Spacesaver 90300 User manual

(Fits most TV sizes weighing up to 50 lbs)
Model: 90300
Questions, problems, missing parts? Before returning to the store,
call STC Customer Service
9 a.m. - 5 p.m., Monday to Friday
Toll Free 1-833-GOSTCNY (1-833-467-8269)
STCNY.COM
Full Motion Wall Mount for Flat Panel TVs

This mount has been tested to
support televisions with maximum
weight as follows: WOOD STUDS,
BRICK,CONCRETE WALLS:
50lbs. (22.7kgs)
Before you begin, carefully read and understand the instructions
in this manual. Please follow the instructions in the order
presented in this manual and observe all warnings and cautions.
16.85"(428mm) 3.15"(80mm)

Toll Free 1-833-GOSTCNY (1-833-467-8269)
AA
Nylon anchor 4
4
4 each
4 each
8 each
AA
BB
CC
DD
EE
Lag bolt
Screw (size M4x14,M5x14,M6x14,M4x30,M5x30,M6x30,M8x30,M8x50)
Washer (size D5 and D8)
Spacer (size Φ15xΦ8x5 and Φ15xΦ8x15)
CC
BB
DD EE
NOTE: The hardware included is suitable for
mounting to walls made of brick, solid concrete
using (AA and BB). If your
mounting situation is different, please consult a
qualified installer or contact customer service
at: 1-833-467-8269
A
D E F G
B C
Wall Mount 1
1
4
4
A
Cable managementB
VESA adapterC
D Screw
4
E Nut
1
F Allen key
1
G Wrench

Screw is too
long
Screw is too
short
Screw ts
correctly
To ensure proper mounting of the brackets to your
TV, this mounting system includes several sizes
(M4, M5, M6, and M8) of screws (DD).
Select the screw diameter to use by inserting
the various sized screws (M4, M5, M6, and M8)
into the mounting holes in the back of your TV
to identify the right size.
10 20 30 40 50 60 70 80 90 100mm
1 2 3 4in
CAUTION: To avoid potential personal injuries and property
damage, make sure that there are adequate threads to secure the
brackets to your TV. If you encounter resistance, stop immediately and
contact customer service. Use the shortest screw and spacer
combination toaccommodate your TV. Using hardware that is too
long may damage your TV. However, using a screw that is too short
may cause your TV to fall from the mount.

Toll Free 1-833-GOSTCNY (1-833-467-8269)
3
Pull the arm out and then remove the VESA plate and the decorative cover to start assembling.
Arranging the wall plate
4
Installing the VESA adapter
VESA 100x100,200x100,200x200
VESA 400x200,300x200VESA 300x300,400x400
EG
D
EG
D
EG
D
VESA 400x300
15.74"(400mm)
15.74"(400mm)
11.81"(300mm) 15.74"(400mm)
11.81"(300mm)
7.87"(200mm)
11.81"(300mm) 15.74"(400mm)
11.81"(300mm)
7.87"(200mm)
3.93"(100mm)
7.87"(200mm) 3.93"(100mm)
G
G

TVs ≤ 200 VESA
Attaching the mounting brackets to the TV
CAUTION:Tighten the screws so the brackets
are firmly attached. DO NOT OVERTIGHTEN. This
may damage your TV.
EE
DD
CC
TVs > 200 VESA
Use of the spacers (FF) will vary depending on the type of TV you will be mounting.
DD
CC
EE

Toll Free 1-833-GOSTCNY (1-833-467-8269)
For Plasterboard/ Sheetrock walls mount directly on the board, no stud is required.
PLANNING WALL PLACEMENT
5

8
Installing the wall plate (concrete/brick wall)
21
3 4
6
AA BB
Use 1/4 in (6mm) drill bit to drill a pilot holes and then use a 3/8 in (10 mm) masonry drill bit to slowly drill
2.4 in (60 mm) holes.
(10 mm) 3/8”(6 mm) 1/4” (60 mm) 2.4”

9
Toll Free 1-833-GOSTCNY (1-833-467-8269)
8
Installing the decorative cover
7
Use a commercially-available stud finder to locate the stud centers in the wall. Studs are usually spaced 16 in. apart.
Use a 3/16 in. (4.5 mm) drill bit to slowly drill 2.2 in. (55 mm) pilot holes.
Installing the wall plate (wood stud)
21
3 4
BB

10
Mounting the TV to the wall plate
Secure the TV
HEAVY! You will need
assistance with this step.
9
Managing the cable
Remove the cable management
Pass the cables and connect the cable management back in place
10
B
G
G

11
Toll Free 1-833-GOSTCNY (1-833-467-8269)
To adjust the tilting position, release the screws by using the Allen key, adjust the best tilting position
and tight the screws to keep the position.
Adjusting the TV to the desired position
11
STEP 1: MOVE LEG 1 into the housing. STEP 2: POSITION LEG 2 at the approximate angle
shown to avoid contact with the decorative plate.
STEP 3: MOVE LEG 2 and your TV backward and into the decorative rear housing.
To fold the mount into the decorative rear housing
12
F
1
2
