Soyal AR-821EF User manual

SOYAL
ACCESS CONTROL SYSTEM
®AR-821EF / AR-821EV
V091028
DO MT
or P1 P2 P3 P4
P1 P2 P3 P4
P1 P2
P3
P4
1
2
A. B.
Contents
AR-821EF [Fingerprint]
AR-821EV [Finger Vein]
2User Guide
2User Guide
Installation
Use a screwdriver to screw the mounting plate to the wall.
Pull cables ends through the access hole in the mounting plate.
Attach AR-821EF or AR-821EV to the mounting plate and install screws (supplied) into the
holes at the bottom with the allen key (supplied).
Apply power. LED (green) will light up with one beep.
1Products
1Products
3Terminal Cables
3Terminal Cables
4Allen Key and Screws
4Allen Key and Screws
Notice
1. Tubing: The communication wires and power line should not be housed in the same electrical conduit or tubing.
They should always be installed in separate tubes.
2. Cable selection: Use AWG 22-24 “Shielded Twisted Pair” to avoid star wiring.
3. Power supply: Do not connect the reader and lock to the same power suppy. While the lock activates, it will cause the reader’s power to be unstable
and affect the readers operation. The standard connection of power supply is to have the door relay and the lock use one supply;
the reader uses an independent supply.
Connector Table
Wire Application
Door Relay
Common-COM-Point
Door Sensor
Exit Switch
Alarm Relay
Power
Wire Application
Tamper Switch
Wire Application
Networking
Wiegand
Buzzer
LED
Wire Application
Serial Port
Description
(N.O.)DC24V1Amp
(N.C.)DC24V1Amp
(COM)DC24V1Amp
Negative Trigger Input
Negative Trigger Input
N.O./N.C. Optional
(by jumper)
DC 12V
DC 0V
Description
N.C.
COM
N.O.
Description
RS-485 (B-)
RS-485 (A+)
WG DAT: 1 Inpu
ABA Clock Input
WG DAT: 0 Input
ABA Data Input
Buzzer Output 5V/100mA, MAX
LED Green Output 5V/20mA, MAX
LED Red Output 5V/20mA, MAX
Description
Signal Ground
TTL Serial Data Output in
4800, N, 8, 1
Color
Blue White
Purple White
White
Orange
Purple
Gray
Thick Red
Thick Black
Color
Red
Orange
Yellow
Color
Thick Green
Thick Blue
Blue
Green
Pink
Brown
Yellow
Color
Black
Blue
Wire
1
2
3
4
5
6
7
8
Wire
1
2
3
Wire
1
2
3
4
5
6
7
Wire
1
2
P1.
P3.
P2.
P4.
Front Panel & Indicator
Power(Green)
Busy(Red)
Alarm(Red)
Card Present/ Arming(Green)
OK(Green)
Error(Red)
Fingerprint or Finger-Vein
Scan Area

V091028
N.O. N.C. COM Door SEN PB ALM V+ V-
A+
B-
V-
V+
B- A+ WG0 WG1 BZ GLED RLED
V-
+12V
+12V V-
N.C.
N.O.
RS-232
USB
WG1WG0BZ LED
GR
LED
RED V- V+
12V
CTL
COM
N.O
N.C
RS-485 RS-232
RS-485 USB
or
N.O.
COM
N.C.
TTL
GND
P1 P2
P3
P4
Fingerprint & Finger Vein
LCD Access Controller
Diagram
Manu Tree
5. Tools
1. Language
2. Master Code
3. Master Range
4. Terminal Port
5. AR401RO16 Node
6. Open Time Zone
7. Informations
8. Clock Setting
6. Quit
7. Quit & Arming
4. Parameters[2]
1. Auto Relock
2. Egress(R.T.E)
3. Attendance
4. Master Node
5. Force Open
6. Close & Stop
7. Anti-pass-back
8. Duress Code
9. Check User FP
3. Parameters[1]
1. Node ID
2. Auto open Zone
3. Door Relay Tm
4. Door Close Tm
5. Alarm Relay Tm
6. Alarm Delay Tm
7. Arming Delay Tm
8. Arming PWD
2. User Setting
1. Password
2. Access Mode
3. Extend Options
4. Single Floor
5. Multi Floor
6. Enroll FP
7. Delete FP
1. Add/ Delete
1. Add > Card ID
2. Add > RF Learn
3. Suspend > Address
4. Suspend > ID #
5. Delete > Address
6. Delete > ID #
7. Recover > Address
8. Recover > ID #
9. Antipass Group
Programming
A. Keyboard Lock/ Unlock
Lock/ Unlock
At the same time according to and keyboard can be locked, and then press once to unlock.
1. System will automatically exit from Programming Mode when inactivating for 30 seconds.
2. LED status indicates controller’s mode and status.
Busy (red) – blinking constantly when operates in Programming Mode
– or ashing an existed card in card learn mode, it comes 2 beeps warning and LCD panel displays “Same Card: user address / card number”
Error (red) – invalid card with 2 beeps warning and LCD panel displays “Card Number Err!”
– or in anti-pass-back mode, when violates the access, it comes one beep warning and LCD panel displays “Anti-pass Error!”
Arming (green) – arming on status
Alarm (red) – any abnormal condition occurs
3. Keypad will be locked up when constantly entering incorrect pin code or master code.
4. Maximum error times of pin code and master code can be changed via the software 701Server (default: 3 times)
B. Entering and Exiting Programming Mode
Entering
Input 123456 or PPPPPP
[i.e.] The Default Value= 123456. If already changed the Master Code= 876112, input 876112 → Access programming mode
P.S.If within 30 sec. entering no instruction, it will automatically leave the programming mode.
Exiting
Press the repeatedly → Quit → then press to conrm
6
Changing the Master Code
Access programming mode → Tools → Master Code → Input the 6-digit new master code → Succeeded
5 2
C. Initial setup
Changing the Node ID of Reader
Access programming mode → Parameters[1] → Node ID → Input New Node ID:1~254(default value: 001) → Input: 1~4 to Show Card ID
in which format? (1.No, 2.WG, 3.ABA, 4.HEX) → Succeeded
3 1
Changing the Language
Access programming mode → Tools → Language → EN → Succeeded → Initial system...
5 1 1
Strike Lock
Bolt Lock
(Magnet Lock)
Lock Power
Converter
Power
Magnetic Door Contacts
Thick Green
Thick Blue
Blue
Green
Pink
Brown
Yellow
Push Button

SOYAL
ACCESS CONTROL SYSTEM
®AR-821EF / AR-821EV
V091028
D. Adding / Deleting Fingerprint or Finger-Vein
E. Access Mode
F. PIN Code
G. Arming Password
H. Duress Code
Adding
Access programming mode → User Setting → Enroll FP → Key in 5-digit user address → 2 different ngers on the sensor lens → Succeeded
P.S. The AR-821EF need to collect twice, and the AR-821EV need to collect three times.
2 6
Deleting
Access programming mode → User Setting → Delete FP → Key in 5-digit user address → Succeeded
P.S. If you want to delete all users’ FP, key in 9999
2 7
#
Access programming mode → User Setting → Access Mode → Key in 5-digit user address → 1:FP/Tag; 2:or PIN; 3: and PIN; 4: Pause →
Check FP Image: 1: Yes; 2: No → Succeeded
Access programming mode → User Setting → Password → Key in 5-digit user address → Key in 4-digit PIN (0001~9999) → Succeeded
Access programming mode → Parameters[1] → Arming PWD → Key in 4-digit PIN (0001~9999; Default: 1234) → Succeeded
Access programming mode → Parameters[2] → Duress Code → 4 sets (select one) → Key in 4-digit PIN (0001~9999) → Succeeded
Or via 701Client to set it on Users screen
Or via 701Server to set it on AR-821EF or AR-821EV screen
Or via 701Server to set it on AR-821EF or AR-821EV screen
※Duress Code is only available in networking mode. It will substitute a personal pin code and send the message of Duress to computer as a warning
signal and access door.
2
2
3
4
※ Parameters[2] → Check User FP → must select [1: Yes]
4 9
2
1
8
8
Access Mode
1: FP/Tag
2: or PIN
3: and PIN
4: Pause
User Access Type
[Check FP Image] must select [1: Yes]
FP only/ Tag + FP
FP only/ Tag + FP/ PIN + FP
FP + PIN
Pause
[Check FP Image] must select [2: NO]
FP only/ Tag only
FP only/ Tag only/ PIN only
FP + PIN/ Tag + PIN
Pause
I. Setting up the alarm
Conditions:
1. Arming enabled
2.Alarm system connected
3
3
3
3
3
3
4
5
6
7
Function
Door Relay TM
Door Close TM
Alarm Relay TM
Alarm Delay TM
Arming Delay TM
Command Description
To set how long the door relay (lock release) is active after showing a card.
Range: 0 ~ 600 (sec.); 601~609 (0.1~0.9 second). To set value “0” will make door keep opening til the card is
presented again, and then door close. (Default value: 7 sec.)
Setting how long the door can remain open before activating the alarm.
(Based on second, range: 000~255, default value: 15 sec.)
When an alarm condition has arisen, the alarm will activate for this duration. Range: 1 ~ 600 (sec.)
To set value “0” will make alarm relay keep on until disarming, then alarm relay off. (Default value: 7 sec.)
To delay the activation of the alarm relay after an alarm condition has arisen, so that user can have enough time
to disable alarm. (Based on second, range: 000~255, dfault value: 1 sec.)
To delay the time of enabling arming, so that user can have enough time to disable arming.
(Based on second, range: 000~255, default value: 1 sec.)
1
2
4
31
2
Application:
1. Door opened too long (After Normal Opening): The Door is Opened over the time of door relay time and door close time.
2. Door sensor error: Door sensor is open loop.
3. Force open (Opened without a valid user card being showed): Access by force and illegal procedure.
Flow chart:
A.Normal Opening: Door Opened
Enable Arming Arming Delay TM
Enable Arming Arming Delay TM
Alarm system activated
Arming settingArming setting Alarm triggerAlarm triggerDoor open durationDoor open duration
Alarm system activated
Arming settingArming settingAlarm triggerAlarm trigger
B.Abnormal Opening:
Alarm Delay TM
1Alarm Relay TM2
Door Relay TM
1Door Close TM2Alarm Delay TM3Alarm Relay TM4

V091028
SOYAL http://www.soyal.com
Fingerprint & Finger Vein
LCD Access Controller
Access mode Card and Pin, Card Pin or Card only for the model AR-721K
Access mode Card only for the model AR-721U, AR-737H/U (WG mode) and AR-661U
J. Anti-pass-back
Device enable
Access programming mode → Parameters[2] → Anti-pass-back → must select [1: Yes]
4 7
Card user enable
Access programming mode → Add/ Delete → Antipass Group → Key in 5-digit starting user address → Key in 5-digit ending user
address → select [1: Yes]
1 9
Software Settings on 701Server
Uploading ngerprint database to PC
First of all, please make sure users have registered their ngerprints to the device.
1. select node number of the device
2. click “Read from Controller”
3. set range to 20 (it is suggested not to exceed more than 20 ngerprints each uploading and downloading)
4. click “Upload from Device to File”
5. status popped up
Downloading ngerprint database from PC to the device(s)
6. by selecting “Single” or “All Connected”, the FP database can be downloaded to one single device or all connected devices.
(Suggest to download by "Single".)
7. click “Download”
Deleting ngerprint database on the device
3. select the range of the ngerprints to delete (Not over 20 Fingerprints.)
8. click “Delete”
1. Click “82X” icon
2. Click “Read From Controller”
3. Click “Write To Controller” once setting completed
4. Click “Exit”
※Please note that the ngerprint data will be saved in different format V3 and V9, so the data is not compatible.
Thanks for You
To have more detailed information, E-learning, and Q&A, please visits our website.
0004 FP Image !
1.
2. 3.
4.
5.
6.
7. 8.
