SOYO Onyx DYLT032D User manual

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
LCD TV
OWNER'S MANUAL
IMPORTANT:
The serial numberof this productmay be foundon the back
of the unit.Youshould record thenumber and othervital
information here andretain this manualas a permanentrecord
of your purchaseto aid identificationin case oftheft. Serial
numbers are notkept on file.
IMPORTANT INFORMATION
The lightning flash with arrowhead symbol, within an equilateral
traingle, is intended to alert the user to the presence of uninsulated
"dangerous voltage”within the product's enclosure that may be of
sufficient magnitude to constitute arisk of electricshock to persons.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
The exclamation point within a triangle is intended to alert the user to the
presence of important operating and maintenance(servicing)instruction
accompanying the product.
DYLT032D
1
ENGLISH
Model No:DYLT032D
Serial No:
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN

This product utilizes tin-lead solder, and flourescent lamp containing a small amount of
mercury. Disposal of these materials may be regulated due to environmental
considerations, For disposal or recycling information, please contact your local
authorities .
IMPORTANT INFORMATION(Continued)
WARNING: FCC Regulations state that any unauthorized changes or modifications to this
equipment not expresslyapproved by themanufacturer could void the user's
authority to operatethis equipment.
CAUTION :TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLAND OF PLUG TO WIDE SLOT,
FULLY INSERT.
"Note to CATV SYSTEM installer, This reminder isprovided to call CATV system installer's
attention to Article 820-40 of the National Electrical Code that provides guidelines for proper
grounding and, in particular, specifies that the cable ground has; be connected to the grounding
system of thebuliding,as close tothe point of cable entry as practical."
2
SERVICE INSTRUCTIONS:
No user-serviceable parts inside, refer servicing to qualfied service personnel.
Call 1-800-287-4871 to find the nearest service center.
ENGLISH

IMPORTANT SAFETY PRECAUTIONS
3
Electricity is usedto perform manyuseful functions, butit can alsocause personal injuriesand property
damage if improperlyhandled .This producthas been engineeredand manufactured withsafety being the
highest priority .However, improper use can result in personal injury and / or property
damage.
Read instructions -All opertinginstructions must beread and understood before the productis operated.
Keep this manualin a safe place - Thesesafety and operatinginstructions must be kept in asafe place for future reference.
Observe warnings -All warnings on the productand in the instructions must beobserved closely.
Follow instructions -All operating instructions must befollowed.
Attachments - Donot use attachments not recommended bythe manufacturer. Use of inadequateattachments can result in
accidents.
Power source -This product mustbe operated on a power sourcespecified on the specification label. Ifyou are not sure of
the type ofpower supply used in your home,consult your dealer or local powercompany. Forunits designed to operate on
batteries or anotherpower source, refer to the operatinginstructions.
Power cord protection- The powercords must be routed properly toprevent people from stepping on themor objects from
resting on them.
If theAC adapter is misplaced or needsto be replaced,obtain the same typeof adapter from our service centeror your dealer.
Overloading - Donot overload AC outlets orextension cords, overloading can cause fireor electric shock.
Entering of objectsand liquids - Never insert anobject into the product through ventsor openings. High voltage flows through
the product. Insertingobjects can cause electric shock and/orshort circuit internal parts. Also,do not spill water, orany other
Liquid on theproduct.
Servicing - Donot attempt to service the productyourself. Removing covers can expose youto high voltage and other
dangerous conditions. Requesta qualified service person to performservicing.
Repair - Ifany of the following conditions occurs,unplug the power cord from theAC outlet, and request aqualified service
person to performrepairs.
a. When thepower cord or plug is damaged.
b. When aliquid was spilled on the productor when objects have fallen intothe product.
c. When theproduct has been exposed to rainor water.
d. When theproduct does not operate properly asdescribed in the operating instructions.
Do not touchthe controls other than those describedin the operating instructions. Improper adjustmentof controls not
described in theinstructions can cause damage,which often requiresextensive adjustment work by a qualifiedtechnician.
e. When theproduct has been dropped or damaged.
f. When theproduct displays an abnormal picture.
g. Any noticeable abnormality in the product.
Replacement parts -In case the product needs replacementparts, make sure that the serviceperson uses replacement parts
specified by themanufacturer.
Safety check -Upon completion of service or repairwork, request the service technician toperform safety check to ensure
that the productis in proper operating condition.
Wall or ceiling mounting -When mounting the product on awall or ceiling, be sure toinstall the product according to the
method recommended bythe manufacturer.
Polarization - ThisAC adaptermay be equipped with a polarizedalternating current line plug (a plughaving one blade wider
than the other).Thisplug will fit into the poweroutlet only one way .
This is asafety feature, Ifyou are unable to insert theplug fully into the outlet, tryreversing the plug, If the plug still doesn't fit
,contact your electricianto replace your obsolete outlet.
Do not defeatthe safety purpose of the polarizedplug.
ENGLISH

4
IMPORTANT SAFETY PRECAUTIONS(Continued)
Cleaning - Unplugthe power cord from the AC outlet before
cleaning the product.Use a damp cloth to clean the product.
Do not useliquid cleaners or aerosol Cleaners.
Water and moisture - Do not use the product near water, such as
bathtub , washbasin,kitchen sink and laundry tub, swimming pool
and in awet basement.
Stand - Do not place the product on an unstable cart, stand,
tripod or table. Placing the product on an unstable base can
cause the product to fall, resulting in serious personal injuries
as well as damage to the product. Use only a cart, stand, tripod,
bracket or tablerecommended by the manufacturer's
instruction. Use only the mounting hardware recommended by
the manufacturer.
When relocating the product, place it on a cart. It must be moved
with utmost care. Sudden stops, excessive force and uneven floor
surface can causethe product to fall from the cart.
Ventilation -The vents and other openingsin the cabinetare
designed for ventilation. Do not cover or block these vents and
openings since insufficient ventilation can cause overheatings
and/or shorten thelife of the product. Do not place the product
on a bed, sofa, rug or other similar surface, since they can
block ventilation openings. This product is not designed for built-in
installations; do not place the product in an enclosed place such as a
bookcase or rack, unless proper ventilation is provided or the
manufacturer's instruction are followed.
The Liquid Crystalpanel used in this product is made of glass,
Therefore ,it can break when the product is dropped or when
pressure is applied. Be careful not to injure yourself from broken
glass in casethe Liquid Crystal Panel breaks.
Heat sources -Keep the product away from heat sources such
as radiators, heaters,stoves and other heat-generating products
(including amplifiers).
ENGLISH

5
If an outside antenna is connected to the television equipment, be sure the antenna system is
grounded so asto provide some protection against voltage surges and built-up static charges.
Section 810 of the Nation Electrical Code provides information with respect to proper
grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna
discharge unit, sizeof grounding conductors,location of antenna-discharge unit, connection to
grounding electrode, and requirement for the grounding electrode.
Lightning - For added protection for this television equipment
during a lightning storm, or when it is left unattended and
unused for long period of time, unplug it from the wall outlet
and disconnect the antenna. This will prevent damage to the
equipment due to lightning and power-line surge.
IMPORTANT SAFETY PRECAUTIONS(Continued)
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTROCE SYSTEM
(NEC ART250,PARTH)
GROUND
CLAMP
ELECTRIC
SERVICE
EQUIPMENT
Power Lines - Anoutside antenna system should not be
located in the vicinity of overhead power lines or other
electric light orpower circuits, orwhere it can fall into such
power lines or circuits. When installing an outside antenna
system, extreme care should be taken to keep from touching
such power lines or circuits as contact with them might be fatal.
To prevent fire, never place any type of candle or naked
flames on thetop or near the TV set.
Toprevent fire or shock hazard,do not expose this products
to dripping orsplashing.No objects filledwith liquids, such
as vases, shouldbe placed on the products.
ENGLISH

6
CONTENTS
IMPORTANT INFORMATION..............................................................................
IMPORTANT SAFETY PRECAUTIONS...............................................................
CONTENTS......................................................................................................
SUPPLIED ACCESSORIES................................................................................
PREPARATION.................................................................................................
REMOTE CONTROL OVERVIEW........................................................................
PDPTV CONTROLS OVERVIEW........................................................................
CONNECTORS OVERVIEW...............................................................................
BASIC OPERATION..........................................................................................
SELECTING MENU ITEMS.................................................................................
ADJUSTMENTS ...............................................................................................
CONNECTING EXTERNAL DEVICES................................................................
TROUBLESHOOTING.......................................................................................
SPECIFICATIONS.............................................................................................
Page
1-2
3-5
6
7
8-11
12-13
14
15
16-17
18
19-27
35
36-38
39
ENGLISH

SUPPLIED ACCESSORIES
Make sure the following accessories are included in the product packaging.
7
ENGLISH
Remote Control Instruction Manual
AC cord 2 X"AAA" Size Batteries
OK
MUTEMTS
POWER
BRIGHT
ZOOM VOL CH
123
456
789
0
DISPLAY YPbPr
SCREEN SIZE
SWAP
PIP ON
-
SLEEP
RECALL
MENU
ENTER
EXIT
SOURCE
MULTI-PIP
FREEZEPARENTALCC

PREPARATION
Using the Remote Control
Cautions regarding useof the remote control
Do not exposethe remote control to shock.
In addition, do not expose the remote control to liquid, and do not place in an area with high
humidity.
Do not install or place the remote control under direct sunlight. The heat may cause deformation
of the unit.
The remote control may not work properly if the remote control sensor window of the main unit is
under direct sunlightor strong lighting. In such case,change the angle of the lighting or PDP
TV set, or operate the remote control closer to the remote control sensor window.
Installing the Batteries
Before using the PDP TV set for the first time, insert 2 "AAA" size batteries into the remote control
(supplied). When thebatteries become depletedand the remote control fails to operate, replace
the batteries withnew (AAAsize) batteries.
Cautions regarding batteries
Improper use of batteries can result in chemical leakage and/or explosion. Be sure to follow the
instructions below:
Insert batteries withtheir terminals correspondingto the (+) and (-) as indicated in thecompartment.
Different types of batteries have different characteristics. Do not mixbatteries of different types.
Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries
and/or cause the old battery to leak .
Remove batteries when they become weak. Chemicals that leak from batteries can cause a rash.
If chemical leakage is found, wipe clean with cloth.
The batteries supplied with the product may have a shorter life expectancy due to storage
conditions.
If the remote control will not be used for an extended period of time, remove the batteries from the
remote control.
Caution!
8
Power on LED
Use the remotecontrol by pointing it towards the remote control sensorwindow on the main unit.
Objects between the remote control and sensor window may prevent proper operation.
ENGLISH
1. Press coveredge & pull it to
open the battery cover.
3. Press the battery cover
down.
2. Insert both batteries noting
the polarity markings.
OK
MUTE
MTS
POWER
BRIGHT
ZOOM VOL CH
1
23
456
789
0
DISPLAY YPbPr
SCREENSIZE
SWAP
PIP ON
-
SLEEP
RECALL
MENU
ENTER
EXIT
SOURCE
MULTI-PIP
FREEZE
PARENT
AL
CC

PREPARATION (Continued)
Antenna Connection
ANTENNA
2. A300-ohm system is a flat "twin-lead"cable that can be
attached to a 75-ohm terminal through a 300-75-ohm
adapter (not supplied)
1. A75-ohm system is generally a round cable with F-type
Connector that can easily be attached to a terminal without
tools (not supplied).
OUTDOOR ANTENNACONNECTION
Use one of the following two diagrams if you connect to an outdoor antenna
A: Using a VHF/UHF combination outdoor antenna
B: Using separate VHF and/or UHF outdoor antennas
Connect the outdoorantenna cable lead-into ANT. (Antenna terminal)on the rear of the TV set.
F-type connector
75-ohm coaxical cable(round)
300-ohm twin leadcable (flat)
Separate VHF AND/OR
UHF Antennas
UHF antenna
300-ohm
twin-lead
VHF antenna
75-ohm
coaxical cable
300-ohm
twin-lead
Combiner
(not supplied)
OUT INOUT IN
9
The antenna requirements for good color television reception are more important than
those for black & white television reception. For this reason, a good quality outdoor
antenna is strongly recommended.
The following is a brief explanation of the type of connections that are provided with the
various antenna systems.
ENGLISH

PREPARATION (Continued)
Antenna Connection (Continued)
CABLE TV (CATV) CONNECTION
A 75-ohmcoaxial cable connector is built into the back of the PDP TV for easy hookup. When
connecting the 75-ohm coaxial cable to the set, screw the 75-ohm cable to the ANT. Terminal.
Some cable TV companies offer "premium pay channels" Since some of these premium pay
channels are scrambled, a cable TV converter/descrambler is generally provided to the
subscriber by the cable TV company. This converter/descrambler is necessary for normal viewing
of the scrambled channels. (Set your TV to channel 3 or 4, typically one of these channels is used.
If this is unknown, consult your cable TV company.) For more specific instructions on installing
cable TV, consult your cable TV company. One possible method of utilizing the converter
/descrambler provided by your cable TV company is explained below:
"A"position on the RF switch (not supplied):You can view all unscrambled channels
by using the TVs channel keys.
"B"position on theRF switch (not supplied):theconverter/descrambler by using the converters
channel keys.
Consult your Dealer or Service Center for the type of splitter, RF switch or combiner that might
be required.
1. Turn on power switch.
2. PlugAC cord(supplied)to productand wall outlet.
Power Connection
Use only a recommended AC plugcode, if necessary, depending on the design of the wall
outlet.
Unplug the AC cord from the product and power outlet when not using the TV for a long period of
time.
Two-set
signal
splitter
(not
Supplied)
Cable TV converter/
descrambler (not supplied)
A
IN
B
OUT Cable TV Line
Household power outlet
AC cord
10
Please note:An RF switch provided with two inputs (Aand B) is required (not supplied).
NOTE
NOTE
ENGLISH

REMOTE CONTROL OVERVIEW
Button Descriptions
11
Press to turnon and off the TV.
Press to select the applicable input source.
Press to selectpicture brightness .
Press to mute the sound. Press again to restore the sound.
Press repeatedly tocycle through the Multi-channel TV sound MTS options:
MONO, STEREO. and SAP.
Press repeatedly toscroll through the screen size options:4:3, ZOOM ,
Full screen.
Press to selectthe Closed Caption Function, see page 27 for further details.
Press to freeze the picture. Press again to restore the picture.
Press once todisplay the current channel number, available main and PIP
connections.
Press repeatedly tostep through the 30MIN, 60MIN,90MIN, 120MIN, and OFF
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
POWER
SOURCE
BRIGHT
MUTE
MTS
SCREEN
SIZE
CC
FREEZE
DISPLAY
SLEEP
ENGLISH
8.
9.
10.
23.
12.
2.
16.
17.
18.
4.
3.
20.
25.
14.
5.
6.
7.
19.
21.
22.
24.
11.
13.
15.
1.

Press to select PARENTAL CONTROLS, see page 25.
Press to select HDTV picture if you connect a DVD player or digital set-top-box
to YPbPr jacks. Note that the DVD player or the digitalset-top box needs to
have a built-inHDTV tuner, and you need to be tuned into an HDTVchannel to
receive HDTV qualitybroadcasts.
Press to display the menu screen.
Press EXIT to exit from the menu screen.
Press to jump back and forth between two channels. The TV alternates
between the current channel and the last channel that was selected.
Press to enter and to set the function you choose in the menu screen.
Press to scan through channels. To scan quickly through channels, press and
hold down either CH .
Press to adjust the volume.
/
19.
20.
21.
22.
23.
24.
25.
PARENTAL
YPbPr
MENU
EXIT
RECALL
OK
CH /
VOL +/-
ZOOM +/-
0-9
PIP-ON
SWAP
MULTI-PIP
ENTER
12
11.
12.
13.
14.
15.
16.
17.
18.
Press ZOOM + to enlarge picture, press ZOOM - to shrink picture.
Press 0-9 toselect a channel;the channel changes after 3 seconds.
Press repeatedly to cycle through the PIP size, PBP and POP picture.
See page 22for further details.
Press to exchange main and sub picture in PIP, PBPand POP mode.
Press to let you operate Multi-PIP function, see page 23.
Press to move thecursor on screen.To select anitem please press
the "OK"button.
Press to enter and to set the function you choose in the menu screen.
REMOTE CONTROL OVERVIEW(Continued)
Button Descriptions
ENGLISH

LCD TV CONTROLS OVERVIEW
13
REMOTE CONTROL RECEIVER
POWER ON/OFF
SOURCE
MENU
VOL+
VOL-
CH
CH
NOTE
SOURCE, CH / , VOL +/-, and MENU button on the main unit have the same functions as
the same buttons on the remote control. Basically , this operation manual provides a description
based on operation with the remote control.
ENGLISH

14
CONNECTORS OVERVIEW
VHF/UHF Primary RF input connects to your VHF/UHF antenna or
cable.
S-VIDEO Connect to the S-VIDEO OUT jack of your VCR or other video equipment
that has S-VIDEOoutput jack S-VIDEO provides betterpicture quality th
ither composite video or VHF/UHF connections.
VIDEO Connect to the composite A/V output jacks on your VCR or other video
component.
YCbCr Video equipment connected to the YCbCr input terminals.
from 480 interlace output equipment is available.
YPbPr Connect to yourDVD player's or digital set-top box's component video(Y,
Pb,Pr) and audio(L/R) jacks. Component video provide better picture quality
than r .
Connect to the left and ight udio input jacks of your audio amplifier. Youcan
LINE OUT R/ L use these outputsto listen to your TV's a dio through your stereo system.
through tuner that
an
e
component ( )
Use when signal
,o
AUDIO
1.
2.
3.
4.
5.
6.
1.
1. 2.
3.
3.
ENGLISH
YCbCr
YPbPr
VIDEO
AUDIO
AUDIO OUT
AUDIO
S-VIDEO
VHF/UHF
1.
4.
5.
2.
3.
6.

15
CONNECTORS OVERVIEW(Continued)
DVI INPUT JACK
PC(RGB INPUT JACK(15pin)
AUDIO LINE-IN
SERVICE PACK
1.
2.
3.
4.
Receives the digital video/audio signals from PC.
The DVI input is including HDCP.
Connect to the video/audio output jack on your PC.
PC "SOUND CARD"input 3.5mm jacket terminal.
For service only.
ENGLISH
1. 4.
2.
3.

BASIC OPERATION
16
SELECTING AN INPUT SOURCE
MAIN SOURCE
NOTE
VGA
DVI
S VIDEO
AV
YCbCr
TV
YPbPr
1. Turn on the power of the connected
Video equipment.
2. Press SOURCEand / to
select the main input source you
want to view.
The AV input mode indication
remains for 10seconds.
3. VGAand DVI:
Connects to the VGA&DVI jack of
your Personal computer(PC). Note
that a DVI port is not a very common
jack on aPC as it requires a PC
which has adigital video card .
4. S VIDEO:
Connects to theS VIDEO out jack
of your VCR on other video
equipment that hasS VIDEO.
5. AV:
Connects to thecomposite
AV output jacks on your VCR or
other video component.
6. YCbCr :
Video equipment connected to
the YCbCr input terminals.
7. TV:
VHF/UHF/CABLE connect to
the ANTENNA TERMINAL.
8. YPbPr:
Video equipment (such as
HDTV) connected tothe YPbPr
input terminals. Playback from
output
equipment is available.
SOURCE
MENU
VOL+
VOL-
CH
CH
ENGLISH
2.

BASIC OPERATION(Continued)
SELECTING VIDEO PIP SOURCE
PIP SOURCE
1. Press SOURCE twice to show
the available PIP sources. The
available PIP sources will show
up in blackletters and are
available for selection. The
disabled PIP sources will show
up in grey letters and will notbe
available for selection.
2. Press / to select thePIP
source you want to use and then
press the OKbutton to
confirm your choice
17
If you want to use the PIP function you will have to connect a PIP source(see page 33,34,35)
ENGLISH
VGA
DVI
S VIDEO
AV
YCbCr
TV
YPbPr
1.
2.

18
SELECTING MENU ITEMS
This LCD TV set allows you to adjust the various setting using the menu screen. Select the desired
menu item byfollowing the stepsand then refer to the indicated page for details.
1. Press MENU to display the MENU screen.
2. Press either the VOLUME +/- buttons on the remote control or TV to select the sub-menu
(The desired menu& sub-menu itemwill change to yellow when it is selected.)
NOTE
The displayed items depend on the setting conditions.
To return tothe previous screen , press either remote controller EXIT or TV's MENU/EXIT
button.
s
PARAMETERS
PC
PARAMETERS
AUDIO
SETTING
PICTURE-
IN-
CHANNEL
SETTINGS
PARENTAL
CONTROL
GENERAL
SETTINGS
BRIGHTNESS
CONTRAST
SATURATION
HUE
COLOR TEMP
FLESH TONE
SHARPNESS
AUTO
POSITION
AUTO COLOR
BASS
TREBLE
BALANCE
EQUALIZER
LINE OUT
VOLUME
PIP SIZE
MULTI PIP
SYSTEM
CHANNEL EDIT
LOCK MENU
MPAARATING
TV PG RATING OSD
LANGUAGE
OSD
TIMEOUT
I/P INFO
FACTORY
RESET
ENGLISH
BACKLIGHT
BOOT SCREEN

19
ADJUSTMENTS
Video adjustments have different selection items depending onAV mode (signal from external
device).
ADJUSTING PICTURE PARAMETERS SETTINGS
PARAMETERS
BRIGHTNESS
CONTRAST
SATURATION
HUE
COLOR TEMP
FLESHTONE
SHARPNESS
1. Press MENU to display the MENU
screen.
2. Press / move the cursorto
PICTURE PARAMETERS menu.
3. Press / to move thecursor to
the desired item,BRIGHTNESS
/CONTRAST/SATURATION etc.
The selected item changes to RED.
4. Press / to adjust the
highlighted setting.
5. Press EXIT button once to return
to the main menu.
6. Press EXIT button again to return
to the main screen.
ENGLISH
1.
2.
5.
3.
6.
4.

ADJUSTMENTS(Continued)
20
PC adjustments havedifferent selection items depending onVGA/DVI mode (signal from PC).
This setting isonly available when a PC is connected via aVGA/DVI cable to the TV.
ADJUSTING PC PARAMETER SETTINGS
1. Press MENU to display the MENU
screen.
2. Press / to move thecursor to
PC PARAMETERS menu.
3. Press / to move the cursor to the
desired item,AUTO/POSITION/AUTO
COLOR etc. The selected item changes
to GREEN.
4. Press OK to enter the setting
you have highlighted.
5. Press / to adjust display position.
6. Press EXIT to return to the main menu.
7. Press EXITbutton again to return to
the main screen.
PC
PARAMETERS
AUTO
POSITION
AUTO COLOR
NOTE
AUTO: PC configuration is set automatically.
POSITION: To set video signal from PC for best viewing position.
AUTO COLOR: Configures the video signal from the PC to provide
best picture.
ENGLISH
2.
6.
3.
7.
5.
4.
1.
