93034033 CIMARRON CL1 LED INSTALLATION INSTRUCTIONS (PG 1/2)
SAVE THESE INSTRUCTIONS
WARNING! Fix tu res must be gr ounded a nd ins ta ll ed i n accor dan c e with the N at i ona l Electrical C ode a nd a ll local c ode s. Failur e to
do s o may incr ea s e th e RI SK OF P ER SO NAL IN JUR Y, PR OP ER TY D AMAGE, F IR E AND D E ATH . In s ta ll a nd u s e whe r e bu r nou ts d o
no t c au s e a ha zar d and u s e on ly i n envi r on m en ts fo r whic h the pr odu ct is s pe cifically ma rk ed .
WARNING! This p r odu ct c on ta ins c he micals kno w n to the S tate o f Cali fo rni a to c au s e c an cer, b ir th def ects, a nd /o r oth er r ep r odu ct ive
ha rm. T ho r ough ly was h hand s a f te r ins ta lli ng , h and li ng , cl ean i ng , o r oth e rwi s e to uchi ng th is p r odu ct.
CAUTION!Foll ow ALL lu mina ir e recomm en dat i on s, p r od u ct ma rk i ng s, in st ru ct i on s, re st ri ct i on s an d war ni ng s r eg ardi ng lumni na ire
op er at i on an d b urni ng po s it i on. Lu mi na ir e l abe l s ho ws e lectrical a nd e nvi r on m en ta l r equ irem en ts.
Al l ele ct rica l wo rk mu st b e d on e b y a qu al if i ed ele ct rici an.
Tu r n off e le ct ri c powe r to a l l affe ct ed circu it s an d a ll ow to c oo l bef or e ser vi ci ng.
A r egu larly sc hedu l ed mai nt enan c e pr og ram s hou l d be e s ta blis hed to r et ai n op timum li gh t out pu t a nd r edu c e hea t r et en ti on . Dusti ng
with a s of t, cl ean , d ry cl oth is n o rmal ly s uf fici en t. An y a ccumul at i on o f d ust o r d irt s hou l d be rem oved r egu larly from the l en s. Us e on ly a
mil d s oap y sol ut i on , DO NOT u s e a lka li ne o r a ci d cl eane rs.
Car ef ully r ead th es e instructi on s bef or e ins ta lli ng p r odu ct. If y ou do no t u nde rs ta nd th es e instructi on s, bef or e s ta rti ng a ny wo rk , c on ta ct
y ou r H ubbe ll L i gh ti ng d istri bu to r o r te chs uppo rt@ hubb ell-l tg .com o r ( 864 ) 6 78 - 1000
G iv e in st ru ct i on s to fa cil it y o wne r/m anag er fo r futu r e r efe r en c e.
701 M il l ennium Boul eva rd Gre en v il le , S C 29607 (8 6 4) 67 8- 1000 www.
spau lding-ltg. co m
C IM ARRON LED FIXTURE INSTALLATION
NOTE:
IT IS NOT NECESSARY TO OPEN THE FIXTURE FOR INSTALLATION
.
THE
FIXTURE HAS BEEN DESIGNED TO BE INSTALL ED BY REMOVING THE ARM
MOUNTING COVER ONLY .
WARNING: DISCONNECT POWER BEFORE INSTALLATION
CAUTION: FIXTURE WEIGHS ABOUT 50 POUNDS
1. MOUNTING PREPARATION (See Fig. 1)
Remove Arm Cover by removing the (4) Screws.
Remove Pole Cover
Pull the supply wires from Pole through Nut Plate
and into the Arm.
2. MOUNTING FIXTURE TO POLE
Attach Fixture to Pole with (2) ½” Hex Bolts,
Lockwas hers and Flatwashers into Nut Plate inside pole.
Torque Bolts to approx. 45 Ft - Lbs.
C OVE R - S Q POLE
N UT PLA TE
SQU ARE
ROUND
POLE
C OVE R - RN D P OLE
PO LE
ST RA IGHT S Q UARE A ND ROUND P O LES
FIG U RE 1
ARM
CAST
ADPTO R
SCRE W
FLAT WASHE R
HE X BOLT
LO CK WAS HE R
C OVE R
FIG U RE 2
AR M COV ER RE MOV ED
SEC U RE W IRE
INSI DE POLE
SUPPLY W IRES
PO LE
ARM
FI X TURE W IRE S
3.
WIRING
(See Fig.
2
)
POWER MUST BE OFF.
(WIRING MUST BE PERFORMED BY A QUALIFIED ELECTRICIAN)
Wire service leads to fixture power leads according to local
and National Electric Codes.
Luminaire is equipped with u niversal voltage driver s capab le of
120V - 277V input . A n optio nal 347/480 V input transformer is
available.
Wire connections to be made inside A rm with Fixture Wires and
Supply Wires (By others). Secure Wire inside Pole.
For direct wire connections, connect ground wire to green wire,
c onnec t black to black and white to neutral then push connections
back inside Arm and attach Arm Cover.

OR MA I NTENAN CE
WARNING:
D ISCON NECT P OW ER B EF ORE I NST AL LATION
CIM AR RON L ED
(L UMI NAI RE )
S TRA IGHT
SQU AR E PO LE
(SHO WN)
HAND HOL E
BASE COV ER
SHI PP ED WI TH PO LE
HARD W AR E KIT
TEMPL ATE
DRILL
(4 HO LE S)
C AST PLATE
HO LE P LUG
N UTP LATE
W AL L
JUN CTI ON B OX
STRA IGH T
ARM
SCRE W
C OVE R
FLAT WA SHER
HE X BO LT
L OCK WA SHER
SCRE W
CUR VED
ARM
CU RVED A RM M OU NT
FIG U RE 3
COV ER
SCRE W
CAS T ARM
PO LE CO V ER
PO LE
COV ER
CAS T ADP T OR
NUT PLATE
FLAT WA SHER
HE X BO LT
L OCK WA SHER
SQUARE AN D RO UND POLES
NO RT H
P HO T OCON TROL
S CR EW
RECEPTA CLE
WALL M OU NT
FIG U RE 4
268-1300-9901 CIMARRON INSTALLATION INSTRUCTIONS (PG 2/3)
SAVE THESE INSTRUCTIONS
701 M il l ennium Boul eva rd Gre en v il le , S C 29607 (8 6 4) 67 8- 1000 www.
spau lding-ltg. co m
93034033 CIMARRON CL1 LED INSTALLATION INSTRUCTIONS (PG 2/2)
4 . MOUNTING FIXTURE WITH CURVED ARM
Use same procedure as shown on Page 1 ,
except Arm Cover has (1) Screw.
5.
MOUNTING
FIXTURE WITH WALL PLATE
Using template , locate holes in bracket around junction
box on the wall. Mark hole locations . (See Fig. 4 )
Drill wall for the hardware appropriate for the type wall.
Use 1/4 diameter bolt (supplied by others) and attach
Wall Plate to W all with Nut Plate inside.
Pull the supply wires from junction box through Plate .
Apply caulking sealant (supplied by others) around the top
and two sides of the b racket where it meets the wall .
Follow same Instructions as Steps 1, 2, 3 and 4.
PHOTOCONTROL OPTION
NOTE: THE LIGHT WILL NOT OPERATE
WITHOUT A PHOTOCONTROL SWITCH OR A
SHORTING CAP IN PLACE. DO NOT LEAVE
RECEPTABLE OPEN TO THE ELEMENTS.
