before
storing.
• When servicing the blades, be aware that even
though the power source is switched o, the
blades can still move.
• Replace worn or damaged parts for safety. Use
only genuine replacement parts and accessories.
• DO NOT attempt to open the charger and battery
pack. There are no customer-serviceable parts
inside. Return to any authorised service centre.
• Store the appliance with the battery pack fully
charged at room temperature (around 20ºC).

12
• Every deep discharge cycle decreases the capacity
of the battery pack. To prolong battery life, it is
recommended that you charge the battery every
six months, within extended periods of time when
the product is not in use.
Servicing
• Have your tool repaired by an authorised service
agent. This tool is manufactured in accordance
with the relevant safety regulations. To avoid
danger, equipment must only be repaired by
qualied technicians.
• Only use parts and accessories made for this
machine by the manufacturer. Failure to do so can
result in personal injury.
INTENDED USE
This lawn mower has been designed for cutting
grass. The machine is to be used only for its
prescribed purpose, and any other use is deemed to
be a case of misuse.
PLEASE NOTE: Our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.

13
WARNING SYMBOLS
Safety symbols
The purpose of safety symbols is to attract your attention
to any possible dangers. The safety symbols and their
explanations require your careful attention and full
understanding. The symbol warnings do not, by themselves,
eliminate any danger. The instructions and warnings they give
are no substitute for proper accident prevention measures.
WARNING: Be sure to read and understand all safety
instructions within this operator’s manual, including
all safety alert symbols such as ‘DANGER’, ‘WARNING’,
and ‘CAUTION’ before using this tool. Failure to follow
all instructions listed below may result in electric
shock, re and/or serious personal injury.
SAFETY ALERT SYMBOLS: Indicate DANGER, WARNING, or
CAUTION and may be used in conjunction with other symbols
or pictographs.
Symbol meanings
This page depicts and describes safety symbols that may
appear on this product. Read, fully understand and follow all
instructions on the machine before attempting to assemble
and operate.
To reduce the risk of injury, the user must read this
instruction manual carefully.
Avoid using the tool in the rain.
Blade continues to rotate after the machine is
switched o. Wait until all machine components have
completely stopped before touching them.

14
Keep bystanders away. Objects thrown by the product
could hit the user or other bystanders. Always ensure
that other people and pets remain at a safe distance
from the product when it is in operation.
Beware of sharp blades. Blades continue to rotate
after the motor is switched o. Remove the safety key
before performing any maintenance tasks.
Guaranteed sound power level value is 90 dB.
Wear ear protection, eye protection and gloves (PPE)
when using the product.
WEEE symbol. Waste electrical products should not
be disposed of with household waste. Please recycle
where facilities exist. Check with your local authority
or local store for recycling guidelines.
The product complies with the applicable European
Directives, and an evaluation method of conformity for
these directives was done.
The product complies with the applicable UK
Directives, and an evaluation method of conformity for
these directives was done.
90

15
Warning symbols on the battery pack
To reduce the risk of injury, the user must read this
instruction manual carefully.
Do not throw into water.
Do not throw on re.
Do not subject the battery to strong sunlight over long
periods of time. Do not leave on a heater (max. 45°C).
Batteries contain Li-ion. Do not dispose of waste
batteries in domestic waste. Contact your local
authority to nd out how to dispose of batteries.
The product complies with the applicable European
Directives, and an evaluation method of conformity for
these directives was done.
The product complies with the applicable UK
Directives, and an evaluation method of conformity for
these directives was done.
Pole orientation.

16
Warning symbols on the charger
To reduce the risk of injury, the user must read this
instruction manual carefully.
Indoor use only.
Class II equiment.
Fuse T 2A time lag fuse with rated current of 2A.
Pole orientation.
WEEE symbol. Waste electrical products should not
be disposed of with household waste. Please recycle
where facilities exist. Check with your local authority
or local store for recycling advice.
The product complies with the applicable European
Directives, and an evaluation method of conformity for
these directives was done.
The product complies with the applicable UK
Directives, and an evaluation method of conformity for
these directives was done.
T/2A

17
IN THE BOX
Parts
1. Upper handle
2. Switch box
3. Lock-o button
4. Cable clips x 2
5. Grass bag
6. Battery pack locating tank
7. Carry handle
8. Rotating knobs x 2
9. Start lever
10.Battery pack
11.Charger
12.Charger plug
1
3
4
5
6
7
8
9
2
10 11 12

18
ASSEMBLING THE LAWN MOWER
Assemble the lower brace
1. Insert the lower brace into the slot on the mower deck.
2. Use two installation screws to x the lower brace.
Attach the top handle to lower brace
Mount the top handle to the lower brace using the two
rotating knobs.

19
Fitting the cable clip
Ensure that the cable clips supplied are used to x the cable
to the lower brace.
Mounting the grass catcher
1. Fit the upper part onto the lower part by fxing all the outer
clips correctly.

20
2. Fit the handle onto the top of the grass catcher so that it
clicks into place.
3. Lift the safety ap, and hang the grass box on the hook.
Fold the safety ap onto the grass box.
