Spa Electrics MATRIX LSL Series Installation instructions

LANDSCAPE STRIP LIGHT
INSTALLATION
LSL SERIES

1
SPECIFICATIONS
INPUT:
MAX STRIP LENGTH :
MAX CABLE LENGTH:
FUSE:
12V AC 2A ONLY
5 METERS (TOTAL)
40M - (USE ONLY MATRIX EXTENSION CABLES)
TOTAL LAMP WATTS: 25W MAX
2A BLADE FUSE
OUTPUT: 24V DC 1A MAX
1
2
3
4
6
SPECIFICATIONS
READ THIS FIRST
INCLUDED PARTS
INSTALLATION MOUNTING
WIRING

2
BEFORE YOU START:
• MATRIX cables are supplied with pre-fitted quick connect plugs to reduce installation hassle and
guarantee reliability. These cables should not be cut, joined or modified in any way from their
original condition.
• Ensure that the power supply used to operate this system is installed by a qualified person (e.g.
Registered pool builder and/or licensed electrician), in accordance with the most current edition
and/or amendment of the AS3000 wiring code.
• For safe and proper installation, ensure that only those parts supplied with the system are used.
• Lights should only be mounted in a location that is readily accessible after the installation is
complete. Spa Electrics will not be liable for installation of its products in locations that are
deemed non-servicable.
CLEANING
• Only use warm water and a soft brush or cloth to clean MATRIX series lights. DO NOT use
detergents or spirits as this can damage the light and void your warranty.
USE
• Operating the light for at least 15 minutes every week is advised (all year round).
•Temperature range for installation, operation and servicing: 0oC ~ +40oC
Congratulations on your purchase of a MATRIX lighting system. All Spa Electrics lights are
designed and manufactured in Australia from only the highest quality materials. For more
information on Spa Electrics and our products, please visit www.spaelectrics.com.au
Minimum power source wattage requirement - 25 Watts per driver.
Maximum total strip light length per driver = 5 Meters
• DO NOT use electronic or switch-mode transformers. These transformers will damage the light and
void your product warranty.
• Pool chemicals & PH levels: Due to the corrosive nature of unbalanced pool chemicals, Spa
Electrics strongly recommend that your pool water is balanced prior to installing your lights or any
plastic or stainless steel components, and tested weekly to maintain these levels. pH levels should
be maintained between 7.2 – 7.6 at all times to ensure the longevity of these components.
> Failure to do so can result in chemical damage to the light housing and pool fittings,
including stainless steel components.
> Please note: Lights or components found to have excessive chemical damage will not
be covered under our manufacturer’s warranty policy

3
STRIP LIGHT DRIVER
1M INPUT POWER CABLE 20M STRIP LIGHT
POWER CABLE
5M STRIP LIGHT
ADDITIONAL EXTENSION
CABLES AVAILABLE IN
20,30,40M LENGTHS.
CONTACT SPA ELECTRICS FOR
MORE INFORMATION.

4
REMOVE ADHESIVE
PEEL COAT.
POSITION STRIP LIGHT
IN DESIRED LOCATION.
INSTALLATION – MOUNTING
STEP 1
1
STEP 2
2
ENSURE SURFACE IS
CLEAN AND FREE OF
MOISTURE & DEBRIS.

STEP 3
3
Continue to next section
PRESS FIRMLY TO ENSURE
A SOLID BOND.
EACH STRIP LIGHT CAN BE SHORTENED BY SIMPLY TRIMMING TO THE DESIRED LENGTH
USING A PAIR OF SCISSORS. THERE ARE TRIM MARKS VISIBLE ON THE FRONT AND BACK
OF THE STRIP LIGHT TO HIGHLIGHT THE APPROPRIATE TRIM LOCATION.
ONCE THE STRIP LIGHT IS TRIMMED, SIMPLY GLUE THE SPARE END CAP ON THE EXPOSED
END USING NEUTRAL SILICONE.
STRIP LIGHT TOO LONG?
ADDITIONAL CLIPS OR
NEUTRAL ADHESIVES
MAY ALSO BE USED
IF REQUIRED.
5

6
INSTALLATION – WIRING
STEP 1
1
STEP 2
2
ALIGN KEY WAY AND
PRESS PLUG HALVES
TOGETHER.
TIGHTEN PLUG COLLAR
FIRMLY BY HAND.

STEP 3
3
STEP 4
4
CONNECT STRIP LIGHT
POWER CABLE TO DRIVER
BY ALIGNING KEY WAY AND
PUSHING ONTO MATING
CONNECTOR.
CONNECT INPUT
CABLE TO DRIVER
BY ALIGNING KEY WAY AND
PUSHING ONTO MATING
CONNECTOR.
5 PIN CONNECTION
TO STRIP LIGHT
TO 12V AC POWER SUPPLY
2 PIN CONNECTION
7

This lighting system is compatible
with the following power supplies /
controllers.
∙ LiT YARD4 CONTROLLER
∙ LV SERIES TRANSFORMERS
∙ iRIS REMOTE CONTROL
∙ 3rd PARTY POOL CONTROLLERS
MAX LENGTH 1M
TO STRIP LIGHT
STEP 5
5
Smart Outdoor Lighting Controller
SYSTEM COMPATIBLITY
MOUNT THE DRIVER
WITHIN 1 METER OF
THE CHOSEN POWER
SUPPLY.
8

20200407
2020
Spa Electrics
