Sparsh Elegant Series User manual

User Manual
V1.0

DESCRIPTION
The camera uses SONY charge coupled device (CCD)
image sensor, and employs digital signal processing
(DSP) chip-set for image control, and all integrated state
circuitry which provides extremely long life and high
reliability. This camera offers excellent image quality, and
is not subject to distortions from magnetic fields. High
resistance to shock and vibration, and easy to install, this
camera is the best choice for your CCTV system.
TRADEMARKS
Sparsh logo is registered trademarks of Samriddhi
Automations Pvt. Ltd.
SONY, SONY Super HAD & SONY Super HAD-II is
registered trademark of Sony Incorporation.
All other brand, product names, and service names are
trademarks or registered trademarks of their respective
companies or organizations
LIMITATION OF LIABILITY
•This publication is provided “as is” without warranty
of any kind, either express or implied, including but
not limited to, the implied warranties of
merchantability, fitness for any particular purpose, or
non-infringement of the third party’s right.
•This publication could include technical inaccuracies
or typographical errors. Changes are added to the
information herein, at any time, for the improvements
of the publications and/or the corresponding
product(s).
WARNINGS & CAUTIONS
•The information provided in the user manual is for the
safety of the customers. Please read the user manual
before operating the product and follow the
instructions provided accordingly.
Warning Messages
•Do not install under excess hot conditions.
Optimum operational temperature range is 0°C and
+50°C.
•Do not install under varying light conditions.
Continuously varying light frequency might cause
problems in the normal functioning of the camera.
•Do not put camera under shocks and jerks.
This may cause the serious disorientation or the
distortion in the components thereby causing the
malfunctioning of the product.
•Do not install under excess of humid conditions.
This may cause the deposition of water droplets on the
lens and several other sensitive components thereby
lowering the picture quality.
•Do not expose the camera directly to high light
intensity pulse.
This may damage the CCD or may create dead pixels
in the CCD.
•Do not expose camera to water.
This may result in malfunctioning of the camera or
may result in the corrosion of certain components due
to minerals contained in water.
•Do not expose camera to radioactivity.
Radioactive exposure may cause damage to CCD or
may produce dead pixels.
•Do not attempt to open the camera.
Unauthorized opening of camera is not permissible as
it could cause breakage of the fragile components.
•Do not use low quality cables and power supply.
Only recommended cables/wires and power supply
should be used for proper functioning of the camera.
If any abnormality occurs, make sure to unplug the
unit and contact your local dealer or our service centre.
INSTALLATION
•Installation must be carried out by the authorized
personals only.
•Surface on which the camera is to be mounted must
be strong enough to hold the camera firmly, if not so
reinforce the surface again so that the camera may not
fall off the surface.

CONNECTIONS:
The functions of connecting plugs or terminals are as
below:
Video Output terminal, BNC or RCA
DC 12V power supply plug

TROUBLESHOOTING
Problem Solution
No Video Check the power supply and line
connection between the camera and
monitor.
Image not
Clear
•
Check the surface of the lens
•Check the focus of the lens and
refocus it.
Weak
Contrast Check whether the camera is exposed under too strong light or not
Flicker
Image Check whether the camera face to the sun directly or strong light
Noise in
Video
•
Check illumination is low or not
•Check power supply voltage is low or
not
•Check proper wire connectivity

SPECIFICATIONS:
DOME CAMERA MODEL
SP3XXDS, SP3XXDN, SP3XXDVA49, SP3XXDV
XX – 45 (450 TVL), 48 (480 TVL), 54 (540 TVL)
MODEL SP3XXDS SP3XXDN SP3XXDVA49 SP3XXDV SP3XXCSN
Camera Type Dome with DIP
Switch Elegant Dome Vari Focal Auto Iris Dome Vandal Proof Dome Camera C/CS mount Camera
Image sensor 1/3 “ SONY SUPER HAD-II CCD
Effective Pixels NTSC: 510 (H) x 492V, PAL: 500 (H) x 582 (V) (For 450 TVL model)
NTSC : 768 (H) x 494 (V), PAL : 752 (H) x 582 (V) (For 480 & 540TVL model)
Operation Area Indoor Indoor Indoor Indoor Indoor
System View PAL/NTSC
Flicker less Switchable -
On/Off - - - -
Lens
3.6 mm Board Lens, Optional Lens:
2.5 / 6 / 8 / 12 / 16 / 25 mm Built in 4-9 / F 1.6
Optional 2.8-10 mm
/ F 1.6
3.6 mm Board
Lens, Optional
Lens: 2.5 / 6 / 8 /
12 / 16 / 25 mm
C/CS mount
S/N Ratio More than 48dB
Video output level 1.0vp-p (75 Ohms Composite Video Out)
Resolution 450TVL/480TVL/540 TVL
Min. Illumination 0.05 Lux / F2.0
White Balance Switchable -
On/Off ATWB Switchable -On/Off Switchable - On/Off Switchable -On/Off
AGC Switchable -
On/Off Auto Switchable -On/Off Switchable - On/Off Switchable -On/Off
Back Light
Compensation On/Off Auto On/Off On/Off On/Off
Audio Optional Optional Optional Optional Optional
Input Voltage 12 V DC 12 V DC 12 V DC 12 V DC 12 V DC
Current Drawn Approx. 90 m A Approx. 90 m A Approx. 200 m A Approx. 200 m A Approx. 250 m A
I/O Connectors DC FEMALE / BNC FEMALE
Operating
Temperature/Humidity 0°C to +50°C / 30% to 80% RH

IR CAMERA – SP3XXIRYY
SP3 1/3” Sensor
XX Resolution: 45,48,54 ( 450 TVL, 480TVL , 540
TVL)
IR IR Camera Range
YY IR Distance 10,20,30,40,50,70
W With FAN
MODEL SP3XXIRYYD SP3XXIRDV49L SP3XXIRYY SP3XXIR50W
Camera Type IR Dome Vari Focal IR Dome 10-
30Mtr. IR Box Camera IR with Heater & Fan
Image sensor 1/3 “ SONY SUPER HAD-II CCD
Effective Pixels NTSC: 510 (H) x 492V, PAL: 500 (H) x 582 (V) (For 450 TVL model)
NTSC : 768 (H) x 494 (V), PAL : 752 (H) x 582 (V) (For 480 & 540TVL model)
Operation Area Outdoor Outdoor Outdoor Outdoor
System View PAL/NTSC
Lens 3.6 mm Board Lens,
Optional Lens: 2.5 / 6 / 8
/ 12 / 16 / 25 mm
Built in 4-9 / F 1.6
Optional 2.8-10 mm / F
1.6
3.6 mm Board Lens,
Optional Lens: 2.5 / 6 /
8 / 12 / 16 / 25 mm
In-built 12mm C-
Mount Lens (Option
Vari-Focal)
IR Distance 20 mtr, 30 mtr 10-30 mtr. 10, 20, 30,40,50,70 mtr. 50 mtr.
S/N Ratio More than 48dB
Video output level 1.0vp-p (75 Ohms Composite Video Out)
Resolution 450TVL/480TVL/540 TVL
Min. Illumination 0.05 Lux / F2.0
White Balance ATWB ATWB ATWB ATWB
AGC Auto Auto Auto Auto
Back Light
Compensation Auto Auto Auto Auto
Audio Optional Optional Optional Optional
Input Voltage 12 V DC 12 V DC 12 V DC 12 V DC
I/O Connectors DC FEMALE / BNC FEMALE
Operating
Temperature/Humidity 0°C to +50°C / 30% to 80% RH
IR Distance IR LEDs
10 mtr. 12 Pcs 850nm /Ø 5 mm
20 mtr. 24 pcs 850nm /Ø 5 mm
30 mtr. 36 pcs. 850 nm /Ø 5 mm
40 mtr. 48 pcs. 850 mm / Ø 5 mm
50 mtr. 60 pcs. 850 nm/ Ø 5 mm
70 mtr. 12 pcs. 850 mm / Ø 10 mm
