AMP Lighting OrchardPro APL-3018-B-BZ Operating and safety instructions

- 1 -
INSTALLATION & MAINTENANCE GUIDE
Help Hotline:
1-813-978-3900 • Mon-Fri 9am-6pm (EST)
www.amplighting.com
AMP®Low Voltage Landscape Lighting
AMP® OrchardPro Path Light (Lamp - Ready)
APL-3018-B-BZ

Package Contents
Product Dimensions
A. (1) Fixture Body
B. (1) Shade
C. (1) Stake
10” 8”
2”
26”
D. (1) LED Lamp
E. (1) Diffuser
- 2 - - 3 -
LIGHTED LAMP IS HOT!
WARNING – TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS.
1. Turn off/unplug and allow to cool before reducing lamp.
2. Lamp gets HOT quickly!
3. Do not touch the hot lens, guard or cowl.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time.
6. Use a soft cloth.
7. Oil from skin may damage lamp.
8. Do not operate the xture with a damaged or missing lens or shield.
This xture is intended for installation in accordance with local codes and
the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situation.
1. Make sure that the power is turned OFF before installing or servicing this
xture.
2. Warning: this xture is not intended to be installed within 10 feet [3
meters] of a pool, spa or fountain.
3. This xture is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.
4. Underground Low Energy Cable must not be buried over 6” (15.2 cm) in
order to connect to the main low voltage cable.
5. Wiring connections must be made with UL Listed wire connectors that is
suitable for outdoor use.
6. Position the wire connector so that it is located within 6 inches (15.2
cm) from a building structure, a luminaire, or tting.
AMP®OrchardPro Path Light (Lamp - Ready)
APL-3018-B-BZ
INSTALLATION & MAINTENANCE GUIDE
Important Safety Instructions: Read Before Installation
!
Important Safety Instructions: Read Before Installation
!
www.amplighting.com [email protected] • 813.978.3900

Install Fixture Body to Stake
2
Clear away an area in the ground at
the wireway slot on top of the stake.
Lay the luminaire pigtail into the
wireway slot and thread the coupler
at the bottom end of the xture body
onto the stake. Tighten until snug to
secure the base.
Fixture Body
Stake
Pigtail
Wireway Slot
Install Stake
1
Board
Stake
Soil
Ground
- 4 - - 5 -
Determine the desired location for mounting
the luminaire. Hammer the stake into the
ground until ange of stake is ush to grade.
To avoid damage to the stake, place a board on
top of the stake while hammering.
NOTE: If the ground is hard and the stake
is difcult to install, make a crosscut in the
ground using a at shovel.
AMP®OrchardPro Path Light (Lamp - Ready)
APL-3018-B-BZ
INSTALLATION & MAINTENANCE GUIDE
www.amplighting.com [email protected] • 813.978.3900
Wire Connection
3
Strip both leads from the luminaire pigtail. Using two wire connectors (sold
separaetly), connect the leads from the luminaire to the main supply cable leads.
Pigtail
Main Supply Cable
Wire Connectors
Remove Dome Lens
Install Bulb
4
5
Loosen the dome lens from the
holder to expose the socket.
Insert bulb with the correct wattage
and type marked on the xture label.
CAUTION: Do not exceed maximum
wattage marked on luminaire label.
NOTE: DO NOT touch bulb with bare
hands. Use soft cloth to handle bulb.
Holder
Socket
Dome Lens
Bulb

- 7 -- 6 -
www.amplighting.com [email protected] • 813.978.3900
AMP®OrchardPro Path Light (Lamp - Ready)
APL-3018-B-BZ
INSTALLATION & MAINTENANCE GUIDE
Install Dome Lens
6
Thread the dome lens back onto the
holder and hand tighten.
Dome Lens
Holder
Install/Replace Bulb
Please reference Step 4 - Step 6 to expose the Bulb and replace it with the
correct wattage and type marked on the xture label. Reinstall Shield.
IMPORTANT: LED Bulb must be protected from moisture and dust at all
times. Always reinstall shield when removed.

- 8 -
