Space Television Space Ultra Plus User manual

HELPLINE 0861 40 41 42 • www.sPacEtv.co.za
wItH INtEgratEd FIbrE oPtIc PowEr MEtEr
handheld combo meter
ULTRA+ Combo Meter - User Manual
Screen
2.7”
neW

HELPLINE 0861 40 41 42 • www.spacetv.co.za
2
1. MAIN FEATURES 3
2. BUTTONS AND INDICATORS 5
3. HOW TO MEASURE 6
4. HOME MENU 7
5. DVB-S/S2 7
5.1 SATELLITE FINDER 7
5.1.1 ZOOM 8
5.1.2 MULTI TP 8
5.2 LNB SETTING 9
5.3 EDIT SATELLITE 11
5.4 SPECTRUM CHART 11
5.5 ANGLE CALCULATION 12
5.6 Sat IDENTIFICATION 14
6. DVBT/T2/ISDBT 15
6.1 TERRESTRIAL MEASURE 15
6.2 AUTO SCAN 16
6.3 RF CHANNEL LIST 16
6.4 SCOPE 16
6.5 SPECTRUM CHART 16
6.6 ANT POWER 16
Please refer to the following notes before use.
• Please read this user manual carefully to be able to
safely use and maintain your meter.
• The technical specications and operation guides
in this manual are subject to changes
without notice.
• Before using the rst time, please charge the
battery for 3 hours.
• Please use the special adapter for charging
with the meter, do not use it for other
products
• In case of any technical questions, please contact
SpaceTV.
7. DVB-C 17
7.1 CABLE MEASURE 17
7.2 AUTO SCAN 17
7.3 RF CHANNEL LIST 18
7.4 TILT 18
7.5 SPECTRUM CHART 18
8. ANALOGUE TV 19
8.1 MEASURE 19
8.2 TILT 20
8.3 SPECTRUM 20
9. OPTICAL POWER 20
10. SYSTEM SETTING 20
11. ACCESSORIES 21
12. TROUBLE SHOOTING 21
13. TECHNICAL SPECIFICATION 22
CONTENTS:

HELPLINE 0861 40 41 42 • www.spacetv.co.za 3
Thank you for purchasing this product. For optimum performance and safety, please read these
instructions carefully before connecting, operating or adjusting this product. Please keep this
manual for future reference.
1. MAIN FEATURES
• Supports DVBS/DVBS2/DVBT/DVBT2/DVBC/
DVBC2 / MCNS / OPTICAL / ANALOGUE
• LNB short-circuit protection and indicator.
• Extremely fast and accurate with high
sensitivity.
• 400*360 colour LCD display with
controllable back light.
• Database editable by user.
• Audible signal lock notication.
• Optical power level measurement.
• All DiSEqC protocol monitor based on 22KHz
tone.
• Firmware can be upgraded by USB port.
• Power-supply100-240V/50/60Hz 12V@1A.
• Ultra-long standby, low power
consumption.
• Fast charging Li-ion battery that can last up
to 3 hours of use.
DVB-S/S2
• Real time Spectrum-Analyzer.
• Transponder message detection.
• Angle calculation of azimuth and elevation.
• Azimuth and elevation measurement.
• Augmented reality satellite alignment tool.
• Power, CNR, CBER, VBER(DVBS),
LBER(DVBS2) Modulation mode display.
• DiSEqC1.0, DiSEqC1.2, USALS,SCD and SCD2
supported.
• Auto DiSEqC identication for DiSEqC1.0
• Cable identication for Quattro LNB
DVB-T/T2
• Power, VBER(DVBT), LBER(DVBT2) SNR and
CBER display.
• Spectrum analyzer
• SCOPE Display
• Channel Auto Scan
DVB-C/C2/MCNS
• Power, BER, PER(DVBC/MCNS),
LBER(DVBC2), SNR and Symbol Rate display
• Spectrum analyzer
• Channel Auto Scan
• Tilt Display
Optical Power
• Highly accurate optic power measurement.
• Optic wavelength 860 ~1610nm
• -50dBm to +23dBm

HELPLINE 0861 40 41 42 • www.spacetv.co.za
4
2
3
5
7
12
10
11
91
4
6
8

HELPLINE 0861 40 41 42 • www.spacetv.co.za 5
2. BUTTONS AND INDICATORS
LNB Input:
Signal input port for DVB-S. Connects
directly to LNB using coaxial cable.
Antenna Input:
Signal input port for DVB-T and DVB-C and
ISDB(T). Connect directly to Antenna using
coaxial cable.
Charge Light:
Red: the battery is being charged.
Green: the battery is full.
Warning Light:
This will ash if there is a short circuit.
Working Light:
Green: the meter is in working status
Function Keys:
F1: Turn on/o the screen display
F2: Enable/disable beep when pressing
keys
F3: Enter to TP control menu in Satellite
Measure menu
F4: Enter to Auto DiSEqC function in
Satellite Measure menu
Note: Press to display help bar on
menus to get more information.
Navigation Keys:
/: Move focus or change value.
/: Move focus or change value
1. Turn the meter on/o, press and hold
for 2 seconds to power on the meter.
2. Press to show help bar on each menu.
Optical port:
Optical input port.
MENU:
Go into main menu or exit from the
current menu
OK:
Conrm
Charging:
Connect with the charger cord to charge
the meter.
1
2
3
4
5
6
7
8
9
10
11
12
